Honeywell TP-FIT-D-WK User manual

www.HoneywellAirComfort.com
E-mail: suppor[email protected]
Model / Modèle / Modelo / Model /
Modell / Model /Modelo / Modell /
Model / Model:
TP-FIT-D-WK
Product Registration - Get product updates & support info
Enregistrement du produit - Bénéficiez des mises à jour du
produit et d’informations d’aide
Registración del producto - Obtenga actualizaciones de
productos e información de soporte
Product registratie - Ontvang productupdates en
ondersteuningsinformatie
Produktregistrierung - Erhalten Sie Informationen
Produktaktualisierungen und Support
Rejestracja produktu - Otrzymuj aktualizacje produktów i informacje dot.
pomocy technicznej
Registo do produto - Obter atualizações do produto e informações de suporte
Termék regisztrációja - Termékfrissítések beszerzése és támogatási információk
Registrácia produktu - Získajte aktualizácie produktu a informácie o podpore
Registrace produktu - Získejte aktualizace produktu a informace o podpoře
Déshumidificateur Portatif
Mode d'emploi
Lire ces instructions avant l'utilisation et les conserver
FR Desumidificador Portátil
Manual do Utilizador
Leia e guarde estas instruções antes da utilização
PT
Mobiele Ontvochtiger
Gebruiksaanwijzing
Lees de gebruiksaanwijzing zorgvuldig en
bewaar deze goed
NL 3UHQRVQê2GYOKþRYDþ
3RXåtYDWHĐVNiSUtUXþND
3UHGXYHGHQtPGRSUHYiG]N\]DULDGHQLDVLSUHþtWDMWH
QiYRGQDSRXåtYDQLHDXVFKRYDMWHKR
SK
Tragbare Luftentfeuchter
Benutzerhandbuch
Lesen sie die anleitung vor dem gebrauch
und heben sie sie auf
DE 3ĜHQRVQê2GYOKþRYDþ9]GXFKX
8åLYDWHOVNêPDQXiO
3ĜHGXYHGHQtP]DĜt]HQtGRSURYR]XVLSĜHþWČWHXåLYDWHOVNRX
SĜtUXþNXDXVFKRYHMWHML
CZ
Portable Dehumidifier
User Manual
Read and save these instructions before use
EN Osuszacz Powietrza Przenosny
Instrukcja obsługi
Przeczytaj i zachowaj tę instrukcję przed użyciem
PL
Deshumidificador Portátil
Manual de Instrucciones
Lea y guarde estas instrucciones antes de usar la unidad
ES Hordozható Párátlanító
Használati utasítás
Használatbavétel előtt olvassa el a használati utasítást
és őrizze azt meg
HU

1
THANK YOU
SAFETY RULES
Thank you for purchasing a Honeywell Portable Dehumidifier. This User Manual is intended to
provide you with important information needed to set up, operate, maintain and troubleshoot this
product.
WARNING -- READ AND SAVE THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
The use of electrical products may create hazards that include, but are not limited to injury, fire,
electrical shock. Failure to follow these instructions may damage and/ or impair its operation and
void the warranty. In case there is any inconsistency or conflict between the English version and any
other language version of the content of this material, the English version shall prevail.
When using electrical appliances, basic safety precautions should always be followed:
EN
DO NOT touch the dehumidifier or the electrical plug with wet hands.
Check the household voltage to ensure it matches the appliance's
specification.
Before operating, remove all packaging material and check for any
damage that may have occurred during shipping.
DO NOT operate any product with a damaged cord or plug.
DO NOT use an extension cord with this appliance.
DO NOT run power cord under carpeting, or cover it with rugs or
runners. Keep the cord away from areas where it may be tripped over.
Always unplug the dehumidifier before emptying the water tank.
The water collected in the tank must be discarded. The water should
never be used for drinking.
Always unplug the dehumidifier and remove the water from the water
tank before cleaning, servicing or relocating the unit.
Remove the power cord from the electrical receptacle by grasping and
pulling on the power cord plug-end only, never pull the cord.
This appliance has been manufactured for use in domestic
environments and must not be used for other purposes.
•
•
•
•
•
•
•
•
•
•
•

2
DO NOT use the product in areas where gasoline, paint or other
flammable goods and objects are used or stored.
This dehumidifier is designed for indoor residential applications only.
It should not be used for commercial or industrial applications.
DO NOT attempt to repair or adjust any electrical or mechanical
functions of the dehumidifier, as this may cause danger and void the
warranty.
DO NOT cover the air inlet or outlet on the appliance as this may cause
the unit to fail.
DO NOT insert or allow objects to enter any ventilation or exhaust
opening as this may damage the product and could cause electrical
shock or fire.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a
hazard.
DO NOT let children play with this appliance, packaging or included
plastic bag.
If the unit is damaged or it malfunctions, do not continue to operate
it. Unplug the product from the electrical outlet. Refer to the
troubleshooting section and contact the customer support center.
Always place the dehumidifier on a leveled floor.
Never install the product near a bathtub or any water container.
Store in a dry area, away from direct sunlight, when not in use.
This appliance and its packaging materials are not intended for use
by persons (including children and children under age of 8 or elderly)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instructions concerning the use of the appliance by a person
responsible for their safety. Children being supervised not to play with
the appliance (including cleaning and user maintenance).
Always grip the top handle and keep the unit upright when transporting
from room to room – DO NOT tilt the product on its side or upside-
down.
•
•
•
•
•
•
•
•
•
•
•
•
•
SAFETY RULES (CONTINUED)
EN

3
If the dehumidifier was transported tilted on its side, you must position
it upright again and wait at least 4 hours before using it.
WARNING: To reduce the risk of fire or electric shock, do not use this
appliance with any solid state speed control device.
•
•
SAFETY RULES (CONTINUED)
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
Caution: Risk of electric shock!
Do not attempt to disassemble or modify the unit or its accessories. In case any part is
damaged, immediately power off the unit and seek the assistance of a specialist.
In the event that the power cable should become damaged, it should only be replaced
by the manufacturer, its service facility or similarly qualified personnel.
EN

4
REGULATION STATEMENT
EN
TP-FIT - R290
SYMBOL NOTE EXPLANATION
WARNING
This symbol shows that this
appliance uses a flammable
refrigerant. If the refrigerant
is leaked and exposed to an
external ignition source, there
is a risk of fire.
CAUTION
This symbol shows that the
operation manual should be
read carefully.
CAUTION
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
CAUTION
This symbol shows that
information is available such
as the operating manual or
installation manual.
Caution, risk of fire, R290

5EN
REGULATION STATEMENT (CONTINUED)
Read the instruction carefully before using the appliance.
When defrosting or cleaning, do not use any method other than those
recommended by the manufacturer.
Do not place the appliance in a room with continuous sources of
ignition (e.g. open flame, operating gas appliance or working electrical
heater).
Do not pierce and do not burn.
Do not perforate any part of the refrigerant circuit.
Refrigerant gas may be odorless.
The appliance must be installed, used and stored in an area that is
greater than 4 m2.
Accumulation of possible refrigerant leaks in an unventilated room
could lead to fire or explosion should the refrigerant come in contact
with electric heaters, stoves or other sources of ignition.
The appliance must be stored in a way to prevent mechanical damage.
Only individuals authorized by an accredited organization certifying
their competence to handle refrigerants in compliance with industry
legislation should work on the refrigerant circuit.
R290 refrigerant gas complies with European environmental directives.
This appliance contains a certain number of grams (see rating label at
the back of the unit) of R290 refrigerant gas. The maximum refrigerant
charge amount is 0.04 kg.
Additional warnings for appliances with R290 refrigerant gas.
•
•
•
•
•
•
•
•
•
•
•
•
Repair must be performed based on the recommendations from
the manufacturer. Maintenance and repair that requires the
assistance of other qualified personnel must be performed under
the supervision of specialists in the use of flammable refrigerants.

6
HOW A DEHUMIDIFIER WORKS
When the dehumidifier is switched ON, a fan pulls moisture-laden air into the dehumidifier where it
passes through dehumidifying coils inside the unit. These coils condense moisture from the air
and collect it in the water tank. The dry air is then exhausted from the dehumidifier. The air flows
through the air vents of the dehumidifier into the room as dry, warm air.
IMPORTANT: The dehumidifier is designed to operate between 41°F (5°C) and 89°F (32°C).
The dehumidifier’s performance may be greatly reduced if room temperature is beyond this
temperature range.
EN
Before using the dehumidifier, place the unit UPRIGHT for at least 1 hour before use to allow the
refrigerant to stabilize. If the unit was tilted on its side or upside-down during transportation, set
the unit upright for 4 hours before use.
For optimal efficiency, the dehumidifier must be operated in an enclosed area. Keep all doors,
windows and other outside entrances to the room closed.
•
•
SELECTING A LOCATION - IMPORTANT

7
Place the dehumidifier in an area where the temperature will not drop below 41°F (5°C)
Place the dehumidifier at least 17.7 inches (45 cm) away from other objects (e.g. curtains or
furniture) that may restrict airflow from the back or through the air vents of the unit.
The dehumidifier must be positioned on a level floor.
•
•
•
SELECTING A LOCATION - IMPORTANT (CONTINUED)
17.7 inches (45 cm)
17.7 inches (45 cm)
17.7 inches (45 cm)
IMPORTANT: The effectiveness of the dehumidifier can be influenced by different factors. One
factor is the rate at which new, moisture-laden air enters the room and the amount of air circulating
in and out of the area to be dehumidified. For example, if a door to a basement is constantly opened,
letting new, moisture-laden air into the room, dehumidification will take longer than if the door was
kept closed. If the dehumidifier is in a room with a storage closet or cabinets, it will have little or no
effect in drying the inside of the storage closet or cabinets unless there is adequate circulation of
air in and out of these spaces. To dehumidify these spaces, open the storage door or cabinet doors
to allow air circulation. You may find that installing a second dehumidifier may be required for larger
enclosed areas.
EN

8EN
UNPACKAGING THE DEHUMIDIFIER
There is a Foam Float inside the water tank that senses the
water level to automatically stop dehumidification when the
water tank is full. Make sure the Foam Float is positioned
correctly inside the water tank by ensuring it lies level with the
top edge of the water tank.
DO NOT REMOVE THIS FOAM FLOAT.
This Dehumidifier is packaged with a colored or transparent tape to secure some parts during
transportation. Remove the colored or transparent packaging tape from the unit.
1. Gently pull the water tank from out of the dehumidifier
2. Take out the power plug, drain hose and other accessories,
which is placed inside the tank of the dehumidifier.
3. Once all accessories have been removed. Make sure that the
tank is properly positioned.
Foam
Float
•
•

9
PARTS DESCRIPTION
8
7
4
5
1
2
6
3
12
11
9
10
13
1) Control Panel 8) Washable Dust Filter
2) Handle 9) Direct Drain Outlet
3) Foam Float 10) Direct Drain Cap
4) Water Tank 11) Cord Cable Tie
5) Water Level Indicator 12) Power Cord & Plug
6) Casters 13) Continuous Water Drain Tube
Inner Dia: 0.5 in (1.27cm);
Length: 3.28 ft (1 m)
7) Dehumidified Air Exhaust Vent
EN

10EN
USE & OPERATION
1) Filter Indicator light 8) Power Control
2) Timer Indicator Light 9) Mode Controls
3) Water Full Indicator Light - Laundry Mode
4) Humidity / Timer Set Controls - Dehumidifying Mode
5) Filter Alert - Comfort Mode
6) Timer Control - Continuous Mode
7) Display Screen
CONTROL PANEL
(3)(2)(1) (4)
(5) (6) (8)(7) (9)

11
DISPLAY SCREEN
When the unit is switched ON, the Display Screen shows the current humidity percentage and
previous mode setting.
MODE SETTING
Settings: Laundry Mode, Dehumidifying Mode, Comfort Mode & Continuous Mode.
The corresponding indicator light will illuminate to indicate the current mode setting.
Dehumidifying Mode
Press or to adjust your preferred humidity level. Set the desired humidity in % by pressing
button, it will increase in increments of 5%. The adjustable Relative Humidity (RH) range is between
30% RH to 90% RH. Two seconds after setting the preferred humidity setting, the display will revert
back to displaying the current humidity,
Dehumidifier maintains a balanced low speed for whole room dehumidification.
Adjust humidity level as desired (30%RH to 90%RH).
Laundry Mode
Adjust desired humidity level by pressing or as described in Dehumidifying Mode .
Dehumidifier runs on high for more powerful dehumidification intended for drying clothes. Hang wet
clothing in the same room as the dehumidifier, taking care not to allow wet clothes to be hung over
the dehumidifier or cause any water to drip onto the dehumidifier.
Close windows and doors for faster laundry drying.
FUNCTION BUTTONS
USE & OPERATION (CONTINUED)
EN
POWER CONTROL
Press to switch the dehumidifier ON or OFF.

12
Comfort Mode
Dehumidifier automatically adjusts dehumidification Relative Humidity (RH) percentage settings
based on ambient room temperature, for hassle-free operation.
When ambient room temperature is 18°C / 64°F or lower, the dehumidifier adjusts to 55% RH.
When ambient room temperature is between 18°C / 64°F and 25°C / 77°F, the dehumidifier adjusts
to 50% RH.
When ambient room temperature is 25°C / 77°F, or above, the dehumidifier adjusts to 45% RH.
Display Sleep Mode
The top display dims after 1 minute of button inactivity, and then turns off after 3 minutes of inactivity.
Display lights up again when any button is pressed. Mode indicator lights remain ON in display sleep
mode to indicate current settings.
Continuous Mode
The dehumidifier runs continuously with a target of 30%RH or below, on low speed setting. This
mode is used for rooms with more severe dampness and needs continuous dehumidification.
Desired humidity level cannot be adjusted in this mode and will need to be manually switched OFF,
unless unit stops due to a full water tank.
WATER TANK FULL ALERT
When the Water Tank is full, the indicator will be illuminated. The unit will beep for 3 seconds.
The compressor and fan will shut off at the same time. To switch off the indicator light, empty the
water tank and when replacing it ensure the tank is secured properly in place.
IMPORTANT: Do not place the Water Tank on the floor when full. In case of an uneven base which
may cause the tank to spillover.
FUNCTION BUTTONS (CONTINUED)
USE & OPERATION (CONTINUED)
EN

13
USE & OPERATION (CONTINUED)
EN
FILTER ALERT
When the Filter Alert Light is ON, it is time to clean the filter. Switch the unit OFF and carefully
remove the filter from the unit and clean. Replace the filter and switch ON the unit.
The Filter Alert Light should not be illuminated until the filter requires cleaning again. The frequency
of filter cleaning depends on room environment conditions. Some rooms may require changing more
frequently than others.
NOTE: To cancel the filter alert, simply press , and indicator light will disappear.
Auto-On Timer:
When unit is in Standby Mode, press , the timer indicator light will flash, press or to
select the number of hours (0.5-24 hours) until you want the unit to automatically start running. In
5 seconds without the operation, the Timer start function, the timer indicator light is illuminated.
You could decide the mode and adjust the humidity level that you preferred, then the unit will turn on
and continue running until the water tank is full (unless the unit is set up for continuous draining) or
until you switch it off manually. Timer must be set again after each use.
NOTE: To cancel any Timer settings, simply press again, and the timer indicator light will
disappear.
Auto-Off Timer:
While the unit is running, press , the timer indicator light will flash, press or to select
the number of hours (0.5-24 hours) you want the unit to run before it switches off. In 5 seconds
without the operation, the Timer start function, the timer indicator light is illuminated. Timer
must be set again after each use.
TIMER CONTROL
The dehumidifier can be set to automatically switch ON or OFF for a selected period of time (between
0.5-24 hour intervals). The Timer hours selection is displayed on the Display Screen.
NOTE: Before setting the Timer control, make sure there is power to the unit.

14
USE & OPERATION (CONTINUED)
AUTO RESTART FUNCTION
AUTOMATIC DEFROST
This unit is equipped with an Auto Restart feature. When there is a power outage, the dehumidifier
will automatically resume all its previous settings upon regaining power.
Frost may build up on the internal coils of the unit. When there is frost build up, the internal
compressor will turn off and the fan will continue to run until the frost has melted. Once the internal
coils have defrosted and dried, the compressor or fan will automatically restart and dehumidifying
will resume.
EN

15
The condensed water can be collected directly into the water tank. When the water tank is full, the
dehumidifier will automatically shut OFF and the indicator will illuminate on the control panel
followed by a beeping sound.
IMPORTANT: Do not move the dehumidifier when the Water Tank is full as it will be heavy and can
cause water spillage.
USE & OPERATION (CONTINUED)
EN
DRAINING THE WATER
WARNING: Always drain and discard water collected from dehumidification.
The water is not clean and cannot be used for drinking.
IMPORTANT: Improper alignment or positioning of the
water tank will cause the unit to pause operation, the
warning light on top of the dehumidifier will illuminate
followed by a beeping sound, until the water tank is fitted
properly.
NOTE: There is a Foam Float inside the water tank
that senses the water level to automatically stop
dehumidification when the water tank is full. Make sure
the Foam Float is positioned correctly inside the water
tank by ensuring it lies level with the top edge of the
water tank.
DO NOT REMOVE THIS FOAM FLOAT.
Locate the water tank at the front of the dehumidifier.
Gently pull the water tank out.
Carry the water tank to a sink to empty.
Replace the empty water tank back into the front of
the dehumidifier. Please make sure that the tank is
properly positioned. The safety feature ensures that
any misalignment of the tank and the unit will prevent
the unit from turning back on.
1. Draining water collected in the Water Tank
1.1
1.2
1.3
Foam Float
1.1
1.2

16
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)
EN
Locate the drain outlet at the back of the unit. Unscrew and remove the Direct Drain Cap.
Insert and screw the Continuous Water Drain Tube into the Direct Drain Outlet.
2.1
A continuous water drainage tube is included with this unit. To activate the continuous water draining
function, you will require a suitable water drain (e.g. sink or drain hole at floor level)
near the dehumidifier.
2. Continuous Water Drainage – Using a Continuous Water Drain Tube
Direct Drain Cap
Continuous
Water Drain Tube
Continuous Water
Drain Tube
3.28 ft. (1 m)
Continuous Water Drain Cap

17
If there are leaks, the Continuous Water Drain Tube and Cap may have loosened and may not be
connected properly. Disconnect, replace and tighten again.
Position the other end of the Continuous Water Drain Tube in the sink or drain. Make sure the
tube is not bent or kinked which might stop the water flow. Make sure the tube is secured over
the drain and will not fall out of place causing unwanted water spillage.
2.2
2.3
IMPORTANT: Make sure water can flow down the Continuous Water Drain Tube by keeping the tube
angled down and free of bends or kinks.
IMPORTANT: If the unit is placed on uneven ground, or the Drain Tube is installed incorrectly, the
water may fill the water tank and stop running. Please check whether the ground is uneven and
reinstall the Drain Tube.
EN
DRAINING THE WATER (CONTINUED)
USE & OPERATION (CONTINUED)

18
EN
CLEANING & MAINTENANCE
USE & OPERATION (CONTINUED)
Switch off and unplug the dehumidifier from the
electrical outlet.
Carefully pull out the dust filter from the
dehumidifier.
Rinse the dust filter under running water, or
vacuum away the dust with a vacuum cleaner.
After cleaning the dust filter, dry in a cool, shaded
place, then carefully reinstall into the unit.
1.
2.
3.
4.
WARNING: Always switch OFF the dehumidifier and unplug it from the electrical outlet before
attempting any cleaning or maintenance of this product.
Appliance Maintenance:
• Switch OFF the appliance before disconnecting the power supply.
• Only use a soft cloth to clean the appliance.
Dust Filter Maintenance:
The Dust Filter located at the back of the unit helps to remove dust particles from the air. A dirty filter
clogged by dust particles can reduce the efficiency of the dehumidifier. For optimum
dehumidification, it is recommended to clean the dust filter every 2 weeks:
End of Season Storage & Maintenance:
Switch OFF the unit and unplug from the electrical power outlet.
Empty the water tank and let it dry. If your dehumidifier is connected to the continuous drain
hose, you must disconnect the hose, dry and then replace the drain cap back into the drain outlet.
Remove the air filter and clean with water. Let the air filter dry and reinstall back into the unit.
Make sure all parts of the dehumidifier and accessories are dry before storage.
Cover the dehumidifier with a cloth/ plastic bag before storage, to protect the surface from dust
and scratches.
It is recommended to coil the power cord and store it off the floor to ensure it is protected from
bends and kinks.
Store the unit upright in a dry location, away from direct sunlight.
•
•
•
•
•
•
•
If the appliance will not be used for an extended period of time:

19
EN
TROUBLESHOOTING GUIDE
The following troubleshooting guide addresses the most common problems. If problems persist, call
customer service.
PROBLEM POSSIBLE CAUSE SOLUTION
Dehumidifier
does not start
No electricity. Check for power.
The power cord is not
properly plugged in. Remove and reconnect the power cord.
The safety switch
activated on the
electrical plug.
Reset the safety switch and wait for 3 minutes to
pass. Contact customer service if problem persists.
The water tank is not in
the correct position. Position the water tank correctly into the unit. Unit will not operate until the water tank is secure in place.
Unit runs but
the humidity
level does
not decrease
The humidity level setting
is too high. Decrease the humidity level setting.
A door or window is open,
letting in new moisture. Make sure all windows or doors to the outside are closed and tightly sealed.
There are other sources
of humidity in the room
(e.g. boiling water in pot).
Switch on the dehumidifier when these
sources are not present.
The temperature in the
room is too low.
The dehumidifier is designed to operate between
41°F (5°C) and 89°F (32°C). Moisture removal is
greatly reduced if room temperatures exceed this
temperature range.
The dust filter is dirty/
blocked. Clean the dust filter.
Air outlet or intake is
blocked. Remove blockage.
