HOLOVISION 400-S12-VIK User manual

Manual Type 6.2.0.5-RF
Viking W-1000 with Essex
“S-12 Stand - Alone” Keypad
For Models
400-S12-V K 401-S12-V K
403-S12-V K 404-S12-V K
410-S12-V K 411-S12-V K
Specifications
Communication
Viking W-1000 Doorbox uses “half-duplex”
communication, allowing for high speaker and
microphone volume, without the possibility of
feedback
Access Control
Essex “stand-alone” 12 button keypad
1 relay plus 2 grounding outputs
(external relays required)
500 users
12 VDC power supply included
INSTA ATION
INSTRUCTIONS
501 E. Goetz Ave.
Santa Ana, Ca 92707
www.eholovision.com
Ph. 714-434-6904
Fax [phone]
HO OVISION
13.8 VAC (from C-1000B)
12 VDC input (for camera and keypad)
NO, COM, NC relay connections
Keypad case ground
Remote bypass terminals (activate relay)
Connect tamper switch to alarm (optional)
ntercom to W-1000 ( Not polarity senitive)
Cut for NO Contact Closure
AC Loop for Strike

Cut for NO Contact Closure
AC Loop for Strike
12v -
12v +
CO line
12vDC
1.5 A
TO STANDARD
PHONES
Gate Strike
*MOVisrecommended
NOTE: MOV (metal oxide varistor) is the small red component which is included. ts purpose is to absorb “inductive kick
back” which can be created when power is removed from the strike.
Loop is required from 12v positive to contact common for DC power to strike.
Essex Keypad Wiring
DC Out for Gate Strike
Page 2 Type 6.2.0.5-RF
NOTE:
‘’Talk Battery’’ switch
must be in “ON” position
when the C-1000B is
used w/o a CO line
input.
VIKING Model C-1000B
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
EARTH GND
PHONE L NE NPUT
L NE OUT TO PHONES
KEYLESS CONTACT
DOOR BOX 1
DOOR BOX POWER
DOOR BOX 2
DOOR STR KE 1
DOOR STR KE 2
1 2 3
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
OFF ON
13.8 VAC
1.25A
Remote
Bypass
Button

12v -
12v +
CO line
12vDC
1.5 A
TO STANDARD
PHONES
Essex Keypad Wiring
Contact Closure for Gate Operation
Page 3 Type 6.2.0.5-RF
NOTE:
‘’Talk Battery’’ switch
must be in “ON” position
when the C-1000B is
used w/o a CO line
input.
Gate Motor
VIKING Model C-1000B
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
EARTH GND
PHONE L NE NPUT
L NE OUT TO PHONES
KEYLESS CONTACT
DOOR BOX 1
DOOR BOX POWER
DOOR BOX 2
DOOR STR KE 1
DOOR STR KE 2
1 2 3
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
OFF ON
13.8 VAC
1.25A
Cut for NO Contact Closure
AC Loop for Strike

Page 4 TYPE 6.2.0.5-RF
W-1000 Adjustments and Programming
n certain noisy locations (traffic or wind), the microphone volume may need to be decreased. A symptom of this is one-way talk path, in which the distant party cannot be
heard over the speaker. A “MIC VO ” adjustment is provided on the doorphone for increasing or decreasing the microphone volume.
Microphone Volume
The “SPKR VO ” pot can be adjusted to increase or decrease the speaker volume to the desired level.
Speaker Volume
The maximum number of rings can be adjusted using the D P switches.
Maximum Number of Rings
Sw 1 Sw 2 Max Rings
OFF OFF 2
ON OFF 3
OFF ON 10
ON ON 30
C-1000B Door Controller Programming
1 Disconnect the PHONE L NE NPUT.
2 Slide the TALK BATTERY switch to the ON position.
3 Move D P SW TCH 2 from OFF to ON.
4 Connect a phone to terminals 4 & 5 - L NE OUT TO PHONES.
5 Pick up the phone (you will hear a double beep - indicating that you have accessed the PROGRAMM NG MODE).
6 You can now Touch Tone program the features listed below. SEE HOLOV S ON Programming NOTES.
7 When Finished, hang up and move D P SW TCH 2 to the OFF position
8 Slide the TALK BATTERY switch back to the OFF position
9 Reconnect line to PHONE L NE OUT
Step Action
The C-1000 controller is factory set to work right out of the box. f customization of
the default settings is required, see the steps listed below. Refer to the C-1000
manual for additional options
+
+
Spkr Vol
Mic Vol
ON
1 2

HO OVISION’s Programming Notes
Doorstrike Activation Time - Generally the default setting of 1/2 sec is fine. The momentary contact can open a motorized gate, or activate the relay on the
“S-12” keypad. For other keypad types this will be changed.
Doorbell Mode (*1)- phones will not ring when doorbell is pushed. This is useful when conventional door chimes are desired. n order to use this feature, the
Auxiliary Contacts must be programmed. (see above)
Custom Ring Mode (*2)- Distinguishes doorbox ring from CO ring when connected to KSU.
CCTV Video Control Mode (*8)- The C-1000B can switch 2 CCTV cameras, displaying the camera at the doorbox which initiates the call. This mode cannot
be used when the “Auxiliary Contacts” are being used.
Disable Special Modes (*0) - Use this command to disable (clear) all special modes programmed.
REFER TO C-1000B MANUAL FOR MORE NFORMAT ON ON THESE, AND OTHER MODES OF OPERAT ON.
` 1 Slide the TALK BATTERY switch to the OFF position.
2 Move D P SW TCH 2 from ON to OFF.
3 Re-connect the PHONE L NE NPUT and L NE OUT TO PHONES.
Return to normal use mode
Step Action
OPERATION OF C-1000B
ANSWER A CA FROM DOORBOX
When the phones ring, pick up a phone to be connected to the visitor. When the C-1000B controller is used, you will
hear a beep tone when the phone is answered - one beep for doorbox 1, and 2 beeps for doorbox 2.
P ACING CO INE CA S ON HO D (CA WAITING)
f a phone call is in progress, and a door box is activated, a single or double “call waiting “ tone will be heard. To place the call in
progress on hold and speak to the visitor, push #. When you want to return to the original phone call, push #.
ACTIVATING A DOORSTRIKE OR OPENING A GATE
To open the gate, you must first be connected to the doorbox. Push .You will then hear a confirmation tone, and the relay will be
activated for the programmed time. f a call was already in progress, pressing will open the gate, and return the system to the
original phone call.
ATCH / UN ATCH A GATE
To use this feature, you must first be connected to the doorbox.
Latch relay 1 or 2 1
Unlatch relay 1 or 2 0
**
**
**
Page 5 TYPE 6.2.0.5-RF

Programming the Essex Keypad
Note: f the User D, or User Code/P N has already been assigned, you will hear one long beep when # is entered.
n this case, choose a different User D / P N, or see the instructions for changing or deleting codes.
DEFAU T USER CODE & MASTER CODE IS “123#”
1 The default Master Code is “123”.
This can be changed to a unique code 3 - 8 digits long
2 Enter *3 1 2 3 # Double Beep Fast Flash Solid
3 Enter 1 # Double Beep Fast Flash Slow Flash
4 Enter new master code, followed by # Triple Beep Fast Flash Solid
5 Enter * * Double Beep
6 EXAMPLE: old code is 123, new code is 456 * 3 1 2 3 # 1 # 4 5 6 # * *
Set Master Code
STEP ACTION BEEP Red LED Green LED
1 Remove power
2 Jumper the “CONF G” pins on the rear of the keypad . V = 12
3 Apply 12 VDC power to red and black wires Quadruple Beep Flash Solid
4 Enter 9 9 followed by # Double Beep Flash Solid
5 Enter 2 1 4 followed by # Triple Beep Flash Solid
6 Remove power
7 Remove “CONF G” jumper
8 Reapply power
STEP ACTION BEEP Red LED Green LED
Set Keypad llumination to ON A OF THE TIME
TYPE 6.2.0.5-RF Page 6

TYPE 6.2.0.5-RF Page 7
Programming the Essex Keypad
1 The Master Code is necessary to do this step.
Master Code “123” is used as an example.
2 Enter *1 1 2 3 # Double Beep Slow Flash Solid
3 Enter 1 # Double Beep Slow Flash Slow Flash
4 Enter 1st User D (1-500), followed by # Double Beep Slow Flash Fast Flash
5 Enter 1st User Code/P N, followed by # Double Beep Slow Flash Fast Flash
6 Enter #to complete User 1 programming Triple Beep Slow Flash Slow Flash
7 Enter 2nd User D (1-500), followed by # Double Beep Slow Flash Fast Flash
8 Enter 2nd User Code/P N, followed by # Double Beep Slow Flash Fast Flash
9 Enter #to complete User 2 programming Triple Beep Slow Flash Slow Flash
10 Enter * * * * Double Beep X 2
Set User Codes
STEP ACTION BEEP Red LED Green LED
1 The Master Code is necessary to do this step.
Master Code “123” is used as an example.
2 Enter *1 1 2 3 # Double Beep Slow Flash Solid
3 Enter 2 # Double Beep Slow Flash Slow Flash
4 Enter User D to be changed (1-500), followed by # Double Beep Slow Flash Fast Flash
5 Enter new User Code/P N, followed by # Double Beep Slow Flash Fast Flash
6 Enter #to complete programming Triple Beep Slow Flash Slow Flash
7 Enter * * * * Double Beep X 2
Changing User Codes - using User D
STEP ACTION BEEP Red LED Green LED
N
* Note: f the User D, or User Code/P N has not been assigned, you will hear one long beep
when # is entered.
N
N
N
N
N
Example for entering user code 1 and 2- * 1 1 2 3 # 1 # 1# 4 5 6 # # 2 # 7 8 9 # # * * * *
Example for changing user code 1- * 1 1 2 3 # 2 # 1 # 7 8 9 # # * * * *

Page 8 TYPE 6.2.0.5-RF
Programming the Essex Keypad
* Note: f the User D, or User Code/P N has not been assigned, you will hear one long beep
when # is entered.
1 The Master Code is necessary to do this step.
n this example, the Master Code is 123
2 Enter *1 1 2 3 # Double Beep Slow Flash Solid
3 Enter 5# Double Beep Slow Flash Slow Flash
4 Enter User Code/P N to be changed, followed by # Double Beep Slow Flash Fast Flash
5 Enter new User Code/P N, followed by # Double Beep Slow Flash Fast Flash
6 Enter #to complete programming Triple Beep Slow Flash Slow Flash
7 Enter * * * * Double Beep X 2
Deleting User Codes - using User Code/P N
STEP ACTION BEEP Red LED Green LED
1 The Master Code is necessary to do this step.
n this example, the Master Code is 123
2 Enter *1 1 2 3 # Double Beep Slow Flash Solid
3 Enter 4 # Double Beep Slow Flash Slow Flash
4 Enter 1st User D to be deleted (1-500), followed by # Triple Beep Slow Flash Fast Flash
5 Enter 2nd User D to be deleted (1-500), followed by # Triple Beep Slow Flash Fast Flash
.
6 Enter * * * * Double Beep X 2
Deleting User Codes - using User D
STEP ACTION BEEP Red LED Green LED
N
N
N
N
Example for deleting user code # 456- * 1 1 2 3 # 5 # 4 5 6 # 7 8 9 # # * * * *
Example for deleting user D 1 and 2- * 1 1 2 3 # 4 #1 # 2 # * * * *

Programming the Essex Keypad
Note: f the User D, or User Code/P N has not been assigned, you will hear one long beep
when # is entered.
Reset Keypad to Factory Defaults--- This is not normally necessary, but can be done as follows
STEP ACTION BEEP Red LED Green LED
1 The default Master Code is “123”.
This can be changed to a unique code 3 - 8 digits long.
2 Enter *3 1 2 3 # Double Beep Slow Flash Solid
3 Enter 2 # Double Beep Slow Flash Slow Flash
4 Enter the desired activation time in Seconds followed by # Triple Beep Slow Flash Solid
5 Enter * * to exit
6 Example:
2 # 10 # * * (10 second activation time)
Setting Main Relay Opening Time
STEP ACTION BEEP Red LED Green LED
1 Remove power
2 Jumper the “CONF G” pins on the rear of the keypad
3 Apply 12 VDC power to red and black wires ONLY Quadruple Beep Flash Solid
5 Enter 0 0 9 9 # Double Beep Flash 3 Sec Flash
6 WA T about 4 seconds Quadruple Beep Flash Solid
7 Enter 9 9 # Triple Beep Flash Solid
8 Remove power
9 Remove “CONF G” jumper
10 Reapply power
Page 9 TYPE 6.2.0.5-RF
