Honeywell Notifier ifs-2600 Technical document

IFS-2600

Fire Indicator Panel

TECHNICAL, PROGRAMMING

& INSTALLATION MANUAL

P/N 10069 ECN08-0066

8/05/08

Rev:

3.01

Installation Precautions

Adherence to the following will aid in

problem-free installation with long-term

reliability:

WARNING - Several different sources of power

can be connected to the fire alarm control

panel. Disconnect all sources of power before

servicing. Control unit and associated equipment

may be damaged by removing and/or inserting

cards, modules, or interconnecting cables while the

unit is energized. Do not attempt to install, service,

or operate this unit until manuals are read and

understood.

Verify that wire sizes are adequate for all

initiating and indicating device loops. Most devices

cannot tolerate more than a 10% I.R. drop from the

specified device voltage.

Like all solid state electronic devices, this

system may operate erratically or can be damaged

when subjected to lightning induced transients.

Although no system is completely immune from

lightning transients and interference, proper

grounding will reduce susceptibility. Overhead or

outside aerial wiring is not recommended, due to

an increased susceptibility to nearby lightning

strikes. Consult with the Technical Services

Department if any problems are anticipated or

encountered.

Disconnect AC power and batteries prior to

removing or inserting circuit boards. Failure to do

so can damage circuits.

Remove all electronic assemblies prior to any

drilling, filing, reaming, or punching of the

enclosure. When possible, make all cable entries

from the sides or rear. Before making

modifications, verify that they will not interfere with

battery, transformer, or printed circuit board

location.

Do not over tighten screw terminals. Over

tightening may damage threads, resulting in

reduced terminal contact pressure and difficulty

with screw terminal removal.

This system contains static-sensitive

components. Always ground yourself with a

proper wrist strap before handling any circuits so

that static charges are removed from the body.

Use static suppressive packaging to protect

electronic assemblies removed from the unit.

Follow the instructions in the installation,

operating, and programming manuals. These

instructions must be followed to avoid damage to

the control panel and associated equipment.

FACP operation and reliability depend upon proper

installation.

This equipment must be correctly programmed

and installed to suit the specific application.

Please ensure correct operational parameters are

set prior to commissioning. If further details on

programming options are required, please consult

the programming manual or contact our helpful

technical support personnel.

EMC WARNING:

This equipment may radiate radio frequency energy. It may also be affected by radio frequency energy and, if

not installed and operated in accordance with the manufacturers instructions, may cause interference to radio

communications. It has been tested and found to comply with the Class A radiated and conducted EMI

requirements of AS/NZ 3548:1995 (including Amendments 1 & 2) as well as the EMI susceptibility

requirements of Clause C3.5 in AS4428.0:1997.

Radio communication devices should not be used in the vicinity of fire panels or associated ancillary devices

and systems.

Documentation Feedback

Your feedback helps us keep our documentation up to date and accurate. If you have any comments or suggestions about

our printed manuals you can email us.

Please include the following information:

Product name and version number (if applicable)

Manual part number and revision (found on the front cover)

Page number

Brief description of the content you think should be improved or corrected

Your suggestion for how to correct/improve documentation

Send email messages to:

techpubs@notifier.com.au

Please note this email address is for documentation feedback only. If you have any technical issues, please contact

you nearest branch for technical support.

IFS-2600 Installation & Programming Manual Page 1

P/N 10069 ECN08-0066

TABLE OF CONTENTS

COMPATIBLE DETECTORS................................................................................................5

OVERVIEW...........................................................................................................................6

CAUTION ........................................................................................................................................................................... 6

SPECIFICATION...................................................................................................................7

APPROVALS...................................................................................................................................................................... 7

ENVIRONMENTAL LIMITS........................................................................................................................................... 7

POWER SUPPLY RATINGS AND SETTINGS ............................................................................................................. 9

INTERNAL 24 VDC (nom) 3.0A MAIN POWER SUPPLY .......................................................................................... 9

INTERNAL 27.3V DC 1.5A BATTERY CHARGER..................................................................................................... 9

Internal 5VDC 2A Power Supply ..................................................................................................................................... 9

EXTERNAL 27VDC POWER SUPPLY....................................................................................................................... 10

BATTERY TYPE AND CAPACITIES .......................................................................................................................... 10

TECHNICAL DESCRIPTION..............................................................................................11

GENERAL ........................................................................................................................................................................ 11

TRANSIENT SUPPRESSION......................................................................................................................................... 11

CURRENT CONSUMPTION ......................................................................................................................................... 11

AZF DESCRIPTION........................................................................................................................................................ 12

AZF SUPERVISORY CURRENT .................................................................................................................................. 12

OVERLOAD PROTECTION.......................................................................................................................................... 12

ZONE OVERLOAD SELF RESET ................................................................................................................................ 12

PRINTER OUTPUT......................................................................................................................................................... 13

CABLE CONNECTION.................................................................................................................................................. 13

PROGRAMMING BY COMPUTER............................................................................................................................. 13

ALIGNMENT AND ADJUSTMENT.....................................................................................14

PCB2006 POWER SUPPLY BOARD ............................................................................................................................ 14

INTERNAL 24VDC (nom) POWER SUPPLY.............................................................................................................. 14

INTERNAL 27.3 VDC BATTERY CHARGER............................................................................................................ 14

EXTERNAL 24VDC (nom) POWER SUPPLY (if fitted)............................................................................................. 14

Page 2 IFS-2600 Installation & Programming Manual

P/N 10069 ECN08-0066

PCB2005 TERMINATION BOARD...............................................................................................................................14

INTERNAL 5VDC POWER SUPPLY TP8...................................................................................................................14

POWER SUPPLY COMPARATOR REFERENCE VOLTAGE TP10 .........................................................................14

NON ADJUSTABLE TEST POINTS..............................................................................................................................14

ALARM THRESHOLD COMPARATOR TP7.............................................................................................................15

FAULT THRESHOLD COMPARATOR TP6 ..............................................................................................................15

CONFIGURATION JUMPERS......................................................................................................................................16

IFS2004 - JP3 DEFAULT .............................................................................................................................................16

IFS2004 - JP4 PROGRAM DISABLE ..........................................................................................................................16

IFS2004 - JP5 CPU RESET...........................................................................................................................................16

IFS2005 – JP2 DOOR HOLDER BYPASS...................................................................................................................16

IFS2006 – JP1 EXTERNAL PS MONITORING..........................................................................................................16

IFS804 - JP1-7 ZONE BOARD ADDRESSING...........................................................................................................16

PLACING INTO OPERATION............................................................................................17

EQUIPMENT AS FITTED..............................................................................................................................................17

INITIAL CHECKLIST....................................................................................................................................................17

POWER UP CHECKLIST...............................................................................................................................................18

FUNCTIONAL TESTING...............................................................................................................................................18

FAULT RECORD.............................................................................................................................................................19

INSTRUCTIONS TO OPERATORS....................................................................................20

INDICATORS...................................................................................................................................................................20

SUGGESTED ALARM PROCEDURE..........................................................................................................................21

OPERATOR INSTRUCTIONS.......................................................................................................................................21

FIREFIGHTER FUNCTIONS........................................................................................................................................21

GLOBAL FUNCTIONS.................................................................................................................................................22

ZONE FUNCTIONS.......................................................................................................................................................24

PROGRAMMING................................................................................................................27

GLOBAL OPTIONS.........................................................................................................................................................27

ZONE OPTIONS ..............................................................................................................................................................27

OUTPUT RELAY OPTIONS..........................................................................................................................................28

DEFAULT SETTINGS.....................................................................................................................................................28

PROGRAM MODE..........................................................................................................................................................29

PROGRAMMING MODE..............................................................................................................................................29

PROGRAMMING HIERARCHY..................................................................................................................................29

ZONES............................................................................................................................................................................29

RELAYS.........................................................................................................................................................................30

GLOBAL ........................................................................................................................................................................30

PRINT.............................................................................................................................................................................30

IFS-2600 Installation & Programming Manual Page 3

P/N 10069 ECN08-0066

MAIN MENU.................................................................................................................................................................... 30

EXIT PROGRAMMING MODE................................................................................................................................... 31

ZONE PROGRAMMING................................................................................................................................................ 31

SELECT ZONE #........................................................................................................................................................... 31

ZONE SELECTED......................................................................................................................................................... 31

ZONE TYPE .................................................................................................................................................................. 31

ZONE OUTPUT CONFIGURATION........................................................................................................................... 32

RELAY PROGRAMMING MODE................................................................................................................................ 32

SELECT RELAY # ........................................................................................................................................................ 32

RELAY SELECTED...................................................................................................................................................... 32

RELAY TYPE................................................................................................................................................................ 33

RELAY MAPPING........................................................................................................................................................ 33

GLOBAL PROGRAMMING.......................................................................................................................................... 33

ACF OUTPUT................................................................................................................................................................ 34

AVF................................................................................................................................................................................ 34

RELAY (GLOBAL RELAY UNITY MAP) .................................................................................................................. 34

PRINT PROGRAMMING DATA .................................................................................................................................. 35

TIME (DATE & TIME)................................................................................................................................................... 35

APPENDIX A ......................................................................................................................36

DESCRIPTION OF ALARM ZONE TYPES................................................................................................................ 36

LATCHING TYPE......................................................................................................................................................... 36

NON LATCHING TYPE ............................................................................................................................................... 36

TIME DELAY AZF........................................................................................................................................................ 37

APPENDIX B ......................................................................................................................38

ZONE OUTPUT CONFIGURATIONS.......................................................................................................................... 38

APPENDIX C ......................................................................................................................39

ALARM VERIFICATION FACILITY (AVF).............................................................................................................. 39

GLOBAL PROGRAMMABLE OPTIONS.................................................................................................................... 39

APPENDIX D ......................................................................................................................40

ANCILLARY TRIP (ACF).............................................................................................................................................. 40

GLOBAL PROGRAMMABLE OPTIONS.................................................................................................................... 40

APPENDIX E.......................................................................................................................41

RELAY OUTPUT MAPPING......................................................................................................................................... 41

AND MAPPING ............................................................................................................................................................... 41

OR MAPPING.................................................................................................................................................................. 41

FAULT MAPPING........................................................................................................................................................... 41

FAULT/ISOLATE MAPPING........................................................................................................................................ 42

ISOLATE MAPPING ...................................................................................................................................................... 42

Page 4 IFS-2600 Installation & Programming Manual

P/N 10069 ECN08-0066

APPENDIX F ......................................................................................................................43

GLOSSARY OF TERMS.................................................................................................................................................43

APPENDIX G......................................................................................................................44

SUMMARY OF TERMINATIONS AND CAUTIONS.................................................................................................44

MCP LOOP.....................................................................................................................................................................44

DETECTION ZONES....................................................................................................................................................44

RELAY OUTPUTS ........................................................................................................................................................44

BELL OUTPUTS ...........................................................................................................................................................44

ACF OUTPUTS..............................................................................................................................................................44

WARNING SYSTEM.....................................................................................................................................................44

DOOR HOLDER OUTPUTS.........................................................................................................................................44

AUXILIARY POWER & MIMIC POWER ...................................................................................................................44

MAF ISOL & TRANSPONDER 0V ..............................................................................................................................44

MIMIC DATA & CLOCK..............................................................................................................................................44

AC INPUT......................................................................................................................................................................44

BATTERY......................................................................................................................................................................45

DOOR HOLDER AC INPUT.........................................................................................................................................45

OUTPUT RELAYS........................................................................................................................................................45

APPENDIX H......................................................................................................................46

IFS-2600 PROGRAMMED OPTIONS...........................................................................................................................46

APPENDIX I........................................................................................................................53

TECHNICAL DRAWINGS.............................................................................................................................................53

MAIN KEYPAD AND DISPLAY..................................................................................................................................53

EXPANSION DISPLAY ................................................................................................................................................53

Block Connection Diagram.............................................................................................................................................54

System Sensor Conventional Detector Connection Diagram..........................................................................................54

System Sensor Conventional Detector Connection Diagram..........................................................................................55

Hochiki Conventional Detector Connection Diagram.....................................................................................................55

Hochiki Conventional Detector Connection Diagram.....................................................................................................56

Ancillary Connection Diagram........................................................................................................................................57

ASE Connection Diagram...............................................................................................................................................58

Auto Changeover Dual Sounder Connection Diagram....................................................................................................59

Auto Change Over Dual Sounder Connection Diagram..................................................................................................60

MIMIC Connection Diagram..........................................................................................................................................61

Single Fan Connection Diagram .....................................................................................................................................62

Dual Fan Connection Diagram........................................................................................................................................63

Exhaust Fan Connection Diagram...................................................................................................................................64

Supply Fan Connection Diagram....................................................................................................................................65

Smoke Spill Fan Connection Diagram............................................................................................................................66

10W EVAC Connection Diagram...................................................................................................................................67

10W EVAC Slave Connection Diagram.........................................................................................................................68

30W EVAC Connection Diagram...................................................................................................................................69

30W EVAC Slave Connection Diagram.........................................................................................................................70

50W EVAC Connection Diagram...................................................................................................................................71

50W EVAC Slave Connection Diagram.........................................................................................................................72

IFS-2600 Installation & Programming Manual Page 5

P/N 10069 ECN08-0066

COMPATIBLE DETECTORS

Make Model Type Model Number

System Sensor Thermal Type A 5451 AUS

System Sensor Thermal Type A 51A51

System Sensor Thermal Type B 4451 AUS

System Sensor Thermal Type B 51B51

System Sensor Thermal Type B Sealed 51B51S

System Sensor Thermal Type C 51C51

System Sensor Thermal Type D 51D51

System Sensor Smoke Photo-Optical 2151 AUS

System Sensor Smoke Photo-Optical 2151B AUS

System Sensor Smoke Ionisation 1151 AUS

System Sensor Thermal Type D 51D51

System Sensor Smoke Beam BEAM1224

System Sensor Smoke Duct DHP-100

Apollo Thermal Type A Series 60

Apollo Thermal Type B Series 60

Apollo Thermal Type C Series 60

Apollo Thermal Type D Series 60

Apollo Smoke Ionisation Series 60

Apollo Smoke Photo Optical Series 60

Hochiki Thermal Type A DCA-B-60R MkV

Hochiki Thermal Type A DCC-A

Hochiki Thermal Type A DCD-A

Hochiki Thermal Type B DFE-60B

Hochiki Thermal Type B DFJ-60B

Hochiki Thermal Type C DCA-B-90R Mk1

Hochiki Thermal Type C DCC-C

Hochiki Thermal Type C DCD-C

Hochiki Thermal Type D DFE-90D

Hochiki Thermal Type D FDJ-90D

Hochiki Thermal Cool Room Type B sealed DFG-60BLKJ

Hochiki Smoke Ionisation SIH-AM

Hochiki Smoke Ionisation SIJ-ASN

Hochiki Smoke Photo Optical SLK-A

Hochiki Smoke Photo Optical SLR-AS

Olsen Thermal Type A T56B-T6A

Olsen Thermal Type B T56B-T6B

Olsen Thermal Type C T56B-T6C

Olsen Thermal Type D T56B-T6D

Olsen Smoke Ionisation C24B

Olsen Smoke Photo Optical P24B

Panelect Thermal Type A PFS-A

Panelect Thermal Type B PFS-B

Panelect Thermal Type C PFS-C

Panelect Thermal Type D PFS-D

Panelect Smoke Ionisation PFS-I

Panelect Smoke Ionisation PFS-I , MkII

Panelect Smoke Photo Optical PFS-P

Panelect Smoke Photo Optical PFS-P, MkII

IEI VESDA E700, E70D CONTACT DEVICE

Please contact NOTIFIER INERTIA for any additional detectors.

Page 6 IFS-2600 Installation & Programming Manual

P/N 10069 ECN08-0066

OVERVIEW

IFS-2600 Fire Indicator Panel (FIP) is designed to provide simplicity to the end user. The FIP uses both a liquid crystal

display and conventional LED displays for fast and accurate display of system status and changing events.

A custom designed membrane keypad is used together with the liquid crystal display and LED indicators to provide fast,

efficient and simple modes of operation. The keypad also provides the required flexibility for the programming of the

many user configurable options of this FIP. The FIP can be configured on-site without the need of expensive

programmers or components.

A serial printer can also be connected if required. The printer can be used to output programming information for ease of

modification, for safekeeping and to assist in the commissioning of the installation.

IFS-2600 uses serial chain mimic outputs which significantly saves time and costs of cabling to mimic panels.

A door holder power supply (using optional transformer) is incorporated into the system for the release of smoke and fire

doors on alarm.

IFS-2600 is available in a standard 8-zone configuration and can be expandable to its fully expanded state as required.

The IFS-2600 in its fully expanded state can;

• Monitor 64 detection zones

• Control 64 optional "mapped" relay outputs

• Output to a serial printer

• Output serially to a mimic panel

• Control to door holders

• Interface as required to any Australian Fire Brigade

IFS-2600 has been designed to be functional, flexible and reliable whilst maintaining a user-friendly interface.

CAUTION

IFS-2600 FIP has been tested and approved to AS4428.1 and meets the requirements of AS1670 and AS1668 Parts 1 &

However, the equipment must be correctly programmed and installed to suit the specific application. Please ensure

correct operational parameters are set prior to commissioning. If further details on programming options are required,

please consult the programming manual or contact our helpful technical support personnel.

WARNING:

This equipment may radiate radio frequency energy. It may also be affected by radio frequency energy and, if

not installed and operated in accordance with the manufacturers instructions, may cause interference to radio

communications. It has been tested and found to comply with the Class A radiated and conducted EMI

requirements of AS/NZ 3548:1995 (including Amendments 1 & 2) as well as the EMI susceptibility

requirements of Clause C3.5 in AS4428.0:1997

CAUTION: Radio communication devices should not be used in the vicinity of fire panels or associated

ancillary devices and systems

IFS-2600 Installation & Programming Manual Page 7

P/N 10069 ECN08-0066

SPECIFICATION

Cabinet Zinc Sealed Steel 1.6mm

Powder Coated

Hinged Inner Door

Hinged Outer Door

Outside Dimensions 2608 (8 zones) 394mm H x 390mm W x 180mm D*

2624 (24 zones) 750mm H x 390mm W x 180mm D*

2600 (32 to 64 zones) 18U, 28U & 40U Cabinets

Battery Box

*Note: the depth quoted is including the door and break glass.

The internal cabinet depth not including he door and break glass

is 140mm.

AC Operational Voltage 240 VAC 50Hz + 10%

Internal Power Supplies Battery Charger 27.3 VDC 1.5AMP

Panel Supply 24 VDC(nom) 3.0AMP

Logic Supply 5 VDC 2.0AMP

Microprocessor 80C52

Memory Type Non-volatile E2ROM

Liquid Crystal Display 2 Lines x 16 Characters LED Backlit

Fuses F1: Panel Supply M205 5A

F2: Battery Charger M205 3A

F3: Battery Protection Polyfuse 3A

F4: External Supply M205 7A

F5: Door Holder M205 3A

F6: Aux Power Output M205 1A Slow Blow

F7: Bell M205 1A

F8: Warning System M205 1A

F9: ACF M205 1A

E.O.L Resistor On AZFs, monitored

outputs, Bells, Warning system, ACF 4K7 Ohms

APPROVALS

Australian Standard AS4428.1 1998

SSL Approval No AFP-1553

C-Tick Approval No. N1336

ENVIRONMENTAL LIMITS

-10 Deg. C to +55 Deg. C Dry heat.

+40 Deg. C @ 93% Relative Humidity.

Page 8 IFS-2600 Installation & Programming Manual

P/N 10069 ECN08-0066

SYSTEM EXPANSION

Zones Qty Hardware Required Product Code

8 1 Main Control Board PCB-2004
