Home Care Medical LOTUS TRANSPOTER HCM9062F User manual

LOTUS TRANSPOTER
HCM9062F
Aluminum Transport Wheelchair
1. Introduction
Powder coating aluminum frame
Singel cross braces
Flip back desk armrest
Swing in and out footrest
8"x2" PU front castor
12" rear wheel with PU solid tire
Nylon with sponge
Backrest half folding
Attendant brake
With small wheels

Specification
N.W./ G.W.: 10/ 12 Kg
Weight capacity: 120 Kg
Overall Dimensions: 97 (L)* 63.5 (W)* 92 (H) cm
Seat Width: 40 cm, 45cm, 51cm
Seat Depth: 41 cm
2. Mounting
Handgrip
Attendant brake
Back Upholstery
Armrest
Rear wheel
Hand brake
Footplate
Single cross brace
Backrest half folding

3. Use
3.1 Unfolding the Wheelchair
Figure 1
Hold the handles with both hands to separate the frame slightly. Push
down both sides of the seat upholstery to flatness lightly by hand, so
that the wheelchair has been unfolded. (Figure 1)
3.2 Folding
Figure 2
First turn over both the footplates, lift up both sides of the seat
upholstery lightly with hands, and then it can be folded. (Figure 2)
3.3 Use of brake
Figure 3
The user holds the brake handles with both hands when the
wheelchair stops, and then moves the brake handles forward to self-
locking condition, to make the rear wheels stop completely to keep
still. The process for braking is completed. (Figure 3)

3.4 Use of armrest
Figure 4
When detaching the armrest, first press the armrest fastener with
one hand to separate it from the front bracket of seat tube, then you
can flip it back. When assembling the armrest, make the armrest
fastener aim at the position of the front bracket of the seat tube and
press lightly to self-locking fastener. (Figure 4)
3.5 Use of legrest
Figure 5
To mount the footrest, positioning holes to fit with the sides of the
footplate. Fit the footrests and rotated inwards until the closing
perfectly. To remove the footrests, squeeze the handle rotate footrest
outward and lift them up. (Figure 5)
4. Caution
4.1 General precautions
a. This wheelchair has been designed for Indoor use of vehicles of
any kind. Always transfer to the user of the Chair in an approved
seat by the vehicle manufacturer and use all available Safety
restraints.
b. Do not use this wheelchair in Roads, streets or any Surface traffic.
c. Don't try to operate in inclined planes of 10% or more, without
adequate support.
d. Make sure to fully Activate the Wheel Brakes when getting on or
off the Chair, or when you're in an elevator or Lift for wheelchair.
The Wheelchair must be on a Flat Surface, stable and level.
e. When you get on or off the wheelchair, do not climb or put Weight
on the foot. When trying to extend the arms on the back, do so

only until his arm can be extended without changing your sitting
position.
f. Do not stand in the wheelchair.
4.2 Stability
Wheelchairs are designed to be safe and stable while the center
of gravity is maintained during normal use. You must take
precautions if you want to perform activities that require a change of
the center of gravity. Should never try to achieve something that is
not available to any way, bowing out of the Chair. If you need to lean
or Lean on the Chair, take care that the front Wheels pointing Forward,
so as to extend the base surface of the Wheel, to stabilize the Chair.
4.3 Ramps
Make sure your own capacity constraints and force before
attempting to upload a Ramp. You can ask a professional qualified
the right skills to go up or down a Ramp. It is advised to help when
going up or down slopes over 10. If you must stop on a Slope, avoid
Sudden movements and Quick when you move. A Move can cause
instability due to the angle of the Chair. The use of The Brakes could
result in accidental Brake Brakes, an uncontrolled movement or a
sudden blockage. Try not to change direction down a Ramp, could
cause instability and lead to the
overturning of the Chair.
4.4 Maintenance of the Chair
Always make sure that the chair is dried after use to prevent
corrosion. The chair should be cleaned frequently, using warm water
and a mild detergent. Dry after cleaning. All the metal parts can be
cleaned with Wax for cars or similar products. Do not use Abrasive
Cleanser that can scratch the finish.
Among the uses the wheelchair must be folded for Storage. The
Chair can be folded to approximately half its width.
4.5 Security
Manual wheelchair has a legal guarantee of two years from the
invoice against manufacturer defect. The warranty does not cover
the wear of wheels, seats and backrests, Brakes, so as problems
caused by improper use or maintenance had not been indicated. In
this case the transport costs for compensation shall be borne by the
customer.
The Wheelchairs has been tested and certified in accordance with CE
requirements and BSEN 12183.
