MS9535 VoyagerBT
Honeywell’s MS9535 VoyagerBT®wireless, single-line laser scanner
frees retailers and healthcare professionals to aggressively scan all
standard 1D bar codes anytime, anywhere.
Voyager scanners are the industry benchmark for value and performance.
To conserve valuable counter space, the scanner cradle mounts to any
wall. In addition to automatic infrared activation, the VoyagerBT comes
with Honeywell’s patented CodeGate®and RangeGate®technology.
CodeGate technology easily completes data transmission with the
push of a single button.
RangeGate enables VoyagerBT to scan 250 bar codes when out of
range of a host system.VoyagerBT then automatically downloads them
to the host when the connection is re-established.
Honeywell’s MS9535 VoyagerBT brings you closer to your customers
and your patients.
For more information on the MS9535 VoyagerBT wireless single-line
laser scanner, please visit www.honeywell.com/aidc
Wireless Single-Line Laser Scanner
Bluetooth• ®Wireless Technology: Facilitates scanning
all standard 1D bar codes anytime, anywhere
Multiple Scan Indicators:• Provides audible and visual
confirmation of each scan
Wall-Mountable Cradle:• Conserves valuable counter space
CodeGate:• Zero in on desired code and complete data
transmission with the push of a single button—ideal for
menu scanning applications
RangeGate:• Scans 8KB of bar codes while out of range
and then communicates with host once connectivity is
re-established
Features

MS9535-DS Rev A 01/09
© 2009 Honeywell International Inc.
Honeywell Security & Data Collection
Honeywell Scanning & Mobility
90 Coles Road
Blackwood, NJ 08012
856.228.8100
www.honeywell.com
For more information:
www.honeywell.com/aidc
RoHS
2002/95/EC
MS9535 VoyagerBT Technical Specifications
Operational
Light Source Visible Laser Diode 650 nm ± 10 nm
Visual Indicators
Blue = ready to scan, White = good read; Steady Yellow = battery full; Flashing Yellow = battery charging
Host System Interfaces USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Wireless
Radio/Range 2.4 to 2.4835 GHz (ISM Band) Frequency-Hopping Bluetooth v1.2; Class 2: 10 m (33’) line of sight
Data Rate (Transmission Rate) 1 Mbit/s (721 Kbit/s)
Battery 1100 mAh Li-ion
Number of Scans up to 12,000 scans per charge
Expected Hours of Operation 8 hours
Expected Charge Time 2.5 hours
Mechanical/Electrical
Scanner Base
Dimensions (LxWxH) 198 mm x 78 mm x 56 mm (7.8˝ x 3.1˝ x 2.2˝) 205 mm x 100 mm x 52 mm (8.1˝ x 3.9˝ x 2.0˝)
Weight 199 g (7.0 oz) 225 g (7.9 oz)
Charging Power (typical) 2.75 W (550 mA @ 5V)
Non-Charging Power (typical) 650 mW (130 mA @ 5V)
DC Transformers Internal Battery Class 2: 5.2 VDC @ 2 A
Laser Class Class 1: IEC60825-1, EN60825-1
EMC FCC Part 15, ICES-003, EN55022 Class B
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Drop
Designed to withstand 1.5 m (5´) drops
Environmental Sealing Sealed to resist airborne particulate contaminants
Light Levels 4,842 Lux (450 foot-candles)
Scan Performance
Scan Pattern Single scan line
Scan Speed 72 scan lines per second
Scan Angle Horizontal: 48°
Print Contrast 35% minimum reflectance difference
Pitch, Skew 68°, 52°
Decode Capabilities Reads standard 1D and GS1 DataBar symbologies. Visit www.honeywell.com/aidc/symbologies for details.
Warranty 2 year factory warranty (note: 1 year warranty for battery)
Typical Performance*
Narrow Width Depth of Field
5.2 mil 0 mm - 51 mm (0˝ - 2.0˝)
7.5 mil 0mm - 127 mm (0˝ - 5.0˝)
10 mil 0 mm - 165 mm (0˝ - 6.5˝)
13 mil 0 mm - 203 mm (0˝ - 8.0˝)
21 mil 25 mm - 254 mm (1.0˝ - 10.0˝ )
*Resolution: 5 mil (0.127 mm)
*Performance may be impacted by bar code
quality and environmental conditions
