Honeywell Farenhyt RPS-1000 Operating instructions

Document 151153 Rev: N
08/09/2017 ECN: 17-0387
RPS-1000 / RPS-1000B
Intelligent Power Module
Installation and Operation Guide
Farenhyt™ Series

2RPS-1000 / RPS-1000B P/N 151153:N 12/18/2017
Fire Alarm & Emergency Communication System Limitations
While a life safety system may lower insurance rates, it is not a substitute for life and property insurance!
An automatic fire alarm system—typically made up of smoke
detectors, heat detectors, manual pull stations, audible warning
devices, and a fire alarm control panel (FACP) with remote notifica-
tion capability—can provide early warning of a developing fire. Such
a system, however, does not assure protection against property
damage or loss of life resulting from a fire.
An emergency communication system—typically made up of an
automatic fire alarm system (as described above) and a life safety
communication system that may include an autonomous control
unit (ACU), local operating console (LOC), voice communication,
and other various interoperable communication methods—can
broadcast a mass notification message. Such a system, however,
does not assure protection against property damage or loss of life
resulting from a fire or life safety event.
The Manufacturer recommends that smoke and/or heat detectors
be located throughout a protected premises following the
recommendations of the current edition of the National Fire
ProtectionAssociation Standard 72 (NFPA 72), manufacturer's
recommendations, State and local codes, and the
recommendations contained in the Guide for Proper Use of System
Smoke Detectors, which is made available at no charge to all
installing dealers. This document can be found at http://
www.systemsensor.com/appguides/.A study by the Federal
Emergency ManagementAgency (an agency of the United States
government) indicated that smoke detectors may not go off in as
many as 35% of all fires. While fire alarm systems are designed to
provide early warning against fire, they do not guarantee warning or
protection against fire.Afire alarm system may not provide timely or
adequate warning, or simply may not function, for a variety of
reasons:
Smoke detectors may not sense fire where smoke cannot reach
the detectors such as in chimneys, in or behind walls, on roofs, or
on the other side of closed doors. Smoke detectors also may not
sense a fire on another level or floor of a building.A second-floor
detector, for example, may not sense a first-floor or basement fire.
Particles of combustion or “smoke” from a developing fire may
not reach the sensing chambers of smoke detectors because:
• Barriers such as closed or partially closed doors, walls, chim-
neys, even wet or humid areas may inhibit particle or smoke
flow.
• Smoke particles may become “cold,” stratify, and not reach the
ceiling or upper walls where detectors are located.
• Smoke particles may be blown away from detectors by air out-
lets, such as air conditioning vents.
• Smoke particles may be drawn into air returns before reaching
the detector.
The amount of “smoke” present may be insufficient to alarm smoke
detectors. Smoke detectors are designed to alarm at various levels
of smoke density. If such density levels are not created by a devel-
oping fire at the location of detectors, the detectors will not go into
alarm.
Smoke detectors, even when working properly, have sensing limita-
tions. Detectors that have photoelectronic sensing chambers tend
to detect smoldering fires better than flaming fires, which have little
visible smoke. Detectors that have ionizing-type sensing chambers
tend to detect fast-flaming fires better than smoldering fires.
Because fires develop in different ways and are often unpredictable
in their growth, neither type of detector is necessarily best and a
given type of detector may not provide adequate warning of a fire.
Smoke detectors cannot be expected to provide adequate warning
of fires caused by arson, children playing with matches (especially
in bedrooms), smoking in bed, and violent explosions (caused by
escaping gas, improper storage of flammable materials, etc.).
Heat detectors do not sense particles of combustion and alarm
only when heat on their sensors increases at a predetermined rate
or reaches a predetermined level. Rate-of-rise heat detectors may
be subject to reduced sensitivity over time. For this reason, the rate-
of-rise feature of each detector should be tested at least once per
year by a qualified fire protection specialist. Heat detectors are
designed to protect property, not life.
IMPORTANT! Smoke detectors must be installed in the same
room as the control panel and in rooms used by the system for the
connection of alarm transmission wiring, communications, signal-
ing, and/or power. If detectors are not so located, a developing fire
may damage the alarm system, compromising its ability to report a
fire.
Audible warning devices such as bells, horns, strobes, speak-
ers and displays may not alert people if these devices are located
on the other side of closed or partly open doors or are located on
another floor of a building. Any warning device may fail to alert peo-
ple with a disability or those who have recently consumed drugs,
alcohol, or medication. Please note that:
• An emergency communication system may take priority over a
fire alarm system in the event of a life safety emergency.
• Voice messaging systems mustbe designed to meet intelligibility
requirements as defined by NFPA, local codes, and Authorities
Having Jurisdiction (AHJ).
• Language and instructional requirements must be clearly dis-
seminated on any local displays.
• Strobes can, under certain circumstances, cause seizures in
people with conditions such as epilepsy.
• Studies have shown that certain people, even when they hear a
fire alarm signal, do not respond to or comprehend the meaning
of the signal.Audible devices, such as horns and bells, can have
different tonal patterns and frequencies. It is the property
owner's responsibility to conduct fire drills and other training
exercises to make people aware of fire alarm signals and
instruct them on the proper reaction to alarm signals.
• In rare instances, the sounding of a warning device can cause
temporary or permanent hearing loss.
A life safety system will not operate without any electrical power. If
AC power fails, the system will operate from standby batteries only
for a specified time and only if the batteries have been properly
maintained and replaced regularly.
Equipment used in the system may not be technically compatible
with the control panel. It is essential to use only equipment listed for
service with your control panel.
Telephone lines needed to transmit alarm signals from a premises
to a central monitoring station may be out of service or temporarily
disabled. For added protection against telephone line failure,
backup radio transmission systems are recommended.
The most common cause of life safety system malfunction is inad-
equate maintenance. To keep the entire life safety system in excel-
lent working order, ongoing maintenance is required per the
manufacturer's recommendations, and UL and NFPA standards.At
a minimum, the requirements of NFPA 72 shall be followed. Envi-
ronments with large amounts of dust, dirt, or high air velocity require
more frequent maintenance.A maintenance agreement should be
arranged through the local manufacturer's representative. Mainte-
nance should be scheduled as required by National and/or local fire
codes and should be performed by authorized professional life
safety system installers only. Adequate written records of all inspec-
tions should be kept. Limit-D2-2016

RPS-1000 / RPS-1000B P/N 151153:N 12/18/2017 3
Installation Precautions
Adherence to the following will aid in problem-free installation with long-term reliability:
WARNING - Several different sources of power can be con-
nected to the fire alarm control panel. Disconnect all sources of
power before servicing. Controlunit and associated equipment may
be damaged by removing and/or inserting cards, modules, or inter-
connecting cables while the unit is energized. Do not attempt to
install, service, or operate this unit until manuals are read and
understood.
CAUTION - System Re-acceptance Test after Software
Changes: To ensure proper system operation, this product must be
tested in accordance with NFPA 72 after any programming opera-
tion or change in site-specific software. Re-acceptance testing is
required after any change, addition or deletion of system compo-
nents, or after any modification, repair or adjustment to system
hardware or wiring.All components, circuits, system operations, or
software functions known to be affected by a change must be 100%
tested. In addition, to ensure that other operations are not inadver-
tently affected, at least 10% of initiating devices that are not directly
affected by the change, up to a maximum of 50 devices, must also
be tested and proper system operation verified.
This system meets NFPA requirements for operation at 0-49º C/
32-120º F and at a relative humidity 93% ± 2% RH (noncondens-
ing) at 32°C ± 2°C (90°F ± 3°F). However, the useful life of the sys-
tem's standby batteries and the electronic components may be
adversely affected by extreme temperature ranges and humidity.
Therefore, it is recommended that this system and its peripherals
be installed in an environment with a normal room temperature of
15-27º C/60-80º F.
Verify that wire sizes are adequate for all initiating and indicating
device loops. Most devices cannot tolerate more than a 10% I.R.
drop from the specified device voltage.
Like all solid state electronic devices, this system may operate
erratically or can be damaged when subjected to lightning induced
transients. Although no system is completely immune from light-
ning transients and interference, proper grounding will reduce sus-
ceptibility. Overhead or outside aerial wiring is not recommended,
due to an increased susceptibility to nearby lightning strikes. Con-
sult with the Technical Services Department if any problems are
anticipated or encountered.
DisconnectAC power and batteries prior to removing or inserting
circuit boards. Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing,
reaming, or punching of the enclosure. When possible, make all
cable entries from the sides or rear. Before making modifications,
verify that they will not interfere with battery, transformer, or printed
circuit board location.
Do not tighten screw terminals more than 9 in-lbs. Over-tighten-
ing may damage threads, resulting in reduced terminal contact
pressure and difficulty with screw terminal removal.
This system contains static-sensitive components. Always
ground yourself with a proper wrist strap before handling any cir-
cuits so that static charges are removed from the body. Use static
suppressive packaging to protect electronic assemblies removed
from the unit.
Follow the instructions in the installation, operating, and pro-
gramming manuals. These instructions must be followed to avoid
damage to the control panel and associated equipment. FACP
operation and reliability depend upon proper installation.
Precau-D1-9-2005
FCC Warning
WARNING: This equipment generates, uses, and can radi-
ate radio frequency energy and if not installed and used in
accordance with the instruction manual may cause interfer-
ence to radio communications. It has been tested and found
to comply with the limits for classA computing devices pur-
suant to Subpart B of Part 15 of FCC Rules, which is
designed to provide reasonable protection against such
interference when devices are operated in a commercial
environment. Operation of this equipment in a residential
area is likely to cause interference, in which case the user
will be required to correct the interference at his or her own
expense.
Canadian Requirements
This digital apparatus does not exceed the ClassA limits for
radiation noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Depart-
ment of Communications.
Le present appareil numerique n'emet pas de bruits radio-
electriques depassant les limites applicables aux appareils
numeriques de la classeA prescrites dans le Reglement sur
le brouillage radioelectrique edicte par le ministere des
Communications du Canada.
Farenhyt™ is a trademark; and eVance®, Honeywell®, Silent Knight® and SWIFT® are registered trademarks of Honeywell International Inc. Microsoft® and
Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The
Mozilla Foundation.
©2018 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited.

4RPS-1000 / RPS-1000B P/N 151153:N 12/18/2017
Software Downloads
In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent
upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we
strongly recommend that you download the most current version of software for each product prior to commissioning any system.
Contact Technical Support with any questions about software and the appropriate version for a specific application.
Documentation Feedback
Your feedback helps us keep our documentation up-to-date and accurate. If you have any comments or suggestions about our online
Help or printed manuals, you can email us.
Please include the following information:
• Product name and version number (if applicable)
• Printed manual or online Help
• Topic Title (for online Help)
• Page number (for printed manual)
• Brief description of content you think should be improved or corrected
• Your suggestion for how to correct/improve documentation
Send email messages to:
FireSystems.T[email protected]
Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical
Services.

1
Contents
Section 1: Overview .......................................................................................................................................................... 1
1.1: RPS-1000 Description.......................................................................................................................................................................................1
1.1.1: Maximum Number of SBUS Modules ...................................................................................................................................................1
1.2: Agency Requirements........................................................................................................................................................................................3
Section 2: Before You Begin Installing ........................................................................................................................... 5
2.1: Inventory............................................................................................................................................................................................................5
2.2: Environmental Specifications............................................................................................................................................................................5
2.3: Software Downloads..........................................................................................................................................................................................5
2.4: RPS-1000 Board and Terminal Strip Description..............................................................................................................................................6
2.5: Earth Fault Resistance .......................................................................................................................................................................................7
2.6: Calculating Current Draw and Standby Battery................................................................................................................................................8
2.6.1: Worksheet Requirements........................................................................................................................................................................8
Maximum Battery Standby Load..............................................................................................................................................................8
2.6.2: Current Draw Worksheet for IDP SLC Devices.....................................................................................................................................8
2.6.3: Current Draw Worksheet for SK SLC Device .....................................................................................................................................11
2.6.4: Current Draw Worksheet for SD SLC Devices....................................................................................................................................14
2.7: Wiring Specifications.......................................................................................................................................................................................17
2.7.1: Length Limitations................................................................................................................................................................................17
2.7.2: Calculating Wiring distance for SBUS modules ..................................................................................................................................17
2.7.3: Wire Routing ........................................................................................................................................................................................19
Section 3: Hardware Installation.................................................................................................................................... 21
3.1: AC Power.........................................................................................................................................................................................................21
3.2: Battery Connection..........................................................................................................................................................................................21
3.3: Connecting the RPS-1000 to the FACP...........................................................................................................................................................22
3.3.1: Setting the Device ID............................................................................................................................................................................24
3.4: Connecting SBUS Modules to the RPS-1000 .................................................................................................................................................24
3.5: Flexputs™I/O Circuits ....................................................................................................................................................................................25
3.5.1: Conventional Notification Appliance...................................................................................................................................................25
3.5.2: Releasing Operations............................................................................................................................................................................26
Class B Notification Wiring ...................................................................................................................................................................26
Class A Notification Wiring ...................................................................................................................................................................26
3.5.3: Conventional Initiation Circuits ...........................................................................................................................................................27
Class B Inputs.........................................................................................................................................................................................27
Class A Inputs.........................................................................................................................................................................................27
3.5.4: Installing 2-Wire Smoke Detectors ......................................................................................................................................................28
3.5.5: Installing 4-Wire Smoke Detectors ......................................................................................................................................................29
3.5.6: Auxiliary Power Configuration ............................................................................................................................................................30
Door Holder Power.................................................................................................................................................................................30
Constant Power.......................................................................................................................................................................................31
Resettable Power.....................................................................................................................................................................................31
Sounder Sync Power...............................................................................................................................................................................31
3.6: Conventional Relay Installation ......................................................................................................................................................................31
Compatible Devices
A.7: Notification Appliances ..................................................................................................................................................................................33
Honeywell Fire Product Warranty and Return Policy
Manufacturer Warranties and Limitation of Liability

1RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Section 1: Overview
1.1 RPS-1000 Description
The RPS-1000 Intelligent Power Module provides additional power and circuits to the IFP-2100, IFP-2100ECS, IFP-2000, IFP-
2000ECS, IFP-1000, IFP-1000ECS, IFP-300, IFP-300ECS, IFP-100, IFP-100ECS or IFP-75 FACPs. The RPS-1000 can power all the
FACP compatible modules, including SLC devices (via a Model 5815XL or 6815 SLC Expander), remote annunciators, notification
appliances, auxiliary power modules, and all other compatible modules. RPS-1000 is available in a black cabinet as P/N RPS-1000B*
The RPS-1000 has six Flexputs™ and two programmable relays. Outputs are rated 3.0 A (6.0 A total for each RPS-1000). Relays are
Form C rated at 2.5 A @ 24 VDC. Outputs and relays are fully programmable.
The RPS-1000 is optically isolated, providing ground loop isolation and transient protection. It functions as an SBUS repeater which
conditions the RS-485 signal and allows the module to drive up to 6,000 feet of additional SBUS wiring.
The RPS-1000 is housed in a metal cabinet that is identical in size to the IFP-1000/IFP-1000ECS FACP cabinet. This cabinet is large
enough to house two 17 AH batteries. The RPS-1000 cabinet provides mounting studs for two Model 5815XL or 6815 SLC Expander
modules.
The RPS-1000 communicates to the main FACPvia the SBUS. Each RPS-1000 provides an additional 6,000 feet of SBUS wiring length
to the main panel. As the drawings on the next pages illustrate, this allows you to distribute modules, SLC devices, and outputs through-
out an extremely large facility.
As well as expanding the wiring length capabilities of the FACP, the RPS-1000 also expands the power capabilities by an additional 6.0
A of current.
*All references to RPS-1000 within this manual are applicable to the RPS-1000B.
1.1.1 Maximum Number of SBUS Modules
The chart below shows the maximum number of compatible modules that can be used in an Intelligent installation. Modules can be dis-
tributed among the main panel SBUS and each additional RPS-1000 SBUS in virtually any combination.
NOTE: The IFP-100 and IFP-75 do not use 5815XL or 6815 SLC expanders.
Module or Device Maximum Number
RPS-1000/RPS-1000B Intelligent Power
Module
8 per IFP-1000/ECS, IFP-100/ECS, IFP-50 or IFP-75 installation
16 per IFP-300/ECS installation
63 per IFP-2100/ECS or IFP-2000/ECS installation
RA-100 or RA-1000 Remote Annunciator
8 per IFP-50 or IFP-75 installation
12 per IFP-100/ECS, IFP-1000/ECS installation
16 per IFP-300/ECS installation
31 per IFP-2100/ECS installation
RA-2000 Remote Annunciator 63 per IFP-2100/ECS or IFP-2000/ECS installation
6815 SLC Expander 63 per IFP-300/ECS or IFP-2100/ECS installation
5815XL SLC Expander 7 per IFP-1000/ECS installation
63 per IFP-300/ECS, IFP-2000/ECS or IFP-2100/ECS installation
5824 Serial/Parallel Modules 4 per IFP-1000/ECS, IFP-300/ECS, IFP-2000/ECS or IFP-2100/ECS
installation
Outputs 6 per IFP-1000 or IFP-1000ECS / RPS-1000
Conventional Relays 2 per IFP-1000 or IFP-1000ECS / RPS-1000

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 2
RPS-1000 Description Overview
Figure 1.1 Example RPS-1000 Installation Overview

3RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Overview Agency Requirements
Figure 1.2 Example RPS-1000 Installation Overview (Details Added)
1.2 Agency Requirements
The RPS-1000 has the same requirements as the main control panel. These requirements are listed in:
ECS Series Model Number FACP Installation Manual
IFP-2000ECS 151430-L8
IFP-1000ECS 151460
IFP-100ECS 151458
IFP-300ECS LS10145-001SK-E
IFP-2100ECS LS10143-001SK-E

5RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Inventory
Section 2: Before You Begin Installing
2.1 Inventory
The Model RPS-1000 ships with the following hardware:
• A cabinet with all hardware assembled
• Two keys for the front door
• Ten 4.7K ohm end-of-line resistors
• A battery cable for batteries wired in series
2.2 Environmental Specifications
It is important to protect the RPS-1000 control panel from water. To prevent water damage, the following conditions should be
AVOIDED when installing the units:
• Do not mount directly on exterior walls, especially masonry walls (condensation)
• Do not mount directly on exterior walls below grade (condensation)
• Protect from plumbing leaks
• Protect from splash caused by sprinkler system inspection ports
• Do not mount in areas with humidity-generating equipment (such as dryers, production machinery)
When selecting a location to mount the RPS-1000, the unit should be mounted where it will NOT be exposed to temperatures outside the
range of 0°C-49°C (32°F-120°F) or humidity outside the range of 10%-93% at 30°C (86°F) non-condensing.
2.3 Software Downloads
In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent
upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly
recommend that you download the most current version of software for each product prior to commissioning any system. Contact Tech-
nical Support with any questions about software and the appropriate version for a specific application. Software updates can be found at
NOTE: For UL installations, 4.7kend-of-line resistor (ordered separately) must be used.

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 6
RPS-1000 Board and Terminal Strip Description Before You Begin Installing
2.4 RPS-1000 Board and Terminal Strip Description
Figure 2.1 on page 6 shows the RPS-1000 circuit board including location of terminals, the DIP switch for setting module ID, and the
LED.
Figure 2.1 The RPS-1000 Board Layout
Table 2.1 Terminal Strip Description and Electrical Ratings
Terminal # and Label Description Rating
Voltage Current
1 L AC input (hot) 120/240 VAC,
50/60 Hz 2.7 A 1.4 A
2 G Earth ground N/A N/A
3 N AC input (neutral) 120/240 VAC,
50/60 Hz 2.7 A 1.4 A
4 X I/O 6* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
5O 100 mA Initiation Circuits
6 X I/O 5* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
7 O 100 mA Initiation Circuits
8 X I/O 4* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
9O 100 mA
Initiation Circuits

7RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Earth Fault Resistance
* Regulated/special application when used for releasing.
2.5 Earth Fault Resistance
Table 2.2 lists the earth fault resistance detection for each applicable terminal on the FACP.
10 XI/O 3* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
11 O100 mA Initiation Circuits
12 X I/O 2* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
13 O 100 mA Initiation Circuits
14 XI/O 1* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
15 O100 mA Initiation Circuits
16 B SBUS OUT SBUS communication 5 VDC 100 mA
17 A
18 + SBUS power 24 VDC 1.0 A
19 -
20 BSBUS IN Used for Class A installations
21 A
22 +
23 -
24 N.C. RELAY 2 General Purpose Relay 2 24 VDC 2.5 A
25 C
26 N.O.
27 N.C. RELAY 1 General Purpose Relay 1 24 VDC 2.5 A
28 C
29 N.O.
30 B SBUS IN/
OUT RPS-1000 communication with main panel or to controlling RPS-
1000 if daisy-chained
5 VDC 100 mA
31 A
32 + MAIN RPS-1000 SBUS power (from IFP-
1000 or IFP-1000ECS) 24 VDC 10 mA
33 -
Table 2.1 Terminal Strip Description and Electrical Ratings
Terminal # and Label Description Rating
Voltage Current
Table 2.2 Earth Fault Resistance Values by Terminal
Function Terminal
Number
Terminal Label Low Biased High Biased
(Values in kohms) High
Trip High Restore Low Trip Low Restore
Flexput™
Notification
Circuits
4 X I/O 6 - - 0 0
5O 00- -
6 X I/O 5 - - 0 0
7O 00- -
8 X I/O 4 - - 0 0
9O 00- -
10 X I/O 3 - - 0 0
11 O 0 0 - -
12 X I/O 2 - - 0 0
13 O 0 0 - -
14 X I/O 1 - - 0 0
15 O 0 0 - -
SBUS
Communication 16 B SBUS OUT - - 0 0
17 A - - 0 0
SBUS Power 18 + 0 0 - -
19 - - - 0 0

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 8
Calculating Current Draw and Standby Battery Before You Begin Installing
2.6 Calculating Current Draw and Standby Battery
This section is for helping you determine the current draw and standby battery needs for your installation.
2.6.1 Worksheet Requirements
The following steps must be taken when determining RPS-1000 current draw and standby battery requirements.
Filling in the Current Draw Worksheet, Table 2.4,Table 2.5 or Table 2.6
1. For the RPS-1000, the worst case current draw is listed for the panel, addressable devices, and SLC expanders. Fill in the number of
addressable devices and expanders that will be used in the system and compute the current draw requirements for alarm and
standby.
2. Add up the current draw for all auxiliary devices and record in the table at Line B.
3. Add up all notification appliance loads and record in the table at Line C.
4. For notification appliances and auxiliary devices not mentioned in the manual, refer to the device manual for the current ratings.
5. Make sure that the total alarm current you calculated, including current for the panel itself, does not exceed 6.0 A. This is the
maximum alarm current allowable.
6. Complete the remaining instructions in the table for determining battery size requirements.
Maximum Battery Standby Load
Table 2.3 shows the maximum battery standby load for the RPS-1000 based on 24 and 60 hours of standby. The standby load calcula-
tions of line G in the Current Draw Calculation Worksheet must be less than the number shown in Table 2.3 for the battery size used and
standby hours required.
*Use a separate worksheet for each RPS-1000
2.6.2 Current Draw Worksheet for IDP SLC Devices
For each RPS-1000* in the installation, use this worksheet to determine current requirements during alarm/battery standby operation.
See individual FACP manual for maximum number of devices.
Used for Class A
Installations 20 B SBUS IN - - 0 0
21 A - - 0 0
22 + 0 0 - -
23 - - - 0 0
Table 2.2 Earth Fault Resistance Values by Terminal
Function Terminal
Number
Terminal Label Low Biased High Biased
(Values in kohms) High
Trip High Restore Low Trip Low Restore
Table 2.3 Maximum Battery Standby Load
Rechargeable
Battery Size Max. Load for 24 hrs. Standby, 5 mins. Alarm *Max. Load for 60 hrs. Standby, 5 mins. Alarm
7 AH 270 mA 105 mA
12 AH 475 mA 190 mA
17 AH 685 mA 270 mA
33 AH 1370 mA 540 mA
* Required for NFPA 72 Auxiliary Protected Fire Alarm systems for Fire Alarm Service (City Box) and
Remote Station Protected Fire Alarm systems (Polarity Reversal) and Digital Alarm
Communicator/Transmitter (DACT).
NOTE: 33AH max battery size for Fm (Factory Mutual) installations
Table 2.4 Current Draw Worksheet for IDP SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
For each device use this formula: This column X This column = Current per number of devices.
RPS-1000 Intelligent Power Module
(Current draw from battery) 1* Standby 40 mA 40 mA
Alarm: 160 mA 160 mA
Additional RPS-1000
(Daisy-chained to this module) (7 max.) Standby 10 mA mA
Alarm: 10 mA mA

9RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Calculating Current Draw and Standby Battery
Addressable SLC Devices
IDP-Photo Standby: .30 mA1mA mA
IDP-Photo-T mA mA
IDP-PhotoR mA mA
IDP-Heat mA mA
IDP-Heat-HT mA mA
IDP-Acclimate Standby: .30 mA1mA mA
IDP-Heat-ROR mA mA
IDP-Beam (without integral test) SLC Standby/Alarm: 2 mA mA mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
IDP-Beam-T (with integral test) SLC Standby/Alarm: 2 mA mA mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
DNR6(non-relay) None, included with IDP-PhotoR
DNR7(with relay) None, included with IDP-PhotoR & IDP-Relay
IDP-CO-Fire SLC Standby: .30 mA mA
Alarm: 7.2 mA mA
IDP-Monitor Standby/Alarm .375 mA mA mA
IDP-Minimon mA mA
IDP-Pull-SA/IDP-Pull-DA mA mA
IDP-Monitor-2 Standby/Alarm: .75 mA mA mA
IDP-Monitor-10 Standby/Alarm: 3.5 mA mA mA
IDP-Control SLC Standby .375 mA mA
Alarm: .375 mA mA
Aux Pwr Standby 1.7 mA mA
Alarm: 7mA mA
IDP-Control-6 SLC Standby 2.25 mA mA
Alarm: 2.25 mA mA
Aux Pwr Standby 8 mA mA
Alarm: 20 mA mA
IDP-Relay Standby/Alarm: .255 mA mA mA
IDP-Relay-6 Standby/Alarm: 1.45 mA mA mA
IDP-RelayMon-2 Standby: 1.3 mA mA
Alarm: 24 mA mA
IDP-Zone Aux Pwr Standby 12 mA mA
Alarm: 90 mA mA
SLC Standby/Alarm .27 mA mA mA
IDP-Zone-6 Aux Pwr Standby 50 mA mA
Alarm: 70 mA mA
SLC Standby/Alarm 2 mA mA mA
SLC Accessories
B200SR Sounder Base Aux Pwr Standby: .5 mA mA
Alarm: 35 mA mA
SLC Standby .3 mA mA
B200S Intelligent Sounder Base Aux Pwr Standby: .5 mA mA
Alarm: (high vol) 35 mA mA
SLC Standby .3 mA mA
Table 2.4 Current Draw Worksheet for IDP SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 10
Calculating Current Draw and Standby Battery Before You Begin Installing
B200SR-LF Low Frequency Sounder
Base Aux Pwr Standby: 1 mA mA
Alarm: 125 mA mA
B200S-LF Low Frequency Sounder
Base Aux Pwr Standby .55 mA mA
Alarm (high vol) 140 mA mA
SLC Standby .30 mA mA
B224RB Relay Base Standby/Alarm: .5 mA mA mA
RT151/151 KEY Alarm: 7.5 mA mA
RA100Z Alarm: 10 mA mA
SLC Isolator Devices
IDP-ISO (Isolator Module) Standby/Alarm: 0.45 mA mA mA
ISO-6 (6 Fault Isolator Module) Standby: (per circuit) .45 mA mA
Alarm: (per circuit) 17 mA mA
B224BI Isolator Base Standby/Alarm: 0.5 mA mA mA
Accessories Modules
6815 SLC Loop Expander Standby: 78 mA mA
Alarm: 78 mA mA
RA-2000 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-1000 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-100 Remote LCD Annunciator Standby: 25 mA mA
Alarm: 50 mA mA
5824 Serial/Parallel Module Standby/Alarm: 45 mA mA mA
5496 NAC Expander Standby/Alarm: 10 mA mA mA
RPS-1000 Power Supply Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches) Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Module Standby: 35 mA mA
Alarm: 145 mA mA
5880 LED I/O Module Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface Standby: 0 mA mA
Alarm: (22 mA/relay) 220 mA mA
ESC-50W or ECS-125W Voice
Amplifier with/without ECS-CE4 Standby 10 mA mA
Alarm 10 mA mA
ECS-INT50W Internal Amplifier Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA mA
ECS-DUAL50W Dual Voice Amp Standby/Alarm: 10 mA mA mA
ECS-50WBU Back-Up Amplifier Standby/Alarm: 10 mA mA mA
ECS-VCM Voice Control Module Standby: 70 mA mA
Alarm: 100 mA mA
ECS-NVCM Voice Control Module Standby/Alarm: 59 mA mA mA
ECS-SW24 Switch Expander Standby: 10 mA mA
Alarm: 25 mA mA
ECS-RPU Remote Paging Unit Standby: 70 mA mA
Alarm: 100 mA mA
ECS-LOC Local Operating Console
(includes RA-2000, RVM & SW-24) Standby: 105 mA mA
Alarm: 175 mA mA
Table 2.4 Current Draw Worksheet for IDP SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current

11 RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Calculating Current Draw and Standby Battery
2.6.3 Current Draw Worksheet for SK SLC Device
For each RPS-1000* in the installation, use this worksheet in Table 2.5 to determine current requirements during alarm/battery standby
operation. See individual FACP manual for maximum number of devices.
Network Cards
SK-NIC Network Interface Card Standby/Alarm: 21 mA mA mA
SK-FML Fiber Optic Multi Mode Standby/Alarm: 53 mA mA mA
SK-FSL Fiber Optic Single Mode Standby/Alarm: 79 mA mA mA
Wireless Modules
WIDP-WGI Wireless Gateway Max current using ext supply 40 mA mA mA
Max current SLC Power 24 mA mA mA
Total System Current
Auxiliary Devices2Refer to devices manual for current rating
IPDACT-2 IP Communicator Standby: 93 mA mA
Alarm: 136 mA mA
IPDACT-2UD IP Communicator Standby: 98 mA mA
Alarm: 155 mA mA
CELL-MOD/CELL-CAB-SK Standby: 55 mA mA
Alarm: 100 mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Auxiliary Devices Current
Notification Devices Refer to device manual for current rating
5495/5499 Power Supply 24 VDC One input circuit: 15 mA mA
Both input circuits: 30 mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
Notification Appliances Current mA
Total current ratings of all devices in system (line A + line B + C) mA mA
Total current ratings converted to amperes (line D x .001): A A
Number of standby hours H
Multiply lines E and F. Total standby AH AH
Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
Multiply lines E and H. Total alarm AH AH
Add lines G and I.3Total ampere hours
required AH
Table 2.4 Current Draw Worksheet for IDP SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
Table 2.5 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
For each device use this formula: This column X This column = Current per number of devices.
RPS-1000 Intelligent Power Module
(Current draw from battery) 1* Standby 40 mA 40 mA
Alarm: 160 mA 160 mA
Additional RPS-1000
(Daisy-chained to this module) (7 max.) Standby 10 mA mA
Alarm: 10 mA mA

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 12
Calculating Current Draw and Standby Battery Before You Begin Installing
Addressable SLC Detectors
SK-PHOTO Standby/Alarm: .30 mA1mA mA
SK-PHOTO-T mA mA
SK-HEAT mA mA
SK-HEAT-HT mA mA
SK-ACCLIMATE mA mA
SK-HEAT-ROR mA mA
SK-DUCT5(includes PhotoR) mA mA
SK-BEAM (without integral test) SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-BEAM-T4(with integral test) SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-FIRE-CO SLC Standby: .30mA mA
Alarm: 7.2mA mA
Addressable SLC Module
SK-MONITOR Standby/Alarm: .375 mA mA mA
SK-MINIMON mA mA
SK-PULL-SA mA mA
SK-PULL-DA mA mA
SK-MONITOR-2 Standby/Alarm: .75 mA mA mA
SK-MON-10 Standby/Alarm: 3.5 mA mA mA
SK-CONTROL SLC Standby: .375 mA mA
Alarm: .375 mA mA
Aux Pwr Standby: 1.7 mA mA
Alarm: 7 mA mA
SK-CONTROL-6 SLC Standby: 2.25 mA mA
Alarm: 2.25 mA
Aux Pwr Standby: 8 mA mA
Alarm: 20 mA mA
SK-RELAY Standby/Alarm: .255 mA mA mA
SK-RELAY-6 Standby/Alarm: 1.45 mA mA mA
SK-RELAYMON-2 Standby: 1.3 mA mA
Alarm: 24 mA mA
SK-ZONE Aux Pwr Standby 12 mA mA
Alarm 90 mA mA
SLC Standby/
Alarm .27 mA mA mA
SK-ZONE-6 Aux Pwr Standby 50 mA mA
Alarm 270 mA mA
SLC Standby/Alarm 2 mA mA mA
Table 2.5 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current

13 RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Calculating Current Draw and Standby Battery
SLC Modules
B200SR Sounder Base Aux Pwr Standby: .50 mA mA
Alarm: 35 mA mA
SLC Standby .30 mA mA
B200S Sounder Base Aux Standby .50 mA mA
Alarm (high vol) 35 mA mA
SLC Standby .30 mA mA
B224RB Relay Base Standby/Alarm: 0.5 mA mA mA
RTS151/151 KEY Alarm: 7.5 mA mA
RA100Z Alarm: 10 mA mA
SLC Isolator Devices
SK-ISO (Isolator Module) Standby/Alarm: .45 mA mA mA
B224BI Isolator Base Standby/Alarm: .5 mA mA mA
Accessories Modules
6815 SLC Loop Expander Standby/Alarm: 78 mA mA mA
RA-2000 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-1000 Remote LCD Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-100 Remote LCD Annunciator Standby: 25 mA mA
Alarm: 50 mA mA
5824 Serial/Parallel I/O Module Standby/Alarm: 45 mA mA mA
5895XL Power Supply Standby/Alarm: 10 mA mA mA
5496 NAC Expander Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches) Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Standby: 35 mA mA
Alarm: 145 mA mA
5880 I/O Module Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface Standby: 0 mA mA
Alarm: 220 mA
(22 mA per relay) mA
ECS-50W or ECS-125W Audio
Amplifier with/without EVS-CE4 Standby: 10 mA mA
Alarm: 10 mA mA
ECS-INT50W Internal Amplifier Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA mA
ECS-VCM Voice Control Module Standby: 70 mA mA
Alarm: 100 mA mA
ECS-NVCM Voice Control Module Standby/Alarm: 59 mA mA mA
ECS-SW24 Switch Expander Standby: 10 mA mA
Alarm: 25 mA mA
ECS-RPU Remote Paging Unit Standby: 70 mA mA
Alarm: 100 mA mA
ECS-LOC Local Operating Console
(includes RA-2000, RVM & SW-24) Standby: 105 mA mA
Alarm: 175 mA mA
Total System Current
Network Cards
Table 2.5 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 14
Calculating Current Draw and Standby Battery Before You Begin Installing
2.6.4 Current Draw Worksheet for SD SLC Devices
For each RPS-1000* in the installation, use this worksheet in Table 2.6 to determine current requirements during alarm/battery standby
operation. See individual FACP manual for maximum number of devices.
SK-NIC Network Interface Card Standby/Alarm: 21 mA mA mA
SK-FML Fiber Optic Multi Mode Standby/Alarm: 53 mA mA mA
SK-FSL Fiber Optic Single Mode Standby/Alarm: 79 mA mA mA
Wireless Modules
SK-WGI Wireless Gateway Max current using ext supply 40 mA mA mA
Max current SLC Power 24 mA mA mA
Total System Current
Auxiliary Devices2
IPDACT-2 IP Communicator Standby: 93 mA mA
Alarm: 136 mA mA
IPDACT-2UD IP Communicator Standby: 98 mA mA
Alarm: 155 mA mA
CELL-MOD/CELL-CAB-SK Standby: 55 mA mA
Alarm: 100 mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Auxiliary Devices Current
Notification Appliance Circuits
5495/5499 Power Supply 24 VDC One input circuit: 15 mA mA
Both input circuits: 30 mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
Notification Appliances Current mA
Total current ratings of all devices in system (line A + line B + C) mA mA
Total current ratings converted to amperes (line D x .001): A A
Number of standby hours: H
Multiply lines E and F. Total standby AH AH
Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
Multiply lines E and H. Total alarm AH AH
Add lines G and I.3Total ampere hours
required AH
Table 2.5 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
Table 2.6 Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
For each device use this formula: This column X This column = Current per number of devices.
RPS-1000 Intelligent Power
Module (Current draw from
battery)
1* Standby 40 mA 40 mA
Alarm: 160 mA 160 mA
Additional RPS-1000
(Daisy-chained to this module) (7 max.) Standby 10 mA mA
Alarm: 10 mA mA

15 RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017
Before You Begin Installing Calculating Current Draw and Standby Battery
SD500-AIM Standby/Alarm: .55 mA6mA mA
SD500-MIM mA mA
SD500-PS mA mA
SD500-ARM mA mA
SD505-HEAT mA mA
SD505-PHOTO mA mA
SD500-ANM Aux. Pwr Standby: 8 mA mA
Alarm: 60 mA mA
SLC Standby/Alarm: .55 mA mA mA
SD500-SDM SLC Standby/Alarm: .55 mA mA mA
Aux. Pwr Standby: 20 mA mA
Alarm: 106 mA mA
SLC Accessory Base
SD505-6RB Standby/Alarm: .082 mA mA mA
SD505-6SB Aux. Pwr Standby: 1 mA mA
Alarm: 32 mA mA
SLC Standby/Alarm: .082 mA mA mA
SD505-DUCTR Aux. Pwr Standby: 20 mA2mA
Alarm: 62 mA2mA
SLC Standby/Alarm: .5 mA mA mA
SD505-DTS-K None, included with SD505-DUCTR worst case.
SD505-DUCT SLC Standby/Alarm .5 mA mA mA
SLC Isolator Devices
SD505-LIM Standby/Alarm .092 mA mA mA
SD505-6IB
Accessories Modules
5815XL SLC Expander Standby/Alarm: 55 mA mA mA
RA-2000 Remote LCD
Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-1000 Remote LCD
Annunciator Standby: 20 mA mA
Alarm: 25 mA mA
RA-100 Remote LCD
Annunciator Standby: 25 mA mA
Alarm: 50 mA mA
5824 Serial/Parallel Printer
Interface Module Standby/Alarm: 45 mA mA mA
5496 NAC Expander Standby/Alarm: 10 mA mA mA
RPS-1000 Power Supply Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches) Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Standby: 35 mA mA
Alarm: 145 mA mA
5880 LED I/O Module Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface Standby: 0 mA mA
Alarm: 220 mA (22 mA per relay) mA
Table 2.6 Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current

RPS-1000 / RPS-1000B Manual - P/N 151153:N 08/09/2017 16
Calculating Current Draw and Standby Battery Before You Begin Installing
**If you are using door holders, you do not need to consider door holder current for alarm/battery standby, because power is removed
ECS-VCM Voice Control Module Standby: 70 mA mA
ECS-NVCM Network Voice
Control Module Standby/Alarm: 59 mA mA mA
ECS-SW24 Switch Expander Standby: 10 mA mA
Alarm: 25 mA mA
ECS-50W or ECS-125W Audio
Amplifier with/without ECS-CE4 Standby: 10 mA mA
Alarm: 10 mA mA
ECS-INT50W Internal Amplifier Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA mA
ECS-RPU Remote Paging Unit Standby: 70 mA mA
Alarm: 100 mA mA
ECS-LOC Local Operating
Console (includes RA-2000,
RVM & SW-24)
Standby: 105 mA mA
Alarm: 175 mA mA
ECS-DUAL50W Dual Voice Amp Standby/Alarm: 10 mA mA mA
ECS-50WBU Back-Up Amplifier Standby/Alarm: 10 mA mA mA
Network Cards
SK-NIC Network Interface Card Standby/Alarm: 21 mA mA mA
SK-FML Fiber Optic Multi Mode Standby/Alarm: 53 mA mA mA
SK-FSL Fiber Optic Single Mode Standby/Alarm: 79 mA mA mA
A Total System Current
Auxiliary Devices Refer to devices manual for current rating.
IPDACT-2 IP Communicator Alarm: 136 mA mA
Standby: 93 mA mA
IPDACT-2UD IP Communicator Alarm: 155 mA mA
Standby: 98 mA mA
CELL-MOD/CELL-CAB-SK Standby: 55 mA mA
Alarm: 100 mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
B Auxiliary Devices Current
Notification Devices Refer to devices manual for current rating.
5495/5499 Power Supply 24 VDC One input circuit: 15 mA mA
Both input circuits: 30 mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
C Notification Appliances Current mA
D Total current ratings of all devices in system (line A + line B + C) mA mA
E Total current ratings converted to amperes (line D x .001): A A
F Number of standby hours H
G Multiply lines E and F. Total standby AH AH
H Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
I Multiply lines E and H. Total alarm AH AH
J Add lines G and I. Total ampere hours required AH
Table 2.6 Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device Standby
Current Alarm Current
