N568X/N569X Decoded
Image Engines
Integration Manual

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been
made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
2011-2016 Honeywell International Inc. All rights reserved.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.
Web Address: www.honeywellaidc.com
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.
For patent information, please refer to www.hsmpats.com.

i
Contact Customer Support
Product Service and Repair ................................................................................................... v
Limited Warranty .................................................................................................................... v
Send Feedback ...................................................................................................................... v
Chapter 1 - Introduction and Installation
About the N56XX Decoded Out Image Engines ..................................................................1-1
Optics Module to Decoder Board Connector .......................................................................1-2
Decoder Board to Host Interface Connectors ......................................................................1-2
12-pinM FPC Connector (Gold) ...........................................................................................1-2
Host Interface Signal Descriptions .................................................................................1-3
Micro-B Connector ...............................................................................................................1-4
TTL Level 232 Interface .......................................................................................................1-5
Interface Signal Polarity Control.....................................................................................1-5
USB Interface.......................................................................................................................1-5
Keyboard........................................................................................................................1-5
COM Port Emulation ......................................................................................................1-5
HIDPOS .........................................................................................................................1-5
IBM SurePOS.................................................................................................................1-5
Trigger Modes......................................................................................................................1-5
Manual/Serial Trigger.....................................................................................................1-5
Low Power Manual Trigger (Power Off Mode)...............................................................1-5
Presentation Mode .........................................................................................................1-6
Streaming Presentation Mode........................................................................................1-6
Status Indicators ..................................................................................................................1-6
Good Read LED (Pin 10) ...............................................................................................1-6
Beeper (Pin 9) ................................................................................................................1-6
Power Down/nFlash Out (Pin 8).....................................................................................1-6
Chapter 2 - Power Control
Illumination/Aimer Control....................................................................................................2-1
Thermal Considerations .................................................................................................2-1
SDRTIMxxx Menu Settings..................................................................................................2-1
Definition of SDRTIMxxx ................................................................................................2-1
Negative Ramifications of Long SDRTIM Settings.........................................................2-1
Recommendations .........................................................................................................2-1
Chapter 3 - Electrical
DC Characteristics ...............................................................................................................3-1
Operating Voltage ..........................................................................................................3-1
Absolute Maximum Ratings (T=23°C)............................................................................3-2
DC Operating .................................................................................................................3-2
Current Draw........................................................................................................................3-3
Power Conditioning and Interruptions..................................................................................3-4
Table of Contents

ii
AC Characteristics............................................................................................................... 3-4
Power Up From Power Off State (Low Power Mode)*................................................... 3-4
Power Off Timing (Low Power Mode)* .......................................................................... 3-5
USB Enumeration Timing .............................................................................................. 3-6
Interleaved Mode........................................................................................................... 3-7
Environmental Specifications .............................................................................................. 3-8
Chapter 4 - Optics and Illumination
Sensor ................................................................................................................................. 4-1
Illumination Wavelength ...................................................................................................... 4-1
Aiming Wavelength.............................................................................................................. 4-1
Window Placement.............................................................................................................. 4-1
Distance from Window................................................................................................... 4-1
Window Size and Material Requirements...................................................................... 4-1
N56XX Laser Aimer (ER lens at 9.27”) Window Size Diagram ..................................... 4-2
N56XX Laser Aimer (SR and HD lens at 5.27”) Window Size Diagram ........................ 4-3
Reflective Materials in the Imager’s Field of View ............................................................... 4-3
Bar Code Presentation Angle .............................................................................................. 4-3
Laser/LED Safety Standard for N56XX Engines ................................................................. 4-3
Depth of Field Specifications—Guaranteed ........................................................................ 4-4
Guaranteed—Red Illumination ...................................................................................... 4-4
Guaranteed—White Illumination.................................................................................... 4-5
Depth of Field Specifications—Typical ................................................................................ 4-7
Typical—Red Illumination .............................................................................................. 4-7
Typical—White Illumination ........................................................................................... 4-8
Field of View/Resolution ...................................................................................................... 4-8
Bar Code Reading Angles ................................................................................................... 4-9
Chapter 5 - Mechanical Specifications
N56XX Engine Bracketed Mounting .................................................................................... 5-1
N56XX Unbracketed Mounting ............................................................................................ 5-2
N56XX Connector Position.................................................................................................. 5-3
Mounting Configuration for N56XX (Laser Aimer) Optics Module without Ears .................. 5-4
Mounting Configuration for N56XX (LED Aimer) Optics Module without Ears .................... 5-6
Mounting Configuration for N56XX (LED Aimer) Optics Module with Ears ......................... 5-7
Protecting the Engine from Movement ................................................................................ 5-8
Optics Module Interface Connector ..................................................................................... 5-8
Host Interface Connector..................................................................................................... 5-8
Decoder Board Interface Connector.................................................................................... 5-8
Optics Module to Decoder Board Flex Circuit ..................................................................... 5-8
Host Flex Circuit/Strip........................................................................................................ 5-11
........................................................................................................................................... 5-11
Appendix A - Design Considerations / Test Results
EMI Considerations .............................................................................................................A-1
The Decoder Board .......................................................................................................A-1
The Image Engine .........................................................................................................A-1

iii
Design Considerations ........................................................................................................A-1
Test Results.........................................................................................................................A-1
Model 1: Corded Unit in TTL-232 Mode (RJ45/RS232).................................................A-2
Model 2: Corded Unit in USB Full-Speed Mode (RJ45/USB Standard A).....................A-6
Model 3: Corded Unit in USB High-Speed Mode (USB Micro-B/USB Standard A).....A-10
Appendix B - Laser Aimer Patterns
N56XX Laser Aimer Pattern ................................................................................................B-1
Pattern 11 ......................................................................................................................B-1
Pattern 12 ......................................................................................................................B-2
Appendix C - Customer Validation Testing
Temperature Test ............................................................................................................... C-1
Operating Voltage...............................................................................................................C-1
Laser Aimer PCB Assembly ............................................................................................... C-1
LED Aimer PCB Assembly ................................................................................................. C-2

iv

v
Contact Customer Support
To search our knowledge base for a solution or to log in to the Technical Support portal and report a problem, go to
www.hsmcontactsupport.com.
For our latest contact information, see www.honeywellaidc.com/locations.
Product Service and Repair
Honeywell International Inc. provides service for all of its products through service centers throughout the world. To find
your service center, go to www.honeywellaidc.com and select Support. Contact your service center to obtain a Return
Material Authorization number (RMA #) before you return the product.
To obtain warranty or non-warranty service, return your product to Honeywell (postage paid) with a copy of the dated pur-
chase record.Limited Warranty
Limited Warranty
For warranty information, go to www.honeywellaidc.com and click Resources > Warranty.
Send Feedback
Your feedback is crucial to the continual improvement of our documentation. To provide feedback about this manual, con-
tact the Honeywell Technical Communications department at ACSHSMTechnicalCommu[email protected].

vi
Product Agency Compliance
For agency models: N5680, N5683, N5690, and N5693.
Note: It is the OEM manufacturer’s responsibility to comply with applicable regulation(s) in regard to standards for specific
equipment combinations.
Refer to www.honeywellaidc.com/compliance to review and download any publicly available documentation pertaining to the
certification of this product in a given country.
CB Scheme
IEC 60950-1 Second Edition
UL/C-UL (Recognized component)
UL 60950-1 Second Edition
CSA C22.2 No. 60950-1-07, 2nd Edition
D-Mark Statement
Certified to EN 60950-1 Information Technology Equipment product safety.
LED Safety Statement
LEDs have been tested and classified as “EXEMPT RISK GROUP” to the standard IEC 62471:2006.
Laser Safety Standard
LASER has been tested and classified as a “Class 2 LASER Product” to the standard IEC 60825-1 (2007) Second Edition.
The Standard also states that the following be included in all user documentation, spec sheets, and brochures, which describe
this product:
Caution: Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
Note: This warning states that altering the inner parts of the laser engine in a way not specified in the user guide may cause
light levels to exceed Class 2 limits. It is not an issue when using under normal conditions.

vii
ESD Precautions
The engine is shipped in ESD safe packaging. Use care when handling the scan engine outside its packaging. Be sure ground-
ing wrist straps and properly grounded work areas are used.
Dust and Dirt
The engine must be sufficiently enclosed to prevent dust particles from gathering on the imager and lens. When stocking the
unit, keep it in its protective packaging. Dust and other external contaminants will eventually degrade unit performance.
Product Environmental Information
Refer to www.honeywellaidc.com/environmental for the RoHS / REACH / WEEE information.
