Honeywell 720P User manual

Document 800-14747 Rev. A
Honeywell
720P&D1
IR Vari-Focal Bullet Camera
User’s Manual

Honeywell
i
Owner's Record
The model and serial numbers are located at the bottom of device. Record these numbers in
the spaces provided below. Refer to these numbers whenever you call upon your dealer
regarding this product.
Model No. ____________________
Serial No. ____________________
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to
qualified personnel only.
Notice: The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For Customers in the U.S.A
This equipment has been tested and found to comply with the limits for a digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual
could void your authority to operate this equipment.
The shielded interface cable recommended in this manual must be used with this equipment
in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC
Rules.

Honeywell
ii
Declaration of Conformity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void user’s authority
to operate the device.
NOTICE TO USERS
© 2006~12 All rights reserved. This manual or the software described herein, in whole or in
part, may not be reproduced, translated or reduced to any machine readable form without
prior written approval.
WE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE OR
SUCH OTHER INFORMATION. IN NO EVENT SHALL WE BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR THE
USE THEREOF.
We reserve the right to make any modification to this manual or the information contained
herein at any time without notice. The software described herein may also be governed by
the terms of a separate user license agreement.

Honeywell
i
Contents
1. Overview.................................................................................................................................... 1
Introduction ................................................................................................................................. 1
Features ..................................................................................................................................... 1
Minimum System Requirements.................................................................................................. 2
2. Package Contents ..................................................................................................................... 3
3. Connections .............................................................................................................................. 4
4. Hardware Installation ................................................................................................................ 7
5. How to adjust zoom/focus of lens ............................................................................................ 8
6. Preparation................................................................................................................................ 9
Search and Set up by IP Wizard.................................................................................................. 9
Search.................................................................................................................................. 9
View ................................................................................................................................... 10
LAN .................................................................................................................................... 11
Wireless ............................................................................................................................. 12
UPnP of Windows® XP, Vista or 7 ............................................................................................ 12
Install the Device behind a NAT Router ..................................................................................... 13
Access the device from the Internet Explorer for the first time.................................................... 14
Logging in as an Viewer ............................................................................................................ 15
Logging in as an Administrator .................................................................................................. 15
7. Operating the Network Camera .............................................................................................. 16
Monitor Image Section .............................................................................................................. 16
Video Profile ............................................................................................................................. 17
Streaming Protocol ................................................................................................................... 17
Language.................................................................................................................................. 17
2-Way Audio ............................................................................................................................. 17
Full Screen ............................................................................................................................... 17
PTZ Control .............................................................................................................................. 18
ActiveX Control ......................................................................................................................... 19
Digital Zoom ....................................................................................................................... 19
Snapshot ............................................................................................................................ 20
Record................................................................................................................................ 20
Volume ............................................................................................................................... 21
About.................................................................................................................................. 21
8. Administrating the Device ...................................................................................................... 22

Honeywell
ii
System Setting.......................................................................................................................... 22
Network: Configure Network settings .................................................................................. 22
Camera: Adjust Camera parameters ................................................................................... 33
System: Configure and maintain system ............................................................................. 39
Video: Configure OSD, Overlay, Profile, and ROI................................................................ 43
Audio: Audio parameters..................................................................................................... 48
User: Manage user name, password and login privilege...................................................... 48
E-Mail: Setup E-Mail configuration ...................................................................................... 51
Event Detection: ................................................................................................................. 52
Storage: Status and configuration of SAMBA Server ........................................................... 54
SAMBA Server.......................................................................................................................... 54
Continuous Recording: ....................................................................................................... 55
Recording List: Files list inside the SAMBA server............................................................... 56
Continuous Recording List ........................................................................................................ 56
Event Server: Setup FTP/TCP/HTTP/SAMBA server configuration...................................... 57
FTP Server ............................................................................................................................... 57
TCP Server ............................................................................................................................... 58
HTTP Server............................................................................................................................. 59
SAMBA Server.......................................................................................................................... 61
Event Schedule: Configure the event schedule ................................................................... 62
Setting ...................................................................................................................................... 62
Record...................................................................................................................................... 65
Port Status................................................................................................................................ 65
9. Appendix A: Alarm I/O Connector.......................................................................................... 67
10. Appendix B: Troubleshooting & Frequently Asked Questions............................................. 69
11. Appendix C: PING IP Address ................................................................................................ 73
12. Appendix D: Bandwidth Estimation ....................................................................................... 74
13. Appendix E: Specifications .................................................................................................... 75
14. Appendix F: Configure Port Forwarding Manually ................................................................ 78
15. Appendix G: Power Line Frequency ...................................................................................... 81

Honeywell
1
1. Overview
The user’s guide explains how to operate this camera from a computer. User should read
this manual completely and carefully before you operate the device.
Introduction
This camera is an inexpensive and fully scalable surveillance device. Because the Network
Cameras can be plugged into your existing local area network (LAN), you will potentially
save thousands of dollars from unnecessary cabling.
The device is accessible via the LAN or Internet connection. Connect your device directly to
a local area network or xDSL modem, and with web browser you get instant, on demand
video streams. Within minutes you can set up the device to capture a video sequence to a
PC. The live video can be uploaded to a website for the world to see.
Features
Sony Exmor™ image sensor
720P : 720p / 1.3 Mega mode ; SVGA/D1 : 800x600 / D1 mode
720P : 60fps in all resolutions ; SVGA/D1: 30fps in all resolution
ONVIF compliant
Camera tampering and audio detection
Gigabit 1000Base-T Ethernet
Weather-proof enclosure
24pcs IR LED, over 20m IR distance
Day and night function with ICR
Easy installation with setup wizard (IP Wizard II)

Overview
2
UPnP device discovery and NAT router transversal for easy installation
Dynamic IP Service, DIPS®, to search your IP camera from Internet easily
H.264, MPEG4 and MJPEG triple compression simultaneously
12-profile encoder simultaneously
UDP / TCP / HTTP / HTTPS protocols selectable
Event and Continuous recording to SD card or SAMBA server
External microphone input
Audio line out
Two-way audio
Composited video out
Intelligent motion detection up to 10 zones
Voice alerting while event triggered
Privacy masks
3D noise reduction to improve picture quality at low lux.
Digital WDR to provide clear images even under back light circumstances
Image transmission using an FTP or e-mail for event
Digital sensor input and alarm output
RS485 interface for P/T scanner control
Multi-channel control software for surveillance application
IEEE 802.3af PoE support (for IP camera and IR LED board only)
Minimum System Requirements
Microsoft Internet Explorer 8.0 or later
Microsoft Media Player 11.0 or later (to playback recorded file)
VGA Monitor resolution 1280 x 1024 or higher
Intel Core 2 Duo E8600(3.33GHz) or faster
Memory Size: 2GB or more
Windows XP, Vista, 7

Honeywell
3
2. Package Contents
User can find the following items in the package:
Item Descriptions
1. IR Network Camera is the main element of the product.
2. Switching Power Supply Convert AC/DC 24V to DC 12V for
camera
3. User’s Manual CD provides installation software, application
program, important information and instructions for operating the
Network Camera.
If any of the above items are missing, please contact your dealer immediately.
Note: Using a power supply with a different voltage than the one included with the Network
Camera will cause damage and void the warranty for this product.

Connections
4
3. Connections
1. RJ45 LAN socket: Connect to PC or Hub/Switch.
It’s for connections to 10Base-T Ethernet, 100Base-TX, or 1000Base-TX Ethernet cabling.
This Ethernet port built N-Way protocol can detect or negotiate the transmission speed of the
network automatically. Please use Category 5 or better cable to connect the Network
Camera to an Ethernet network switch or hub.
In the LAN socket, there are two LEDs embedded:
LAN LED (green color)

Honeywell
5
This LED will be flashing while network accessing via Ethernet.
Power LED (orange color)
This LED is used to indicate whether DC power is on or not.
2. RS-485: Connect to a local keyboard controller.
DI/ DO: Connect to sensor in and alarm out devices
Cable for I/O connectors:
Name Number Function
12VDC 1 DC 12V (50mA maximum)
DI 2 Digital signal input
GND 3 GND
DO 4 Digital signal output
485+ 5 RS485 data +
485- 6 RS485 data -
3. Factory Default Reset
This button is used to restore the all factory default settings. Sometimes restarting the device
will make the system back to a normal state. However, if the system still got problems after
restart, user can restore the factory default settings and install it again.
Restore the device:
While the Camera is ready and then press the button down continuously.
Hold the button at least 5 seconds and release it. Then the device has been restored to
default settings and reboot again.
Note: Restoring the factory default setting will lose the all previous settings included IP
address forever. User needs to run the IPWizard II program to search the device and
configure it to let the device work properly again.
4. DC-in Jack
The input power is 12VDC. Note that supply the power to the Network Camera with the
power adapter included in package.
5. MIC in (audio in)
Connect a microphone to the network camera.
6. Line out (audio out)
Connect a loud speaker to the network camera. This function is for voice alerting and
two-way audio.
7. Video out (BNC connector)

Connections
6
The Network Camera also provides composite video output. The video output function is
only for easy installation to check view angle and focus. The output is not a Mega-pixel
resolution. Furthermore, the video output is off by default. To turn on video, please refer to
Setting\Camera\Picture chapter.

Honeywell
7
4. Hardware Installation
1. Fix IR camera to desired location with stand
2. Plug-in Ethernet Cable into LAN port
Connect an Ethernet cable to the RJ45 connector.
3. Connect RS485 D+ and D- (if you need to control PT scanner)
4. Connect the attached power adapter to camera and plug-in this adapter into
power outlet, if not powering by PoE
5. Done

How to Adjust Zoom/Focus of Lens
8
5. How to Adjust Zoom/Focus of Lens
1. Open the back cover of the camera
2. Adjust zoom stick first
3. Adjust focus stick to get clear image
4. Close the back cover of the camera tightly. Otherwise, the camera may fail to
waterproof.
Focus stick
Zoom stick

Honeywell
9
6. Preparation
Search and Set up by IP Wizard
Once you installed the Camera on a LAN environment, you have two easy ways to search
your Cameras by IP Wizard II or UPnP™ discovery. Here is the way to execute IP Wizard II
to discover Camera’s IP address and set up related parameter in a Camera.
Search
When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to
search Network Cameras on the LAN. The existed devices will be listed as below.

Preparation
10
View
If IPWizard II finds network devices, View button will be available. Please select the device
you want to view and click the View button. Then you could see the video from camera
directly. Furthermore you could double click the left button of mouse to link to the network
device by web browser.

Honeywell
11
LAN
In case you want to change the IP related parameters of wired interface, please select the
device you want to configure and click the LAN button. Relative settings will be carried out
as below.
You could modify the relative settings of the selected device. Click “<<” button will quit the
LAN setting procedure and click “>>” button will move to next page as below.
In case, you do not want to change username and/or password, then just click “Submit”
button to perform your setting accordingly. Click “<<” button will go back to previous page.

Preparation
12
If you like to change username and/or password of the device, just click the check button.
Then, the related fields will show up as below.
After keying in new username and password, click “Submit” button to perform your setting
accordingly. Click “<<” button will go back to previous page.
Wireless
This model does not support wireless function. Therefore, IP Wizard II disables this function
automatically.
UPnP of Windows
®
XP, Vista or 7
UPnP™ is short for Universal Plug and Play, which is a networking architecture that provides
compatibility among networking equipment, software, and peripherals. This device is an
UPnP enabled device. If the operating system, Windows XP, Vista or 7, of your PC is UPnP
enabled, the Network Camera will be very easy to be found.
Please make sure to enable UPnP settings first if your operating system of PC is running
Windows XP.
Note: Windows 2000 does not support UPnP feature.
To discover your device, go to your Desktop and click My Network Places.

Honeywell
13
Click the targeted Device. Then Internet Explorer will connect to this Network Camera
automatically.
Install the Device behind a NAT Router
Once installed, the device is accessible on your LAN. To access the device from the Internet
you must configure your broadband router to allow incoming data traffic to the device. If the
device is installed on the LAN with a router, then it may get a dynamic IP address from the
DHCP server. However, if the device wants to be accessed from the WAN, its IP address
needs to be setup as fixed IP, also the port forwarding or Virtual Server function of router
needs to be setup.
However, if your NAT router supports UPnP feature, it can be very easy to achieve NAT
traversal automatically. To do this, enable the NAT-traversal feature, which will attempt to
automatically configure the router to allow access to the camera.
Installing the device with an UPnP router on your network is an easy 3–step procedure:
1. Enable UPnP option of your NAT router
To use UPnP IGD function (NAT traversal), you need to make sure the UPnP function is
enabled in your router. Most new home routers should support this function. Some of routers
are default enable and others are not. Please check user’s manual of your NAT router for
detail.
2. Enable UPnP NAT traversal option of the Network Camera
Refer to Setting 

Network 

UPnP page for detail NAT traversal setting. Note that this
option is default enabled.

Preparation
14
3. Access your Network Camera by DIPS
Refer to Setting 

System 

System page for detail DIPS information.
Access the device from the Internet Explorer for the first time
1. If it’s the first you want to access your Network Camera by Windows PC, it would
strongly recommend you to use Internet Explorer as default browser as possible. Start
the web browser on the computer and type the IP address of the Camera you want to
monitor as below:
The Login Window of the Camera is prompted:
2. Type in your login name and password under “USERNAME” and “PASSWORD”
textbox.
For the first time use (default value), input the
User Name: admin
Password: admin
That’s, type in “admin” on the “USERNAME” as a default name and type in “admin” on the
PASSWORD textbox. Click “OK” button to start the main menu.
