Home Styles 20 08002 0691 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
20 08002 0691
Pantry
Carton 20 08002 0692 is also needed for assembly.
F.
Side Panel
4 pcs.
G.
Back Upright
4 pcs.
H.
Back Panel
2 pcs.
I.
Door
4 pcs.
J.
Plinth
2 pcs.
K.
Plinth
2 pcs.
Cam Lock Screw
32 pcs. (+2 extra)
Cam Lock
44 pcs. (+6 extra)
Cam Lock Screw (long)
6 pcs. (+1 extra)
M3.5x14
Wood Screw
for Hinge
72 pcs. (+1 extra)
M3.5x19
Wood Screw (short)
6 pcs. (+1 extra)
M3.5x64
Wood Screw (long)
8 pcs. (+1 extra)
M3x20
Wood Screw
for Plastic Clip
12 pcs. (+1 extra)
Plastic Clip
12 pcs. (+1 extra)
Dowel
20 pcs. (+1 extra)
Dowel (long)
4 pcs. (+1 extra)
Plastic Cap (small)
6 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+1 extra) Plastic Cap (large)
16 pcs. (+1 extra)
Hinge
12 pcs.

Assembly Instructions 2/11
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Make sure unit is level before tightening these screws.
The unit must be level to work properly. Use the included adjustable levelers to level.
A
J
J
F
F
Cam Lock Screw
F
STEP 1
Insert Cam Lock Screws into pre-drilled holes in Top (A),
Side Panels (F) and Plinths (J), then tighten. (See Figure 1) Figure 1
F

Assembly Instructions 3/11
Figure 2
J
J
K
K
STEP 2
Attach Plinths (J) to Plinths (K)
with Cam Locks. (See Figure 2)
Cam Lock
E
Wood Screw (long)
Figure 4
Figure 3
STEP 4
Turn unit over to its upright position.
Insert Dowels and Cam Lock Screws into pre-drilled holes in unit, then tighten.
STEP 3
Place Base (E) upside down on a soft cloth.
Insert Dowels into pre-drilled
holes in Base (E). (See Figure 3)
Attach unit to Base (E) with
Wood Screws (long). (See Figure 4)
Dowel
Dowel
Cam Lock Screw

Assembly Instructions 4/11
F
F
G
G
Cam Lock
STEP 5
Insert Dowels into pre-drilled
holes in Side Panels (F).
Attach Back Uprights (G) to
Side Panels (F) with Cam Locks.
Dowel
Plastic Cap (large)
Cam Lock
STEP 6
Attach units from Step 5 to unit
from Step 4 with Cam Locks.
Cover Cam Locks with Plastic Caps (large).
(See Figure 5)
Slide Back Panel (H) into position.
H
Figure 5

Assembly Instructions 5/11
C
B
STEP 7
Attach Rail (C) to Middle Panel (B)
with Wood Screws (short).
Cover Wood Screws (short) with
Plastic Caps (small). (See Figure 6)
Plastic Cap (small)
Wood Screw (short)
Figure 6
Figure 7
STEP 8
Insert Dowels (long) and Cam Lock
Screws (long) into pre-drilled holes
in unit from Step 6. (See Figure 7)
Attach Middle Panel (B)
to unit with Cam Locks.
Cover Cam Locks with
Plastic Caps (large).
Cam Lock
Plastic Cap (large)
Cam Lock Screw (long)
B
Dowel (long)

Assembly Instructions 6/11
STEP 9
Attach Hinges to Doors (I) with Wood Screws
for Hinge into pre-drilled holes, then tighten.
(See Figure 8)
I
I
Wood Screw
for Hinge
Hinge
Figure 9
STEP 10
Attach Doors (I) to unit with Wood Screws for Hinge. (See Figure 9)
Insert Adjustable Pins into side panels at desired level. (See Figure 10)
Place Shelves (D) into position.
D
D
Wood Screw
for Hinge
Adjustable Pin
I
I
Figure 8
Figure 10

Assembly Instructions 7/11
F
F
G
G
Cam Lock
STEP 11
Insert Dowels into pre-drilled
holes in Side Panels (F).
Attach Back Uprights (G) to
Side Panels (F) with Cam Locks.
Dowel
Cam Lock
Plastic Cap (large)
STEP 12
Attach units from Step 11 to unit
from Step 10 with Cam Locks.
Cover Cam Locks with Plastic Caps (large).
Slide Back Panel (H) into position.
H

Assembly Instructions 8/11
A
C
Plastic Cap (small)
Wood Screw (short)
STEP 13
Attach Rail (C) to Top (A) with Wood Screws (short).
Cover Wood Screws (short) with Plastic Caps (small).
STEP 14
Insert Dowels into pre-drilled
holes in unit from Step 12.
Attach Top (A) to unit with Cam Locks.
Cover Cam Locks with Plastic Caps (large).
A
Plastic Cap (large)
Cam Lock
Dowel

Assembly Instructions 9/11
STEP 15
Attach Hinges to Doors (I) with Wood Screws
for Hinge into pre-drilled holes, then tighten.
I
I
Wood Screw
for Hinge
Hinge
STEP 16
Attach Doors (I) to unit
with Wood Screws for Hinge.
Insert Adjustable Pins into
side panels at desired level.
Place Shelves (D) into position.
D
D
Wood Screw
for Hinge
Adjustable Pin
I
I

Assembly Instructions 10/11
Wood Screw
for Plastic Clip
Plastic Clip
STEP 17
Level unit by adjusting the adjustable levelers on bottom of unit. (See Figure 11)
Attach Plastic Clips to unit with Wood Screws for Plastic Clip. (See Figure 12)
Note: Unit must be level before attaching Plastic Clips.
Figure 11
Figure 12
Figure 13 Figure 14
UP Front Back
Down
Figure 15
Left
Right
STEP 18
If needed, adjust doors up or down by removing the front Wood Screws for Hinge and
loosening slightly the back Wood Screws for Hinge from side panel, adjusting doors up or down
and reinstalling screws. (See Figure 13)
If needed, adjust doors left to right. (See Figure 14)
If needed, adjust doors front to back. (See Figure 15)

Assembly Instructions 11/11
Hardware List
STEP 19
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on unit.
(See Figure 16)
Put tie end of Tip-over Restraint into lock
end of Tipover estraint and pull until tight.
Figure 16
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.
Drill 3/8” hole in wall
Top of unit
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Tie end
Lock end
Bracket at
top of unit
Tipover
Restraint
3/16” hole in
side panel of unit
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tip-over Restraint
1 pc. (+1 extra)
M3.5x38
Wall Screw
1 pc. (+1 extra)
M3x16
Wood Screw
1 pc. (+1 extra)

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
