Honeywell NX series User manual

User's Manual
NX series
Constant and variable torque
Variable Speed Drives
for induction motors
Subject to changes without notice
Honeywell
EN2B-0232GE51 R0308

AT LEAST THE 10 FOLLOWING STEPS OF THE START-UP QUICK GUIDE MUST BE PERFORMED
DURING THE INSTALLATION AND COMMISSIONING.
IF ANY PROBLEMS OCCUR, PLEASE CONTACT YOUR LOCAL DISTRIBUTOR.
Start-up Quick Guide
1. Check that the delivery corresponds to your order, see Chapter 1.
2. Before taking any commissioning actions read carefully the safety instructions in Chapter
1.
3. Before the mechanical installation, check the minimum clearances around the unit and
check the ambient conditions in Chapter 5.
4. Check the size of the motor cable, mains cable, mains fuses and check the cable
connections, read Chapters 6.1.1.1 to 6.1.1.5.
5. Follow the installation instructions, see Chapter 6.1.5.
6. Control connections are explained in Chapter 6.2.1.
7. If the Start-Up wizard is active, select the language of the keypad and the application
you want to use and confirm by pressing the Enter button. If the Start-Up wizard is not
active, follow the instructions 7a and 7b.
7a. Select the language of the keypad from the Menu M6, page 6.1. Instructions on using
the keypad are given in Chapter 7.
7b. Select the application you want to use from the Menu M6, page 6.2.Instructions on
using the keypad are given in Chapter 7.
8. All parameters have factory default values. In order to ensure proper operation, check
the rating plate data for the values below and the corresponding parameters of
parameter group G2.1.
•nominal voltage of the motor
•nominal frequency of the motor
•nominal speed of the motor
•nominal current of the motor
•motor cosϕ
All parameters are explained in the All in One Application Manual.
9. Follow the commissioning instructions, see Chapter 8.
10. The NX_ Frequency Converter is now ready for use.
Honeywell is not responsible for the use of the frequency converters
against the instructions.

2(110)
CONTENTS
NXS/P USER’S MANUAL
INDEX
1 SAFETY
2 EU DIRECTIVE
3 RECEIPT OF DELIVERY
4 TECHNICAL DATA
5 INSTALLATION
6 CABLING AND CONNECTIONS
7 CONTROL KEYPAD
8 COMMISSIONING
9 FAULT TRACING

3(110)
ABOUT THE NXS/P USER'S MANUAL
Congratulations for choosing the Smooth Control provided by NX Frequency Converters!
The User's Manual will provide you with the necessary information about the installation, commissioning
and operation of NX Frequency Converters. We recommend that you carefully study these instructions
before powering up the frequency converter for the first time.
This manual is available in both paper and electronic editions. We recommend you to use the electronic
version if possible. If you have the electronic version at your disposal you will be able to benefit from the
following features:
The manual contains several links and cross-references to other locations in the manual which makes it
easier for the reader to move around in the manual, to check and find things faster.
The manual also contains hyperlinks to web pages. To visit these web pages through the links you must
have an internet browser installed on your computer.
All specifications and information are subject to changes without further notice

4(110)
NXS/P User's Manual
Index
1. SAFETY......................................................................................................................................6
1.1 Warnings.....................................................................................................................................6
1.2 Safety instructions.......................................................................................................................6
1.3 Earthing and earth fault protection..............................................................................................7
1.4 Running the motor ......................................................................................................................7
2. EU DIRECTIVE...........................................................................................................................8
2.1 CE marking.................................................................................................................................8
2.2 EMC directive..............................................................................................................................8
2.2.1 General............................................................................................................................8
2.2.2 Technical criteria.............................................................................................................8
2.2.3 Frequency converter EMC classification.........................................................................8
2.2.3.1 Environment definitions in product standard EN 61800-3 (2004).............................9
2.2.4 Manufacturer's declaration of conformity ........................................................................9
3. RECEIPT OF DELIVERY.........................................................................................................13
3.1 Type designation code..............................................................................................................13
3.2 Storage .....................................................................................................................................14
3.3 Maintenance .............................................................................................................................14
3.3.1 Capacitor recharge........................................................................................................14
3.4 Warranty ...................................................................................................................................15
4. TECHNICAL DATA..................................................................................................................16
4.1 Introduction...............................................................................................................................16
4.2 Power ratings............................................................................................................................18
4.2.1 NX_5 – Mains voltage 380—500 V...............................................................................18
4.2.2 NX_6 – Mains voltage 525—690 V...............................................................................19
4.2.3 NX_2 – Mains voltage 208—240 V...............................................................................20
4.3 Brake resistor ratings................................................................................................................21
4.4 Technical data...........................................................................................................................23
5. INSTALLATION .......................................................................................................................25
5.1 Mounting...................................................................................................................................25
5.2 Cooling......................................................................................................................................35
5.2.1 FR4 to FR9....................................................................................................................35
5.2.2 Standalone units (FR10 to FR12)..................................................................................37
5.3 Power losses ............................................................................................................................39
5.3.1 Power losses as function of switching frequency..........................................................39
6. CABLING AND CONNECTIONS.............................................................................................43
6.1 Power unit.................................................................................................................................43
6.1.1 Power connections........................................................................................................43
6.1.1.1 Mains and motor cables.........................................................................................43
6.1.1.2 DC supply and brake resistor cables......................................................................44
6.1.1.3 Control cable..........................................................................................................44
6.1.1.4 Cable and fuse sizes, NX_2 and NX_5, FR4 to FR9 .............................................44
6.1.1.5 Cable and fuse sizes, NX_6, FR6 to FR9 ..............................................................45
6.1.1.6 Cable and fuse sizes, NX_5, FR10 to FR12 ..........................................................46
6.1.1.7 Cable and fuse sizes, NX_6, FR10 to FR12 ..........................................................46
6.1.2 Understanding the power unit topology.........................................................................47
6.1.3 Changing the EMC protection class..............................................................................48
6.1.4 Mounting of cable accessories......................................................................................50
6.1.5 Installation instructions..................................................................................................52
6.1.5.1 Stripping lengths of motor and mains cables .........................................................53
6.1.5.2 NX frames and installation of cables......................................................................54

5(110)
6.1.6 Cable selection and unit installation in accordance with the UL standards...................64
6.1.7 Cable and motor insulation checks ...............................................................................64
6.2 Control unit................................................................................................................................65
6.2.1 Control connections.......................................................................................................66
6.2.1.1 Control cables ........................................................................................................67
6.2.1.2 Galvanic isolation barriers......................................................................................67
6.2.2 Control terminal signals.................................................................................................68
6.2.2.1 Digital input signal inversions.................................................................................69
6.2.2.2 Jumper selections on the OPT-A1 basic board......................................................70
7. CONTROL KEYPAD................................................................................................................72
7.1 Indications on the Keypad display ............................................................................................72
7.1.1 Drive status indications .................................................................................................72
7.1.2 Control place indications...............................................................................................73
7.1.3 Status LEDs (green – green – red) ...............................................................................73
7.1.4 Text lines.......................................................................................................................73
7.2 Keypad push-buttons................................................................................................................74
7.2.1 Button descriptions........................................................................................................74
7.3 Navigation on the control keypad..............................................................................................75
7.3.1 Monitoring menu (M1)...................................................................................................77
7.3.2 Parameter menu (M2)...................................................................................................78
7.3.3 Keypad control menu (M3)............................................................................................79
7.3.3.1 Selection of control place.......................................................................................79
7.3.3.2 Keypad reference...................................................................................................80
7.3.3.3 Keypad direction.....................................................................................................80
7.3.3.4 Stop button activated..............................................................................................80
7.3.4 Active faults menu (M4).................................................................................................81
7.3.4.1 Fault types..............................................................................................................82
7.3.4.2 Fault codes.............................................................................................................83
7.3.4.3 Fault time data record ............................................................................................87
7.3.5 Fault history menu (M5) ................................................................................................88
7.3.6 System menu (M6)........................................................................................................89
7.3.6.1 Language selection................................................................................................91
7.3.6.2 Application selection...............................................................................................91
7.3.6.3 Copy parameters....................................................................................................92
7.3.6.4 Parameter comparison...........................................................................................94
7.3.6.5 Security ..................................................................................................................95
7.3.6.6 Keypad settings......................................................................................................96
7.3.6.7 Hardware settings ..................................................................................................98
7.3.6.8 System info...........................................................................................................100
7.3.7 Expander board menu (M7) ........................................................................................103
7.4 Further keypad functions ........................................................................................................103
8. COMMISSIONING..................................................................................................................104
8.1 Safety......................................................................................................................................104
8.2 Commissioning of the frequency converter.............................................................................104
9. FAULT TRACING...................................................................................................................107

6(110) SAFETY
1
1. SAFETY
1.1 Warnings
1 The NX frequency converter is meant for fixed installations only.
2 Do not perform any measurements when the frequency converter is con-
nected to the mains.
3 Do not perform any voltage withstand tests on any part of NX. There is a
certain procedure according to which the tests shall be performed. Ignor-
ing this procedure may result in damaged product.
4 The earth leakage current of NX_ frequency converters exceeds 3.5mA
AC. According to standard EN61800-5-1, a reinforced protective ground
connection must be ensured. See chapter 1.3.
5 If the frequency converter is used as a part of a machine, the machine
manufacturer is responsible for providing the machine with a main switch
(EN 60204-1).
6 Only spare parts delivered by Honeywell can be used.
7 The motor starts at power-up if the start command is 'ON'. Furthermore,
the I/O functionalities (including start inputs) may change if parameters,
applications or software are changed. Disconnect, therefore, the motor if
an unexpected start can cause danger.
8 Prior to measurements on the motor or the motor cable, disconnect the
motor cable from the frequency converter.
9 Do not touch the components on the circuit boards. Static voltage dis-
charge may damage the components.
1.2 Safety instructions
1 The components of the power unit of the frequency converter are live
when NX is connected to mains potential. Coming into contact with
this voltage is extremely dangerous and may cause death or severe
injury. The control unit is isolated from mains potential.
2 The motor terminals U, V, W and the DC-link/brake resistor terminals are
live when NX is connected to mains, even if the motor is not running.
3 After disconnecting the frequency converter from the mains, wait until the
fan stops and the indicators on the keypad go out (if no keypad is at-
tached see the indicators on the cover). Wait 5 more minutes before
doing any work on NX connections. Do not even open the cover before
this time has expired.
4 The control I/O-terminals are isolated from the mains potential. However,
the relay outputs and other I/O-terminals may have a dangerous control
voltage present even when NX is disconnected from mains.
5 Before connecting the frequency converter to mains make sure that the
NX front and cable covers are closed.
ONLY A COMPETENT ELECTRICIAN MAY CARRY OUT
THE ELECTRICAL INSTALLATION
WARNING

SAFETY 7(110)
1
1.3 Earthing and earth fault protection
The NX frequency converter must always be earthed with an earthing conductor connected to the earthing
terminal .
The earth leakage current of NX frequency converters exceeds 3.5mA AC. According to EN61800-5-1, one
or more of the following conditions for the associated protective circuit shall be satisfied:
a. The protective conductor shall have a cross-sectional area of at least 10 mm2Cu or 16 mm2Al, through
its total run.
b. Where the protective conductor has a cross-sectional area of less than 10 mm2Cu or 16 mm2Al, a
second protective conductor of at least the same cross-sectional area shall be provided up to a point
where the protective conductor has a cross-sectional area not less than 10 mm2Cu or 16 mm2Al.
c. Automatic disconnection of the supply in case of loss of continuity of the protective conductor. See chapter 6.
The cross-sectional area of every protective earthing conductor which does not form part of the supply
cable or cable enclosure shall, in any case, be not less than:
a. 2,5mm2 if mechanical protection is provided or
b. 4mm2 if mechanical protection is not provided.
The earth fault protection inside the frequency converter protects only the converter itself against earth
faults in the motor or the motor cable. It is not intended for personal safety.
Due to the high capacitive currents present in the frequency converter, fault current protective switches
may not function properly.
1.4 Running the motor
Warning symbols
For your own safety, please pay special attention to the instructions marked with the following symbols:
= Dangerous voltage
WARNING = General warning
HOT SURFACE = Hot surface – Risk of burn
MOTOR RUN CHECK LIST
1 Before starting the motor, check that the motor is mounted properly and
ensure that the machine connected to the motor allows the motor to be
started.
2 Set the maximum motor speed (frequency) according to the motor and
the machine connected to it.
3 Before reversing the motor make sure that this can be done safely.
4 Make sure that no power correction capacitors are connected to the
motor cable.
5 Make sure that the motor terminals are not connected to mains potential.
WARNING

8(110) EU DIRECTIVE
2
2. EU DIRECTIVE
2.1 CE marking
The CE marking on the product guarantees the free movement of the product within the EEA (European
Economic Area).
NX frequency converters carry the CE label as a proof of compliance with the Low Voltage Directive (LVD)
and the Electro Magnetic Compatibility (EMC). The company SGS FIMKO has acted as the Competent
Body.
2.2 EMC directive
2.2.1 General
The EMC Directive provides that the electrical apparatus must not excessively disturb the environment it is
used in, and, on the other hand, it shall have an adequate level of immunity toward other disturbances from
the same environment.
The compliance of NX frequency converters with the EMC directive is verified with Technical Construction
Files (TCF) checked and approved by SGS FIMKO, which is a Competent Body. The Technical
Construction Files are used to authenticate the comformity of the NX frequency converters with the Direc-
tive because such a large-sized product family is impossible to be tested in a laboratory environment and
because the combinations of installation vary greatly.
2.2.2 Technical criteria
Our basic idea was to develop a range of frequency converters offering the best possible usability and
cost-efficiency. EMC compliance was a major consideration from the outset of the design.
NX frequency converters are marketed throughout the world, a fact which makes the EMC requirements of
customers different. As far as the immunity is concerned, all NX frequency converters are designed to fulfil
even the strictest requirements, while as regards the emission level, the customer may want to upgrade
NX's already high ability to filter electro-magnetic disturbances.
2.2.3 Frequency converter EMC classification
NX frequency converters are divided into five classes according to the level of electromagnetic distur-
bances emitted, the requirements of a power system network and the installation environment (see chapter
2.2.3.1). The EMC class of each product is defined in the type designation code.
Class C (NX_5, FR4 to FR6, Protection class IP54):
Frequency converters of this class comply with the requirements of category C1 of the product standard
EN 61800-3 (2004). Category C1 ensures the best EMC characteristics and it includes converters the rated
voltage of which is less than 1000V and which are intended for use in the 1st environment. NOTE: If the
protection class of the frequency converter is IP21 the requirements of class C are fulfilled only as far as
the conducted emissions are concerned.
Class H (NX_5, FR4 to FR9 and NX_2, FR4 to FR9):
Frequency converters of this class comply with the requirements of category C2 of the product standard
EN 61800-3 (2004). Category C2 includes converters in fixed installations and the rated voltage of which is
less than 1000V. The class H frequency converters can be used both in the 1st and the 2nd environment.
Class L (Protection classes IP21 and IP54: NX_5 FR10 and greater, NX_6 FR6 and greater):
Frequency converters of this class comply with the requirements of category C3 of the product standard
EN 61800-3 (2004). Category C3 includes converters the rated voltage of which is less than 1000V and
which are intended for use in the second environment only.

EU DIRECTIVE 9(110)
2
Class T:
Frequency converters of this class fulfil the product standard EN 61800-3 (2004) if intended to be used in
IT systems. In IT systems, the networks are isolated from earth, or connected to earth through high imped-
ance to achieve a low leakage current. NOTE: if converters are used with other supplies, no EMC
requirements are complied with.
Class N:
The drives of this class do not provide EMC emission protection. These kinds of drives are mounted in
enclosures. NOTE: An external EMC filter is usually required to fulfil the EMC emission requirements.
All NX frequency converters fulfil all EMC immunity requirements (standard EN 61800-3 (2004).
Note: For changing the EMC protection class of your NX frequency converter from class H or L to class T,
please refer to the instructions given in Chapter 6.1.3.
2.2.3.1 Environment definitions in product standard EN 61800-3 (2004)
First environment: Environment that includes domestic premises. It also includes establishments directly
connected without intermediate transformers to a low-voltage power supply network which supplies
buildings used for domestic purposes.
NOTE: houses, apartments, commercial premises or offices in a residential building are examples of first
environment locations.
Second environment: Environment that includes all establishments other than those directly connected to
a low-voltage power supply network which supplies buildings used for domestic purposes.
NOTE: industrial areas, technical areas of any building fed from a dedicated transformer are examples of
second environment locations.
2.2.4 Manufacturer's declaration of conformity
The following pages present the Manufacturer's Declarations of Conformity assuring the compliance of the
NX frequency converters with the EMC-directives.
Warning: This is a product of the restricted sales distribution class according to IEC 61800-3. In a
domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.

10(110) EU DIRECTIVE
2
EU DECLARATION OF CONFORMITY
We
Manufacturer's name:
Manufacturer's address:
hereby declare that the product
Product name: NXS/P Frequency converter
Model designation: NXS/P 0003 5…. to 1030 5….
has been designed and manufactured in accordance with the following
standards:
Safety: EN 61800-5-1 (2003)
EMC: EN61800-3 (2004)
and conforms to the relevant safety provisions of the Low Voltage Directive
(2006/95/EC) and EMC Directive 2004/108/EC.
It is ensured through internal measures and quality control that the product
conforms at all times to the requirements of the current Directive and the
relevant standards.
In Vaasa, 16th of May, 2007
Vesa Laisi
President
The year the CE marking was affixed: 2002

EU DIRECTIVE 11(110)
2
EU DECLARATION OF CONFORMITY
We
Manufacturer's name:
Manufacturer's address:
hereby declare that the product
Product name: NXS/P Frequency converter
Model designation: NXS/P 0004 6…. to 0820 6….
has been designed and manufactured in accordance with the following
standards:
Safety: EN 61800-5-1 (2003)
EMC: EN61800-3 (2004)
and conforms to the relevant safety provisions of the Low Voltage Directive
(2006/95/EC) and EMC Directive 2004/108/EC.
It is ensured through internal measures and quality control that the product
conforms at all times to the requirements of the current Directive and the
relevant standards.
In Vaasa, 16th of May, 2007
Vesa Laisi
President
The year the CE marking was affixed: 2003

12(110)
2
EU DECLARATION OF CONFORMITY
We
Manufacturer's name:
Manufacturer's address:
hereby declare that the product
Product name: NXS/P Frequency converter
Model designation: NXS/P 0004 2…. to 0300 2….
has been designed and manufactured in accordance with the following
standards:
Safety: EN 61800-5-1 (2003)
EMC: EN61800-3 (2004)
and conforms to the relevant safety provisions of the Low Voltage Directive
(2006/95/EC) and EMC Directive 2004/108/EC.
It is ensured through internal measures and quality control that the product
conforms at all times to the requirements of the current Directive and the
relevant standards.
In Vaasa, 16th of May, 2007
Vesa Laisi
President
The year the CE marking was affixed: 2003

RECEIPT OF DELIVERY 13(110)
3
3. RECEIPT OF DELIVERY
NX frequency converters have undergone scrupulous tests and quality checks at the factory before they
are delivered to the customer. However, after unpacking the product, check that no signs of transport
damages are to be found on the product and that the delivery is complete (compare the type designation of
the product to the code below, Figure 3-1.
Should the drive have been damaged during the shipping, please contact primarily the cargo insurance
company or the carrier.
If the delivery does not correspond to your order, contact the supplier immediately.
In the small plastic bag included in the delivery you will find a silver Drive modified sticker. The purpose of
the sticker is to notify the service personnel about the modifications made in the frequency converter.
Attach the sticker on the side of the frequency converter to avoid losing it. Should the frequency converter
be later modified (option board added, IP or EMC protection level changed), mark the change in the sticker.
3.1 Type designation code
Figure 3-1. NX type designation code
NXS 0000 A 2 H 1 S A1A20000C3
5V 3
Product range: NXS = standard, NXP = high-performance
Nominal current (low overload)
0007 = 7A, 0022 = 22A, 0205 = 205 Aetc.
Voltage range:
2 = 208–240Vac, 5 = 380–500Vac, 6 = 525–690Vac (All 3-phase)
Control keypad:
A = standard (alpha-numeric)
B = no local control keypad
F = dummy keypad
G = graphic display
Enclosure class:
0 = IP00 (FR9 only), 2 = IP21 (Nema 1), 5 = IP54 (Nema 12)
C = fulfils requirements of category C1 of standard EN61800-3 (2004),
1st environment and rated voltage less than 1000V
H = fulfils requirements of category C2 of standard EN61800-3 (2004),
fixed installations and rated voltage less than 1000V
L = fulfils requirements of category C3 of standard EN61800-3 (2004),
2nd environment and rated voltage less than 1000V
T = fulfils standard EN61800-3 (2004) when used in IT networks
N = No EMC emission protection. An external EMC filter needed
Brake chopper
0 = no brake chopper
1 = internal brake chopper
2 = internal brake chopper and resistor
Hardware modifications;
S = standard
V = varnished boards
Option boards; each slot is represented by two characters where:
A = basic I/O board, B = expander I/O board,
C = fieldbus board, D = special board
Phase 1 or 3
Voltage
Note: Ask factory for other possible installation combinations.

14(110) RECEIPT OF DELIVERY
3
3.2 Storage
If the frequency converter is to be kept in store before use make sure that the ambient conditions are
acceptable:
Storing temperature –40…+70°C
Relative humidity <95%, no condensation
If the converter is to be stored during longer periods power should be connected to the converter once a
year and kept on for at least 2 hours. If the storage time exceeds 12 months the electrolytic DC capacitors
need to be charged with caution. Therefore, such a long storage time is not recommended. If longer
storage time is, however, necessary, follow the instructions in chapter 3.3.1 to recharge the capacitors.
3.3 Maintenance
In normal conditions, NX frequency converters are maintenance-free. However, regular maintenance is
recommended to ensure a trouble-free operation and a long lifetime of the drive. We recommend to follow
the table below for maintenance intervals.
Maintenance interval Maintenance action
Whenever necessary •Clean heatsink
Regularly •Check tightening torques of terminals
12 months (if unit stored) •Recharge capacitors (see chapter 3.3.1)
6-24 months
(depending on environment) •Check input and output terminals and control
I/O terminals.
•Clean cooling tunnel.
•Check operation of cooling fan, check for cor-
rosion on terminals, busbars and other surfaces
•Check door filters in case of cabinet installation
5-7 years •Change cooling fans:
-main fan
-internal IP54 fan
-cabinet cooling fan/filter
5-10 years •Change DC bus capacitors
Table 3-1. Maintenance intervals
3.3.1 Capacitor recharge
After a longer storage time the capacitors need to be recharged in order to avoid capacitor damage.
Possible high leakage current through the capacitors must be limited. The best way to achieve this is to
use a DC-power supply with adjustable current limit.
1) Set the current limit to 300…800mA according to the size of the drive.
2) Then connect the DC-power supply to the B+/B- terminals (DC+ to B+, DC- to B-) of the DC-link or
directly to the capacitor terminals. NX converters with no B+/B- terminals (FR8/FR9) can be powered
connecting the DC-supply between two input phases (L1 and L2).
3) In drives FR8 to FR12: To ensure full recharge of capacitors, remove the fuses of the cooling fan. Ask
your distributor for further instructions if necessary.
4) Then set the DC-voltage to the nominal DC-voltage level of the unit (1.35*Un AC) and supply the
converter for at least 1h.
If DC-voltage is not available and the unit has been stored much longer than 12 months deenergized,
consult the factory before connecting power.

RECEIPT OF DELIVERY 15(110)
3
3.4 Warranty
Only manufacturing defects are covered by the warranty. The manufacturer assumes no responsibility for
damages caused during or resulting from transport, receipt of the delivery, installation, commissioning or
use.
The manufacturer shall in no event and under no circumstances be held responsible for damages and
failures resulting from misuse, wrong installation, unacceptable ambient temperature, dust, corrosive
substances or operation outside the rated specifications.
Neither can the manufacturer be held responsible for consequential damages.
The Manufacturer's time of warranty is 18 months from the delivery or 12 months from the commissioning
whichever expires first (Warranty Terms).
The local distributor may grant a warranty time different from the above. This warranty time shall be
specified in the distributor's sales and warranty terms. The manufacturer assumes no responsibility for
warranties offered by others.
In all matters concerning the warranty, please contact first your distributor.

16(110) TECHNICAL DATA
4
4. TECHNICAL DATA
4.1 Introduction
Figure 4-1 presents the block diagram of the NX frequency converter. The frequency converter mechani-
cally consists of two units, the Power Unit and the Control Unit. Pictures of the mechanical assemblage on
pages 54 to 62.
The three-phase AC-choke (1) at the mains end together with the DC-link capacitor (2) form an LC-filter,
which, again, together with the diode bridge produce the DC-voltage supply to the IGBT Inverter Bridge (3)
block. The AC-choke also functions as a filter against High Frequency disturbances from the mains as well
as against those caused by the frequency converter to the mains. It, in addition, enhances the waveform of
the input current to the frequency converter. The entire power drawn by the frequency converter from the
mains is active power.
The IGBT Inverter Bridge produces a symmetrical, 3-phase PWM-modulated AC-voltage to the motor.
The Motor and Application Control Block is based on microprocessor software. The microprocessor con-
trols the motor basing on the information it receives through measurements, parameter settings, control I/O
and control keypad. The motor and application control block controls the motor control ASIC which, in turn,
calculates the IGBT positions. Gate drivers amplify these signals for driving the IGBT inverter bridge.
=
=
L1
L2
L3
PE
U
V
W
3~
3~
RS 232
NK4_1
Mains Motor
Brake
Chopper*
Measure-
ments
Gate
Drivers
Motor
Control
ASIC
Motor and
Application
Control
Control
Keypad
Fan
Current
Sensors
Rectifier IGBT
Inverter
Brake resistor*
Output
filter
Power
Supply
Control
I/O Control I/O Control
I/O Control I/O Control I/O
1)
2)
3)
Integrated input module
*The brake resistor can be installed internally in sizes FR4 to FR6 (NX_2 and NX_5). In all other
frames of voltage classes NX_2 and NX_5, as well as in all frames of all other voltage classes, the
brake resistor is available as option and installed externally.
Brake chopper belongs to the standard equipment in sizes FR4 to FR6, while in greater sizes
(FR7 to FR9) it is optional.
Control
module
Power
module
Charg.res.
Figure 4-1. NX block diagram

TECHNICAL DATA 17(110)
4
The control keypad constitutes a link between the user and the frequency converter. The control keypad is
used for parameter setting, reading status data and giving control commands. It is detachable and can be
operated externally and connected via a cable to the frequency converter. Instead of the control keypad,
also a PC can be used to control the frequency converter if connected through a similar cable.
You can have your frequency converter equipped with a control I/O board which is either isolated (OPT-A8)
or not isolated (OPT-A1) from the ground.
The basic control interface and the parameters (the Basic Application) are easy to use. If a more versatile
interface or parameters are required, a more suitable application can be chosen from the "All in One" Appli-
cation Package. See the "All in One" Application Manual for more information on the different applications.
A brake resistor is available as internal option for frames FR4 to FR6 of voltage classes NX_2 and NX_5.
In all other frames of voltage classes NX_2 and NX_5, as well as in all frames of all other voltage classes,
the brake resistor is available as option and installed externally.
Optional I/O expander boards that increase the number of inputs and outputs to be used are also available.
For closer information, contact the Manufacturer or your local distributor (see back cover).

18(110) TECHNICAL DATA
4
4.2 Power ratings
4.2.1 NX_5 – Mains voltage 380—500 V
High overload = Max current IS, 2 sec/20 sec, 150% overloadability, 1 min/10 min
Following continuous operation at rated output current, 150 % rated output current (IH)
for 1 min, followed by a period of load current less than rated current, and of such
duration that the r.m.s output current, over the duty cycle, does not exceed rated output
current (IH)
Low overload = Max current IS, 2 sec/20 sec, 110% overloadability, 1 min/10 min
Following continuous operation at rated output current, 110% rated output current (IL)
for 1 min, followed by a period of load current less than rated current, and of such
duration that the r.m.s output current, over the duty cycle, does not exceed rated output
current (IL)
All sizes are available as IP21/NEMA1 Sizes FR4 to FR10 are additionally available as IP54/NEMA12.
FR12 is available only as NXP.
Mains voltage 380-500 V, 50/60 Hz, 3~
Loadability Motor shaft power
Low High 380V supply 500V supply
Frequency
converter
type Rated
continuous
current IL
(A)
10%
overload
current
(A)
Rated
continuous
current IH
(A)
50%
overload
current
(A)
Max
current
IS
10%
overload
40°C
P(kW)
50%
overload
50°C
P(kW)
10%
overload
40°C
P(kW)
50%
overload
50°C
P(kW)
Frame Dimensions and weight
WxHxD/kg
NX 0003 5 3.3 3.6 2.2 3.3 4.4 1.1 0.75 1.5 1.1 FR4 128x292x190/5
NX 0004 5 4.3 4.7 3.3 5.0 6.2 1.5 1.1 2.2 1.5 FR4 128x292x190/5
NX 0005 5 5.6 6.2 4.3 6.5 8.6 2.2 1.5 3 2.2 FR4 128x292x190/5
NX 0007 5 7.6 8.4 5.6 8.4 10.8 3 2.2 4 3 FR4 128x292x190/5
NX 0009 5 9 9.9 7.6 11.4 14 4 3 5.5 4 FR4 128x292x190/5
NX 0012 5 12 13.2 9 13.5 18 5.5 4 7.5 5.5 FR4 128x292x190/5
NX 0016 5 16 17.6 12 18.0 24 7.5 5.5 11 7.5 FR5 144x391x214/8.1
NX 0022 5 23 25.3 16 24.0 32 11 7.5 15 11 FR5 144x391x214/8.1
NX 0031 5 31 34 23 35 46 15 11 18.5 15 FR5 144x391x214/8.1
NX 0038 5 38 42 31 47 62 18.5 15 22 18.5 FR6 195x519x237/18.5
NX 0045 5 46 51 38 57 76 22 18.5 30 22 FR6 195x519x237/18.5
NX 0061 5 61 67 46 69 92 30 22 37 30 FR6 195x519x237/18.5
NX 0072 5 72 79 61 92 122 37 30 45 37 FR7 237x591x257/35
NX 0087 5 87 96 72 108 144 45 37 55 45 FR7 237x591x257/35
NX 0105 5 105 116 87 131 174 55 45 75 55 FR7 237x591x257/35
NX 0140 5 140 154 105 158 210 75 55 90 75 FR8 291x758x344/58
NX 0168 5 170 187 140 210 280 90 75 110 90 FR8 291x758x344/58
NX 0205 5 205 226 170 255 336 110 90 132 110 FR8 291x758x344/58
NX 0261 5 261 287 205 308 349 132 110 160 132 FR9 480x1150x362/146
NX 0300 5 300 330 245 368 444 160 132 200 160 FR9 480x1150x362/146
NX 0385 5 385 424 300 450 540 200 160 250 200 FR10 595x2018x602/340
NX 0460 5 460 506 385 578 693 250 200 315 250 FR10 595x2018x602/340
NX 0520 5 520 572 460 690 828 250 250 355 315 FR10 595x2018x602/340
NX 0590 5 590 649 520 780 936 315 250 400 355 FR11 794x2018x602/470
NX 0650 5 650 715 590 885 1062 355 315 450 400 FR11 794x2018x602/470
NX 0730 5 730 803 650 975 1170 400 355 500 450 FR11 794x2018x602/470
NX 0820 5 820 902 730 1095 1314 450 400 500 500 FR12 1210x2017x602/600
NX 0920 5 920 1012 820 1230 1476 500 450 630 500 FR12 1210x2017x602/600
NX 1030 5 1030 1133 920 1380 1656 500 500 710 630 FR12 1210x2017x602/600
Table 4-1. Power ratings and dimensions of NX, supply voltage 380—500V.
Note: The rated currents in given ambient temperatures are achieved only when the switching frequency is equal to
or less than the factory default.
Note: The rated currents for FR10 to FR12 are valid at an ambient temperature of 40°C (except for 0520 5: rated
currents valid at an ambient temperature of 35°C).

TECHNICAL DATA 19(110)
4
4.2.2 NX_6 – Mains voltage 525—690 V
High overload = Max current IS, 2 sec/20 sec, 150% overloadability, 1 min/10 min
Following continuous operation at rated output current, 150 % rated output current (IH)
for 1 min, followed by a period of load current less than rated current, and of such
duration that the r.m.s output current, over the duty cycle, does not exceed rated output
current (IH)
Low overload = Max current IS, 2 sec/20 sec, 110% overloadability, 1 min/10 min
Following continuous operation at rated output current, 110% rated output current (IL)
for 1 min, followed by a period of load current less than rated current, and of such
duration that the r.m.s output current, over the duty cycle, does not exceed rated output
current (IL)
All sizes are available as IP21/NEMA1 Sizes FR4 to FR10 are additionally available as IP54/NEMA12.
FR12 is available only as NXP.
Mains voltage 525-690 V, 50/60 Hz, 3~
Loadability Motor shaft power
Low High 690V supply 575V supply
Frequency
converter
type Rated
continuous
current IL
(A)
10%
overload
current
(A)
Rated
continuous
current IH
(A)
50%
overload
current
(A)
Max
current
IS
10%
overload
40°C
P(kW)
50%
overload
50°C
P(kW)
10%
overload
40°C
P(hp)
50%
overload
50°C
P(hp)
Frame Dimensions and
weight
WxHxD/kg
NX 0004 6 4.5 5.0 3.2 4.8 6.4 3 2.2 3.0 2.0 FR6 195x519x237/18,5
NX 0005 6 5.5 6.1 4.5 6.8 9.0 4 3 3.0 3.0 FR6 195x519x237/18,5
NX 0007 6 7.5 8.3 5.5 8.3 11.0 5.5 4 5.0 3.0 FR6 195x519x237/18,5
NX 0010 6 10 11.0 7.5 11.3 15.0 7.5 5.5 7.5 5.0 FR6 195x519x237/18,5
NX 0013 6 13.5 14.9 10 15.0 20.0 10 7.5 11 7.5 FR6 195x519x237/18,5
NX 0018 6 18 19.8 13.5 20.3 27 15 10 15 11 FR6 195x519x237/18,5
NX 0022 6 22 24.2 18 27.0 36 18.5 15 20 15 FR6 195x519x237/18,5
NX 0027 6 27 29.7 22 33.0 44 22 18.5 25 20 FR6 195x519x237/18,5
NX 0034 6 34 37 27 41 54 30 22 30 25 FR6 195x519x237/18,5
NX 0041 6 41 45 34 51 68 37.5 30 40 30 FR7 237x591x257/35
NX 0052 6 52 57 41 62 82 45 37.5 50 40 FR7 237x591x257/35
NX 0062 6 62 68 52 78 104 55 45 60 50 FR8 291x758x344/58
NX 0080 6 80 88 62 93 124 75 55 75 60 FR8 291x758x344/58
NX 0100 6 100 110 80 120 160 90 75 100 75 FR8 291x758x344/58
NX 0125 6 125 138 100 150 200 110 90 125 100 FR9 480x1150x362/146
NX 0144 6 144 158 125 188 213 132 110 150 125 FR9 480x1150x362/146
NX 0170 6 170 187 144 216 245 160 132 150 150 FR9 480x1150x362/146
NX 0208 6 208 229 170 255 289 200 160 200 150 FR9 480x1150x362/146
NX 0261 6 261 287 208 312 375 250 200 250 200 FR10 595x2018x602/340
NX 0325 6 325 358 261 392 470 315 250 300 250 FR10 595x2018x602/340
NX 0385 6 385 424 325 488 585 355 315 400 300 FR10 595x2018x602/340
NX 0416 6 416 458 325 488 585 400 315 450 300 FR10 595x2018x602/340
NX 0460 6 460 506 385 578 693 450 355 450 400 FR11 794x2018x602/400
NX 0502 6 502 552 460 690 828 500 450 500 450 FR11 794x2018x602/400
NX 0590 6 590 649 502 753 904 560 500 600 500 FR11 794x2018x602/470
NX 0650 6 650 715 590 885 1062 630 560 650 600 FR12 1210x2017x602/600
NX 0750 6 750 825 650 975 1170 710 630 800 650 FR12 1210x2017x602/600
NX 0820 6 820 902 650 975 1170 800 630 800 650 FR12 1210x2017x602/600
Table 4-2. Power ratings and dimensions of NX, supply voltage 525—690V.
Note: The rated currents in given ambient temperatures are achieved only when the switching frequency is equal to
or less than the factory default.
Note: The rated currents for FR10 to FR12 are valid at an ambient temperature of 40°C (except for 0416 6, 0590 6
and 0820 6: rated currents valid at an ambient temperature of 35°C).
