Honeywell HPXD2 User manual

Performance Series Cameras
HPXD2 1080P HQA/TVI/AHD/CVBS
Pin-hole Camera
Quick Installation Guide
Thank you for purchasing a Honeywell Performance
Series HQA HPXD2 camera. Follow the instructions
in this guide to install and log in to your camera.
Warnings and Cautions
WARNING This device is configured for 12 VDC operation. Do not connect to a higher
voltage. Use only with NRTL-approved Class 2 power supplies.
Important Safeguards
•Read and keep these instructions.
•Confirm the installation surface can support at least three times the weight of the camera.
•Do not apply power to the camera before completing installation.
•Do not aim the camera toward a bright light source for extended periods to prevent damage to the
imager. Avoid operating the unit under or close to unstable light sources (may cause flickering), or
close to fluorescent lamps or objects reflecting light.
•Do not touch the camera lens.
•Do not drop the camera or subject it to physical shock.
•Do not use a strong or abrasive detergent when cleaning the camera.
•Avoid operating or storing the unit in extremely humid, dusty, hot/cold environments, where the
operating temperature is outside the recommended range of -22°F to 140°F (-30°C to 60°C).
Before You Begin
Before you begin, check that you have received all of the parts listed below. If any parts are missing or
damaged, contact your dealer immediately.
CAUTION Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
CAUTION THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICINGTO QUALIFIED SERVICE
PERSONNEL.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
•Camera •Analog exclusive combination cable
Mounting surface
Bracket
Mounting screws
Adjusting screw
Camera body
•Power pigtail

2700 Blankenbaker Pkwy, Suite 150
Louisville, KY, 40299, USA
www.honeywell.com/security
[phone]
(North America only)
Aston Fields Road, Whitehouse Industrial Estate
Runcorn, Cheshire, WA7 3DL, UK
www.honeywell.com/security/uk
[phone]
(Europe only)
35F Tower A, City Center, 100 Zunyi Road
Shanghai, 200051, China
www.asia.security.honeywell.com
[phone]
(Asia Pacific only)
Document 800-23998 – Rev A – 01/2018
© 2018 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell. The information in this publication is believed to be accurate in all respects. However, Honeywell cannot assume responsibility for any consequences
resulting from the use thereof. The information contained herein is subject to change without notice. Revisions or new editions to this publication may be issued to incorporate such changes.
Regulatory Statements
FCC Compliance
Information to the User: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Manufacturer’s Declaration of Conformance
Europe The manufacturer declares that the equipment supplied is compliant with the European Parliament and
Council Directive on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(2011/65/EU), General Product Safety Directive (2001/95/EC), and the essential requirements of the EMC directive
(2014/30/EU), conforming to the requirements of standards EN 55032 for emissions, EN 50130-4 for immunity, and
EN 60950-1 for electrical equipmentsafety.
WEEE (Waste Electrical and Electronic Equipment)
Correct disposal of this product (applicable in the European Union and other European countries with
separate collection systems). This product should be disposed of, at the end of its useful life, as per applicable
local laws, regulations, and procedures.
Mounting and Aiming the Camera
1. Install the camera together with the bracket on the mounting surface and secure the
installation screw firmly.
2. Connect the camera’s BNC connector to a coaxial cable.
3. Connect the camera’s power connector to a 12 VDC source.
4. Adjust the camera angle and tighten the locking screw.
Configuring the Camera
1. Connect the camera to a Honeywell Performance Series HQA DVR and log on as the admin user.
2. Right-click to display the shortcut menu, then click Camera
Menu. The Menu Operationwindow opens.
3. Click Enter to display the camera’s OSD menu.
4. To configure the camera, in the Menu Operation window,
click the up/down arrows to move through the menu list,
click the left/right arrows to change a menu setting, or click
Enter to enter a submenu () or execute a command.
5. After you have finished configuring the camera, scroll down
to Exit, and then click Enter to exit the OSD menu. Right-click to close the Menu Operationwindow.
Recommended Recorders
HRHQ104* 4-channel, 1 SATA, 720p@120fps, 1080p@60fps, alarm I/O
HRHQ108* 8-channel, 2 SATA, 720p@240fps, 1080p@120fps, alarm I/O
HRHQ116* 16-channel, 2 SATA, 720p@480fps, 1080p@240fps, alarm I/O
CAUTION The default resolution is 1080P in HQA. Use the OSD
menu to change definition and formats.
