HOMCOM 823-005V70 User manual

Original instructions
R290
INcjg004_UK_DE_FR_ES_RO
Portable Air Conditioner
Local air conditioner
Owner’s Manual
823-005V70/823-005V71/823-005V72/823-005V90/823-005V91/823-
005V92(With R290 refrigerant)
READ AND SAVE THESE INSTRUCTIONS

2
CONTENTS
1. BEFORE YOU BEGIN .........................................................03
2. FOR YOUR SAFETY............................................................07
3. PRODUCT OVERVIEW.......................................................13
4. INSTALLATION ..................................................................16
5. OPERATION........................................................................21
6. CLEANING AND CARE.......................................................27
7. TROUBLESHOOTING.........................................................29
8. DECOMMISSIONING .........................................................30

3
1. BEFORE YOU BEGIN
1.1 PRODUCT DESCRIPTION
Our powerful portable air conditioners are great cooling solutions for
single rooms, creating a comfortable atmosphere in your space. It also
has ventilation and dehumidifying function for circulating air and removal
of moisture. They're self-contained systems that do not require any
permanent installation allowing you to move to the space in which it is
most needed. They're commonly used in kitchen, temporary-resided,
computer rooms, garages, and many other places where installation of
Air-conditioner Outdoor Unit is limited.
The environmentally friendly R290 is used as the refrigerant. R290 has no
damaging influence on the ozone layer (ODP), a negligible greenhouse
effect (GWP) and is available worldwide. Because of its efficient energy
properties, R290 is highly suitable as a coolant for this application. Special
precautions must be taken into consideration due to the coolant's high
flammability.
1.2 SYMBOLS FROM THE UNIT AND USER MANUAL
This unit uses a flammable refrigerant.
If refrigerant leaks and comes in contact with fire or heating
warning part, it will create harmful gas and there is risk of fire.
Read the USER MANUAL carefully before operation.

4
Further information is available in the USER MANUAL,
SERVICE MANUAL, and the like.
Service personnel are required to carefully read the USER
MANUAL and SERVICE MANUAL before operation.

5
THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
⚫This appliance is intended to be used by expert or trained users in
shops, in light industry and on farms, or for commercial use by lay
persons.
⚫This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
⚫The unit is designed only for use with R-290(propane) gas as
the designated refrigerant.
⚫The refrigerant loop is sealed. Only a qualified technician
should attempt to service!
⚫Do not discharge the refrigerant into the atmosphere.
⚫R-290 (propane) is flammable and heavier than air.
⚫It collects first in low areas but can be circulated by the fans.
⚫If propane gas is present or even suspected, do not allow
untrained personnel to attempt to find the cause.
⚫The propane gas used in the unit has no odor.
⚫The lack of smell does not indicate a lack of escaped gas.
⚫If a leak is detected, immediately evacuate all persons from
the store, ventilate the room and contact the local fire
department to advise them that a propane leak has occurred.
⚫Do not let any persons back into the room until the qualified
service technician has arrived and that technician advises that
it is safe to return to the room.
⚫No open flames, cigarettes or other possible sources of
ignition should be used inside or in the vicinity of the units.
⚫Component parts are designed for propane and non-incentive and

6
non-sparking. Component parts shall only be replaced with identical
repair parts.
FAILURE TO ABIDE BY THIS WARNING COULD RESULT IN AN
EXPLOSION, DEATH, INJURY AND PROPERTY DAMAGE.

7
Please read this manual carefully and fully
understand before operating your appliance.
Your safety is the most important thing we concerned!
2.1 OPERATIONAL PRECAUTIONS
WARNING- to reduce the risk of fire, electric shock or injury to
persons or property:
◼If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
◼The A-weighted sound pressure level is below 55 dB.
◼The appliance shall be disconnected from its power source during
service.
◼Always operate the unit from a power source of equal voltage,
frequency and rating as indicated on the product identification plate.
◼Always use a power outlet that is grounded.
◼Unplug the power cord when cleaning or when not in use.
◼Do not operate with wet hands. Prevent water from spilling onto the
unit.
◼Do not immerse or expose the unit to rain, moisture or any other
liquid.
◼Do not leave the unit running unattended. Do not tilt or turn over the
unit.
2. FOR YOUR SAFETY
WARNING

8
◼Do not unplug while the unit is operating.
◼Do not unplug by pulling on the power cord.
◼Do not use an extension cord or an adapter plug.
◼Do not put objects on the unit.
◼Do not climb or sit on the unit.
◼Do not insert fingers or other objects into the air outlet.
◼Do not touch the air inlet or the aluminum fins of the unit.
◼Do not operate the unit if it is dropped, damaged or showing signs of
product malfunction.
◼Do not clean the appliance with any chemicals.
◼Ensure the unit is far away from fire, inflammable, or explosive
objects.
◼The unit shall be installed in accordance with national wiring
regulations.
◼Do not use means to accelerate the defrosting process or to clean,
other than those recommended by the manufacture.
◼The appliance shall be stored in a room without continuously operation
sources (for example: open flames, an operating gas appliance or an
operating electric heater).
◼The appliance shall be stored so as to prevent mechanical damage
from occurring.
◼Do not piece or burn, even after use.
◼Be aware that refrigerants may not contain an odour.
◼Pipe-work shall be protected from physical damage and shall not be
installed in an unventilated space, if that space is smaller than 7m².

9
◼Compliance with national gas regulations shall be observed.
◼Keep any required ventilation openings clear of obstruction.
◼The appliance shall be stored in a well-ventilated area where the room
size corresponds to the room area as specified for operation.
WARNING
Any person who is involved with working on or breaking
into a refrigerant circuit should hold a current valid
certificate from an industry-accredited assessment
authority, which authorizes their competence to handle
refrigerants safely in accordance with an industry,
recognized assessment specification.
WARNING
Servicing shall only be performed as recommended by
the equipment manufacturer. Maintenance and repair
requiring the assistance of other skilled personnel shall
be carried out under the supervision of the person
competent in the use of flammable refrigerants.
If you don't understand something or need help, please contact the dealer
services.

10
2.2 SAFETY PRECAUTIONS ON SERVICING
Please follow these warnings when to undertake the following when
servicing an appliance with R290.
2.2.1 Checks to the area
Prior to beginning work on systems containing flammable refrigerants,
safety checks are necessary to ensure that the risk of ignition is minimized.
For repair to the refrigerating system, the following precautions shall be
complied with prior to conducting work on the system.
2.2.2 Work procedure
Work shall be undertaken under a controlled procedure so as to minimize
the risk of a flammable gas or vapor being present while the work is being
performed.
2.2.3 General work area
All maintenance staff and others working in the local area shall be
instructed on the nature of work being carried out. Work in confined
spaces shall be avoided. The area around the work space shall be
sectioned off. Ensure that the conditions within the area have been made
safe by control of flammable material.
2.2.4 Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to
and during work, to ensure the technician is aware of potentially
flammable atmospheres. Ensure that the leak detection equipment being
used is suitable for use with flammable refrigerants, i.e. no sparking,
adequately sealed or intrinsically safe.
2.2.5 Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or any
associated parts, appropriate fire extinguishing equipment shall be
available to hand. Have a dry powder or CO2 fire extinguisher adjacent to
the charging area.
2.2.6 No ignition sources

11
No person carrying out work in relation to a refrigeration system which
involves exposing any pipe work that contains or has contained flammable
refrigerant shall use any sources of ignition in such a manner that it may
lead to the risk of fire or explosion. All possible ignition sources, including
cigarette smoking, should be kept sufficiently far away from the site of
installation, repairing, removing and disposal, during which flammable
refrigerant can possibly be released to the surrounding space. Prior to
work taking place, the area around the equipment is to be surveyed to
make sure that there are no flammable hazards or ignition risks. “No
Smoking” signs shall be displayed.
2.2.7 Ventilated area
Ensure that the area is in the open or that it is adequately ventilated
before breaking into the system or conducting any hot work. A degree of
ventilation shall continue during the period that the work is carried out.
The ventilation should safely disperse any released refrigerant and
preferably expel it externally into the atmosphere.
2.2.8 Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the
purpose and to the correct specification. At all times the manufacturer’s
maintenance and service guidelines shall be followed. If in doubt consult
the manufacturer’s technical department for assistance.
The following checks shall be applied to installations using flammable
refrigerants:
–The charge size is in accordance with the room size within which the
refrigerant containing parts are installed;
–The ventilation machinery and outlets are operating adequately and are
not obstructed;
–If an indirect refrigerating circuit is being used, the secondary circuit
shall be checked for the presence of refrigerant;
–Marking to the equipment continues to be visible and legible. Markings
and signs that are illegible shall be corrected;

12
–refrigeration pipe or components are installed in a position where they
are unlikely to be exposed to any substance which may corrode
refrigerant containing components, unless the components are
constructed of materials which are inherently resistant to being corroded
or are suitably protected against being so corroded.
2.2.9 Checks to electrical devices
Repair and maintenance to electrical components shall include initial
safety checks and component inspection procedures. If a fault exists that
could compromise safety, then no electrical supply shall be connected to
the circuit until it is satisfactorily dealt with. If the fault cannot be
corrected immediately but it is necessary to continue operation, an
adequate temporary solution shall be used. This shall be reported to the
owner of the equipment so all parties are advised.
Initial safety checks shall include:
-those capacitors are discharged: this shall be done in a safe manner to
avoid possibility of sparking;
-that there no live electrical components and wiring are exposed while
charging, recovering or purging the system;
-that there is continuity of earth bonding.
WARNING!
Install the unit in rooms which exceed 7 m² for 5000-
7000BTU/h model,8m² for 8000BTU/h model,9m² for
9000BTU/h model,10m² for 10000BTU/h model.
Do not install the unit in a place where inflammable gas
may leak.
NOTE!
The manufacture may provide other suitable example or
may provide additional information about the refrigerant
odour.

13
3. PRODUCT OVERVIEW
3.1 PRODUCT DIAGRAM
1
Control panel
4
Power cord
6
Air Exhaust
2
Air outlet with
adjustable
louver
5
Recessed
handle
7
Drain opening
with sealing plug
3
Air outlet with
adjustable
louver
Note: The appearance is only for reference. Please see the real product
for detailed information.

14
3.2 FEATURES
✓ High Capacity in a compact size with cooling, heating,
dehumidifying and ventilating function.
✓ Temperature setting and display
✓ LED Digital display
✓ Electronic control with built-in timer, sleep mode
✓ Self-evaporating system for better efficient
✓ Auto shut off when tank full
✓ Automatic restart in the event of power outage
✓ Auto defrosting function at low ambient temperatures
✓ Remote control
✓ 2- speed fan
✓ Casters for easy mobility

15
4.1 UNPACKING
⚫Unpack the carton and take the appliance and accessories out.
⚫Check the device after unpacking for any damage or scratches on
it.
⚫Accessories:
◼1. Exhaust hose
◼2. Hose connector
◼3. Window kit adapter
◼4. Remote control
◼5. Window kit
4. INSTALLATION

16
4.2 Choose your location
⚫If tipped more than 45°, allow the
unit to set upright for at least 24
hours before start up.
⚫Place the unit on a firm, level surface
in an area with at least 50cm of free
space around it to allow for proper air
circulation.
⚫Do not operate in close proximity to
walls, curtains, or other objects that
may block air inlet and outlet. Keep
the air inlet and outlet free of obstacles.
⚫Never install the unit where it could be subject to：
➢Heat sources such as radiators, heat registers, stoves or other
products that products that produce heat.
➢Direct sunlight
➢Mechanical vibration or shock
➢Excessive dust
➢Lack of ventilation, such as cabinet or bookcase
➢Uneven surface
WARNING!
Install the unit in rooms which exceed 7 m² for 5000-
7000BTU/h model,8m² for 8000BTU/h model,9m² for
9000BTU/h model,10m² for 10000BTU/h model.
Do not install the unit in a place where inflammable gas
may leak.
NOTE!
The manufacture may provide other suitable example or
may provide additional information about the refrigerant
odour.

17
4.3 ATTACH THE EXHAUST HOSE
The air conditioner requires being vented outside so that the exhaust air
can escape the room which coming from the appliance contains waste heat
and moisture.
Do not replace or extend exhaust hose which will result in decreased
efficiency, even worse shut down the unit due to low backpressure.
Step 1: Connect the hose connector to one end of the exhaust hose.
Step 2: Connect the windows kit adapter to the other end of the
exhaust hose.
Step 3: Extend the adjustable window kit the length of your window.
Connect the exhaust hose to the window kit.
Step 4: Close your window to secure the kit in place. It needs to hold the

18
windows kit firmly in place, secure the window kit with duct tape if required. It is
recommended that the gap between the adapter and the sides of the window
should be sealed off for maximum efficiency.
Step 5: Attach the hose connector to the exhaust air outlet of unit.

19
Step 6: Adjusting the length of the flexible exhaust hose, and avoid
bends in the hose. Then place AC near an electrical outlet.
Step 7: Adjust the louver at the air outlet, and then switch on the
unit.

20
5.1 CONTROL PANEL AND DISPLAY
5. OPERATION
