Honeywell NOTIFIER NFS-320C User manual

DN-60085:J • 12/20/2013 — Page 1 of 6
NFS-320C
Intelligent Addressable
Fire Alarm System
Intelligent Fire Alarm Control Panels
Canadian DN-60085:J • A-15
General
The NFS-320C intelligent Fire Alarm Control Panel is part of
the ONYX® Series of Fire Alarm Controls from NOTIFIER.
In stand-alone or network configurations, ONYX Series prod-
ucts meet virtually every application requirement.
The NFS-320C’s modular design makes system planning eas-
ier. The panel can be configured with just a few devices for
small building applications, or networked with many devices to
protect a large campus or a high-rise office block. Simply add
additional peripheral equipment to suit the application. For
example, certain geographic regions such as Canada have
specific LED annunciation requirements. To provide up to 48
zones/points in the same cabinet, add an optional ACM Series
annunciator (sold separately).
Features
• Listed to Standard ULC-S527-99.
• Certified for seismic applications when used with the appro-
priate seismic mounting kit.
• Approved for Marine applications when used with listed
compatible equipment. See DN-60688.
• One isolated intelligent Digital Communications Loop (DCL)
Style 4, 6 or 7.
• Up to 159 detectors (any mix of ion, photo, thermal, or
multi-sensor) and 159 modules (Addressable pull station,
normally-open contact devices, two-wire smoke detectors,
notification, or relay). 318 devices maximum.
• Standard 80-character display.
• Network options:
–High-speed network for up to 200 nodes (NFS2-3030,
NFS2-640, NFS-320(C), NFS-320SYS, NCA-2, DVC-EM,
ONYXWorks, NFS-3030, NFS-640, and NCA).
–Standard network for up to 103 nodes (NFS2-3030,
NFS2-640, NFS-320(C), NFS-320SYS, NCA-2, DVC-EM,
ONYXWorks, NCS, NFS-3030, NFS-640, NCA, AFP-200,
AFP-300/400, AFP-1010, and AM2020). Up to 54 nodes
when DVC-EM is used in network paging.
• 6.0 A power supply with four Class A/B built-in Notification
Appliance Circuits (NAC). Selectable System Sensor, S, or
Gentex strobe synchronization.
• Built-in Alarm, Trouble, Security, and Supervisory relays.
• VeriFire® Tools online or offline programming utility. Upload/
Download, save, store, check, compare, and simulate panel
databases. Upgrade panel firmware.
• Autoprogramming and Walk Test reports.
• Optional universal 318-point DACT.
• 80-character remote annunciators (up to 32).
• EIA-485 annunciators, including custom graphics.
• Printer interface (80-column and 40-column printers).
• History file with 800-event capacity in nonvolatile memory,
plus separate 200-event alarm-only file.
• Alarm Verification selection per point, with automatic
counter.
• Presignal/Positive Alarm Sequence (PAS).
• Silence inhibit and Auto Silence timer options.
• March time / temporal / Canadian two-stage coding, 20 ppm
and temporal / strobe synchronization.
• Field-programmable on panel or on PC, with VeriFire Tools
program check, compare, simulate.
• Full QWERTY keypad.
• Battery charger supports 18 – 200 AH batteries.
• Non-alarm points for lower priority functions.
• Remote ACK/Signal Silence/System Reset/Drill via monitor
modules.
• Automatic time control functions, with holiday exceptions.
• Surface Mount Technology (SMT) electronics.
• Extensive, built-in transient protection.
• Powerful Boolean logic equations.
FLASHSCAN® INTELLIGENT FEATURES
• Polls up to 318 devices in less than two seconds.
• Activates up to 159 outputs in less than five seconds.
• Multicolor LEDs blink device address during Walk Test.
• Fully digital, high-precision protocol (U.S. Patent
5,539,389).
• Manual sensitivity adjustment — up to nine levels (see indi-
vidual device information for available settings).
• Pre-alarm ONYX intelligent sensing — up to nine levels.
• Day/Night automatic sensitivity adjustment.
• Sensitivity windows:
–Ion–0.5 to 2.5%/foot obscuration.
– Photo – 0.5 to 2.35%/foot obscuration.
– Laser (VIEW®) – 0.02 to 2.0%/foot obscuration.
– Acclimate Plus™ – 0.5 to 4.0%/foot obscuration.
– IntelliQuad – 1.0 to 4.0%/foot obscuration.
– IntelliQuad™ PLUS – 1.0 to 4.0%/foot obscuration
• Drift compensation (U.S. Patent 5,764,142).
NFS-320C

Page 2 of 6 — Canadian DN-60085:J • 12/20/2013
• Degraded mode: In the unlikely event that the FACP’s
microprocessor fails, FlashScan detectors revert to
degraded operation and can activate the NAC circuits and
alarm relay. Each of the four built-in panel circuits includes a
Disable/Enable switch for this feature.
• Multi-detector algorithm involves nearby detectors in alarm
decision (U.S. Patent 5,627,515).
• Automatic detector sensitivity testing (NFPA-72 compliant).
• Maintenance alert (two levels).
• Self-optimizing pre-alarm.
FSL-751A VIEW (VERY INTELLIGENT EARLY WARNING)
SMOKE DETECTION TECHNOLOGY
• Advanced ONYX intelligent sensing algorithms differentiate
between smoke and non-smoke signals (U.S. Patent
5,831,524).
• Addressable operation pinpoints the fire location.
• Early warning performance comparable to the best aspira-
tion systems at a fraction of the lifetime cost.
FAPT-851A ACCLIMATE PLUS
LOW-PROFILE INTELLIGENT MULTI-SENSOR
• Detector automatically adjusts sensitivity levels without
operator intervention or programming. Sensitivity increases
with heat.
• Microprocessor-based technology; combination photo and
thermal technology.
• Low-temperature warning signal at 40°F ± 5°F (4.44°C ±
2.77°C).
FSC-851 INTELLIQUAD
ADVANCED MULTI-CRITERIA DETECTOR
• Detects all four major elements of a fire (smoke, heat, CO,
and flame).
• Automatic drift compensation of smoke sensor and CO cell.
• High nuisance-alarm immunity.
FSA-8000A INTELLIGENT FAAST DETECTOR
• Connects directly to the SLC loop of compatible ONYX
series panels
• Provides five event thresholds that can be individually pro-
grammed with descriptive labels for control-by-event pro-
gramming; uses five detector addresses.
• Uses patented particle separator and field-replaceable filter
to remove contaminants.
• Advanced algorithms reject common nuisance conditions
FCO-851A INTELLIQUAD™ PLUS
ADVANCED MULTI-CRITERIA FIRE/CO DETECTOR
• Detects all four major elements of a fire.
• Separate signal for life-safety CO detection.
• Optional addressable sounder base for Temp-3 (fire) or
Temp-4(CO) tone.
• Automatic drift compensation of smoke sensor and CO cell.
• High nuisance-alarm immunity.
RELEASING FEATURES
• Ten independent hazards.
• Sophisticated cross-zone (three options).
• Delay timer and Discharge timers (adjustable).
• Abort (four options).
• Low-pressure CO2listed.
Sample
System
Options 7112blok-201311.wmf
SLC Intelligent Loop
DEVICES
FSC-851A IntelliQuad
FAPT-851A Acclimate PLUS
FSL-751A FlashScan VIEW
FSP-851A Photo
FSI-851A Ion
FST-851A Thermal
FSA-8000A
...etc.
NBG-12LX XP6A/10A I/O Modules
FMM-1 A
IDC
FDU-80
LCD2-80
Up to 32 remote displays
EIA-485
EIA-485
EIA-232
2048 annunciator/control points
Optional 318-point UDACT
Dual phone
lines to
Central
Station
ACM/AEM-24AT
LED Annunciator
LDM-32
Custom Graphics
ACM-8R
Relay Control
FCM-1A
NAC
FRM-1
Relay Contact
PRN Series Printer
NFS-320C

Canadian DN-60085:J • 12/20/2013 — Page 3 of 6
VOICE FEATURES
• Integrates with FirstCommand Series. See DN-60772.
Note: Only NFC-50/100 and NFC-LOC are approved for
Canadian applications.
HIGH-EFFICIENCY OFFLINE SWITCHING
3.0 A POWER SUPPLY (6.0 A IN ALARM)
•120VAC.
• Displays battery current/voltage on panel (with display).
FlashScan, Exclusive
World-Leading Detector Protocol
At the heart of the NFS-320C is a set of detection devices and
device protocol — FlashScan (U.S. Patent 5,539,389). FlashS-
can is an all-digital protocol that gives superior precision and
high noise immunity.
In addition to providing quick identification of an active input
device, this protocol can also activate many output devices in a
fraction of the time required by competitive protocols. This high
speed also allows the
NFS-320C to have the largest device per
loop capacity in the industry — 318 points — yet every input
and output device is sampled in less than two seconds. The
microprocessor-based FlashScan detectors have bicolor LEDs
that can be coded to provide diagnostic information, such as
device address during Walk Test.
ONYX Intelligent Sensing
Intelligent sensing is a set of software algorithms that provides
the
NFS-320C with industry-leading smoke detection capabil-
ity. These complex algorithms require many calculations on
each reading of each detector, and are made possible by the
high-speed microcomputer used by the
NFS-320C .
Drift Compensation and Smoothing: Drift compensation
allows the detector to retain its original ability to detect actual
smoke, and resist false alarms, even as dirt accumulates. It
reduces maintenance requirements by allowing the system to
automatically perform the periodic sensitivity measurements
required by NFPA 72. Smoothing filters are also provided by
software to remove transient noise signals, such as those
caused by electrical interference.
Maintenance Warnings: When the drift compensation per-
formed for a detector reaches a certain level, the performance
of the detector may be compromised, and special warnings
are given. There are three warning levels: (1) Low Chamber
value; (2) Maintenance Alert, indicative of dust accumulation
that is near but below the allowed limit; (3) Maintenance
Urgent, indicative of dust accumulation above the allowed limit.
Sensitivity Adjust: Nine sensitivity levels are provided for
alarm detection. These levels can be set manually, or can
change automatically between day and night. Nine levels of
pre-alarm sensitivity can also be selected, based on predeter-
mined levels of alarm. Pre-alarm operation can be latching or
self-restoring, and can be used to activate special control func-
tions.
Self-Optimizing Pre-Alarm: Each detector may be set for
“Self-Optimizing” pre-alarm. In this special mode, the detector
“learns” its normal environment, measuring the peak analog
readings over a long period of time, and setting the pre-alarm
level just above these normal peaks.
Cooperating Multi-Detector Sensing: A patented feature of
ONYX intelligent sensing is the ability of a smoke sensor to
consider readings from nearby sensors in making alarm or
pre-alarm decisions. Without statistical sacrifice in the ability to
resist false alarms, it allows a sensor to increase its sensitivity
to actual smoke by a factor of almost two to one.
Field Programming Options
Autoprogram is a timesaving feature. The FACP “learns” what
devices are physically connected and automatically loads
them in the program with default values for all parameters.
Requiring less than one minute to run, this routine allows the
user to have almost immediate fire protection in a new installa-
tion, even if only a portion of the detectors are installed.
Keypad Program Edit (with KDM-R2) The
NFS-320C , like all
NOTIFIER intelligent panels, has the exclusive feature of pro-
gram creation and editing capability from the front panel key-
pad, while continuing to provide fire protection. The
architecture of the
NFS-320C software is such that each point
entry carries its own program, including control-by-event links
to other points. This allows the program to be entered with
independent per-point segments, while the
NFS-320C simulta-
neously monitors other (already installed) points for alarm con-
ditions.
VeriFire® Tools is an offline programming and test utility that
can greatly reduce installation programming time, and
increase confidence in the site-specific software. It is Win-
dows®-based and provides technologically advanced capabili-
ties to aid the installer. The installer may create the entire
program for the
NFS-320C in the comfort of the office, test it,
store a backup file, then bring it to the site and download from
a laptop into the panel.
Placement of Equipment
in Chassis and Cabinet
The following guidelines outline the NFS-320C ’s flexible sys-
tem design.
Wiring: When designing the cabinet layout, consider separa-
tion of power-limited and non-power-limited wiring as dis-
cussed in the
NFS-320/C/E Installation Manual.
It is critical that all mounting holes of the NFS-320C are
secured with a screw or standoff to ensure continuity of Earth
Ground.
Networking: If networking two or more control panels, each
unit requires a Network Communication Module or High-
Speed Network Communication Module (HS-NCM can sup-
port two nodes; see “Networking Options” on page 5). These
modules can be installed in any option board position (see
manual), and additional option boards can be mounted in front
of them.
KDM-R2 Controls and Indicators
Program Keypad: QWERTY type (keyboard layout).
12 LED Indicators: Power; Fire Alarm; Pre-Alarm; Security;
Supervisory; System Trouble; Signals Silenced; Points Dis-
abled; Control Active; Abort; Pre-Discharge; Discharge.
Keypad Switch Controls: Acknowledge/Scroll Display; Signal
Silence; Drill; System Reset; Lamp Test.
LCD Display: 80 characters (2 x 40) with long-life LED back-
light.

Page 4 of 6 — Canadian DN-60085:J • 12/20/2013
Product Line Information
• “Configuration Guidelines” on page 4
• “Main System Components” on page 4
• “Networking Options” on page 5
• “Auxiliary Power Supplies and Batteries” on page 4
• “Audio Options” on page 4
• “Compatible Devices, EIA-232 Ports” on page 4
• “Compatible Devices, EIA-485 Ports” on page 4
• “Compatible Intelligent Devices” on page 4
• “Enclosures, Chassis, and Dress Plates” on page 5
• “Other Options” on page 5
CONFIGURATION GUIDELINES
The NFS-320C system ships assembled; description and
some options follow. See “Enclosures, Chassis, and Dress
Plates” on page 5 for information about mounting peripherals.
NOTE: Stand-alone and network systems require a main display.
On stand-alone systems, the panel’s keypad provides the required
display. On network systems (two or more networked fire panel
nodes), at least one NCA-2, NCS, or ONYXWorks annunciation
device is required. For NCA-2, see DN-7047.)
MAIN SYSTEM COMPONENTS
NFS-320C: The standard, factory-assembled NFS-320C sys-
tem includes the following components: one control panel
mounted on chassis (120 V operation — ships with grounding
cable, battery interconnect cables, and document kit); one
integral power supply mounted to the control panel; one pri-
mary display KDM-R2 keypad/display; and one cabinet for sur-
face or semi-flush mounting. Purchase batteries separately.
One or two option boards may be mounted to the NFS-320
cabinet, with one visible to the left of the display and one
inside; additional option boards can be used in remote cabi-
nets. See Canadian applications manual addendum 52747.
NFS-320CR: Same as
NFS-320C but in red enclosure.
NFS-320C-FR: Same as
NFS-320C but in French language.
TR-320: Trim ring for the NFS-320C cabinet.
AUXILIARY POWER SUPPLIES AND BATTERIES
ACPS-610: 6.0 A or 10.0 A addressable charging power sup-
ply. See DN-60244.
FCPS-24S6C/8C: Remote 6 A and 8 A power supplies. See
DN-6297. For use only as a NAC expander.
BAT Series: Batteries. NFS-320 uses two 12 volt, 18 to 200
AH batteries. See DN-6933.
AUDIO OPTIONS
NFC-50/100: 25 watt, 25 VRMS, emergency Voice Evacuation
Control Panel (VECP) with integral commercial microphone,
digital message generator, and Class A or Class B speaker cir-
cuits. See DN-60772.
COMPATIBLE DEVICES, EIA-232 PORTS
PRN-6: 80-column printer. See DN-6956.
VS4095/5: Keltron printer, 40-column, 24 V. Mounted in exter-
nal backbox. See DN-3260. (Not ULC-listed.)
DPI-232: Direct Panel Interface, specialized modem for
extending serial data links to remotely located FACPs and/or
peripherals; mount on NFS-320 chassis. See DN-6870.
COMPATIBLE DEVICES, EIA-485 PORTS
ACM-24AT: ONYX Series ACS annunciator – up to 96 points
of annunciation with Alarm or Active LED, Trouble LED, and
switch per circuit. Active/Alarm LEDs can be programmed (by
powered-up switch selection) by point to be red, green, or yel-
low; the Trouble LED is always yellow. See DN-6862.
AEM-24AT: Same LED and switch capabilities as ACM-24AT,
expands the ACM-24AT to 48, 72, or 96 points. See DN-6862.
ACM-48A: ONYX Series ACS annunciator – up to 96 points of
annunciation with Alarm or Active LED per circuit. Active/
Alarm LEDs can be programmed (by powered-up switch selec-
tion) in groups of 24 to be red, green, or yellow. Expandable to
96 points with one AEM-48A. See DN-6862.
AEM-48A: Same LED capabilities as ACM-48A, expands the
ACM-48A to 96 points. See DN-6862.
ACM-8R: Remote Relay Module with eight Form-C contacts.
Can be located up to 6,000 ft. (1828.8 m) from panel on four
wires. See DN-3558.
LCD-80: ACS mode. 80-character, backlit LCD display.
Mounts up to 6,000 ft. (1828.8 m) from panel. Up to 32 per
FACP. See LCD-80/LCD-80TM (DN-3198).
FDU-80: Terminal mode. 80-character, backlit LCD display.
Mounts up to 6,000 ft. (1828.8 m) from panel. Up to 32 per
FACP. Not for use as a primary display in Canada. See FDU-
80 (DN-6820).
LCD2-80: Terminal and ACS mode. 80-character, backlit LCD
display. Mounts up to 6,000 ft. (1828.8 m) from panel. Up to 32
per FACP. Not for use as primary display in Canadian applica-
tions. See DN-60548.
LDM: Lamp Driver Modules LDM-32, LDM-E32, and LDM-
R32; remote custom driver modules. See DN-0551.
SCS: Smoke control stations SCS-8, SCE-8, with lamp drivers
SCS-8L, SCE-8L; eight (expandable to 16) circuits (HVAC
only). See DN-4818.
TM-4: Transmitter Module. Includes three reverse-polarity cir-
cuits and one municipal box circuit; mount on NFS-320C chas-
sis or remotely. See DN-6860.
UDACT-2: Universal Digital Alarm Communicator Transmitter,
636 channel. See DN-60686.
UZC-256: Programmable Universal Zone Coder provides pos-
itive non-interfering successive zone coding. Microprocessor-
controlled, field-programmable from IBM®-compatible PCs
(requires optional programming kit). Mounts in BB-UZC or
other compatible chassis (purchased separately). See DN-
3404.
COMPATIBLE INTELLIGENT DEVICES
FSA-8000A: Intelligent FAAST Fire Alarm Aspiration Sensing
Technology®. Intelligent aspirating smoke detector with ULC
listing. See DN-60792.
FSB-200A: Intelligent beam smoke detector. See DN-6985.
FSB-200SA: Intelligent beam smoke detector with integral
sensitivity test. See DN-6895.
FSC-851A: FlashScan IntelliQuad Advanced Multi-Criteria
Detector. See DN-60412.
FCO-851A: FlashScan IntelliQuad PLUS Advanced Multi-Cri-
teria Fire/CO Detector. See DN-60689.
FSI-851A: Low-profile FlashScan ionization detector. See DN-
6934.
FSP-851A: Low-profile FlashScan photoelectric detector. See
DN-6935.
FSP-851TA: Low-profile FlashScan photoelectric detector with
135°F (57°C) thermal. See DN-6935.
FSP-851RA: Remote-test capable photoelectric detector for
use with DNR(W) duct detector housings. See DN-6935.

Canadian DN-60085:J • 12/20/2013 — Page 5 of 6
FST-851A: FlashScan thermal detector 135°F (57°C). See
DN-6936.
FST-851RA: FlashScan thermal detector 135°F (57°C) with
rate-of-rise. See DN-6936.
FST-851HA: FlashScan 190°F (88°C) high-temperature ther-
mal detector. See DN-6936.
FAPT-851A: FlashScan Acclimate Plus low-profile multi-sen-
sor detector. See DN-6937.
FSL-751A: FlashScan VIEW laser photo detector. See DN-
6886.
DNR: InnovairFlex low-flow non-relay duct-detector housing
(order FSP-851A/FSP-851RA separately). Replaces FSD-
751PL/FSD-751RPL. See DN-60429.
DNRW: Same as above with NEMA-4 rating, watertight. See
DN-60429.
B224RBA: Low-profile relay base. See DN-60054.
B224BIA: Isolator base for low-profile detectors. See DN-
60054.
B210LPA: Low-profile base. Standard U.S. style. Replaces
B710LPA. See DN-60054.
B501A: European-style, 4" (10.16 cm) base. See DN-60054.
B200SA: Intelligent programmable sounder base, capable of
producing a variety of tone patterns including ANSI Temporal
3. Compatible with sychronization protocol. See DN-60054.
B200SCOA: Based on B200SA, with added CO detector
markings in English/French.
B200SRA: Sounder base, Temporal 3 or Continuous tone.
See DN-60054.
FMM-1A: FlashScan monitor module. See DN-6720.
FDM-1A: FlashScan dual monitor module. See DN-6720.
FZM-1A: FlashScan two-wire detector monitor module. See
DN-6720.
FMM-101A: FlashScan miniature monitor module. See DN-
6720.
FCM-1A: FlashScan control module. See DN-6724.
FCM-1-RELA: FlashScan releasing control module. See DN-
60390.
FRM-1A: FlashScan relay module. See DN-6724.
FDRM-1A: FlashScan dual monitor/dual relay module. See
DN-60709.
NBG-12LX: Manual pull station, addressable. See DN-6726.
N-MPS series: Manual pull stations, addressable and conven-
tional. For use in Canada only. See DN-5497.
FM-955: Addressable pull station with two FMM-101A mod-
ules.
FM-9551: Addressable pull station with one FMM-101A mod-
ule.
FM-955-20C: Addressable pull station with two open contacts.
FM-9551S20C: Addressable pull station with one open and
one closed extra contacts.
ISO-XA: Isolator module. See DN-2243.
XP6-CA: FlashScan six-circuit supervised control module.
See DN-6924.
XP6-MAA: FlashScan six-zone interface module; connects
intelligent alarm system to two-wire conventional detection
zone. See DN-6925.
XP6-RA: FlashScan six-relay (Form-C) control module. See
DN-6926.
XP10-MA: FlashScan ten-input monitor module. See DN-
6923.
SLC-IM: SLC integration module, for VESDAnet detectors.
See DN-60755\
NETWORKING OPTIONS
NCM-W, NCM-F: Standard Network Communications Mod-
ules. Wire and multi-mode fiber versions available. See DN-
6861.
HS-NCM-W/MF/SF/WMF/WSF/MFSF: High-speed Network
Communications Modules that can connect to two nodes.
Wire, single-mode fiber, multi-mode fiber, and media conver-
sion models are available. See DN-60454.
RPT-W, RPT-F, RPT-WF: Standard-network repeater board
with wire connection (RPT-W), multi-mode fiber connection
(RPT-F), or allowing a change in media type between wire and
fiber (RPT-WF). Not used with high-speed networks. See DN-
6971.
ONYXWorks: UL-listed graphics PC workstation, software,
and computer hardware. See DN-7048 for specific part num-
bers.
NFN-GW-EM-3: NFN Gateway, embedded. See DN-60499.
NWS-3: NOTI•FIRE•NET™ Web Server. See DN-6928.
CAP-GW: Common Alerting Protocol Gateway. See DN-
60576.
VESDA-HLI-GW: VESDAnet high-level interface gateway. See
DN-60753.
LEDSIGN-GW: UL-listed sign gateway. Interfaces with classic
and high-speed NOTI•FIRE•NET networks through the NFN
Gateway. See DN-60679.
OAX2-24V: UL-listed LED sign, used with LEDSIGN-GW. See
DN-60679.
ENCLOSURES, CHASSIS, AND DRESS PLATES
CAB-BM Marine System: Protects equipment in shipboard
and waterfront applications. Also order BB-MB for systems
using 100 AH batteries. For a full list of required and optional
equipment, see DN-60688.
NFS-LBB: Battery Box (required for batteries over 26 AH).
NFS-LBBR: Same as above, but red.
BB-UZC: Backbox for housing the UZC-256. Required for
NFS-320 applications, black. For red, order BB-UZC-R.
SEISKIT-320/B26: Seismic mounting kit. Required for seismic-
certified applications with NFS-320C and BB-26. Includes bat-
tery bracket for two 26 AH batteries.
SEISKIT-LBB: Seismic kit for the NFS-LBB. Includes battery
bracket for two 55 AH batteries.
OTHER OPTIONS
411 Series: Slave Digital Alarm Communicator Transmitters.
See DN-6619.
IPGSM-4GC: Internet and Digital Cellular Fire Alarm Commu-
nicator. Provides selectable configurable paths: cellular only,
IP only, or IP primary with cellular backup. Connects to the pri-
mary and secondary ports of a DACT. See DH-60769.
NFS-320-RB: Replacement board with central processing unit
NOTE: Keypad must be removed before shipping old unit out
for repair.
NFS-320-RBC-FR: Replacement board with central process-
ing unit, Canadian French. NOTE: Keypad must be removed
before shipping old unit out for repair.
NOTE: For other options including compatibility with retrofit equip-
ment, refer to the panel's installation manual, the SLC manual (for

NOTI•FIRE•NET™, IntelliQuad™, and ONYXWorks™ are trademarks; and
Acclimate® Plus™, FirstCommand®, FlashScan®, NOTIFIER®, ONYX®,
VeriFire®, and VIEW® are registered trademarks of Honeywell International
Inc. Microsoft® and Windows® are registered trademarks of Microsoft
Corporation. IBM® is a registered trademark of IBM Corporation.
©2013 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
Page 6 of 6 — Canadian DN-60085:J • 12/20/2013
This document is not intended to be used for
installation purposes. We try to keep our
product information up-to-date and accurate.
We cannot cover all specific applications or
anticipate all requirements. All specifications are
subject to change without notice.
For more information, contact Notifier.
[phone]
10 Whitmore Road
Woodbridge, Ontario LZL 7Z4
www.notifier.com
intelligent DCL equipment), and the Device Compatibility Docu-
ment.
System Specifications
SYSTEM CAPACITY
• Intelligent Digital Communications Loop (DCL) ................. 1
• Intelligent detectors ....................................................... 159
• Addressable monitor/control modules ............................ 159
• Programmable internal hardware and output circuits ........4
• Programmable software zones ......................................... 99
• Special programming zones ............................................. 14
• LCD annunciators per FACP ............................................ 32
• ACS annunciators per FACP ........ 32 addresses x 64 points
SPECIFICATIONS
•Primaryinputpower:120 VAC, 50/60 Hz, 5.0 A.
• Current draw (standby/alarm):
–NFS-320C board: 0.250 A. Add 0.035 A for each NAC in
use.
–KDM-R2 (Backlight on): 0.100 A.
• Total output 24 V power: 6.0 A in alarm.
NOTE: The power supply has a total of 6.0 A of available power.
This is shared by all internal circuits.
• Standard notification circuits (4): 1.5 A each.
• Resettable regulated 24V power: 1.25 A.
• Two non-resettable regulated 24V power outputs. One at
1.25 A and the other at 0.50 A.
• Non-resettable 5V power: 0.15 A.
• Battery charger range: 18 AH – 200 AH. Use separate cab-
inet for batteries over 26 AH.
• Float rate: 27.6 V.
CABINET SPECIFICATIONS
• NFS-320C cabinet dimensions:
–Backbox: 18.12 in. (46.025 cm) width; 18.12 in. (46.025
cm) height; 5.81 in. (14.76 cm) depth.
–Door: 18.187 in. (46.195 cm) width; 18.40 in. (46.736 cm)
height; 0.75 in. (1.905 cm) depth.
When using trim ring TR-320, mount backbox with at least 1
inch (2.54 cm) between wall surface and front of backbox, to
allow door to open fully past the trim ring. The TR-320 molding
width is 0.905 in. (2.299 cm).
SHIPPING WEIGHT
–NFS-320C: 37 lb (16.78 kg) without batteries.
TEMPERATURE AND HUMIDITY RANGES
This system meets NFPA requirements for operation at 0 –
49°C and at a relative humidity 93% ± 2% RH (noncondens-
ing) at 32°C ± 2°C. However, the useful life of the system's
standby batteries and the electronic components may be
adversely affected by extreme temperature ranges and humid-
ity. Therefore, it is recommended that this system and its
peripherals be installed in an environment with a normal room
temperature of 15 – 27°C.
AGENCY LISTINGS AND APPROVALS
The listings and approvals below apply to the basic NFS-320C
control panel. In some cases, certain modules may not be
listed by certain approval agencies, or listing may be in pro-
cess. Consult factory for latest listing status.
•UL/ULC Listed: S635 (UOJC).
• FM Approved.
•CSFM: 7165-0028:0243.
•FDNY: COA#6085, #6121.
Marine Applications: Marine approved systems must be con-
figured using components itemized in this document. (See
Main System Components, in “Product Line Information.) Spe-
cific connections and requirements for those components are
described in the installation document, PN 54756. When these
requirements are followed, systems are approved by the fol-
lowing agencies:
•US Coast Guard: 161.002/50/0, 161.002/55/0 (Standard
46 CFR and 161.002).
•Lloyd's Register: 11/600013 (ENV 3 category).
• American Bureau of Shipping.
NOTE: For information on marine applications, see DN-60688.
STANDARDS
The NFS-320C complies with the following ULC Standards
and NFPA 72, International Building Code (IBC), and Califor-
nia Building Code (CBC) Fire Alarm Systems requirements:
• ULC-S527-99.
•LOCAL (Automatic, Manual, Waterflow and Sprinkler
Supervisory).
•AUXILIARY (Automatic, Manual and Waterflow) (requires
TM-4).
•REMOTE STATION (Automatic, Manual, Waterflow and
Sprinkler Supervisory) (requires TM-4).
•PROPRIETARY (Automatic, Manual, Waterflow and Sprin-
kler Supervisory). Not applicable for FM.
•CENTRAL STATION (Automatic, Manual, Waterflow and
Sprinkler Supervisory) (requires DACT).
•EMERGENCY VOICE/ALARM.
•IBC 2012, IBC 2009, IBC 2006, IBC 2003, IBC 2000 (Seis-
mic).
•CBC 2007 (Seismic).
