Home Styles 88556980 User manual

88 5569 80
Arm Chair
Home Styles Consumer Assistance : www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Hardware List
Part List
Tools recommended for assembly : Level
IMPORTANT NOTE
This product is made of sturdy, high quality aluminum
and will provide years of enjoyment. Do not use power tools
to assemble and only tighten bolts until they are snug.
Over tightening can cause damage to the aluminum.
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the parts.
We have taken great care in the design of this product and
request that you carefully and strictly follow our assembly
instructions to ensure a completed product as it was designed.
A.
Back
1 pc.
C.
Frame
1 pc.
Spring Washer
8 pcs. (+1 extra)
Flat Washer
8 pcs. (+1 extra)
B.
Seat
1 pc.
D.
Frame
1 pc.
Hex Wrench
1 pc.
M6x30
Head Cap Bolt (long)
4 pcs. (+1 extra)
M6x25
Head Cap Bolt (short)
4 pcs. (+1 extra)
E.
Cushion
1 pc.

STEP 2
Place Cushion (E) onto seat.
Use the tie-downs on Cushion (E) to attach to chair.
To level the unit, adjust the adjustable levelers on
the bottom of legs.
(See Figure 3)
Figure 1 Figure 2
IMPORTANT
* Please keep Key Wrench and Hex Wrench in a safe place as you may need to tighten up the Nuts in the future.
* Use a soft cloth between these parts and the floor.
* Do not use power tools to assemble and do not over tighten the bolts and nuts.
* Do not tighten up all the bolts and nuts until each part is properly assembled.
Figure 3
Assembly Instructions 2/2
E
A
B
C
D
Head Cap Bolt (short)
Flat Washer
Head Cap Bolt (long)
Flat Washer
STEP 1
Attach Back (A) to Frame (C) with Flat Washers,
Spring Washers and Head Cap Bolts (short).
(See Figure 1)
Attach Seat (B) to Frame (C) with
Flat Washers, Spring Washers and
Head Cap Bolts (long). (See Figure 2)
Attach Frame (D) to unit with Flat Washers,
Spring Washers, Head Cap Bolts (short) and
Head Cap Bolts (long).
Spring Washer
Spring Washer
