Honeywell Vuquest 3310g User manual

Vuquest™ 3310g
Area-Imaging Scanner
User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been
made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the selection and use of
software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
2011-2014 Honeywell International Inc. All rights reserved.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.
Web Address: www.honeywellaidc.com
Microsoft® Windows®, Windows NT®, Windows 2000, Windows ME, Windows XP, and the Windows logo are trademarks or
registered trademarks of Microsoft Corporation.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.

Product Agency Compliance - Vuquest 3310
USA
FCC Part 15 Subpart B Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio or television technician for help.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions.
The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional
offices. Honeywell is not responsible for any radio or television interference caused by unauthorized modifications of this
equipment or the substitution or attachment of connecting cables and equipment other than those specified by Honeywell.
The correction is the responsibility of the user.
Use only shielded data cables with this system. This unit has been tested with cables less than 3 meters. Cables greater
than 3 meters may not meet class B performance.
Caution: Any changes or modifications made to this equipment not expressly approved by Honeywell may void the FCC
authorization to operate this equipment.
UL Statement
UL listed: UL60950-1, 2nd Edition.
Canada
Industry Canada ICES-003
This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Conformité à la règlementation canadienne
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada. Son fonctionnement est assujetti
aux conditions suivantes :
1. Cet appareil ne doit pas causer de brouillage préjudiciable.
2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un fonctionnement
indésirable.
C-UL Statement
C-UL listed: CSA C22.2 No.60950-1-07, 2nd Edition.

Europe
The CE marking indicates compliance to 2004/108/EC EMC Directive with Standards EN55022 CLASS B, EN55024,
EN61000-3-2, EN61000-3-3. In addition, complies to 2006/95/EC Low Voltage Directive, when shipped with recom-
mended power supply.
European Contact:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell International Inc. shall not be liable for use of our product with equipment (i.e., power supplies, personal comput-
ers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
Honeywell Scanning & Mobility Product Environmental Information
Refer to www.honeywellaidc.com/environmental for the RoHS / REACH / WEEE information.
South Korea
This product meets Korean agency approval.
Taiwan
If the following label is attached to your product, the product meets Taiwan agency approval:
BSMI Standard: CNS13438, CNS14336-1
依據標準 : CNS13438, CNS14336-1
International
LED Safety Statement
LEDs have been tested and classified as “EXEMPT RISK GROUP” to the standard: IEC 62471:2006.
CB Scheme
Certified to CB Scheme IEC 60950-1, Second Edition.
Patents
For patent information, please refer to www.hsmpats.com.
Solids and Water Protection
The Vuquest 3310 has a rating of IP53, immunity of foreign particles and dripping water.
Warning
To reduce the possibility of heat-related injuries, avoid touching sections of the scanner that feel warm.
Caution
To maintain compliance with standards when not powering the imager with the optional power supply, the power
source should be listed and meet applicable requirements for a limited power source or a Class 2 power supply with
rating: 5 - 5.2 Vdc, 1.0 A minimum.
!
!

Required Safety Labels
Scanner
Compliance
Label
location
Part Number,
Serial Number
and Revision
Information
location
Illumination output

i
Chapter 1 - Getting Started
About This Manual ...............................................................................................................1-1
Unpacking Your Device .......................................................................................................1-1
Connecting the Device.........................................................................................................1-1
Connecting with USB .....................................................................................................1-1
Connecting with Keyboard Wedge.................................................................................1-1
Connecting with RS232 Serial Port................................................................................1-2
Reading Techniques ............................................................................................................1-3
Menu Bar Code Security Settings........................................................................................1-3
Setting Custom Defaults ......................................................................................................1-3
Resetting the Custom Defaults ............................................................................................1-4
Chapter 2 - Programming the Interface
Introduction ..........................................................................................................................2-1
Programming the Interface - Plug and Play .........................................................................2-1
Keyboard Wedge ...........................................................................................................2-1
Laptop Direct Connect ...................................................................................................2-1
RS232 Serial Port ..........................................................................................................2-1
USB IBM SurePos..........................................................................................................2-2
USB PC or Macintosh Keyboard....................................................................................2-2
USB HID.........................................................................................................................2-2
USB Serial......................................................................................................................2-3
Remote MasterMind™ for USB......................................................................................2-3
Verifone®Ruby Terminal Default Settings.....................................................................2-4
Gilbarco®Terminal Default Settings ..............................................................................2-4
Honeywell Bioptic Aux Port Configuration......................................................................2-4
Datalogic™ Magellan©Aux Port Configuration..............................................................2-5
NCR Bioptic Aux Port Configuration ..............................................................................2-5
Wincor Nixdorf Terminal Default Settings ......................................................................2-5
Wincor Nixdorf Beetle™ Terminal Default Settings .......................................................2-6
Keyboard Country Layout ....................................................................................................2-6
Keyboard Style...................................................................................................................2-14
Keyboard Conversion ........................................................................................................2-15
Control Character Output...................................................................................................2-15
Keyboard Modifiers ............................................................................................................2-15
RS232 Modifiers ................................................................................................................2-18
RS232 Baud Rate ........................................................................................................2-18
RS232 Word Length: Data Bits, Stop Bits, and Parity .................................................2-19
RS232 Receiver Time-Out...........................................................................................2-21
RS232 Handshaking ....................................................................................................2-21
RS232 Timeout ............................................................................................................2-21
XON/XOFF...................................................................................................................2-22
ACK/NAK .....................................................................................................................2-22
Table of Contents

ii
Scanner to Bioptic Communication ................................................................................... 2-22
Scanner-Bioptic Packet Mode .....................................................................................2-22
Scanner-Bioptic ACK/NAK Mode................................................................................. 2-23
Scanner-Bioptic ACK/NAK Timeout............................................................................. 2-23
Chapter 3 - Input/Output Settings
Power Up Beeper ................................................................................................................ 3-1
Beep on BEL Character.......................................................................................................3-1
Trigger Click ........................................................................................................................ 3-1
Good Read and Error Indicators..........................................................................................3-2
Beeper – Good Read.....................................................................................................3-2
Beeper Volume – Good Read........................................................................................ 3-2
Beeper Pitch – Good Read............................................................................................ 3-2
Beeper Pitch – Error ......................................................................................................3-3
Beeper Duration – Good Read ......................................................................................3-3
LED – Good Read ......................................................................................................... 3-3
Number of Beeps – Good Read ....................................................................................3-4
Number of Beeps – Error...............................................................................................3-4
Good Read Delay .......................................................................................................... 3-4
User-Specified Good Read Delay..................................................................................3-4
Manual Trigger Modes......................................................................................................... 3-5
LED Illumination - Manual Trigger .................................................................................3-5
Serial Trigger Mode.............................................................................................................3-5
Read Time-Out .............................................................................................................. 3-6
Presentation Mode .............................................................................................................. 3-6
LED Illumination - Presentation Mode ...........................................................................3-6
Presentation LED Behavior after Decode......................................................................3-7
Presentation Sensitivity ................................................................................................. 3-7
Presentation Centering.................................................................................................. 3-7
CodeGate®.......................................................................................................................... 3-9
Streaming Presentation™ Mode ......................................................................................... 3-9
Mobile Phone Read Mode................................................................................................. 3-10
Hands-Free Time-Out........................................................................................................ 3-10
Character Activation Mode ................................................................................................ 3-10
Activation Character .................................................................................................... 3-11
Character Activation Laser Timeout ............................................................................3-11
Character Deactivation Mode ............................................................................................ 3-11
End Character Activation After Good Read.................................................................3-11
Character Activation Timeout ...................................................................................... 3-12
Deactivation Character ................................................................................................ 3-12
Reread Delay..................................................................................................................... 3-12
User-Specified Reread Delay ............................................................................................3-13
2D Reread Delay ............................................................................................................... 3-13
Illumination Lights.............................................................................................................. 3-13
Aimer Delay ....................................................................................................................... 3-14
User-Specified Aimer Delay.........................................................................................3-14
Aimer Mode ....................................................................................................................... 3-14
Centering........................................................................................................................... 3-14

iii
Preferred Symbology......................................................................................................... 3-16
High Priority Symbology ..............................................................................................3-16
Low Priority Symbology ............................................................................................... 3-16
Preferred Symbology Time-out.................................................................................... 3-17
Preferred Symbology Default....................................................................................... 3-17
Output Sequence Overview............................................................................................... 3-17
Output Sequence Editor .............................................................................................. 3-17
To Add an Output Sequence ....................................................................................... 3-17
Other Programming Selections.................................................................................... 3-18
Output Sequence Editor .............................................................................................. 3-19
Partial Sequence ......................................................................................................... 3-19
Require Output Sequence ........................................................................................... 3-19
Multiple Symbols ............................................................................................................... 3-20
No Read ............................................................................................................................ 3-20
Video Reverse ...................................................................................................................3-21
Working Orientation........................................................................................................... 3-21
Chapter 4 - Data Editing
Prefix/Suffix Overview ......................................................................................................... 4-1
To Add a Prefix or Suffix:...............................................................................................4-1
Example: Add a Tab Suffix to All Symbologies..............................................................4-2
To Clear One or All Prefixes or Suffixes........................................................................4-2
To Add a Carriage Return Suffix to All Symbologies.....................................................4-2
Prefix Selections.................................................................................................................. 4-2
Suffix Selections.................................................................................................................. 4-2
Function Code Transmit ......................................................................................................4-3
Communication Check Character........................................................................................ 4-3
Intercharacter, Interfunction, and
Intermessage Delays ....................................................................................................... 4-4
Intercharacter Delay ...................................................................................................... 4-4
User Specified Intercharacter Delay..............................................................................4-4
Interfunction Delay......................................................................................................... 4-5
Intermessage Delay....................................................................................................... 4-5
Chapter 5 - Data Formatting
Data Format Editor Introduction ..........................................................................................5-1
Add a Data Format ..............................................................................................................5-1
Other Programming Selections...................................................................................... 5-2
Terminal ID Table................................................................................................................ 5-3
Data Format Editor Commands........................................................................................... 5-3
Move Commands........................................................................................................... 5-6
Search Commands........................................................................................................ 5-7
Miscellaneous Commands............................................................................................. 5-9
Data Formatter ..................................................................................................................5-11
Data Format Non-Match Error Tone............................................................................5-12
Primary/Alternate Data Formats........................................................................................5-12
Single Scan Data Format Change............................................................................... 5-13

iv
Chapter 6 - External Input / Output
External Input ...................................................................................................................... 6-1
External Trigger Control................................................................................................. 6-1
External Trigger Polarity ................................................................................................ 6-1
External Trigger Parameters..........................................................................................6-2
External Trigger Schematic ...........................................................................................6-2
External Output.................................................................................................................... 6-3
External Illumination Control.......................................................................................... 6-3
External Illumination Parameters...................................................................................6-3
External Illumination Schematic..................................................................................... 6-4
Chapter 7 - Symbologies
All Symbologies................................................................................................................... 7-1
Message Length Description ............................................................................................... 7-1
Codabar............................................................................................................................... 7-2
Codabar Concatenation................................................................................................. 7-3
Code 39 ............................................................................................................................... 7-4
Code 32 Pharmaceutical (PARAF)................................................................................ 7-5
Full ASCII....................................................................................................................... 7-6
Code 39 Code Page ......................................................................................................7-6
Interleaved 2 of 5................................................................................................................. 7-7
NEC 2 of 5...........................................................................................................................7-8
Code 93 ............................................................................................................................... 7-9
Code 93 Code Page ....................................................................................................7-10
Straight 2 of 5 Industrial (three-bar start/stop)................................................................... 7-11
Straight 2 of 5 IATA (two-bar start/stop)............................................................................7-12
Matrix 2 of 5....................................................................................................................... 7-13
Code 11 ............................................................................................................................. 7-14
Code 128........................................................................................................................... 7-15
ISBT 128 Concatenation.............................................................................................. 7-15
Code 128 Code Page .................................................................................................. 7-16
GS1-128 ............................................................................................................................ 7-17
Telepen.............................................................................................................................. 7-18
UPC-A ............................................................................................................................... 7-19
UPC-A/EAN-13
with Extended Coupon Code .......................................................................................... 7-21
Coupon GS1 DataBar Output............................................................................................ 7-21
UPC-E0 ............................................................................................................................. 7-22
UPC-E1 ............................................................................................................................. 7-24
EAN/JAN-13 ......................................................................................................................7-24
Convert UPC-A to EAN-13 ..........................................................................................7-24
ISBN Translate ............................................................................................................ 7-26
EAN/JAN-8 ........................................................................................................................ 7-27
MSI .................................................................................................................................... 7-29
GS1 DataBar Omnidirectional ........................................................................................... 7-31
GS1 DataBar Limited......................................................................................................... 7-31
GS1 DataBar Expanded .................................................................................................... 7-32

v
Trioptic Code ..................................................................................................................... 7-32
Codablock A ...................................................................................................................... 7-33
Codablock F ...................................................................................................................... 7-34
PDF417 ............................................................................................................................. 7-35
MacroPDF417 ................................................................................................................... 7-35
MicroPDF417.....................................................................................................................7-36
GS1 Composite Codes...................................................................................................... 7-36
UPC/EAN Version........................................................................................................ 7-37
GS1 Emulation .................................................................................................................. 7-37
TCIF Linked Code 39 (TLC39) .......................................................................................... 7-38
QR Code............................................................................................................................ 7-38
QR Code Page ............................................................................................................7-39
Data Matrix ........................................................................................................................ 7-40
Data Matrix Code Page ............................................................................................... 7-40
MaxiCode .......................................................................................................................... 7-41
Aztec Code ........................................................................................................................ 7-42
Aztec Code Page......................................................................................................... 7-42
Chinese Sensible (Han Xin) Code..................................................................................... 7-43
Postal Codes - 2D ............................................................................................................. 7-44
Single 2D Postal Codes:..............................................................................................7-44
Combination 2D Postal Codes:.................................................................................... 7-45
Postal Codes - Linear........................................................................................................ 7-48
China Post (Hong Kong 2 of 5)....................................................................................7-48
Korea Post................................................................................................................... 7-49
Chapter 8 - Imaging Commands
Single-Use Basis ................................................................................................................. 8-1
Command Syntax ................................................................................................................ 8-1
Image Snap - IMGSNP........................................................................................................8-1
IMGSNP Modifiers......................................................................................................... 8-1
Image Ship - IMGSHP ......................................................................................................... 8-3
IMGSHP Modifiers......................................................................................................... 8-4
Intelligent Signature Capture - IMGBOX ........................................................................... 8-10
Signature Capture Optimize ........................................................................................ 8-10
IMGBOX Modifiers....................................................................................................... 8-11
Chapter 9 - Interface Keys
Keyboard Function Relationships........................................................................................9-1
Supported Interface Keys ....................................................................................................9-3
Chapter 10 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies........................................................... 10-1
Show Decoder Revision .................................................................................................... 10-1
Show Scan Driver Revision ............................................................................................... 10-1
Show Software Revision.................................................................................................... 10-1
Show Data Format............................................................................................................. 10-1
Test Menu.......................................................................................................................... 10-2

vi
TotalFreedom ....................................................................................................................10-2
Application Plug-Ins (Apps) ............................................................................................... 10-2
EZConfig-Scanning Introduction........................................................................................ 10-3
Installing EZConfig-Scanning from the Web................................................................10-3
Resetting the Factory Defaults .......................................................................................... 10-4
Chapter 11 - Serial Programming Commands
Conventions....................................................................................................................... 11-1
Menu Command Syntax .................................................................................................... 11-1
Query Commands ............................................................................................................. 11-1
Responses................................................................................................................... 11-2
Trigger Commands............................................................................................................ 11-3
Resetting the Custom Defaults.......................................................................................... 11-3
Menu Commands .............................................................................................................. 11-4
Chapter 12 - Product Specifications
3310 Scanner Product Specifications................................................................................12-1
Depth of Field .................................................................................................................... 12-2
Typical Performance.................................................................................................... 12-2
Guaranteed Performance ............................................................................................12-2
Mounting General Guidelines ............................................................................................ 12-3
Standard Cable Pinouts..................................................................................................... 12-4
Keyboard Wedge......................................................................................................... 12-4
Serial Output ............................................................................................................... 12-5
USB ............................................................................................................................12-5
Chapter 13 - Maintenance
Repairs .............................................................................................................................. 13-1
Maintenance ...................................................................................................................... 13-1
Cleaning the Scanner .................................................................................................. 13-1
Cleaning the Window................................................................................................... 13-1
Inspecting Cords and Connectors ............................................................................... 13-1
Replacing Cables .............................................................................................................. 13-1
Replacing an Interface Cable ...................................................................................... 13-2
Troubleshooting a Corded Scanner................................................................................... 13-2
Chapter 14 - Customer Support
Technical Assistance......................................................................................................... 14-1
Product Service and Repair............................................................................................... 14-1
Appendix A - Reference Charts
Symbology Charts ...............................................................................................................A-1
Linear Symbologies .......................................................................................................A-1
2D Symbologies.............................................................................................................A-3
Postal Symbologies .......................................................................................................A-3

vii
ASCII Conversion Chart (Code Page 1252)........................................................................A-3
Lower ASCII Reference Table.............................................................................................A-4
ISO 2022/ISO 646 Character Replacements ......................................................................A-8
Unicode Key Maps ............................................................................................................A-10
Sample Symbols
Programming Chart

viii

1 - 1
1
Getting Started
About This Manual
This User’s Guide provides installation and programming instructions for the Vuquest™ 3310 area-imaging scanner. Product
specifications, dimensions, warranty, and customer support information are also included.
Honeywell bar code scanners are factory programmed for the most common terminal and communications settings. If you need
to change these settings, programming is accomplished by scanning the bar codes in this guide.
An asterisk (*) next to an option indicates the default setting.
Unpacking Your Device
After you open the shipping carton containing the product, take the following steps:
• Check for damage during shipment. Report damage immediately to the carrier who delivered the carton.
• Make sure the items in the carton match your order.
• Save the shipping container for later storage or shipping.
Connecting the Device
Connecting with USB
A scanner can be connected to the USB port of a computer.
1. Connect the appropriate interface cable to the device first, then to the computer.
2. The scanner beeps.
3. Verify the scanner operation by scanning a bar code from the Sample Symbols in the back of this manual.
The unit defaults to a USB PC Keyboard. Refer to page 2-2 for other USB terminal settings.
For additional USB programming and technical information, refer to “USB Application Note,” available at www.honey-
wellaidc.com.
Connecting with Keyboard Wedge
A scanner can be connected between the keyboard and PC as a “keyboard wedge,” where the scanner provides data out-
put that is similar to keyboard entries. The following is an example of a keyboard wedge connection:
1. Turn off power and disconnect the keyboard cable from the back of the terminal/computer.
Scanner USB
Connection:

1 - 2
2. Connect the appropriate interface cable to the device and to the terminal/computer.
3. Turn the terminal/computer power back on. The scanner beeps.
4. Verify the scanner operation by scanning a bar code from the Sample Symbols in the back of this manual. The scanner
beeps once.
The unit defaults to an IBM PC AT and compatibles keyboard wedge interface with a USA keyboard. A carriage return (CR)
suffix is added to bar code data.
Connecting with RS232 Serial Port
1. Turn off power to the terminal/computer.
2. Connect the appropriate interface cable to the scanner.
Note: For the scanner to work properly, you must have the correct cable for your type of terminal/computer.
3. Plug the serial connector into the serial port on your computer. Tighten the two screws to secure the connector to the
port.
4. Once the scanner has been fully connected, power up the computer.
This interface programs 115,200 baud, 8 data bits, no parity, and 1 stop bit.
Note: Please note, the end of the cable with the ferrite plugs into the scanner. The end of the cable with the label “DO NOT
connect this end to the bar code scanner” plugs into the computer.
Scanner
Keyboard Wedge
Connection:
Scanner RS232
Serial Port
Connection:

1 - 3
Reading Techniques
The scanner has a view finder that projects a bright green aiming beam that corresponds to the scanner’s horizontal field of
view. The aiming beam should be centered over the bar code, but it can be positioned in any direction for a good read.
The aiming beam is smaller when the scanner is closer to the code and larger when it is farther from the code. Symbologies
with smaller bars or elements (mil size) should be read closer to the unit. Symbologies with larger bars or elements (mil size)
should be read farther from the unit. To read single or multiple symbols (on a page or on an object), hold the scanner at an
appropriate distance from the target, press the button, and center the aiming beam on the symbol. If the code being scanned is
highly reflective (e.g., laminated), it may be necessary to tilt the code up 15° to 18° to prevent unwanted reflection.
Menu Bar Code Security Settings
Honeywell scanners are programmed by scanning menu bar codes or by sending serial commands to the scanner. If you want
to restrict the ability to scan menu codes, you can use the Menu Bar Code Security settings. Please contact the nearest techni-
cal support office (see Technical Assistance on page 14-1) for further information.
Setting Custom Defaults
You have the ability to create a set of menu commands as your own, custom defaults. To do so, scan the Set Custom Defaults
bar code below before scanning the menu commands for your custom defaults. If a menu command requires scanning numeric
codes from the back cover, then a Save code, that entire sequence will be saved to your custom defaults. When you have
entered all the commands you want to save for your custom defaults, scan the Set Custom Defaults bar code.
Linear bar code 2D Matrix symbol
Set Custom Defaults
Save Custom Defaults

1 - 4
You may have a series of custom settings and want to correct a single setting. To do so, just scan the new setting to overwrite
the old one. For example, if you had previously saved the setting for Beeper Volume at Low to your custom defaults, and decide
you want the beeper volume set to High, just scan the Set Custom Defaults bar code, then scan the Beeper Volume High
menu code, and then Save Custom Defaults. The rest of the custom defaults will remain, but the beeper volume setting will be
updated.
Resetting the Custom Defaults
If you want the custom default settings restored to your scanner, scan the Activate Custom Defaults bar code below. This is
the recommended default bar code for most users. It resets the scanner to the custom default settings. If there are no custom
defaults, it will reset the scanner to the factory default settings. Any settings that have not been specified through the custom
defaults will be defaulted to the factory default settings.
Activate Custom Defaults

2 - 1
2
Programming the Interface
Introduction
This chapter describes how to program your system for the desired interface.
Programming the Interface - Plug and Play
Plug and Play bar codes provide instant scanner set up for commonly used interfaces.
Note: After you scan one of the codes, power cycle the host terminal to have the interface in effect.
Keyboard Wedge
If you want your system programmed for an IBM PC AT and compatibles keyboard wedge interface with a USA keyboard,
scan the bar code below. Keyboard wedge is the default interface.
Note: The following bar code also programs a carriage return (CR) suffix.
Laptop Direct Connect
For most laptops, scanning the Laptop Direct Connect bar code allows operation of the scanner in parallel with the inte-
gral keyboard. The following Laptop Direct Connect bar code also programs a carriage return (CR) suffix and turns on
Emulate External Keyboard (page 2-14).
RS232 Serial Port
The RS232 Interface bar code is used when connecting to the serial port of a PC or terminal. The following RS232 Inter-
face bar code also programs a carriage return (CR) and a line feed (LF) suffix, baud rate, and data format as indicated
below. It also changes the trigger mode to manual.
Option Setting
Baud Rate 115,200 bps
Data Format 8 data bits, no parity bit, 1 stop bit
IBM PC AT and Compatibles with
CR suffix
Laptop Direct Connect
with CR suffix
RS232 Interface

2 - 2
USB IBM SurePos
Scan one of the following “Plug and Play” codes to program the scanner for an IBM SurePos (USB handheld scanner) or
IBM SurePos (USB tabletop scanner) interface.
Note: After scanning one of these codes, you must power cycle the cash register.
Each bar code above also programs the following suffixes for each symbology:
USB PC or Macintosh Keyboard
Scan one of the following codes to program the scanner for USB PC Keyboard or USB Macintosh Keyboard. Scanning
these codes also adds a CR and LF.
USB HID
Scan the following code to program the scanner for USB HID bar code scanners.
Symbology Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 Interleaved 2 of 5 00 0D 0B
UPC A 0D Code 128 00 18 0B
UPC E 0A Code 39 00 0A 0B
USB IBM SurePos
(USB Handheld Scanner)
Interface
USB IBM SurePos
(USB Tabletop Scanner)
Interface
USBKeyboard(PC)
USB Keyboard (Mac)
USB Japanese Keyboard (PC)
USB HID Bar Code Scanner
