HoMedics HEALTH PLUS BPS-FD1 User manual

BPS-FD1
El manual en español
empieza en la página 26
Manual Inflate Digital
Blood Pressure Monitor
™
health
PLUS
™
health
PLUS
©2006 FKA Distributing Co. y sus compañías afiliadas, reservados todos los derechos.
y sus compañías afiliadas. Health Plus™ es una marca registrada de
FKA Distributing Co. y sus compañías afiliadas. Reservados todos los derechos.
IB-BPS-FD1
LA GARANTÍA AQUÍ ESTABLECIDA SERÁ LA ÚNICA Y
EXCLUSIVA GARANTÍA. NO HABRÁ NINGUNA OTRA
GARANTÍA EXPRESA NI IMPLÍCITA, INCLUYENDO
NINGUNA GARANTÍA DE COMERCIALIZACIÓN O APTITUD
NI NINGUNA OTRA OBLIGACIÓN POR PARTE DE LA
COMPAÑÍA CON RESPECTO A PRODUCTOS CUBIERTOS
POR ESTA GARANTÍA. HEALTH PLUS NO TENDRÁ
RESPONSABILIDAD ALGUNA POR NINGÚN DAÑO
INCIDENTAL, CONSECUENTE NI ESPECIAL.
BAJO NINGÚN CONCEPTO ESTA GARANTÍA REQUERIRÁ
MÁS QUE LA REPARACIÓN O CAMBIO DE ALGUNA PIEZA
O PIEZAS QUE SE HALLEN DEFECTUOSAS DENTRO DEL
PERÍODO DE VIGENCIA DE ESTA GARANTÍA. NO SE
EFECTUARÁN REEMBOLSOS. SI NO HAY PIEZAS DE
REPUESTO DISPONIBLES PARA LOS MATERIALES
DEFECTUOSOS, HEALTH PLUS SE RESERVA EL
DERECHO DE REALIZAR SUSTITUCIONES EN VEZ
DE REPARAR O CAMBIAR.
Esta garantía no se extiende a la compra de productos
abiertos, usados, embalados otra vez y o abiertos y vueltos
a cerrar, incluyendo entre otras cosas la venta de dichos
productos en sitios de remate por Internet y/o la venta de
dichos productos por revendedores o mayoristas.
Todas y cada una de las garantías cesarán y terminarán
inmediatamente con respecto a cualquier producto o pieza
del mismo que estén alterados o modificados sin el
consentimiento previo explícito y por escrito de Health Plus.
Esta garantía le proporciona derechos legales específicos.
Es posible que usted tenga derechos adicionales que
pueden variar de un estado a otro. Debido a las
regulaciones de ciertos estados, es posible que algunas de
las limitaciones y exclusiones no se apliquen en su caso.
Por servicio o reparación,
no devuelva esta unidad
al distribuidor. Póngase en
contacto con Relaciones
con el Consumidor:
Correo:
Health Plus
Service Center
Dept. 168
3000 Pontiac Trail
Commerce Township,
MI 48390
Teléfono:
1-800-466-3342
Horario comercial:
8:30am a 5pm Hora
del Este
De lunes a viernes
BPS-FD1.qxd 7/13/06 9:55 AM Page 1

21
TABLE OF CONTENTS
INTRODUCTORY INFORMATION:
Important Product Notices and Safety
Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
About Blood Pressure . . . . . . . . . . . . . . . . . . . .4
What is Blood Pressure?
Why Measure Your Blood Pressure?
Blood Pressure Standard . . . . . . . . . . . . . . . . . .4
How This Blood Pressure Monitor Works . . . . .6
USAGE INFORMATION:
Name/Function of Each Part . . . . . . . . . . . . . . . .7
Display Explanations . . . . . . . . . . . . . . . . . . . . .8
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . .9
Applying the Cuff . . . . . . . . . . . . . . . . . . . . . . .10
Measurement Procedure . . . . . . . . . . . . . . . . .15
Important Notes Regarding Your
Blood Pressure Measurement . . . . . . . . . . . . .18
Care, Maintenance & Cleaning . . . . . . . . . . . . .19
Potential for Radio/Television Interference . .21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .22
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . .23
Five Year Limited Warranty . . . . . . . . . . . . . . .24
IMPORTANT PRODUCT NOTICES AND SAFETY
INSTRUCTIONS
When using your blood pressure monitor, basic
precautions should always be followed. Please read
and follow all instructions and warnings before using
this product. Save these instructions for future reference.
• Please note that this is a home healthcare product
only and it is not intended to serve as a substitute
for the advice of a physician or medical professional.
• Do not use this device for diagnosis or treatment of
any health problem or disease. Measurement results
are for reference only. Consult a healthcare professional
for interpretation of pressure measurements. Contact
your physician if you have or suspect any medical problem.
• Proper cuff size is critical for accurate measure-
ments. If the index line on the cuff falls outside of
the OK range when applied to the user’s arm,
contact HoMedics Consumer Relations regarding
additional cuff sizes.
• This product is not suitable for people with
arrythmias. This device may have difficulty
determining the proper blood pressure for individuals
with diabetes, poor circulation of blood, kidney
problems or for users who have suffered from a stroke.
™
health
PLUS
BPS-FD1.qxd 7/13/06 9:55 AM Page 1

43
• The pulse display is not suitable for checking the
frequency of heart pacemakers.
• Electromagnetic interference: The device contains
sensitive electronic components. Avoid strong
electrical or electromagnetic fields in the direct
vicinity of the device (e.g. mobile telephones,
microwave ovens). These may lead to temporary
impairment of measurement accuracy.
• Use blood pressure monitor only for its intended use.
• Do not wrap the cuff around body parts other than
your arm.
• This unit is intended for use in measuring the blood
pressure and pulse rate of adults. Do not use this
device on infants or those who cannot express their
own consent. This unit should not be operated by
children.
Blood pressure measurements determined with this
device are equivalent to those obtained by a trained
observer using the cuff/stethoscope ausculatory
method, within the limits prescribed by the American
National Standard, Manual, electronic, or automated
sphygmomanometers.
ABOUT BLOOD PRESSURE
What is Blood Pressure?
Blood pressure is the pressure exerted on the artery
walls while blood flows through the arteries. The
pressure measured when the heart contracts and
sends blood out of the heart is systolic (highest)
blood pressure. The pressure measured when the
heart dilates with blood flowing back into the heart is
called diastolic (lowest) blood pressure.
Why Measure Your Blood Pressure?
Among today’s various health problems, those
associated with high blood pressure are very common.
High blood pressure dangerously correlates with
cardiovascular diseases. Therefore, blood pressure
monitoring is important for identifying those at risk.
BLOOD PRESSURE STANDARD
The US Department of Health and Human Services
and the National Institutes of Health have developed
a blood pressure standard, that identifies areas of
low- and high-risk blood pressure.
BPS-FD1.qxd 7/13/06 9:55 AM Page 3

65
This standard, however, is a general guideline as an
individual’s blood pressure varies among different
people, age groups, etc.
It is important that you consult with your physician
regularly. Your physician will tell you your normal blood
pressure range as well as the point at which you will
be considered at risk.
For reliable monitoring and reference of blood pressure,
keeping long-term records is recommended.
Systolic (mmHg) Diastolic (mmHg)
Stage 2 Hypertension >160 >100
Stage 1 Hypertension 140~159 90~99
Prehypertension 120~139 80~89
Normal <120 <80
__
To determine category of risk when systolic and diastolic readings fall
into two areas, use the higher of the two numbers for classification.
HOW THIS BLOOD PRESSURE
MONITOR WORKS
This manual inflate digital blood pressure monitor
provides systolic pressure, diastolic pressure and
pulse readings quickly and easily. Once the cuff is
inflated, the monitor will determine your blood
pressures by analysis of your pressure oscillations.
When the measurement is completed, the device will
deflate the cuff and display your systolic pressure,
diastolic pressure and pulse readings.
BPS-FD1.qxd 7/13/06 9:55 AM Page 5

87
NAME/FUNCTION OF EACH PART
LCD Display
Battery Cover
(Located on
back of unit)
Inflation Bulb START/STOP Button
Arm Cuff
Air Tube and
Connector
Measurement Error: Measure again. Wrap the cuff
correctly and keep arm steady during measurement.
Air Circuit Abnormality: Check cuff connection. Measure
again.
Pressure Exceeding 300 mmHg: Switch the unit off to
clear, then measure again.
Data Error: Remove and reload the batteries.
If any of the following letters and numbers appear in the area that diastolic
pressure should be displayed, an error has occurred with your reading.
See Troubleshooting section of this manual for more information.
DISPLAY EXPLANATIONS
Systolic
Pressure
Diastolic
Pressure
Pulse Rate
Weak Battery
Symbol
Pulse Symbol
BPS-FD1.qxd 7/13/06 9:55 AM Page 7

APPLYING THE CUFF
Please see the illustration below for a description of
the arm cuff.
1. If the cuff is not assembled, pass the end of the
cuff furthest away from the tubing through the metal
D-Ring in order to form a loop. The smooth side,
without felt material, should be on the inside of the
cuff loop.
INDEX
Select Large Adult Cuff
INDEX must be
inOK range
OK OK
Artery Mark
Adult Cuff
24~ 36cm
9.5”~14.2”
Latex free
0.8
˝
~
1.2
˝
2~
3
cm
Main
Artery
LEFT ARM
CF00X04030
Patented
INSTALLING BATTERIES
1. Press down on latch and lift the battery cover
towards you to open the battery compartment.
2. Install or replace 4 “AA” sized batteries in the
battery compartment according to the indications
inside the compartment.
3. Replace the battery cover by clicking in the
bottom hooks first, then push in the top end
of the battery door.
Replace the batteries if:
1. The weak battery symbol appears on the display.
2. Nothing appears on the display when the power is
switched on.
Replace the batteries in pairs. Remove batteries when
unit is not in use for extended periods of time.
Note: Batteries are hazardous waste. Do not dispose
of them together with the household garbage.
109
Artery Symbol ( )
OK Range Indicator
Tube
Índex
OK
Adult Cuff
24~36cm
9.5”~14.2”
Latex free
0.8
˝
~
1.2
˝
2~
3
cm
Main
Artery
LEFTARM
CF00X04030
INDEX
D-ring
End of cuff
Felt Material
on the outside
of cuff
BPS-FD1.qxd 7/13/06 9:55 AM Page 9

2. Plug the cuff tube into the left side of the unit.
3. Open the arm cuff so that your arm may be placed
through it.
4. Remove tight fitting clothing from around your upper
left arm. Wrap the cuff around your upper left arm as
shown below. The rubber tube should point in the
direction of your hand. The bottom edge of the cuff
should be 0.8"~1.2" (2~3 cm) above your elbow with
the tube positioned over the middle of your arm.
1211
Main
Artery
INDEX
LEFT ARM
Main
Artery
2~3cm
(0.8”~1.2”)
5. Locate the main artery by pressing with two
fingers approximately 1" (2 cm) above the bend of
your elbow on the inside of your left arm. Identify
where the pulse can be felt the strongest. This is
your main artery.
6. Position the red area of the cuff on the inside of
your left arm with the artery symbol ( ) over the
main artery.
7. To secure the cuff, pull the end toward you,
wrap it over the cuff, then press the hook and loop
closure together. Allow room for two fingers to fit
between the cuff and your arm.
Pull end toward you, then
wrap over cuff
Insert plug here
BPS-FD1.qxd 7/13/06 9:55 AM Page 11

Note: If it is not possible to fit the cuff to your left
arm, it can also be placed on your right arm.
However, all measurements should be made
using the same arm. To use on the right arm,
you must position the symbol over the main
artery on the inside of your right arm.
Very Important: Proper cuff size is critical to
accurate measurement. This cuff is suitable for your
use if the Index line falls within the OK range as
shown below. If the Index line falls out of the OK
range, you will need a cuff with other circumferences.
Contact Health Plus Consumer Relations regarding
additional cuff sizes.
1413
8. Lay your arm on a table (palm upward) so the cuff is
at the same height as your heart. Make sure the
tube is not kinked.
INDEX
Select Large Adult Cuff
INDEX must be
inOK range
OK OK
Artery Mark
Adult Cuff
24~ 36cm
9.5”~14.2”
Latex free
0.8
˝
~
1.2
˝
2~
3
cm
Main
Artery
LEFT ARM
CF00X04030
Patented
OK Range Indicator
Index
INDEX
i
n
O
K
r
a
n
g
0.8
˝~
1.2
˝
2~
3
cm
Main
Artery
LEFT ARM
CF00X04030
OK
BPS-FD1.qxd 7/13/06 9:55 AM Page 13

1. With the cuff wrapped around your arm, press the
START/STOP button. Do not inflate the cuff unless it
is wrapped around your arm. All digits will light up to
check the display functions. The checking procedure
will be completed after about 2 seconds. The
arrow will appear momentarily and then the display
will show a “0”. The monitor is “Ready to Measure”
at this point.
2. Using the hand of the arm that does not have the cuff
on it (this will be your right hand if wearing the cuff on
your left arm), squeeze the inflation bulb and continue
pumping until the pressure reading on the display
reaches 170 mmHg. The cuff will then begin slowly
deflating as part of the measurement process.
If the pressure in the cuff is not enough, an upward
arrow ( ) will appear, directing you to continue
pumping. It is recommended that you pump until the
pressure reading on the display reaches 200 mmHg.
1615
MEASUREMENT PROCEDURE
Important Notes:
• Blood pressure changes with every heartbeat and is
in constant fluctuation throughout the day.
• Blood pressure measurement can be affected by
the position of the user, his or her physiologic
condition and other factors. For greatest accuracy,
wait 1 hour after exercising, bathing, eating,
drinking beverages with alcohol or caffeine,
or smoking to measure blood pressure.
• Before measurement, it is suggested that you sit
quietly for 15 minutes as measurements taken during
a relaxed state will have greater accuracy. You
should not be physically tired or exhausted while
taking a measurement.
• During the measurement, do not talk or move your
arm or hand muscles.
• See page 18 for additional notes regarding your
blood pressure measurement.
ON/OFF
BPS-FD1.qxd 7/13/06 9:55 AM Page 15

1817
IMPORTANT NOTES REGARDING YOUR BLOOD
PRESSURE MEASUREMENT
• Take your reading in a comfortable environment
as measurements can be affected by hot or cold
temperatures. Take your blood pressure at normal
body temperature.
• Do not move or talk during measurement as this
can elevate readings.
• Do not move or cross legs during measurement.
Keep feet flat on floor.
• Do not touch cuff or monitor during measurement
procedure.
• It is suggested that you take your measurements at
the same time each day and use the same arm for
consistency.
• Users should wait a minimum of 5 minutes before
taking additional measurements. More time may be
necessary depending upon your physiology.
• The measurement results that users receive
are for reference only. If users have any blood
pressure concerns, please consult a physician.
• If inflation reaches 300 mmHg, the unit will
deflate automatically for safety reasons.
• This product is not suitable for people with
arrhythmias.
4. When the measurement is completed, the cuff
will deflate entirely. Systolic pressure, diastolic
pressure and pulse will be shown simultaneously
on the LCD screen.
Note: 1. This monitor automatically turns off approximately 1 minute after
last operation. You may also press the START/STOP button to turn
the unit off.
2. To interrupt the measurement, you may press the START/STOP
button. The cuff will deflate immediately after a button is pressed.
BPS-FD1.qxd 7/13/06 9:55 AM Page 17
