BRADSTONE 3 DRAWER FILE CABINET
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Bradstone
3 Drawer File Cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see
our full line of products available for your home improvement needs. Thank you for choosing Home Decoratons Collection!
1005557041
JS-3414-A
1005540343
JS-3414-B
1005557053
JS-3414-C

HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.

HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
3
Pre-assembly
PLANNING ASSEMBLY
Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit.
TOOLS REQUIRED
Small head
Phillips
screwdriver
(Not Included)
Large head
Phillips
screwdriver
(Not Included)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Part Description
(1)X2 (2)X1 (3)X1 (4)X1 (5)X1 JJ
AA
FF
BB CC DD EE
GG HH II
Big cam lock
Big cam lock bolt
Wood dowel
Small cam lock
Small cam lock bolt
Cross round head bolt
Handle
Flat head screw
Round head screw
Anti-tipping hardware package
AA
BB
CC
DD
EE
FF
GG
23+2
23+2
18+2
12+2
12+2
3
3
HH
II
JJ
12+2
20+2
1
Quantity Quantity

Pre-assembly (continued)
PACKAGE CONTENTS
4
Part Description Part Description
A
B
C
F
G
D
D
H
E
E
I
M
J
K
L
N
I
M
J
K
L
N
I
M
J
K
L
N
Top panel
Left side panel
Right side panel
Back cross brace
Front cross brace
Bottom panel
Back panel
Drawer back panel
Drawer left side panel
Drawer right side panel
Drawer bottom panel
Drawer front panel
Front cross brace at bottom Metal bar
A
B
C
D
E
F
G
1
2
2
1
1
1
1
1
3
6
3
3
3
3
H
I
J
K
L
M
N
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Quantity Quantity

5HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES TO REMOVE DUST AND DIRT THAT MAY
HAVE SETTLED ONTO FINISH DURING SHIPMENT. IN ORDER TO PREVENT DAMAGE DURING ASSEMBLY,
PLEASE ASSEMBLE THIS ITEM WITH AT LEAST TWO PEOPLE.
HOW TO USE THE CAM TOOL
NOTE:THE ARROWS ON THE HIDDEN CAM-LOCKS SHOULD POINT TO THE CAM-BOLTS.
ARROW
SHOULDER
ARROW
BB
NOTE:TURN THE CAM-BOLT SCREWS UNTIL THEY
ARE TIGHT,THE SHOULDER SHOULD BE AGAINST
THE SURFACE OF THE PART.
Notification
AA

6
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
1
Please contact 1-800-986-3460 for further assistance.
Small head Large head
(DD)x12 (EE)x12 (CC)x12 (FF)x3 (GG)x3 (HH)x12
Assemble drawers
EE
HH
CC
IK
J
L
CC
N
N
GG
FF
M
M
DD
a) Insert wood dowel(CC) into panel(I), then
assemble panel(I) and panel(J&K) by rotating the
flat head screw(HH).
b) Insert the panel(L) into the slot correctly.
c) Insert bolt(EE) into panel(M).
d) Insert wood dowel(CC) into panel(J&K), then
rotate the cam lock(DD) tight to assemble panel(J&K)
and panel(M).
e) Install the metal bar(N)
f) Assemble the handle(GG) by rotating cross round
head bolt(FF)
Small cam
lock
cross round
head bolt Handle Flat head screw
Wood dowel
Small cam
lock bolt

7
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
2
Please contact 1-800-986-3460 for further assistance.
(AA)x3 (BB)x3
Assemble bottom base(D,F,G)
BB
G
F
D
G
F
AA
F
Big cam lock Big cam lock bolt
Small head Large head
a) Insert and rotate the bolt(BB)
into the panel(G) and Panel(F)
c) Insert and rotate cam lock(AA) to
assemble panel(G), panel(D) and
panel(F)
b) Assemble the panel(G) and panel(D)
with panel(F)

8
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
3
Please contact 1-800-986-3460 for further assistance.
(AA)x7 (BB)x7 (CC)x3
Assemble panel(B), panel(D&E)
and bottom base(D,F,G)
B
BB
B
AA
CC
E
D
B
F
F
G
D
G
D
Big cam lock Big cam lock bolt Wood dowel
Small head Large head
a) Insert and rotate cam lock bolt(BB)
into panel(B) tightly.
b) Insert wood dowel(CC) into cross brace(E/G); then
assemble cross brace(E) and bottom component
parts(D/F/G) to panel(B)
c) Assemble and tighten the above
panels by inserting and rotating the
cam lock(AA).
E

9
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
4
Please contact 1-800-986-3460 for further assistance.
BB
C
CC
CAA
C
(AA)x7 (BB)x7 (CC)x3
Big cam lock Big cam lock bolt Wood dowel
Small head Large head
a) Insert cam lock bolt(BB) into
panel(C).
Assemble the panel(C).
b) Insert the wood dowel(CC)
into panel(E) and bottom
base.
c) Assemble panel(C) by inserting and
rotating the cam lock(AA).

10
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
5
Please contact 1-800-986-3460 for further assistance.
(AA)x6 (BB)x6
BB
A
A
AA
Assemble panel(A)
Big cam lock Big cam lock bolt
Small head Large head
a) Insert the bolt(BB) into top panel(A).
b) Assemble panel top (A) as illustration
as below.
c) Insert and rotate cam lock(AA) to assemble top
panel(A).
c) Assemble panel(C) by inserting and
rotating the cam lock(AA).

11
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
6
a) Open back panel(H).
Please contact 1-800-986-3460 for further assistance.
(II)x20
II
H
H
Round head screw
Small head
Install back panel(H)
b) Insert screw(II) into back panel(H) holes

12
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
7
Please contact 1-800-986-3460 for further assistance.
lnserting the drawer
lnsert the drawer into the assembled body as shown.
SAFETY RELEASE TAB
SAFETY RELEASE TAB
Left
Right
NOTE: Make sure the slide piece is at the front end of the
glide when installing the drawer into the body.
NOTE: When removing the drawer,tip up and press down the
safety release tab to remove the drawer from the body.
3.Insert into slide slot correctly, push
the drawer into the cabinet body
with even force
2.Push slide back inside.
Repeat for every slide!
1.Pull out slide. Slide bearings
forward.

(1)X2
13
HOMEDEPOT.COM/HOMEDECORATORS
Assembly
8
Please contact 1-800-986-3460 for further assistance.
JJ
(2)X1 (3)X1 (4)X1 (5)X1
Finalizing the assembly
Wall
wall
(3) (1)
(5)
(4)
(1)
(2)
Rectangle
metal plate
0.63 in.Round
head screw
Plastic anchor Plastic band 1.97 in.Round
head screw
a) Install anti-tipping hardware Package(JJ) as
illustration below.
b) Connect plastic strip(4) with anti-tipping
hardware.
Small head

14
□If your furniture is stained or otherwise damaged during use, contact a professional for repairs.
Care and Cleaning
□Use a soft, clean cloth that will not scratch the surface when dusting.
□Use of furniture polishes is not necessary. Should you choose to use polishes, test the polish in an inconspicuous
area before using over the entire surface of the product.
□Using solvents of any kind on your furniture may damage the finish.
□Never use water to clean your furniture as it may cause damage to the finish.
□Always use coasters under beverage glasses and flowerpots.
□Liquid spills should be remove immediately. Using a soft, clean cloth, blot the spill gently avoid rubbing.
□Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may create spotting
within the furniture finish.
□Use care as stains or marks from crayons or ink markers will be difficult to remove.
□Be sure to immediately clean red wine or soda stains within 30 minutes or the surface will stain.
Troubleshooting
Maintenance
PROBLEMS SOLUTIONS
Panel cannot be assemble d Make sure panel is on right direction.
Drawers cannot pull in or
pull out smoothly
Refer assembly instruction details to assemble drawers, and pull in and pull out drawers
several times gently
Drawer cannot be removed
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
When removing the drawer, tip up and press down the safety release tab to remove the drawer
from the body.
