INSTALLATION INSTRUCTIONS
H-Series
Green Class Net Meter
ADVANCED KWH/DEMAND METER
WITH CO2 FOOTPRINT

H-SERIES GREEN CLASS NET METER
62-0424-02 2
TABLE OF CONTENTS
Section 1.0 Introduction 3
Section 2.0 Internal Electronic Assemblies 5
Section 2.1 Main Power Board 6
Section 2.2 Display Board 7
Section 2.3 Input Board 8
Section 3.0 Meter Technical Specifications 8
Section 4.0 Safety Label Definitions and Information 12
Section 5.0 Precautionary/Safety Information 13
Section 6.0 Meter Installation 14
Section 6.1 Mounting the Green Class Net Meter 14
Section 6.2 Main Power Board Connections 14
Section 6.3 Phasing of Line Voltage 16
Section 6.4 Current Sensor Installation & Wiring 18
Section 6.5 Main Power & Current Sensor Wiring Diagram 20
Section 6.6 Line Voltage/Current Sensor Diagnostics 22
Section 6.7 RS-485 Wiring 24
Section 6.8 RS-232 Communications 26
Section 6.9 Connecting Green Class Net Meters to USB Key using RS485 30
Section 6.10 Ethernet Communications 31
Section 7.0 Multiple Load Monitoring 33
Section 8.0 Preventative/Scheduled Maintenance 34
Section 9.0 Lithium Battery Replacement 35
Section 10.0 Green Class Net Meter Features 37
Section 10.1 Display Board Push Buttons 37
Section 10.2 Reading The Green Class Net Meter Display 40
Section 11.0 Frequently Asked Questions 41
Section 12.0 Modbus Point Maps 42
Section 13.0 Meter Limited Warranty 48

H-SERIES GREEN CLASS NET METER
3 62-0424-02
1.0 INTRODUCTION
The Honeywell Green Class Net meter is a 3-phase meter with communications. The
device is used to monitor electric power usage of individual loads after the utility meter
and store kW and kVAR data for automatic meter reading. The Green Class Net meter
is dual protocol capable and provides both RS485 and Ethernet communications.
Installation must only be performed by qualified personnel and in accordance with
these instructions and all applicable local and national electrical codes. Honeywell and
its representatives assume no responsibility for damages or injury resulting from the
improper installation of this meter.
Verify the input voltage rating and configuration on the unit panel label to ensure that it
is suitable for the intended electrical service. For example, Green Class Net meters
labeled for 120/208V service MUST NOT be installed on service feeds of 277/480 volts
or 347/600 and vice versa (see chart below):
Verify that the Green Class Net meter’s current sensors are sized suitably for the load
to be monitored. Compare the color of the arrows on the current sensors to the chart
below to confirm the correct current sensor is being used.
Meter Labeled: Works On:
120V 120V, Single Phase
120/240V 120/240V, Single Phase
277V 277V, Single Phase
208V 208V, Three Phase
240V 240V, Three Phase
400V (380V,415V) 400V, Three Phase
480V 480V, Three Phase
600V 600V, Three Phase
Sensor Arrow Color Code Sensor Rating
Brown 100 A
Red 200 A
Yellow 400 A
Black 800 A
Blue 1600 A
White/Black 3200 A

H-SERIES GREEN CLASS NET METER
62-0424-02 4
CAUTION
Internal circuit card components are extremely sensitive to electrostatic
discharge. Prior to handling or touching internal circuitry, discharge any static
buildup on your person. To discharge yourself, touch a grounded metal object
such as conduit or an earth grounded metal enclosure.
WARNING
Use of this instrument, Green Class Net meter, in a manner inconsistent with
this manual or not specified by the manufacturer in writing, can cause
permanent damage to the unit and/or serious injury to the operator. The
protection and safety features provided by this equipment may become
impaired or otherwise compromised.

H-SERIES GREEN CLASS NET METER
5 62-0424-02
2.0 INTERNAL ELECTRONIC ASSEMBLIES
The unit is comprised of two major subassembly boards, the main power board and
the display board. Both circuit boards are mounted inside either a JIC STEEL
Enclosure.
Fig. 1. Internal Electronic Assemblies.
MAIN POWER
BOARD
DISPLAY
BOARD
M33270

H-SERIES GREEN CLASS NET METER
62-0424-02 6
2.1 Main Power Board
Connections to this board include the MAIN Power Input and current sensors. The
MAIN Power Input terminals are positions one through four on the four position screw
terminal block, TB1. These terminals are covered with a protective shield for safety
purposes. The current sensor assemblies interface to the TB2, TB3 and TB4. Each
terminal block corresponds to an input voltage phase; care must be exercised to
ensure that each current sensor is connected to the correct terminal block. One three
terminal screw connector(TB42) is provided for RS-485 communications. One RJ-45
jack (J8) is provided for 10/100-base T Ethernet. One two terminal screw connector
provides phase loss alarming.
Fig. 2. Main Power Board Connections.
M33271
J3
J4
TB1
POSITIONS 1-4
MAIN POWER INPUT
TB1 POSITIONS 6-10
CURRENT SENSOR
INPUTS
ETHERNET
CONNECTION
RS-485
CONNECTION
PHASE OUTPUT

H-SERIES GREEN CLASS NET METER
7 62-0424-02
2.2 Display Board
The display board connects to the main power board via a flex ribbon cable and the
board mounts on the inside of the housing door.
No additional connections to the display board are required. The display board’s LCD
readout indicates the metered values as well as errors associated with the Green
Class Net meter, such as phase loss or sensor error conditions.
Fig. 3. Display Board.
M33279
DOWN UP SELECT MENU

H-SERIES GREEN CLASS NET METER
62-0424-02 8
2.3 Input Board
The Green Class Net meter is supplied with an input board which allows it to accept
pulses (dry contact) from third party meters, such as gas, water, BTU, etc. This 3rd
party meter information that comes in through the pulse input can be communicated
via the communication protocols. Only one input is available with EZ7 PROTOCOL.
Fig. 4. Input Board.
The input terminals and output terminals are used by the Green Class Net meter.
Connect metering devices with “dry contacts” only. If the contacts are from solid - state
(electronic) sources, polarity must be observed for proper operation.
M33321
+–
INP1
+–+–+–
INP2 OUT1 OUT2
NC COM2 NO NC COM1 NO
IO - Terminals
Relay - Terminals

H-SERIES GREEN CLASS NET METER
9 62-0424-02
3.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, current sensor rating,
enclosure, protocols/options, and sensor type in the format A-BB-CCC-DDDD-E-FF-G-
HHH, where:
A = Brand: H for Honeywell
BB = designates Class: 320 (32) or 500 (50) meter
CCC = input voltage: (208, 480, 600, 120 volt for high voltage applications only)
DDDD = current sensor rating: (100, 200, 400, 800, 1600, 3200, 25HV)
E = enclosure: J = metal (type 1), R = non-metallic (rain tight) (type 4X)
FF= protocol option:
G = no package = “blank”
NSP= Single or Two Phase (Optional)
HHH= Sensor Type: kit=split-core, scs= solid-core, non-supplied blank”
Brand Class Voltage Amperage Enclosure Communication Protocol Current Sensor/Option Current Sensor/Option Current Sensor/Option
Example H 50- 208 100- J 01 -N- KIT
H50-208100-J01-N-KIT
Brand Honeywell
Class 500
Voltage 120, 208, 400 (380-415), 480, 600
Amperage 2HV, 100, 200, 400, 800, 1600, 3200
Enclosure J (JIC Steel), I (Interior only), R (Rain tight)
Communication
Protocol
01 (EZ-7, EZ-7 ETHERNET),
02 (MODBUS RTU, EZ-7 ETHERNET),
03 (BACNET MSTP, EZ-7 ETHERNET),
04 (EZ-7, MODBUS TCP/IP),
05 (EZ-7, BACNET IP),
06 (MODBUS RTU, MODBUS TCP/IP),
07 (LONWORKS TP,EZ-7 ETHERNET),
08 (LONWORKS TP, MODBUS TCP/IP),
09 (EX-7, EZ-7 ETHERNET WITH MODEM),
10 (EZ-7, MODBUS TCP/IP WITH MODEM),
11 (EZ-7, BACNET IP WITH MODEM)
Current Sensors/
Options
-N- (GREEN CLASS NET METER), KIT (Split Core), SCS
(Solid-Core), NSP (Single or Two phase Green Class Net
Meter - 2 element)

H-SERIES GREEN CLASS NET METER
62-0424-02 10
3.0 METER TECHNICAL SPECIFICATIONS
Input Voltage
Configuration
3-wire (Delta) Or 4-wire (Wye)
Mains Voltage Input Up To 600 VAC RMS Available
Input Power 12 VA Maximum Rating
Current Sensor Rating Up To 3200 Amps RMS AC Available
Power Factor 0.5 Leading Or Lagging
Line Frequency 50-60 Hz
Metering Accuracy ANSI C12.20
Voltage Operating
Range
+/-10% Of Rated Load
Temperature Range -20 C To +50 C
Relative Humidity
Range
0-95% Non-condensing
Altitude 2000 Meters Maximum
Voltage Overload +25% Continuously: +100% For 20 Cycles
Current Sensor
Overload
100% For 1 Minute Without Damaging Meter
Pollution Degree Degree 2 In Accordance With IEC 664
Installation
(Overvoltage) Category
Category 111
Measurement
Category
Category 111
Enclosure Type Green heavy duty JIC steel enclosure with padlocking hasp
and mounting flanges for indoor installation
Display Readout 4 Line LCD
Standard Ranges 2-Wire Delta 120 VAC: 100, 200, 400, 800,1600, 3200 Amp
4-Wire Wye 120/208 VAC: 100, 200, 400, 800,1600, 3200 Amp
3-Wire Delta 120/240 VAC: 100, 200, 400, 800,1600, 3200 Amp
4-Wire Wye 277/480 VAC: 100, 200, 400, 800,1600, 3200 Amp
2-Wire Wye 277 VAC: 100, 200, 400, 800,1600, 3200 Amp
4-Wire Wye 400 VAC: 100, 200, 400, 800,1600, 3200 Amp
3-Wire Delta 480 VAC: 100, 200, 400, 800,1600, 3200 Amp
4-Wire Wye 600 VAC: 100, 200, 400, 800,1600, 3200 Amp

H-SERIES GREEN CLASS NET METER
11 62-0424-02
RS-485 Serial
Communications
Cable: UL-listed/rated Telephone Cord. 4-cond.
Input/output
Voltage:
Ground-isolated +/-5.4VDC
Cable Connector: Screw Terminal Termination
Circuit Input
Isolation:
5.3kVAC
Max Cable
Distance:
4000 Feet
Max Network
Nodes:
64 Cabling Nodes (Including Master)
Default Baud Rate: 9600 for EZ-7
Recommended
In-line Fuse
Manufacturer: Littlefuse
Mfg. Part No: KLDR.100
Rating: 100mA, Time-delay, 600VAC Cartridge
Fuse
Battery Cell Description: Non-rechargeable Cell Used For
Memory Retention
Manufacturer: Panasonic
Mfg Part No: CR2032
Working Voltage: 3 VDC
Current Capacity 225 mAHr
Electrolyte: Manganese Dioxide Lithium

H-SERIES GREEN CLASS NET METER
62-0424-02 12
4.0 SAFETY LABEL DEFINITIONS AND
INFORMATION
The Green Net Class meter may contain one or more of the following labels.
Operator(s) should familiarize themselves with the meaning of each label to minimize
risk.
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Standards Compliance:
BACnet MS/TP and IP protocol is BTL listed.
LonWorks TP/FT-10 protocol is LonMark® certified.
The Green Class Net meter may contain one or more of the following labels.
Operator(s) should familiarize themselves with the meaning of each label to minimize
risk.
The presence of this label is a cautionary indicator identifying a
danger risk. The manual should be consulted prior to proceeding.
The presence of this label indicates an electrical shock hazard exists
in the location or area where the label is placed. Prior to proceeding,
the MAINS power must be disconnected and the manual consulted for
safety information.

H-SERIES GREEN CLASS NET METER
13 62-0424-02
5.0 PRECAUTIONARY AND SAFETY
INFORMATION
CAUTION
Internal circuit card components are extremely sensitive to electrostatic
discharge. Be careful not to touch internal circuitry prior to discharging any
static buildup on your person. To discharge yourself, touch a grounded metal
object such as conduit or an earth-grounded metal enclosure.
WARNING
High voltages present on main PCB terminal block TB1 screw terminals. Risk
of serious injury and/or electrical shock exists. Prior to performing any wiring
operations, review all contents of the user manual and de-energize the MAINS
power switch. Only qualified personnel should perform installation wiring.
Installation wiring must comply with all local and national electrical codes.
WARNING
Failure to ground the enclosure creates a possible shock hazard. Do not
operate the Green Class Net meter without a protective earth wire attached
securely to the PE terminal screw. After installing protective earth wiring,
secure the screw tightly (7in-lb torque.)
WARNING
NEVER open front panel of unit while unit has MAINS power applied. Failure to
comply can increase the risk of serious injury and/or electrical shock.

H-SERIES GREEN CLASS NET METER
62-0424-02 14
6.0 METER INSTALLATION
6.1 Mounting the Green Class Net Meter
Fig. 5. Enclosure Dimensions
Use appropriately sized mounting hardware to fasten the meter enclosure to the
selected mounting surface.
The four housing mounting holes are centered 6.75” H x 4” W.
NOTE: Units housed in UL Type 1 JIC steel enclosures must only be installed in
indoor environments, where they will not be affected by the elements.
6.2 Main Power Board Connections
1. Installing a temporary ground for ESD protection: With all circuits de-energized,
connect a temporary protective earth ground connection for ESD protection.
Prior to performing any unit wiring, be sure to discharge any static on your per-
son.
2. * Installing the Green Class Net protective earth ground: Connect an earth
ground wire to the Green Class Net protective earth ground lug with a torque of
17 N-m. * for meters in metal enclosures.
M34684
6-35/64 (166)
6-35/64
(166)
5/8 (16)
7-51/64
(198)
3-17/64 (83)
1-5/8
(41)
3-25/64
(86)
Ø 1-3/32 (28) THROUGH
NEAR SIDE ONLY

H-SERIES GREEN CLASS NET METER
15 62-0424-02
WARNING
Failure to attach the protective earth ground wire securely to the meter creates
a potential shock hazard. Do not operate the meter without a protective earth
ground connection securely installed.
3. Wire Entry: One 3/4” conduit opening is located on the bottom of the unit enclo-
sure. This opening is used for bringing in MAINS power and for current sensor
wiring. Route the appropriate cabling to and through the respective enclosure
opening.
4. After installing the conduit fitting and conduit, verify that each conduit slip nut is
securely tightened to its respective conduit fitting. Any unused openings must be
sealed with a UL rated plugging device suitable for the rating of the enclosure
(check formatting).
NOTE: Metallic enclosure has one additional 1/2” conduit opening at top of unit.
5. Unit MAINS wiring: The first four positions of terminal block TB1, located at the
bottom left corner of the main power board, are clearly labeled Phase A, B, C, N
(neutral). Earth Ground MUST be connected to the PCB mounting screw in the
lower right corner.
NOTE: For 3-wire delta-type meters, Do NOT connect the NEUTRAL wire. Remove
the terminal block screw for this position. Connect the earth ground to the
PCB mounting screw in the lower right corner.
a. Connect the NEUTRAL wire to the appropriate terminal block position.
Fig. 6. Terminal Block TB1.
b. External Switch Mechanism/In-Line Fuse Installation
c. To ensure a safe installation, the Green Class Net meter requires an external
switch mechanism, such as a circuit breaker, be installed on the Green Class
Net meter MAINS input wiring. The switch mechanism must be installed in
close proximity to the meter and easily reachable for the operator. This
device must also be marked as the disconnecting device for the Green Class
Net meter. Install 1/10 Amp Slow Activation in-line fuses with the suitable
voltage rating for each conductor phase at the MAINS input to the meter. The
fuses must be labeled to indicate voltage and current rating as well as ele-
ment characteristics. The fuse element must be slow activating type.

H-SERIES GREEN CLASS NET METER
62-0424-02 16
d. Connect the three AC main power wires (Phases A, B and C) to their respec-
tive positions as labeled on terminal block TB1 and tighten to 7 in-lb. After all
conductors are connected to each of their respective terminal block positions
and tightened down, verify that each terminal block screw is securely fas-
tened by gently tugging on each conductor. Single phase - connect two ac
main power wires phases a and b - jumper from b to c - factory installed for
single phase option.
Verify that no conductor wires are frayed or shorting to adjacent terminal
block positions.
e. Turn ON the AC main power input. The meter display will light up and scroll
through 9 displays. Each display is visible for 5 seconds. Display screens are
as follows:
Screen 1:Total Kilowatt-Hours
(kWh)
Delivered
Received
NET
Screen 2: KWH
Screen 3: CO2
Screen 4: Peak Demand (kW) with Date & Time Stamp
Screen 5: Actual Load (kW) with present time
Screen 6: Average Current (amps) Per Phase
Screen 7: Average Voltage (volts) Per Phase
Screen 8: Average Voltage (volts) Phase to Phase
Screen 9: Power Factor (pf) Per Phase.

H-SERIES GREEN CLASS NET METER
17 62-0424-02
f. Verify the voltage readings on Screen 7 using an AC voltmeter. Typical read-
ings shown below are measured phase to neutral for 4 wire and phase to
phase for 3 wire. Readings should be +/- 10% of nominal.
NOTE: Meters are powered by phases A and B. The displayed voltages will be the
measured AC voltage between phases.
6.3 Phasing of Line Voltage
The three phase AC power input must be in proper phase sequence. Single phase
option - AC power input must be in the proper phase sequence. If the sequence is
incorrect or a phase is missing, there will be a message on the meter’s display: “PH
Sequence Error” or “PH Missing:. (Refer to the section on Line Voltage Diagnostics if
this message is present.) When the line voltage is connected correctly, the meter’s
display will be blank (no message).
For single phase connection: connect two ac main power wires to phases A
and B and a jumper wire from B to C - factory installed for single phase option.
Wait for the meter display to scroll to the voltage display. Verify that the meter reads
correct voltages on all three phases. Repeat Step F above.
Meter Type Nominal Voltage Limits (+/- 10%)
120/208V, 3ø, 4 Wire
120/240V, 1ø, 3 Wire
120V, 1ø, 2 Wire
120 VAC (L-N) 108 to 132 VAC
277/480V, 3ø, 4 Wire
277V, 1ø, 2 Wire
277 VAC (L-N) 249 to 305 VAC
240V, 3ø, 3 Wire 240 VAC (L-L) 216 to 264 VAC
400V, 3ø, 4 Wire (380, 415) 230 VAC (L-N) 207 to 253 VAC
480V, 3ø, 3 Wire 480 VAC (L-L) 432 to 528 VAC
600V, 3ø, 4 Wire, (wye only) 347 VAC (L-N) 312 to 380 VAC

H-SERIES GREEN CLASS NET METER
62-0424-02 18
Once the meter displays the correct line voltages and there are no error messages,
you are ready to connect the current sensors to the meter. Before continuing with the
installation, verify that the nine screens display as follows:
Screen 1:Total Kilowatt-Hours, (kWh), Delivered, Received, NET
Screen 2: KWH
Screen 3: CO2
Screen 4: (Amps per Phase): There should be 0.0 on all three phases. Or
in the NSP option - 0.0 in A and B phases.
Screen 5: Volts RMS Phase to Neutral): See the section 6.2.4.F.
Screen 6: Volts RMS Phase to Phase): See the section 6.2.4.F.
Screen 7: Factor Per Phase): There should be 0.0 PF on all three
phases. Or in the NSP option - 0.0 in A and B phases.
NOTE: The meter will be reset later via the software during “startup” procedures.6.4
Current Sensor Installation & Wiring
6.4 Current Sensor Installation & Wiring
Once the AC voltages have been confirmed to be within acceptable limits, you are
ready to install the current sensors. TB1, positions 5 and 6 are the inputs for Phase A,
TB1 positions 7 and 8 are the inputs for Phase B and TB1 positions 9 and 10 are the
Phase C inputs. On the single Phase option use TB1 pos 5&6 are A - TB1 pos 7&8
are B phase -factory installed jumper wire on positions 9&10
Factory installed Jumper should not be removed.
The Green Class Net meter can only be used with two types of current 0-2V split core
or solid core sensors:.
1. Split-core current sensor. This sensor opens so that it can be attached around
the circuit being monitored without interrupting power. Unless otherwise speci-
fied, all Green Class Net meters are supplied with this sensor type.
2. Solid-core current sensor. This sensor does not open and requires the monitored
conductor to be removed from the circuit to install the current sensor. This type is
only supplied when specified at time of order.

H-SERIES GREEN CLASS NET METER
19 62-0424-02
6.4.1 Installing the Split-Core Current Sensor Assembly
1. Each phase being monitored will require one two-piece current sensor assembly.
Open the two-piece current sensor assembly by releasing the nylon clamp using
a fl at head screwdriver.
Fig. 7. Split Core Current Sensor.
2. Reassemble the current sensor assembly around the conductor(s) to be moni-
tored. Ensure the current sensor halves marked “Load” are both facing the load
side of the conductor. The colored arrow will be on the source side of the con-
ductor being monitored and MUST be pointed in a clockwise direction around
the conductor being monitored. Tighten the nylon clamp to complete the assem-
bly.
Fig. 8. Install On a Split Core Sensor.
IMPORTANT:
When looking from the source side of the conductor(s) being monitored, you should
see the arrow on the current sensor assembly. The arrow should be pointing in a
clockwise direction around the conductor(s) being monitored. If the arrow is not
positioned on the source side, inaccurate readings will result.
M33213
LOAD
SOURCE

H-SERIES GREEN CLASS NET METER
62-0424-02 20
6.4.2 Current Sensor Wiring
Once the current sensors are installed onto their appropriate phase conductors, you
can begin terminating the current sensors onto the Green Class Net meter main board.
The current sensors can be extended up to 500 feet for remote monitoring
applications. To extend the length of the wires, use #22 AWG twisted-pair wire with one
white and one black wire.
The easiest way to connect the current sensors is to use the meter’s built-in current
sensor diagnostics. To do this, there must be at least 1% of the meter’s current rating
(amps) fl owing in each of the conductors being monitored. The Green Class Net
meter’s diagnostic program will provide data to ensure that the current sensor
installation is done properly.
The current sensor connection points are located at the bottom right of the main power
board. These are terminals 5 through 10 of terminal block TB1. Each sensor connects
to two terminals, one labeled “Black” and the other “White.” Current sensors should be
connected to the meter one at a time and verified using the current sensor diagnostic
program.
Connect one of the current sensors to TB1 terminals 5 and 6 (Phase A single phase
option). Wait 5 seconds and look at the meter display. The single phase option will only
display errors for A and B.
If the meter displays an error message (see below), remove the wires from terminals 5
and 6 and install them on terminals 7 and 8 (Phase B). if an error message occurs with
the sensor attached to terminals 7 and 8, try again on terminals 9 and 10 (Phase C).
The “CT Error: * “message will disappear when the current sensor is connected to the
correct terminals (phase).
Error Messages: CT ERROR: A
CT ERROR: A B
CT ERROR: A C
Refer to the section on Current Sensor Diagnostics for assistance in troubleshooting
these errors.
6.4.3 Main Power
After the meter circuit wiring has been examined for correctness, power may be
applied to the circuit board. There are three LEDs located in the upper right corner of
the Meter Board labeled BEAT, STATUS and LOAD. The BEAT and STATUS LEDs will
blink once per second when the meter is operating normally, twice per second if there
is a problem. If the monitored circuit is under load the LOAD LED will actively blink. A
heavy load will cause the LED to blink faster than a light load. Very light loads will
result in an extended blink time.
