INSTALLATION INSTRUCTIONS
62-2022-05
Wireless Repeater for
TB7200/7600 Series
Wireless Thermostats
APPLICATION
The TB-RP5000W ZigBee®wireless repeater is designed for use
with Honeywelll TB7200 and TB7600 Series wireless thermostats.
The repeater is a low cost communication component for use when
some remote thermostats are too far from the main mesh of a
Honeywell device cluster and cannot communication with a
WEBs AX controller with a wireless communication card
(TB-VWG-APP-1014).
The additional repeater(s) will enable the remote thermostat(s) to
establish communication and will act as bridge(s) to the main mesh.
The repeater(s) can typically be installed where most convenient.
Either on a wall or even in a suspended ceiling space if required.
More Information
We recommend downloading the integration reference document and if installing thermostats with occupancy sensor
covers, then also downloading the PIR Application Guide before you begin installation. All documentation is available
on http://customer.honeywell.com.
• Wireless Installation and Integration Reference Guide for TB7200 and TB7600 Thermostats
(Form No. 63-4522).
• PIR Application Guide for TB7200 and TB7300 Series Thermostats (Form No. 63-4526).
• PIR Application Guide for TB7600 Series Thermostats (Form No. 63-4525).
Fig. 1. Typical application for a TB-RP5000W
HONEYWELL THERMOSTAT(S)
MAIN MESH CLUSTER
NETWORK
FIELD WIRING
ELIMINATED
MESH TOPOLOGY
WIRELESS NETWORK
TB-RP5000W
REPEATER
REMOTE HONEYWELL
THERMOSTAT(S) CLUSTER
M32554

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
62-2022—05 2
INSTALLATION
CAUTION
• Electronic controls are static sensitive devices. Discharge yourself properly before manipulation and
installing the Repeater.
• Short circuit or wrong wiring may permanently damage the thermostat or the equipment.
Mounting Guidelines
• Wall surface must be flat and clean.
Repeater Installation
1. Open up by pulling on the bottom side of Repeater. (Fig. 2)
2. Remove wiring terminals.
3. Open the Repeater PCB to the left by pressing the PCB
retaining tabs. (Fig. 3)
4. Pull cables 6 inches out of the wall.
5. Thread cable through the central hole of the base.
6. Align the base and mark the location of the two mounting
holes on the wall. Install proper side of base up.
7. Install anchors in the wall.
8. Insert screws through the mounting holes on each side of
the base and mount base on wall. (Fig. 3)
9. Gently swing back the circuit board on the base and push
on it until the tabs lock it.
10. Strip each wire 1/4 inch.
11. Insert wires for 24 Vac power into terminals.
12. Gently push back excess cable into hole.
13. Install wiring terminal block. (Fig. 4)
14. Reinstall the cover (top first).
15. Install security screw.
M16985
Fig. 2. Removing cover.
PCB
RETAINING
TABS
PCB
RETAINING
TABS
M21301
Fig. 3. Location of PCB retaining tabs and
mounting screws.
M16990
3 POLE
CONNECTOR
Fig. 4. Re-install terminal block.

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
362-2022—05
BASIC INITIAL DESIGN AND DEPLOYMENT
CONSIDERATIONS
Proper design considerations need to be addressed prior to any installation of a WEBs-AX controller with a the wireless
communication card (TB-VWG-APP-1014) and related wireless thermostats.
1. To properly avoid network interference with 802.11 Wi-Fi devices in the 2.4GHz spectrum range, Honeywell
recommends the use of 802.15.4 channels 15 or 25 only. 802.11 Wi-Fi transmissions overlap and may interfere
with other channel selection allowed by 802.15.4 (Channels 11 to 26).
2. Maximum distance between each node (thermostat or repeater) should be:
•Clear line of sight distance between 2 nodes should be under 100 feet (30M)
•Non-line of sight distance for typical drywall partitions made with metal stud frame should be under 30 feet
(10M)
3. Ensure that the minimum distance between any Honeywell ZigBee node and any Wi-Fi devices (wireless routers,
wireless adapters, lap-tops using wireless networks, etc.) is at least 3 feet (1 M) and preferably 10 feet (3 M) or
more.
4. Ensure that at least one thermostat is within 30 feet of the WEBs-AX controller with wireless communication card
for every cluster of 10 thermostats installed.
5. Always try to locate the WEBs-AX controller near the center of all associated wireless thermostats, if possible.
6. Always try to locate the WEBs-AX controller near or in line of sight to as many wireless thermostats as possible.
7. Try to avoid metal, brick walls or concrete obstructions between wireless devices as much as possible.
8. Make sure the antenna on the WEBs-AX controller is always perpendicular to the floor.
9. Avoid placing the WEBs-AX controller and thermostats near metal or enclosed in metal boxes. If the WEBs-AX
controller needs to be installed inside a metal cabinet, use the remote antenna accessory (TB-RA-1014).

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
62-2022—05 4
TB-RP5000W Deployment Considerations
When Honeywell wireless thermostat cannot be discovered or added to a WEBs-AX controller database due to
distance, the use of repeaters to bridge communication back to the WEBs-AX controller is necessary.
The number of repeater(s) necessary depends on how many devices are not able to join the WEBs-AX controller and
how they are organized and distanced from each other.
• Clear line of sight distance between 2 nodes should be under 100 feet (30 M)
• Non line of sight distance for typical wall gypsum partitions made with metal stud frame should be under 30 feet
(10M)
If a single thermostat is too far away and cannot join the main network a single repeater may be used (Fig. 5).
Fig. 5. Single remote thermostat
If a single thermostat is too far away and cannot join the main network with a single repeater, multiple repeaters can be
used to increase the covered communication distance to the required coverage expected (Fig. 6).
Fig. 6. Single remote thermostat with multiple repeaters
If two or more thermostats are too far away and cannot join the main network a single repeater may be used as long as
the cluster of devices are at recommended distances for the main network deployment (Fig. 7).
Fig. 7. Two or more remote thermostats
HONEYWELL THERMOSTAT(S)
MAIN MESH CLUSTER
TB-RP5000W
REPEATER
M32555
ALL DISTANCES
LINE OF SIGHT MAXIMUM 100 FEET (30 M)
THROUGH PARTITIONS MAXIMUM 30 FEET (31 M)
REMOTE
HONEYWELL
THERMOSTAT
TB-RP5000W REPEATER(S)
(MORE THAN TWO
CAN BE USED)
M32556
ALL DISTANCES
LINE OF SIGHT MAXIMUM 100 FEET (30 M)
THROUGH PARTITIONS MAXIMUM 30 FEET (31 M)
REMOTE
HONEYWELL
THERMOSTAT
TB-RP5000W
REPEATER
HONEYWELL THERMOSTAT(S)
MAIN MESH CLUSTER
M32557
ALL DISTANCES
LINE OF SIGHT MAXIMUM 100 FEET (30 M)
THROUGH PARTITIONS MAXIMUM 30 FEET (31 M)
TB-RP5000W REPEATER
(MORE THAN ONE CAN BE USED)
HONEYWELL THERMOSTAT(S)
MAIN MESH CLUSTER
REMOTE HONEYWELL
THERMOSTAT(S) CLUSTER

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
562-2022—05
REPEATER STATUS LED
IMPORTANT
Be sure all thermostats/repeaters connected to a WEBs-AX controller have the same PAN ID and Channel as
the WEBs-AX wireless communication card (TB-VWG-APP-1014).
Table 1. Repeater Wireless Adapter LED Status Indicators
Table 2. System Troubleshooting Recommendations
STATUS DISPLAY INSTRUCTIONS
The repeater features a two-line, eight-character display.
When left unattended after configuration, the repeater will display its currently assigned
communication address.
1 x 200ms short blink Power on
2 x 200ms short blinks Power on and adapter communicating with repeater base
3 x 200ms short blinks Power on, adapter communicating with repeater base and there is connectivity to wireless
network
4 x 200ms short blinks Power on, adapter communicating with repeater base, connectivity to wireless network
and WEBs-AX controller is communicating with wireless repeater
4 x 200ms short blinks and
1 x 1500ms long blink
Power on, adapter communicating with repeater base, connectivity to wireless network
and WEBs-AX controller is communicating with wireless repeater
1. If a repeater is not detected by the WEBs-AX controller, verify that the LED is blinking at least 4 times. If it is only
blinking twice, ensure that the PAN ID and Channel of the thermostat and repeater are the same as the
WEBs-AX controller it must communicate with.
2. When commissioning a network, use channels 15 or 25. Alternate these channels between floors.
3. If a particular repeater or thermostat refuses to join the network and cannot be seen by the WEBs-AX controller,
move the device closer to the WEBs-AX controller until it has joined the network and it is added to the database.
It can then be re-located to its original position.
M16986

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
62-2022—05 6
INSTALLER CONFIGURATION PARAMETER MENU
Local configuration:
1. Remove the repeater cover.
2. To enter configuration mode, press and hold the left button for 8 seconds.
3. Press the left button repeatedly to scroll between all the available parameters.
4. Use the (up/right) and (down/middle/center) key to change the parameter to the desired value.
5. To acknowledge and save the new value, press the Left button again.
6. The next listed parameter is now displayed.
Table 3. Configuration Buttons Interface
Table 4. Configuration Parameters
Left •Enters the configuration mode. Press and hold for 8 seconds
•Pressing repetitively will scroll all available parameters one by one
Middle/Center Adjust/rotate parameter value down
Right Adjust/rotate parameter value up
Configuration
parameters Default value Significance and adjustments
Com Addr Repeater networking address
Default value = 254
Range is: 0 to 254
Valid range is 0 to 254. Each device on the network must have a
unique com address.
PAN ID Personal Area Network
Identification
Default value = 0
Range is: 0 to 500
This parameter is used to link specific thermostats or repeaters to a
single specific Honeywell WEBs controller with a wireless
communication card. For every thermostat or repeater reporting to a
wireless communication card be sure you set the SAME PAN ID
value both at the gateway and the wireless device(s).
The default value of 0is NOT a valid PAN ID. The valid range of
available PAN ID is from 1 to 500
Channel Channel selection
Default value = 10
Set to: 15 or 25
Range is: 10 to 26
This parameter is used to link specific thermostats or repeaters to
specific Honeywell wireless communication card. For every
thermostat or repeater reporting to a Honeywell WEBs controller with
a wireless communication card be sure you set the SAME channel
value both at the gateway and the wireless device(s).
Honeywell recommends using only the following channels:
15 or 25.
The default value of 10 is NOT a valid channel. Although the valid
range of available channels is from 11 to 26 use only channel 15 or
25 to avoid interference with other wireless devices.

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
762-2022—05
SPECIFICATIONS
Thermostat Compatibility: TB7200 and TB7600 Series wireless thermostats
Network Protocol: ZigBee wireless mesh
WEBs-AX Controllers: Compatible with WEB-2xx, WEB-6xx, and WEB-7xx
Platform:
WEB-2xx and WEB-6xx - WEBStation-AX 3.0 or later
WEB-7xx - WEBStation-AX 3.5 or later
Repeater power requirements: 19-30 Vac 50 or 60 Hz; 2 VA Class 2
Operating conditions:
0 C to 50 C (32 F to 122 F)
0% to 95% R.H. non-condensing
Storage conditions:
-30 C to 50 C (-22 F to 122 F)
0% to 95% R.H. non-condensing
Wire gauge: 18 gauge maximum, 22 gauge recommended
Dimensions: See Fig. 8
Fig. 8. Dimensions in inches (mm).
Approximate shipping weight: 0.75 lb (0.34 kg)
Agency Approvals all models:
UL: 873 (US) and CSA C22.2 No. 24 (Canada), File E27734 with CCN XAPX (US) and XAPX7 (Canada)
Industry Canada: ICES-003 (Canada)
FCC: Compliant to CFR 47, Part 15, Subpart B, Class A (US); Compliant to Part 15, Subpart C
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
CE: EMC Directive 89/336/EEC (Europe Union)
C-Tick: EN55022:2006, IEC 61326-1:2005
5
(125)
3-2/5 (86)
1-3/20 (29)
M16984

WIRELESS REPEATER FOR TB7200/7600 SERIES WIRELESS THERMOSTATS
Automation and Control Solutions
Honeywell International Inc.
1985 Douglas Drive North
Golden Valley, MN 55422
customer.honeywell.com
® U.S. Registered Trademark
© 2015Honeywell International Inc.
62-2022—05 M.S. Rev. 01-15
Printed in United States
By using this Honeywell literature, you agree that Honeywell will have no liability for any damages arising out of your use or modification
to, the literature. You will defend and indemnify Honeywell, its affiliates and subsidiaries, from and against any liability, cost, or damages,
including attorneys’ fees, arising out of, or resulting from, any modification to the literature by you.
