Home Decorators Collection HDVB6002 User manual

Model# HDVB6002
ASSEMBLY INSTRUCTIONS
HDVB6002 60 IN. VANITY
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
THANK YOU
We appreciate the trust and condence you have placed in Home Decorators Collection through the purchase of this vanity. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
2
Table of Contents ......................................................... 2
Safety information ........................................................ 2
Warranty ........................................................................ 3
Limited Lifetime Warranty .......................................................3
What is Covered.......................................................................3
What is Not Covered ................................................................3
Pre-assembly ................................................................ 4
Planning Assembly .................................................................4
Tools Required .........................................................................4
Installation guidelines..............................................................4
Package Contents ...................................................................5
Assembly ...................................................................... 6
Maintenance .............................................................. 15
Care and cleaning ...................................................... 15
Troubleshooting.......................................................... 15
Safety Information
Table of Contents
DANGER
□Keep small parts away from children during assembly.
□Failure to follow warnings and cautions could result in
serious injury.
□DO NOT use harsh bathroom cleaners or grout
cleaners on any natural stone.
WARNING
□Read these instructions carefully and keep in a safe place.
□Adult assembly required.
□Do not over tighten connectors (screws, bolts, etc.)
Overtightening can lead to product damage.
□Small parts may present choking hazard prior to assembly.
□Do not stand, step or climb on unit.
Caution
□USE preventative cleaning mesures to keep your stone
pristine.
□USE sealers according to the product specic directions.
□Blot spills quickly, and wash with mild soap and warm water.
□Stone countertops (Granite, Marble, etc.) are suprisingly
resiliant to stains and scratches. However, as a preventative
measure, any spills on the stone surfaces should be wiped
up within a reasonable amount of time. Do not let liquid sit
on the stone overnight. Stones are most prone to staining by
oil and acid, so be sure to blot these spills as soon as they
happen. Follow up by cleaning the stone with a mild non-
abrasive soap and water.
□Be sure to check all packing materials carefully for small
parts that may have come loose inside the carton during
shipment. If parts are missing, contact THE HOME DEPOT to
obtain any missing parts.
□Using abrasive cleansers will damage the surface.

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
3
Warranty
LIMITED LIFETIME WARRANTY
WHAT IS COVERED
Home Decorators Collection products are manufactured with superior quality standards and workmanship and are backed by our limited
lifetime warranty. Home Decorators Collection products are warranted to the original consumer purchaser to be free of defects in materials
or workmanship. We will replace FREE OF CHARGE any product or parts that proves defective.
Simply, return the product / part to any of The Home Depot retail locations or call 1-800-986-3460 to receive the replacement item.
Proof of purchase (original sales receipt) from the original consumer purchaser must be made available for all Home Decorators Collection
warranty claims.
WHAT IS NOT COVERED
This warranty excludes incidental/consequential damages and failures due to misuse, abuse or normal wear and tear.
This warranty excludes all industrial, commercial & business usage, whose purchasers are hereby extended a ve-year limited warranty
from the date of purchase, with all other terms of this warranty applying except the duration of warranty. Some states and provinces do
not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty
gives you specic legal rights and you may also have other rights that vary from state to state and province to province. Please see a store
or contact 1-800-986-3460 for more details.

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
4
Pre-assembly
PLANNING ASSEMBLY
Check the vanity for damage before installation. If any part of the vanity is missing or damaged, contact the Customer Service Team at
1-800-986-3460.
Ensure that the vanity location is accessible to water supply and drain lines. It is suggested that you rough-in the water lines and drain
before installing the vanity.
NOTE: A drain pipe and trap are not included with this vanity.
TOOLS REQUIRED
Safety
goggles
Philips
screwdriver Level
Silicone Clean
rag
When installing this product, the screws should reach the wood studs
behind the plasterboard wall. It is not recommended to install on a
plasterboard wall if the screws and anchors are not secured in the
wood studs.
INSTALLATION GUIDELINES

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
5
Pre-assembly (continued)
PACKAGE CONTENTS
A
C
B
Part Description Quantity
A Countertop 1
B Vanity 1
C Backsplash 1
D Support bar 2
EWall Anchor 12
F Screw 12
D
E
F

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
6
A
B
Unpaking the countertop
1
□Unpack the countertop (A) from its vanity (B)
and place it on a throw rug or other protective
oor covering material to prevent damage to the
countertop (A) or oor.
□Tear off the protective foam above the vanity (B).
CAUTION: During the unpacking and the handling of this
vanity, note that the countertop is not pre-glued to the
frame.
2Remove the drawers
DANGER: You will need at least two people to assemble
this product properly.
Assembly
□Gently remove the drawers from the vanity (B).
B

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
7
Installing support bars
3Installing support bars 4
□Using a stud nder or equivalent tool, locate at least
1 wall stud and mark its positions on the wall for
each support bar (D). While holding the support bar
(D) in its position against the wall, check that it is
level, then mark 2 positions for 2 holes for each
support bar (D) as indicated. One of the holes must
be right over the wall stud.
□Note: make sure the distance between the 2 bar is
smaller than 1-3/4’’ [45mm].
Assembly (continued)
□Measure the height (H1) at where the vanity will be
located, as illustrated.
□Add 18-7/8” (480mm) to the height (H1), this
calculated measure is the distance of the bottom of
the 2 support bars to the oor, as illustrated below.
Mark the bottom position of the 2 support bars (D)
on the wall.
H = H1 + 18-7/8” [480]
Support
bar
D
H1
D
0”~1-3/4” [0~45]
1-3/8’’ [35]
Proper height of the
holes to be drilled on
the Support Bar.

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
8
Installing support bars
5Installing support bars 6
□Except for the holes that are over the stud, drill in
the exisiting holes on the wall using ø5/16” (8mm)
drill bit and insert the wall anchors (E) into the
holes using a rubber mallet until the wall anchors
are ush with the wall.
Assembly (continued)
□Keep the support bars in the position, then drill pilot
holes on the wall through the support bar (D) at the
marked positions using ø1/8” (2.5mm) drill bit.
D
E
ø5/16”
8mm
ø1/8”
2.5mm

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
9
Hang on the vanity
8
□Gently hang the vanity (B) on the support bars (D).
Assembly (continued)
D
B
Installing support bars
7
□Replace and secure the support bars (D) with
screws (F).
D
F

HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
10
Securing the vanity
9Securing the vanity 10
□Gently unhang the vanity (B) from the support bars
(D).
Assembly (continued)
□Mark the positions of the holes through the vanity
(B) onto the wall.
B
D
B
