Honeywell NEXH User manual

- 1 -
ENG
INSTALLATION GUIDE BOOK
NEXH Camera
Explosion proof Security Camera
(FIXED HD IPType)

- 2 -
Important Safety Instructions
ENG
1. Install and use this system after reading these instruction thoroughly.
2. Keep these instructions.
3. Install in accordance with the manufacture’s instruction.
4. Take care of all Cautions and Warnings.
5. Use stainless steel hardware to fasten the mount to outdoor surfaces.
6. Only use replacement parts recommended by the manufacturer.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER(OR BACK).
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PRERSONNEL
Explanationof Graphical Symbols.
This symbol is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient
magnitudeto constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important
operating and maintenance(Servicing)Instructions in the literature
accompanyingthe appliance.
TO REDUCE THE RISK OF IGNITION DO NOT OPEN WHEN AN EXPLOSIVE
GAS ATMOSPHERE MAY BE PRESENT
WARNING: To reduce the risk of ignition of hazardousatmospheres,conduit runs
must have a sealing fitting or cable gland connected within PT 3/4 inches of the
enclosure.
WARNING: To reduce the risk of ignition of Hazardous Atmospheres,
disconnectthe equipment from the supply circuit beforeopening.

- 3 -
Methods of Installation
Figure1.
Method of Installation
ENG
CameraHousing
only with Bracket
This system can be installed in a standard or inverted position or camera Housing only with
optionalbracket as below Figure1.
Wheninstalled for inverted operation,the origin of camera shall be reconfigured through the
Camera function.There is no need to be adjusted physically but sunshield bracket may not
be functionalat this case.
WARNING: Gross weight of this system is about 15kg. Use caution when lifting
and installing. It is recommended you to wear proper non-slip gloves be worn during
installation.

- 4 -
Install on the surface or on the wall with Mount bracket
To install this product, please refer to Figure2 and do the following steps.
1. Make sure the threads of the product and the threads of the supplied stainless steel bolts (Supplied) are
freeof dirt and debris.
2. Apply an amount of threadlocking compound(notsupplied) to the thread of the product and the thread of
the bolts.
3. Secure the product to the mountingsurface with the adjusted wrench and four stainless steel bolts and lock
washers. Tightenthe bolts to 150~300 kgf.cm(14Nm~29Nm)
Figure2.
Note : Figure2 shows the product being installed on a wall mount bracket which is an optional
product; NEXH-WL (not supplied) and if there is no need the wall mount bracket, just follow a
above step to install the product without wall mount bracket.
Methods of Installation
ENG

- 5 -
Methods of Installation
Figure3
Install Product to Mounting surface
PT 3/4 “-14
Seal Fitting
(Not Supplied)
Explosion proof
Flexible conduit
(Not Supplied)
PT 3/4”-14 Nipple
Fiber
Filler
Sealing
compou
nd
Cables
Sealing Method
PT 3/4”-14 Thread
To install this product, please refer to Figure3 and do the following steps.
1. Make sure the threads of the supplied three M10X30mm stainless steel bolts and flat/springwashers are free
of dirt and debris.
2. Apply an amount of threadlocking compound(notsupplied) to the thread of the product and the thread of the
bolts.
3. Make sure the seal fittings(notsupplied) and the threaded hole of this system are free of the dirt and particles.
4. Assemble nipple,the threaded hole of this system, seal fittingand flexibleconduit(notsupplied) to be fasten
firmlyand then the cables must be passed through the seal fitting,Nipple and flexibleconduit.
Plus, the sealing fitting,flexibleconduit, Nipple should be acquired ATEX/IECEx Certification.
Note : Figure3 shows the product being installed on a surface with pedestalmount.
ENG

- 6 -
Figure5.
Base Schematic of Installation
1. Figure5is recommendedfor the base Schematicof Installation.
2. If you wish to consist of another method or other components, you must proceed to do after
conferringwith a manufacture.
Base Schematic
ENG
Power
POWER
AC110 or 220V
BNC
MAIN MONITOR
DATA1 DATA2
+ - -+ + -
REAR
FRONT
KEYBOARD CONTROLLER
HTX-5000
REAR
DATA 2 D ATA1 DC 12V
RS 485
1 DOME 2
IN OUT DVR RS 232C
ALARM/DVR
DC 12V
SLAVE
RS 485 +
-
Pump-
Pump+
RS 485
DVR
Check Valve
Pump
Motor
+
-
Input Power DC 12~24V
+
GND
LAN
Local Network
External Network
Monitoring PC
Router
Monitoring PC
Internet
or
Intranet

- 7 -
Configuration of Wire Harness
Figure4
Cable configuration
Cable Configuration
ENG
2m ±0.3m
Wire Color Function Description
Brown
Sky Blue
Green
Power Input
(AC 110V ~ 230V)
L1
N
GND
LAN Cable Video & Network UTP
Power
LAN Cable
Configuration of Wire Harness

- 8 -
ENG
Key Feature and Introduction
The network camera supports the network service for a sensor image with progressive scan,
which can be monitored on a real-time screen regardless of distances and locations. By using its
dedicatedprogram, many users are able to have an access to the network camera at once or a
single user can monitor various network cameras at the same time. It also enables users to play,
store and retrieve a monitoring image by using a PC. All the settings and real-time monitoring
screens are also provided through an access to the web.
The network camera is fully featuredfor security surveillance and remote monitoring needs. It is
based on the DSP compression chip, and makes it available on the network as real-time, full
framerate Motion JPEG and H.264 video streams
The Highest level Ex Class : Ex d IIC T6 (IECEx, ATEX, CE, FCC, KC)
Corrosion resistant SUS 316 Construction
IP67 Protection
Built-in Wiperfunction
Integratedwith Waterjet : EXWJ400
Approx 15Kg of light weight

- 9 -
Key Feature and Introduction
•Brilliant video quality
The network camera offersthe highly efficientH.264 video compression, which drastically
reduces bandwidth and storage requirementswithout compromising image quality. Motion JPEG
is also supported for increased flexibility.
• Dual or Triple Streams
The network camera can deliver dual or triple video streams simultaneously at full frame rate in
all resolutions up to Full-HD (1920 x 1080p) using Motion H.264 and JPEG. This means that
several video streams can be configuredwith differentcompression formats, resolutions and
framerates for differentneeds.
• Image setting adjustment
The network camera also enables users to adjust image settings such as contrast, brightness
and saturation to improve images beforeencoding takes place.
• Intelligent video capabilities
The network camera includes intelligent capabilities such as VCA (Video Content Analysis). The
network camera’s external inputs and outputs can be connected to devices such as sensors and
relays, enabling the system to react to alarms and activate lights or open/close doors.
• Improved Security
The network camera logs all user access, and lists currently connectedusers. Also, its full frame
rate video can be provided over HTTPS.
• ONVIF Certificate
This is a global interface standard that makes it easier for end users, integrators, consultants,
and manufacturersto take advantageof the possibilities offeredby network video technology.
ONVIF enables interoperability between differentvendor products, increased flexibility, reduced
cost, and future-proofsystems.
• Micro-SD Recording support
The network camera also supports a Micro-SD memory slot forlocal recording with removable
storage.
• Audio support
The network camera also supports two-way audio.
ENG

- 10 -
Specifications
General Mechanical & Electrical
Models
Spec
NEXH3020HD-NET
Signal System
RJ45 (10/100 Base-T)
Ex. Class
Ex d IIC T6
Certifications
IECEx, ATEX, CE, FCC, KC
Front window
Fully tempered plate glass
Material
SUS 316
Protection Degree
IP 67
Input Voltage
100-230 V~, 50/60Hz
Power consumption
Max15W
Operating Temperature
-20°C ~ 60°C
Weight
Approx. 15 kg
ENG

- 11 -
Specifications
ENG
Model
NEXPTZ3020HD-Net
Lens
30x , 4.3mm ~ 129.0mm
Angle of View
65.1°(H) ~ 2.23°(H)
Image Sensor
Type
1/2.8” SONY STARVIS CMOS sensor
Pixels
1945 (H) x 1109 (V)
Min. Illumination
Color : 0.35 Lux @ 50IRE / BW : 0.013 Lux @ 50IRE
Scanning Mode
Progressive Scan
Wide Dynamic Range
True WDR
Day and Night Mode
True D/N (Auto, Day, Night)
Noise Reduction
2DNR, 3DNR
Digital Zoom
16x
Exposure Control
Auto, Manual, Shutter Priority, Iris Priority
White Balance Control
Auto, Manual, Incandescent, Fluorescent, Outdoor
Back Light Compensation
Yes
Image Effect
Flip (Digital)
Shutter Speed
25/30fps : Auto (1/30,000 ~ x8 sec.), Manual
50/60fps : Auto (1/50,000 ~ x8 sec.), Manual
VIDEO/AUDIO
Compression
H.264 (Baseline, Main, High Profile), MJPEG
Bitrate Control
CVBR, VBR
Resolution
1920x1080, 1280x1024, 1280x720/960, 704x480/576,
640x360/480, 320x240
Frame Rate
Max. 50fps/60fps
Streaming
50/60fps (Dual Stream : H.264 x 1, MJPEG x 1)
25/30fps (Triple Stream : H.264 x 2, MJPEG x 1)
SYSTEM
Video Contents Analysis
DIS, Defog, Face Detector, Tampering, Line Detector, Field
Detector
Motion Detection Area
16 Programmable Areas (Include Area 8, Exclude Area 8)
FTP Uploading
MJPEG
NETWORK
Protocols
TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, QoS, FTP, UPnP, RTP, RTSP,
RTCP, DHCP, ARP, Zeroconf, Bonjour
Client Software
Web, SmartManager, Client S/W, Mobile S/W
Max. User Connection
Live : 10 Users, Playback : 3 Users
API Support
Open API, ONVIF Compliance
Mobile Support
Android, i-OS
EXTERNAL IN/OUT
Video Composite Output
BNC Jack
Ethernet
RJ-45 (10/100Base-T)
u-SD Card
SDHC (Max. 32GB)
RS485/RS422
Yes
RESET Button
Tact Switch
ETC
Dimensions
61.7mm(W) x 60.4mm(H) x 126.7mm(D)
Camera Optical

- 12 -
Dimensions
Unit (mm)
ENG

- 13 -
Note: These MountingAccessories are not suppliedwith the NEXH Series units.
These are purchasing parts.
OptionalAccessories
ENG
MODEL NAME
1. NEXH-WL: Wall mount bracket designed to mount the NEXH Series Camera
directly to a load-bearing vertical surface. PAN TILTADJUST Bracket, Pan; 60°x4, Tilt;
-55°~+20°
2. NEXH-CN: Corner adapter Bracket for use with the NEXH-WLto mount the
NEXH Series Camera to the corner of a structure.
3. NEXH-PL: Pole adapter Bracket for use with the NEXH-WL to mount the
NEXH Series Camera to a vertical pole or itself to mount the NEXH Series to a
horizontal pole.
* Recommended pole diameter is Φ12cm to Φ25cm.
General
NEXH-WL NEXH-CN NEXH-PL
Material SUS304 Polished SUS304 Polished SUS304 Polished
Maximum Load 40kg 45kg 50kg
Unit Weight 3.5kg 4.8kg 4.5kg

- 14 -
NEXH-WL Unit (mm)
OptionalAccessories
ENG

ENG
