Honeywell homexpert Rondostat COMFORT+ HR30 User manual

- 1 -
2. Brief description
With the electronic radiator controller you can set your
room temperature exactly to your requirements while
additionally saving energy.
iLowering the room temperature by 1 °C saves
approx. 6% energy!
User-friendly
• Large adjustable display with backlight.
• Convenient programming through removal of the
radiator controller from the valve.
Installation
• The radiator controller fits on the most common
radiator valves M30 x 1.5.
• After being mounted, the radiator controller operates
immediately with the factory setting.
Functions for increased comfort
• Individual heating program for each weekday.
• Up to 6 switching points per day and three different
temperatures.
• Operating modes Holiday, Party, Day off can easily be
activated.
• Parameters can be set individually, see Section 9.
Energy-saving functions
• With the window function an open window is
recognised and the radiator valve closed.
• In ECO mode the room temperature is decreased by
3 °C.
• Optimised heating or lowering of the room
temperature.
CAUTION
Danger of malfunctions!
fUse the radiator controller only in
accordance with these operating
instructions.
fDo not allow children to play with the
radiator controller.
3. Installation
Ready to operate in three steps:
• Inserting batteries
• Setting the language, time and date
• Mounting – FINISHED
1. Scope of delivery
The radiator controller packaging contains:
4
3
1
2
1 Radiator controller, without batteries
2 Valve baseplate M30 x 1.5
3 Display element
4 Bag with adapters (Danfoss RA, RAV, RAVL)
WARNING
Danger of suffocation!
fKeep packaging materials away from
children.
Electronic
Radiator controller
HR30

- 2 -
Inserting/changing batteries
The radiator controller is set for the following battery
type:
• 2 Alkaline mignon cells 1.5 V, type LR6, AA, AM3
You can alternatively use the following batteries/
accumulators:
• Lithium 1.5 V, type LR6, AA, AM3
• NiMH 1.5 V, type LR6, AA, AM3
iIf lithium or NiMH batteries are used, Parameter 14
has to be set correctly, see Section 9.
3.
2.
1.
+
–
–
+
1. Move the front part slightly upwards and remove it
downwards.
The battery compartment is now accessible.
2. Insert the batteries.
Ensure that the polarity is correct.
3. Put the front part back on and push downward.
The software version number, then the language
deutsch (German) is displayed.
4. If applicable, use the adjustment dial to select a
different language.
5. Confirm the selected language with the OK button.
hour is displayed.
iThe language selection is only displayed during initial
commissioning. During future battery changes setting
of time and date is prompted directly.
iThe battery life of new mignon cells amounts to
approx. 2 years. The batteries need changing when
the symbol flashes. All the settings are retained
when the batteries are changed.
WARNING
Explosion hazard!
fNon-rechargeable batteries.
fNever short-circuit batteries or throw them
into fire.
fDispose of used batteries ecologically.
Setting the time and date
1. When hour is displayed, use the adjustment dial to
set the current hour and confirm with OK .
minute is displayed.
2. Use the adjustment dial to set the current minute and
confirm with OK .
year is displayed.
3. Use the adjustment dial to set the current year and
confirm with OK .
month is displayed.
4. Use the adjustment dial to set the current month and
confirm with OK .
day is displayed.
5. Use the adjustment dial to set the current day and
confirm with OK .
The normal display with set temperature and selected
operating mode is displayed.
Mounting the radiator controller
The radiator controller can be mounted easily on all
common radiator valves with a connection M30 x 1.5
without causing dirt or water staining.
WARNING
Damage to the radiator controller due
to short-circuiting through humidity and
moisture!
fMount the radiator controller in dry, closed
rooms only.
fProtect the radiator controller against
humidity, moisture, dust, direct sunlight or
high heat irradiation.
Removing the old thermostat head
1.
2.
1. Turn the old thermostat head to the left until it stops
and loosen the mounting.
2. Remove the old thermostat head from the radiator
valve.

- 3 -
Selecting the adapter
The radiator controller fits on the most common radiator
valves M30 x 1.5. Adapters are required for some valve
types.
1. Check whether an adapter is required and, if
necessary, select the appropriate adapter.
Make Illustration Adapter
Valves M30 x
1.5 Honeywell-
Braukmann,
MNG, Heimeier,
Oventrop
Not
required
Danfoss RA Supplied
Danfoss RAV Supplied
Danfoss RAVL Supplied
2. Slide the adapter onto the radiator valve and turn it
until you feel it click into place.
3. If necessary, screw the adapter tight with a screw.
Mounting the valve baseplate
1a
1b
1. Separate the valve baseplate from the radiator
controller. To do so, slide the slide towards the .
3.
2.
2. Turn the adjustment dial of the valve baseplate anti-
clockwise until it stops.
3. Put the valve baseplate onto the radiator valve or the
adapter and tighten by hand (without tools!).
Mounting the radiator controller
1.3.
2.
1. Ensure that the slide at the radiator controller is in the
open position.
2. Push the radiator controller onto the valve baseplate
so that the geer teeth catch and are no longer visible.
3. Lock the radiator controller in the end position. To do
so, slide the slide towards the .
The radiator controller carries out a self test and after
1 minute displays cycl. Subsequently the radiator
controller changes to automatic mode.
iThe radiator controller only functions if it is
interlocked in the end position.
FINISHED! – Your radiator controller is now ready for
operation with the factory setting!
Securing controller and battery compartment
iThe radiator controller and battery compartment
can be secured against being removed or opened by
means of a screw. These screws are not included in
the packaging.
Countersunk screws
Torx/corss recess 2.2x8mm
Type: WIN1412-KC22X8-Z or
WIN1412-KB22X8-Z

- 4 -
Setting the position of the display
In order to improve the legibility the display of the
radiator controller can be tilted to different positions
(10°, 20°, 30°, 40°).
The angle of 40° can be fixed with the supplied display
element.
1.
2.
1. Lift the display and set it to the desired angle.
2. If desired to fix the angle at 40°, slide the support
bracket between the display and the main body until it
clips into place.
4. Device overview
Operating elements and display
85
7
3
2
1
4
11
10
9
6
PROGAUTO
ECO
MANU
OK
1 Heating/Conserve period in hours
2 Current weekday 1 ... 7 (Monday ... Sunday)
3 Temperature display: e.g. current room temperature
or measured temperature, if configured in
Parameter 9
4 Text display with 9 characters
5 Button OK : Confirm settings
6 Button PROG: Select the operating modes, set the
time program;
Button pressed long (approx. 10 seconds):
Parameters can be changed;
Programming: Back to next level up
7 Adjustment dial: Change settings
8 Button AUTO/ECO/MANU: Change between
automatic, ECO and manual mode
In programming mode: Terminate (without storing)
9 Battery status
10 Operation lock
11 Symbol for Comfort temperature 1 ,
Comfort temperature 2 , Conserve temperature
Battery display
Battery status Meaning
Batteries full
Batteries half-full
Batteries have to be replaced soon
Flashing display: Batteries are flat and
have to be replaced
Operating hints
Operating the radiator controller comfortably
The radiator controller can be removed from the radiator
to facilitate programming.
1.
2.
1. Unlock the radiator controller. To do so, slide the slide
at the radiator controller towards the .
2. Pull the radiator controller off the valve baseplate.
Lost your way in the program?
fPress the button AUTO/ECO/MANU
automatic is displayed. The last entry is rejected.
5. Functionality in automatic mode
Standard time program
In automatic mode the radiator controller automatically
controls the room temperature in accordance with the
stored time program.

- 5 -
Week program 1: At home all day
Factory preset time program is set for each day of the
week (Mo – Su):
Heating
20 °C
16 °C
Lowering/
saving
Switching
point 1
Switching
point 2
Switching point Time Temperature
1 6:00 – 22:00 20 °C (Comfort temperature 1)
2 22:00 – 6:00 16 °C (Conserve temperature)
i• Two further week programs are stored in the
radiator controller. Further information is available
in Section 9.
• You can also adapt one of the stored week
programs to your individual requirements, see
Section 8.
Modifying the temperature temporarily
If you want to change the temperature specified by the
time program temporarily:
fSet your desired temperature using the adjustment
dial.
The change remains in effect until the next switching
point.
iThe process of changing the temperatures
permanently is described in Section 7.
Saving energy in ECO mode
In ECO mode the room temperature in automatic mode
specified by the time program is decreased by 3 °C.
fTo activate ECO mode press the button AUTO/ECO/
MANU until economy is displayed.
The displayed temperature is reduced by 3 °C.
ECO mode runs until you press the button AUTO/
ECO/MANU again and select a different operating
mode.
Manual mode
In manual mode the radiator controller operates at
the (manually) set temperature until you change the
temperature or change to a different operating mode.
fTo activate the manual mode press the button
AUTO/ECO/MANU until manual is displayed.
The temperature can be adjusted manually using the
adjustment dial.
Manual mode runs until you press the button AUTO/
ECO/MANU again and select a different operating
mode.
6. Programming – Operating modes
Overview of the operating modes
• "Party" operating mode: In this operating mode you
can specify a temperature for a number of hours.
After the set period has expired, the radiator controller
changes to automatic mode.
• "Day off" operating mode: If a public holiday lies
during the week, the automatic mode settings may
not meet your requirements on these days. In such
cases you can activate a “Day off” program for one
or more days. After the set period has expired, the
radiator controller changes to automatic mode.
• "Holiday" operating mode: In this operating mode
you can specify a temperature for a specific number
of days. After the set period has expired, the radiator
controller changes to automatic mode.
Selecting operating modes
Selecting the "Party" or "Holiday" operating
mode
1. Press the PROG button and turn the adjustment dial
to the left until party or holiday is displayed.
2. Confirm the selected operating mode with the OK
button.
Hours or Days flashes.
3. Use the adjustment dial to set the desired number of
hours or days and confirm with OK .
The temperature display flashes.
4. Use the adjustment dial to set the desired temperature
and confirm with OK .
The selected operating mode and the set temperature
are displayed.

- 6 -
Selecting the "Day off" operating mode
1. Press the PROG button and turn the adjustment dial
to the left until day off is displayed.
2. Confirm the selected operating mode with the OK
button.
Days flashes.
3. Use the adjustment dial to set the desired number of
days and confirm with OK .
The selected operating mode is displayed.
i• The procedure of creating the time program for a
day off is described in Section 8.
• When the number of days for holiday/day off is
entered, the current day counts as the first day.
• An overview of the program structure is shown on
the last page of these instructions.
7. Programming – Temperatures
For the time program three preset temperatures which
can be assigned to the switching points in the time
program are possible:
• Comfort temperature 1 Factory setting 20 °C
• Comfort temperature 2 Factory setting 22 °C
• Conserve temperature Factory setting 16 °C
Setting the temperatures
1. Press the PROG button.
comfort 1 is displayed.
2. Press the OK button, use the adjustment dial to set
the Comfort temperature 1 and confirm with OK .
saved is displayed briefly and then again
comfort 1.
3. Turn the adjustment dial clockwise until the next
temperature is displayed.
4. Repeat Steps 2 and 3 for the Comfort temperature 2
and the Conserve temperature.
5. Use the AUTO button to terminate programming.
iThe three preset temperatures (Comfort
temperature 1, 2 and Conserve temperature) can be
changed at any time.
i• During programming the PROG button can be
used to return to the next level up.
• You can abort programming at any time by using
the AUTO button.
iAn overview of the program structure is shown on the
last page of these instructions.
8. Programming – Time program
Planning the time program
You can specify up to 6 switching points per day.
The following has to be assigned to each switching
point:
• One of the three preset temperatures (Comfort
temperature 1, 2 and Conserve temperature).
• Beginning of the Heating/Conserve period
• End of the Heating/Conserve period
Example
2345
1 6
Comfort 1
Conserve
Comfort 2
Conserve
Heating
Heating
Heating
Switching points
The example shows the following time program:
Switching point Time Temperature
1 6:00 – 9:00 20 °C (Comfort temperature 1)
2 9:00 – 12:00 16 °C (Conserve temperature)
3 12:00 – 14:00 20 °C (Comfort temperature 1)
4 14:00 – 17:00 16 °C (Conserve temperature)
5 17:00 – 22:00 22 °C (Comfort temperature 2)
6 22:00 – 6:00 16 °C (Conserve temperature)
iAn overview of the program structure is shown on the
last page of these instructions.
Week program
You can adjust the time program to your personal weekly
schedule. You have the following options to this purpose:
• Separate time programs for weekdays (Mo – Fr) and
weekend (Sa – Su)
• One time program for all days of the week (Mo – Su)
• A different time program for each day of the week
(Mo, Tu, We, Th, Fr, Sa, Su)
iWe recommend that you record your time program
before beginning programming.

- 7 -
Setting the time program
Selecting weekdays
1. Press the PROG button.
comfort 1 is displayed.
2. Turn the adjustment dial clockwise until program is
displayed.
3. Press the OK button and use the adjustment dial to
select the desired weekdays for your time program:
mo - fr, sa - su, mo - su, mo, tu, ..., su or
day off
4. Confirm the selected weekdays with the OK button.
The temperature as well as the beginning and end of
the first switching point, e.g.:
i• The end of a switching point is simultaneously the
beginning of the next switching point.
• Only the programmed switching points are
displayed.
Viewing switching points
You can use the adjustment dial to change from one
setting point to another and thus view the setting of all
the programmed switching points.
Editing switching points
1. In order to edit the displayed switching point press
the OK button.
The temperature display flashes.
2. Use the adjustment dial to select the desired
temperature (Comfort temperature 1, 2 or Conserve
temperature) for the selected switching point and
confirm with OK .
The beginning of the selected switching point flashes.
iThe time scale for programming of the switching
points begins at 3:00 in the morning and ends at 2:50
on the following day.
3. Use the adjustment dial to set the desired beginning
for the selected switching point and confirm
with OK.
The end of the selected switching point flashes.
4. Use the adjustment dial to set the desired end of the
selected switching point and confirm with OK .
saved is displayed briefly. Subsequently the
temperature as well as the beginning and end of the
switching point are displayed.
5. For the further switching points also select the
temperature as well as the beginning and end of the
switching point as described in Steps 1 to 5.
i• A switching point is not saved until the
temperature, beginning and end have been
confirmed with the OK button.
• If a switching point is not required, select the
setting --.-.
Editing further weekdays
1. When all the switching points have been edited, use
the PROG button to select the weekdays.
2. Edit the switching points for the next weekdays.
3. After all the required weekdays have been set,
terminate programming with the AUTO button.
The radiator controller operates immediately in
automatic mode with the set time program.
Deleting a switching point
fWhen a switching point is not required, select the
temperature setting --.- and confirm with OK .
iThe first switching point cannot be deleted.
Adding a switching point
1. Turn the adjustment dial until add new is displayed
and confirm with OK .
The temperature display flashes.
2. Use the adjustment dial to select the desired
temperature (Comfort temperature 1, 2 or Conserve
temperature) for the new switching point and confirm
with OK .
The beginning of the new switching point flashes.
3. Use the adjustment dial to set the desired switching
time for the new switching point and confirm
with OK .
The end of the desired switching point flashes.
4. Use the adjustment dial to set the desired end of the
new switching point and confirm with OK .
iadd new is only displayed when less than 6 switch-
ing points are programmed.

- 8 -
9. Basic settings
Overview
If desired, you can modify the 16 basic settings.
Factory settings have a grey background.
Parameters marked with an * are described in more
detail below.
Par. Sett. Meaning
1
1
2
3
4
5
6
Language setting
German
English
French
Dutch
Italian
Danish
2
0
1
2
Preset time programs *
Week program 1 "At home all day"
Week program 2 "At home ifor lunch"
Week program 3 "Working half-time"
3
0
1
Backlight display*
Deactivated
Activated
4
0
1
Summer/winter time changeover
No automatic changeover
Automatic changeover
5
0
30
...
90
Duration of the window function *
Window function not active
Valve opens at the latest after 30 minutes
...
Valve opens at the latest after 90 minutes
6
0.5
...
3.0
Sensitivity of the window function during
dropping room temperature *
0.5 (sensitive)
...
3.0 (less sensitive)
Factory setting: 0.8
7
0.1
...
3.0
Sensitivity of the window function during
rising room temperature *
0.1 (sensitive)
...
3.0 (less sensitive)
Factory setting: 0.3
8
0
1
Setting the valve stroke *
Standard valve stroke
Full-stroke mode
9
0
1
Temperature representation in the display *
Set/programmed temperature (setpoint
temperature)
Measured room temperature
Par. Sett. Meaning
10
16
17
...
30
Upper temperature limit
The room temperature cannot be set higher
than the specified upper temperature limit
(HI LIMIT).
Factory setting: 30 °C
11
5
6
...
15
Lower temperature limit
The room temperature cannot be set lower
than the specified lower temperature limit
(LOW LIMIT).
Factory setting: 5 °C
12
0
1
2
Optimisation function *
No optimisation
Optimum start
Optimum start/stop
13
3
...
-3
Temperature offset *
To adjust the temperatures measured by the
radiator controller and in the room
Factory setting: 0 °C
14
0
1
2
Battery type
Alkaline
Lithium
NiMH (accumulator chargeable)
15
0
1
Display of the valve position *
No display of the valve position
Brief display of the valve position
16
0
1
Restore to factory setting
No reset
Reset to factory setting.
Description of the parameters
Parameter 2 –
Selecting the preset time programs
• Week program 1 (factory setting, 2 switching points):
Mo – Su at home all day
This time program is described in Section 5.
• Week program 2 (6 switching points):
Mo – Fr at home in the lunch break
Sa – Su like Week program 1
20 °C
16 °C 2345
1 6
Conserve
Heating
Heating
22 °C
Switching points

- 9 -
Switching point Time Temperature
1 6:00 – 9:00 20 °C (Comfort temperature 1)
2 9:00 – 12:00 16 °C (Conserve temperature)
312:00 – 13:00 20 °C (Comfort temperature 1)
4 13:00 –17:00 16 °C (Conserve temperature)
517:00 – 22:00 22 °C (Comfort temperature 2)
6 22:00 – 6:00 16 °C (Conserve temperature)
• Week program 3 (4 switching points):
Mo – Fr working half-time
Sa – Su like Week program 1
23
1
Conserve
Heating
Heating
20 °C
16 °C
22 °C
4
Switching points
Switching point Time Temperature
1. 6:00 to 9:00 20 °C (Comfort temperature 1)
2. 9:00 to 13:00 16 °C (Conserve temperature)
3. 13:00 to
22:00
22 °C (Comfort temperature 2)
4. 22:00 to 6:00 16 °C (Conserve temperature)
Parameter 3 – Backlight
The display has a backlight in order to facilitate reading
of information.
• The backlight is activated when the adjustment dial
moves or a button is pressed.
• The backlight switches off if no action is carried out at
the radiator controller for approx. 7 seconds in order
to save energy.
Parameters 5 to 7 – Window function
In order to save energy the radiator controller closes the
radiator valve when you open a window resulting in a
sudden drop of the temperature.
When you close the window so that the temperature
rises the radiator controller opens the radiator valve
again.
If you should ever forget to close the window, the
radiator controller opens automatically after the set time
in order to ensure frost protection.
Parameter 8 – Valve stroke
The radiator controller operates with the optimum valve
stroke set in the factory.
If the entire valve stroke is to be used or if the valve does
not close completely, activate the full-stroke mode.
Parameter 9 – Temperature representation in the
display
• In the factory setting the set or programmed
temperature (Comfort temperature 1, 2 or the
Conserve temperature) is displayed.
• With the setting "measured temperature" the
measured room temperature is displayed. A
changeover to the set temperature is carried out
by turning the adjustment dial or pressing a button.
If required, the temperature can now be reset. The
display returns to the measured temperature after
approx. 3 seconds.
Parameter 12 – Optimisation function
Without optimisation (factory setting) the radiator
controller begins to raise or lower the room temperature
at the programmed time. In order to have the bathroom
warm at 7:00, the switching point must be preponed,
otherwise heating would start only at 7:00. Possibly the
switching point is preponed too much, so that heating
starts much earlier than actually needed.
With optimisation the room has already reached the
desired temperature at the programmed beginning since
the radiator controller has begun to raise or lower the
room temperature at an optimal time.
• Optimum start
The room is heated up at an optimum moment to
reach the programmed temperature.
• Optimum start/stop:
The room is heated up at an optimum moment and
cooled down earlier.
Switching point
Without
Optimisation
Optimum
Start
Optimum
Stop
Without
Optimisation
Switching point
°C

- 10 -
Parameter 13 – Temperature offset
Since the radiator controller measures the room
temperature in the area of the radiator, it is possible
that this temperature deviates from the temperature
measured at a different point in the room.
If, for example, 20 °C is measured in the room and at the
radiator 21.5 °C, this effect can be compensated by an
offset of –1.5 °C. The display at the radiator controller
remains unchanged.
Parameter 15 – Display of the valve position
When this parameter is activated (setting "1"), the
calculated valve position is displayed (0 to 100%
opened) briefly.
The main display is shown again after approx. 3 minutes
or when the AUTO button is pressed.
Changing parameters
1. Keep the PROG button pressed for at least
10 seconds until Parameter 1 flashes (left-hand digit).
The right-hand digit shows the current setting.
The parameter is displayed additionally in plain text.
For example, the display 1 1 stands for Parameter 1
(language) with Setting 1 (German).
2. If desired, use the adjustment dial to select a different
parameter (left-hand digit).
3. Press the OK button to edit the parameter.
The current setting of the parameter flashes (right
hand digit).
4. Use the adjustment dial to set the desired setting
(right-hand digit) and confirm with OK .
5. The parameter being edited flashes (left-hand digit).
6. For the further parameters repeat Steps 2 to 4.
7. Use the AUTO button to return to automatic mode.
10. Further functions
Monitoring functions
Window function
If you open a window causing the temperature to drop,
the radiator controller closes the radiator valve in order
to save energy.
window is displayed.
When the temperature rises again, but at the latest after
the set period (factory setting: 30 minutes), the radiator
controller opens the radiator valve again.
You can also open the radiator valve beforehand by
pressing the AUTO button or turning the adjustment
dial.
The sensitivity of the radiator controller to a temperature
drop or temperature rise can be set, see Section 9,
Parameters 5 to 7.
Valve protection
If the radiator valve has not been opened completely for
2 weeks, a self test is carried out. The radiator controller
opens the radiator valve briefly on the subsequent
Monday in order to prevent seizing.
cycl is displayed.
Frost protection
If the temperature drops below 5 °C, the radiator
controller opens the radiator valve until the temperature
rises above 6 °C again. This prevents the heating from
freezing up. frost is displayed.
iThe heating may not be switched off. Otherwise the
radiator controller cannot carry out the frost protec-
tion function.
Summer break
If you have switched off the central heating system
in summer and do not want to waste the batteries of
the radiator controller, you can close the radiator valve
continuously.
Closing the valve
1. Press the button AUTO/ECO/MANU until manual
is displayed.
2. Turn the adjustment dial anti-clockwise until off is
displayed.
The radiator valve now remains closed. The valve and
frost protection function remains active.

- 11 -
Opening the valve
fUse the AUTO/ECO/MANU button to change to
automatic mode.
– or –
fSet the desired temperature in manual operation.
Child-proofing / Operation lock
You can block the radiator controller to protect it against
unauthorised operation:
fKeep the AUTO/ECO/MANU and PROG buttons
pressed simultaneously for at least 3 seconds.
The symbol is displayed.
iThe same key combination is used to release the
radiator controller again for operation.
11. Help with problems
Error table
Problem/
Display
Cause Remedy
flashes Batteries flat Replace the batteries.
e1
sensor Device defective Replace the device.
e2
valve Motor cannot be
moved.
Check the
installation. If
appropriate, remove
the dirt.
The radiator
does not
become cold.
The radiator valve
does not close
fully.
Check the
installation. If
appropriate, change
to full-stroke mode
(Parameter 8).
The room
does not heat
up during
optimisation
Heating is not
switched on in
time
Ensure that the
heating system is
switched on.
Motor does not
move
Valve baseplate
not interlocked
Set the slide to the
position .
Emergency operation when batteries are flat
1. Unlock the radiator controller. To do so, slide the slide
at the radiator controller towards the .
2. Pull the radiator controller off the valve baseplate.
3. Operate the radiator valve by hand using the
adjustment dial on the valve baseplate.
–
+
Restoring the factory setting
1. Keep the PROG button pressed for approximately
10 seconds until Parameter 1 flashes (left-hand digit).
2. Use the adjustment dial to select Parameter 16 (left-
hand digit) and Setting 1 (right-hand digit).
3. Press the OK button to restore the factory setting.
12. Technical data
Type HR30
Protection class IP30
Supply voltage Batteries 2 x 1.5 V;
type LR6, AA, AM3
Connection to the radiator M30 x 1.5
Ambient temperature 0 ... 50 °C
Dimensions 94 x 50 x 69 mm
Ambient conditions For living area, business and
trade sections as well as
small businesses
Humidity 10 ... 90% rel. humidity
13. Disposal
The radiator controller has to be disposed of in
accordance with WEEE directive 2002/96/EC –
Waste Electrical and Electronic Equipment directive.
fDispose of the packaging and product
in a corresponding recycling centre.
fDo not dispose of the unit with the
domestic refuse.
fDo not burn the product.

Novar GmbH
a Honeywell Company
Gartenstraße 49
58511 Lüdenscheid
www.homexpertbyhoneywell.com
Subject to change in order to improve the product.
Hotline: xxx xxx xxx
50076383-001
14. Programming – Overview
Temperatures and operating modes
(turn adjustment dial anticlockwise) <–– Button PROG ––> (turn adjustment dial clockwise)
time date holiday day off party comfort 1 comfort 2 eco temp program
OK OK OK OK OK OK OK OK
<––> Hour <––> Days <––> Days <––> Hours <––> Temp. <––> Temp. <––> Temp. Edit time
program, see
below
OK OK OK OK OK OK OK
<––> Minute <––> Temp. <––> Temp.
OK OK OK
<––> Year
OK
<––> Month
OK
<––> Day
OK
Time program
program
OK
<––> (turn adjustment dial)
mo - fr sa - su mo - su mo tu ... su day off
OK OK OK OK OK OK OK OK
<––> (turn adjustment dial)
Switch. point 1 ... Switch. point 6 New
switching
point:
add new Delete a
switching
point:
Switch. point x
OK OK OK OK OK
<––> Temp. <––> Temp. <––> Temp. <––> Temp. <––> --:- (Delete)
OK OK OK OK OK
<––>
Beginning
<––>
Beginning
<––>
Beginning
<––>
Beginning
OK OK OK OK
<––> End <––> End <––> End <––> End
OK OK OK OK
