HoMedics TotalClean AP-T10 Instruction Manual

.
H~MEDICS
lEADERS IN HO ME E NV IRO NMENT
READ AND SAVE THESE INSTRUCTIONS
Before turning the unit on:
TOTAL CLEAN
41N AIR PURIFIER
QUICK-START GUIDE
• Take the air purifier out of the box and remove the clear protective plastic bag.
• Place the air purifier on a firm, level surface.
• Plug the power cord into a household electrical outlet.
HOW TO USE
CONTROL PANEL
OIL TRAY
I. Press the power button to
turn the air purifier on/off.
3. Press the ionizer button to
turn the ionizer on/off.
2. Press the fan button to
select desired fan speed .
4. Press the night-light button
to turn the night-light on/off .
ADDING ESSENTIAL OILS
WARNING: Putting oil anywhere but the oil tray will damage the air purifier.
I. The oil tray is located on the
side of the air purifier.
2. Push to open and remove the
tray.
ARE ESSENTIAL OILS SAFE TO USE AROUND PETS?
3. Place 1 aroma pad (3 included)
into the oil tray.
4. Add 5-7 drops of essential oil
to the pad. You may use more
or less depending on personal
preference. WARNING: Only
place essential oil on the
pad and NOT directly into the
tray.
5. Place the oil tray back in its
compartment and push to
close. The scent will start
automatically when the air
purifier is turned on.
We should always exercise caution when using essential oils around our pets. Keep all essential oil and aromatherapy products (like diffusers) out of reach of pets. Keep open bottles away from
pets to avoid internal consumption . We do not recommend the topical use of essential oils on pets , as they have a strong sense of smell and cannot get rid of the oil if they don't like it or ii is
disturbing them . When diffusing essential oils around pets , always diffuse in a well-ventilated area and leave an option for them to remove themselves from the space, such as leaving a door
open. Every animal is different , so carefully observe how each animal responds when introducing an essential oil for the first time. If irritation occurs, discontinue the use of the essential oil.
We recommend seeking medical attention if ingestion of essential oil occurs.
Refer to the instruction book for filter replacement , cleaning, and maintenance .
QS - APT!O
Made in China

TOTALCLEAN
AIRPURIFIER
INSTRUCTION MANUAL AND WARRANTY INFORMATION
3-YEAR LIMITED WARRANTY AP-T10
1
IN
®
4
®

2
IMPORTANT SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING.
DANGER – TO REDUCE THE RISK OF ELECTRIC SHOCK:
• Always unplug the air purifier from the electrical outlet immediately after using and before
cleaning or replacing filters.
• Keep cord away from heated surfaces.
• Always place the air purifier on a firm, level surface.
• Always place the air purifier at least 6 inches away from walls and 3 feet from heat sources, such as
stoves, radiators, or heaters.
• DO NOT reach for an appliance that has fallen into water. Unplug it immediately.
• DO NOT place or store appliance where it can fall or be pulled into a tub or sink.
• DO NOT place in or drop into water or other liquid.
• Keep dry — DO NOT operate in wet or moist conditions.
• Check your air purifier cord and plug connections. Faulty wall outlet connections or loose plugs can cause
the outlet or plug to overheat. Be sure the plug fits tightly in the outlet.
This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by
volume (ppmv) in a 24-hour period. The Health Canada Guideline 2010 recommends that the maximum
exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or less when tested in a sealed,
controlled room approximately 30 m3.
NOTE: This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of shock, this
plug is intended to fit only one way in a polarized outlet. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician.
CAUTION: DO NOT attempt to defeat this safety feature. To do so could result in an electric shock
hazard.

3
WARNING – TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
• Always unplug the air purifier when not in use.
• DO NOT operate the air purifier with a damaged cord or plug, or after the air purifier malfunctions, or
has been dropped or damaged in any manner. Return to a HoMedics Service Center for examination,
electrical or mechanical adjustment, or repair.
• This air purifier is not intended for use in bathrooms, laundry areas, and similar moist indoor locations.
• DO NOT run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord away from traffic areas where it can be tripped over.
• To disconnect the air purifier, first turn controls to the off position, then remove plug from outlet.
• DO NOT tilt or move the air purifier while it is in operation. Shut off and remove plug from outlet
before moving.
• DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the air purifier.
• DO NOT block air intakes or exhaust in any manner. Do not use on any soft surface, like a bed, where
openings may become blocked.
• Use this air purifier only for its intended use as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to persons.
• DO NOT use outdoors.
• This product is intended for household use only.
SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE.

4
UNIQUE FEATURES & SPECIFICATIONS
ALL-IN-ONE HEPA-TYPE FILTRATION SYSTEM
• HEPA-TYPE FILTRATION
Removes up to 99% of airborne particles as small as 0.3 microns, such as allergens, pollen, dust,
germs, pet dander, odor, mold spores, and smoke from air that passes through the filter.
• CARBON ODOR FILTRATION
Reduces household odors and VOCs (volatile organic compounds/gases) as shown by independent
laboratory testing.
• PREFILTER
Captures large particles.
IONIZER WITH ON/OFF
When on, assists in the air purification process.
2 SPEEDS
Low and high.
NIGHT-LIGHT
Built-in night-light with on/off.
REPLACE FILTER INDICATOR
Illuminates when it is time to replace the filter.
SUGGESTED ROOM SIZE
90 FT2/8.3 M2. Portable air purifiers will be more effective in a closed room.
AIR CHANGES PER HOUR
This air purifier will change the air in a 291 FT2/27 M2closed room every hour on high speed
assuming an 8 FT/2.43 M ceiling.
OIL TRAY
Includes 3 essential oil pads. Use with essential oil (not included) to deliver scent into the air.

5
CONTROL PANEL (DETAIL)
POWER
FAN
IONIZER
NIGHT-LIGHT
CONTROL PANEL
MAIN UNIT
ALL-IN-ONE
HEPA-TYPE FILTER
FILTER COVER
OIL TRAY
(SIDE)

6
HOW TO USE
BEFORE TURNING THE UNIT ON
• Take the air purifier out of the box and remove the clear protective plastic bag.
• Place the air purifier on a firm, level surface.
• Plug the power cord into a household electrical outlet.
POWER BUTTON AND FAN SPEED SETTINGS
• To turn the air purifier on, press the power button.
• This air purifier has 2 fan speed settings: low (1) and high (2). The higher the fan speed setting, the faster
the air will be purified. To select or change fan speed, press the fan speed button until the desired
setting is reached.
IONIZER SETTING WITH ON/OFF
Ion particles have a negative charge that attaches to airborne particles, making them easier to be captured by
the filtration system. Press the ionizer button to turn the ionizer on. The blue light will glow to indicate the
ionizer is in use. Press the ionizer button again to turn the ionizer off.
NOTE: Dust particles may accumulate on surfaces around the air purifier when the ionizer is in use. These
dust particles can be vacuumed or wiped away with a soft, damp cloth.
NOTE: You may hear occasional popping sounds when the ionizer is used. This is normal.
NOTE: The ionizer produces less ozone than the UL-established limits of 0.05 ppm. Ozone may be harmful
around birds and small pets. To prevent ozone buildup, use the ionizer feature in a well-ventilated area.
NIGHT-LIGHT
The nightlight has 3 options. Press the night-light button once to turn the blue night-light on. Press again to
turn the blue night-light and display lights off. Press a third time to turn the display lights on.
OIL TRAY
Use essential oil (not included) to deliver scent into the air.
NOTE: For use with the included HoMedics essential oil pads only. Do not add essential oils anywhere else in
the unit as it may cause damage.
NOTE: Do not leave a filled essential oil pad in the oil tray if it will be out of use for a long period of time.

7
ARE ESSENTIAL OILS SAFE TO USE AROUND PETS?
We should always exercise caution when using essential oils around our pets. Keep all essential oil and
aromatherapy products (like diffusers) out of reach of pets. Keep open bottles away from pets to avoid
internal consumption. We do not recommend the topical use of essential oils on pets, as they have a strong
sense of smell and cannot get rid of the oil if they don’t like it or it is disturbing them. When diffusing
essential oils around pets, always diffuse in a well-ventilated area and leave an option for them to remove
themselves from the space, such as leaving a door open. Every animal is different, so carefully observe how
each animal responds when introducing an essential oil for the first time. If irritation occurs, discontinue the
use of the essential oil. We recommend seeking medical attention if ingestion of essential oil occurs.
ADDING ESSENTIAL OILS
WARNING: PUTTING OIL ANYWHERE BUT THE OIL TRAY WILL DAMAGE THE AIR PURIFIER.
To purchase genuine HoMedics Replacement Essential Oil Pads, Model # UHE-PAD1, go to the retailer where you purchased your HoMedics
TotalClean Air Purifier, or visit www.homedics.com (US), www.homedics.ca (CAN).
To purchase genuine HoMedics Essential Oils, go to the retailer where you purchased your HoMedics TotalClean Air Purifier, or visit
www.homedics.com (US), www.homedics.ca (CAN).
1. The oil tray is located on the
side of the air purifier. 2. Push to open and remove the tray.
4. Add 5–7 drops of
essential oil to the pad.
You may use more or less
depending on personal
preference.WARNING: Only
place essential oil on the
pad and NOT directly into
the tray.
5. Place the oil tray back
in its compartment and
push to close. The scent
will start automatically
when the air purifier is
turned on.
3. Place 1 aroma pad
(3 included) into the oil tray.

8
4. Slide the new HEPA-type filter
into the filter cavity.
To purchase genuine HoMedics replacement HEPA-type filters, model AP-T10FL, go back to the retailer where you purchased your air purifier,
or visit www.homedics.com (US), www.homedics.ca (CAN).
1. Unplug the air purifier and turn
upside down. Turn the filter cover
as indicated to remove.
2. Remove the filter cover and
set aside.
FILTER REPLACEMENT
REPLACE FILTER NOTIFICATION
The power button will flash red when it is time to replace the HEPA-type filter based on the air purifier’s hours
of use.
REPLACING THE HEPA-TYPE FILTER
For optimal performance, replace every 12 months under normal usage conditions.
3. Pull to remove the old filter.

9
5. Reinstall the filter cover and turn
to the right to lock in place.
6. Plug the power cord into a household electrical outlet. Turn the
air purifier on. Press and hold the power button for 3 seconds
to reset the indicator.
