MPS-950B Series
Non-Coded Manual Fire Alarm
Pull Stations
Conventional Initiating Devices
Canadian DN-60910:A
General
Notifier’s MPS-950B Series Pull Stations provide manual
fire reporting. The MPS-950B Series manual stations are
non-coded, normally-open contacts, manual initiating alarm
pull stations.
Features
• ULC Listed
• Durable extruded aluminum construction
• Attractive low-profile design
• Standard single-gang mounting
• Easy identification
• Converts to double action with optional kit (MPS-DALK)
• Two-stage option
• Key-switch available
Construction
The MPS-950 Series Pull Stations are constructed of curable
extruded aluminum and finished in red baked enamel. An
abrasion resistant label with large, raised letters provide
clear, legible, bilingual instructions to facilitate identification
and operation.
The rectangular, low-profile design blends with modern archi-
tectural decor. The manual pull stations consist of a pull-
down door and its support, both made of extruded aluminum,
and are designed for semi-flush mounting on a single-gang
box.
All MPS-950 pull stations can be easily converted from sin-
gle-action to double-action with the addition of the
MPS-DALK double-action kit.
Installation
The station mounts with two screws (supplied) to a standard
single-gang electrical box. It can also be mounted to a sur-
face box (NBS-950). The terminal block with screws allows
for quick and easy connections.
Operation
Pulling on the station’s handle will release the internal switch
to trigger the alarm detection circuit.
Resetting is accomplished by inserting a 1/8” screwdriver
from the front. The handle, once pulled, will remain open and
cannot be reset without using a screwdriver.
The MPS-950KB and the MPS-950KB-20C (two-stage ver-
sions) also provide a key switch which is accessible after the
handle has been pulled. Operation of the key switch, when
connected to a separate general alarm circuit, will initiate the
second stage of a two-stage alarm signaling system. A spe-
cial key is supplied with each unit.
The MPS Series of pull stations are also available with addi-
tional N.C. contacts. This optional contact will operate when
the handle has been pulled.
Specifications
PHYSICAL
Height: 4.5” (11.43 cm)
Width: 3.5” (8.9 cm)
Depth: 0.75” (1.9 cm)
ELECTRICAL
Switch rating all models:
1 A@ 30 VDC, 0.1 A @ 125 VAC
mounts to 2” x 4” x 2.25” outlet box.
Ordering Information
MPS-950B: Single-Stage Pull Station
MPS-950KB: Two-Stage Pull Station with keyswitch
MPS-950B-20C: Single-Stage Pull Station with additional
N.C. contact
MPS-950KB-20C: Two-Stage Pull Station with additional
N.C. contact; keyswitch
MPS-DALK: Double-Action Lever Kit (converts any of the
above).
NBS-950: Surface mount box
GL-004K: Break Glass Rods for MPS-950B Series
(pack of 10)
Agency Listings
ULC: S6919

NOTIFIER® is a registered trademark of Honeywell International Inc.
©2016 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
Page 2 of 2 — Canadian DN-60910:A • 6/6/2016
This document is not intended to be used for
installation purposes. We try to keep our
product information up-to-date and accurate.
We cannot cover all specific applications or
anticipate all requirements. All specifications are
subject to change without notice.
For more information, contact Notifier.
[phone]
10 Whitmore Road
Woodbridge, Ontario LZL 7Z4
www.notifier.com
Dimensions
Wiring Diagrams
Optional Double-
Action Lever Kit
(MPS-DALK)
Red Surface Backbox
(NBS-950)
3.56”
9.04 cm
4.56”
(11.58 cm)
2.06”
(5.23 cm)
Optional Break Glass Rod (GL-004K)
0.75”
(1.9 cm)
3.5”
(8.9 cm)
4.5”
(11.43 cm)
MPS-950B
MPS-950KB
MPS-950KB-20C MPS-950B-20C
from
previous
station
from
previous
station
to next
station or
EOL
to next station
or EOL
(MPS-950KB or
MPS-950KB-20C only)
from
previous
station
N.C. switch for
MPS-950KB-20C N.O. keyswitch for MPS-950KB
and MPS-950KB-20C
N.C. switch for
MPS-950B-20C
to next station
or EOL
N.O. switch N.O. switch
Wire as shown so that supervision of connections is maintained.
