Holman GH1004 User manual

Head Office / Service
11 Walters Drive, Osborne Park WA 6017
Ph: [phone] Fax: [phone]
[email protected]
www.holmanindustries.com.au
Caution
Ensure the greenhouse is secured to the ground with pegs or weights (not supplied).
Ensure weight is placed evenly on shelves to avoid the possibility of the greenhouse tipping
over. Ensure all poles and fittings are securely assembled prior to use. The method of
securing will depend on the ground surface. The greenhouse should not be left out in
windy conditions if it has not been secured to the ground. During extreme weather
conditions or high winds, ensure the greenhouse is moved to a sheltered area and
ensure it is secured to the ground using appropriate methods. The greenhouse
should be disassembled when not in use.
Maximum loading: 10kg for each shelf.
User Guide
4 Tier Greenhouse
with Misting System
GH1004
We really appreciate having you as a customer, and would like to say thank you for
choosing us.
We recommend registering your new product on our website. This will ensure we have a copy
of your purchase and activate an extended warranty. Keep up to date to with relevant product
information and special offers available through our newsletter.
www.holmanindustries.com.au/product-registration/
Thanks again for choosing Holman

Assembly
Start assembly with the base of the frame.
Insert 3 of the longer poles (B) into the
holes on the inside of two brackets (C).
Using 4 short poles (A) insert into the holes
on top of each corner of the brackets (C).
For the next level, place two brackets (C)
on top of the shorter poles (A) and repeat
the previous steps. Continue these steps
until the remaining levels have been
assembled. For the top of the greenhouse,
insert the two top poles (E) into the holes
on the top of the brackets (C). Finish the
greenhouse by placing the wire tray (D)
over the 3 longer poles of each level. When
fitting the cover (F), ensure the frame is
tightly pushed together and the door is
unzipped prior to sliding over the frame.
Failure to do so may cause damage to the
cover. Secure the cover to the frame with
the ties attached to the inside of the cover.
Misting System Connection
To start assembly, gather three pieces of
the 500mm poly pipe (A). Place one elbow
(B) at the bottom of one piece of poly pipe.
Connect the other end of the poly pipe
using a joiner (E) to another length of poly
pipe (A), repeat this process on the third
piece. Place an elbow (B) at the top of the
third piece. This is the poly that runs up
the side of your greenhouse. Connect the
three sets of wall clips (D) together and
clip onto the bottom, middle and top of the
back right poles (as pictured). Place the
joined poly pipe on the other side of the
connection clips, ensuring the bottom
elbow is pointing out and away from the
frame. Point the top elbow towards the top
right bracket, this is where the spray jets
will be. Take the last piece of poly pipe (A)
and cut 100mm off, put the 100mm piece
aside. Join the end cap (C) to the 400mm
length of poly pipe and connect the
opposite end to the top elbow. Using the
4mm punch (F), pierce two holes 1/3 and
2/3 down the length of poly pipe. Screw in
the micro spray jets (G). At the bottom of
the poly pipe, connect the 100mm length
of poly pipe to the bottom elbow. Connect
the other end to the 13mm Snap-On Hose
Connector (H), this is where your garden
hose will connect. Turn on your tap and
test the system. Misting system fittings
Greenhouse parts and fittings
LETTER QTY
16
2
1
12
10
4
PICTURE DESCRIPTION DESCRIPTIONLETTER QTYPICTURE
325mm Pole
Top Pole
Cover
685mm Pole
Bracket
Wire Tray H
A
A
A
A
C
E
E
B
B
D
D
D
F
G
G
LETTER QTY
4
2
2
2
1
1
1
6
PICTURE DESCRIPTION
13mm x 500mm
Poly Pipe
13mm Elbow
13mm End Cap
13mm Wall Clip
13mm Joiner
4mm Punch
4mm Micro
Spray Jets
13mm Snap-On
Hose Connector
G
H
Care and Maintenance
Avoid very windy positions and spots where the frame
may stand in water for long periods. Wash off heavy dirt
or dust deposits and remove bird droppings with soapy
water. The cover may be removed from the whole
structure, disassembled and stored when not in use.
