Honeywell HD3C User manual

Document 800-00788 – Rev C – 07/08
User Guide
3 Inch Dome Camera
NTSC / PAL
HD3C, HD3CB HD3CX, HD3CBX
HD3D, HD3DB HD3DX, HD3DBX
HD3CH, HD3CHB HD3CHX, HD3CHBX

2
Revisions
Issue Date Revisions
A 09/07 New document.
B 10/07 Updated Figure 2, Figure 3, and Figure 4.
Added metric screws to surface and flush
mount installations.
C 07/08 Updated regulatory to Class B.

Document 800-00788 Rev C 3
07/08
Warnings
Installation and servicing should be performed only by qualified and experienced
technicians to conform to all local codes and to maintain your warranty.
WARNING! The Use of CSA Certified/UL Listed Class 2 power adapters is
required to ensure compliance with electrical safety standards.
WEEE (Waste Electrical and Electronic Equipment). Correct disposal of this
product (applicable in the European Union and other European countries with
separate collection systems). This product should be disposed of, at the end of its
useful life, as per applicable local laws, regulations, and procedures.
Explanation of Graphical Symbols
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER.
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF
ELECTRIC SHOCK IS PRESENT
WITHIN THE UNIT.
THIS SYMBOL INDICATES THAT
IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS
ACCOMPANY THIS UNIT.
CAUTION

4
FCC Compliance Statement
Information to the User: This equipment has been tested and found to comply with
the limits for a Class B digital device. Pursuant to Part 15 of the FCC Rules, these
limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or a radio/TV technician for help.
Caution Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
Manufacturer’s Declaration of Conformance
The manufacturer declares that the equipment supplied with this guide is compliant
with the essential protection requirements of the EMA directive 89/336/EEC and the
Low Voltage Directive LVD 73/23 EEC, conforming to the requirements of standards
EN 55022 for emissions.

Document 800-00788 Rev C 5
07/08
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Unpack Everything . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cautions and Operating Notes . . . . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Removing the Dome Cover . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mounting the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Preparing the Mounting Surface
(Surface or Flush Mount) . . . . . . . . . . . . . . . . . . . . 10
Connecting the Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4S Electrical Junction Box . . . . . . . . . . . . . . . . . . . 12
Surface Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Flush Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Adjusting the Camera Position. . . . . . . . . . . . . . . . . . . . . . . 15
Optional Camera Settings . . . . . . . . . . . . . . . . . . . 16
Attaching the Dome Cover. . . . . . . . . . . . . . . . . . . . . . . . . . 18
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Product Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Warranty and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cable Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6

Document 800-00788 Rev C 7
07/08
Introduction
The unobtrusive, compact design of the HD3 Series 3 Inch Dome Camera
(HD3) is ideal for indoor installations in commercial and residential
environments.
Before You Begin
Unpack Everything
Check that the items received match those listed on the order form and
packing slip. The HD3 packing box should include, in addition to this Install
Guide:
• One fully assembled camera
• One hardware kit
• One 2nd video monitor output cable
• One mounting template
If any parts are missing or damaged, contact the dealer you purchased the
camera from or call Honeywell Customer Service (see p. 27 for contact
information).
Please read this guide carefully before you
install the HD3 Series 3 Inch Dome Camera.
Keep this guide for future reference.

8
Cautions and Operating Notes
Power Supply This dome camera can operate on 24 VAC or 12 VDC.
Operating Conditions Avoid:
• Viewing bright objects (example, light fixtures) for extended periods.
• Operating or storing the unit in the following locations:
• Extremely humid, dusty, hot/cold environments (where the
operating temperature is outside the recommended range of
14°F to 122°F [-10°C to +50°C])
• Close to sources of powerful electromagnetic radiation, such as
radio or TV transmitters
• Close to fluorescent lamps or objects reflecting light
• Under unstable light sources (may cause flickering)

Document 800-00788 Rev C 9
07/08
Installation
The HD3 is a fully-integrated enclosure with camera and lens.
Note See Figure 7 for an explanation of the camera board settings.

10
Removing the Dome Cover
1. Gently turn the dome cover counter-clockwise (#5 on Figure 1) to
unlock, and pull free of the housing. If required, loosen the security
screw (#2) first.
2. Remove the inner liner (#4) by gently pulling it free of the two notches
(#3) in the housing (#1). Set the dome (and liner) aside.
Figure 1 Dome Cover Removal
1
5
4Legend
1Camera housing
2Security screw
3Notches (x2)
4Inner liner
5Dome cover
3
2

Document 800-00788 Rev C 11
07/08
Mounting the Camera
The HD3 can be surface or flush mounted to a ceiling or wall.
Preparing the Mounting Surface
(Surface or Flush Mount)
1. Place the camera base (or the mounting template supplied on
page 26) on the mounting surface and mark the holes as shown
below.
2. Drill the holes, then insert the screw anchors into the holes.
Camera base

12
Connecting the Wiring
Follow Figure 2 to connect the video output connector (#5) and 24 VAC/12
VDC power connector (#6).
Figure 2 Wiring
Legend
1Conduit hole used for surface
run power/video connector
2Camera housing
3Focus lever (top)
4Zoom lever (bottom)
5Video output connector
624 VAC/12 VDC power input
connector
1
2
3
4
5
6

Document 800-00788 Rev C 13
07/08
4S Electrical Junction Box
1. Use the adapter plate to cover ceiling or wall imperfections around the
electrical box opening (see Figure 3). Secure the adapter plate to the
electrical box using appropriate screws (not supplied).
2. If necessary, tuck the Video/Power and BNC cabling into the notch.
3. Secure the camera base with the three screws, supplied.
Figure 3 4S Electrical Junction Box Installation
4S electrical box (not supplied)
Adapter plate
HD3 base
Screws (x3, supplied)
Mounting screws, not supplied
Notch to hold
Video/Power/
BNC cabling

14
Surface Mount
1. For adapter plate installations — for example, when mounting to a
ceiling tile — secure the skirt with M4 screws of an appropriate length
(not supplied), as shown in Figure 4).
When not using the adapter plate, secure the skirt to the ceiling or wall
using M4 screws of an appropriate length (not supplied) for your
mounting surface. The screws should be capable of holding at least
twice the weight of the camera.
2. If necessary, tuck the Video/Power and BNC cabling into the notch.
3. Secure the camera base with M3 screws (supplied).
Figure 4 Surface Mount Installation
Wiring, cabling
M3 screws, supplied
Skirt
Base
Notch to hold Video/
Power/BNC cabling
Screws, not supplied

Document 800-00788 Rev C 15
07/08
Flush Mount
1. Follow Figure 5 to mount the HD3 flush to a ceiling or wall.
2. If necessary, tuck the Video/Power and BNC cabling into the notch.
3. For adapter plate installations, secure the base with M3 screws of a
length appropriate to your installation (not supplied).
When not using the adapter plate, use M3 screws of a length
appropriate for your mounting surface (not supplied). The screws
should be capable of holding at least twice the weight of the camera.
Figure 5 Flush Mount
Adapter plate (for mounting
to ceiling tile)
Base
M3 screws, not supplied
Notch to hold Video/
Power/BNC cabling

16
Adjusting the Camera Position
Figure 6 Camera Position Adjustment
While monitoring the video signal:
1. If required, loosen the screw that locks the gimbal assembly in place
(see Figure 7).
2. Adjust the camera carrier to the desired view.
3. Tighten the screws to lock the gimbal assembly in place.
Caution Do not turn the lens more than 360° as this may cause the
internal cables to twist and disconnect or break.
Legend
1Focus lever (top) sets focus
2Zoom lever (bottom) sets
focal length
ATilt rotation
BHorizontal rotation
CPan rotation
1
2
A
B
C

Document 800-00788 Rev C 17
07/08
Optional Camera Settings
Figure 7 shows the location of the camera adjustment switches on the
camera board. Their functions are described after Figure 7.
Figure 7 Camera Adjustment Functions
1234 567 8
Legend
1LEVEL adjustment pot
(Iris level)
2V Phase adjustment pot
(24 VAC only)
3Mode setting DIP switches
(see page 18)
4Monitor out
5Camera mounting holes (x3)
6Setscrew
12
3
4
5
= ON
= OFF
+–
HL
6

18
Note Please use the supplied DC Iris and Line lock adjustment tool
to adjust picture brightness and phase adjustment.
Picture Brightness Use the LEVEL screw (#1) to compensate for the iris
level. L(low) makes the picture darker. H(high) makes the picture brighter.
Phase Adjustment Use the V Phase Adjustment Pot (#2) to adjust the
phase difference between cameras. Make sure Switch 7 is ON to activate
the Line lock function (AC operation only).
DIP Switches Depending on your camera model, set the DIP switches
(#3) to activate or deactivate the following functions:
Switch High Res + TDN High Res Standard Res
1DC/AES DC/AES DC/AES
2AWB/ATW AWB/ATW AWB/ATW
3BLC ON/OFF BLC ON/OFF BLC ON/OFF
4AGC ON/OFF AGC ON/OFF AGC ON/OFF
5TDN Not used FLK
6FLK ON/OFF FLK ON/OFF LL ON/OFF
7LL ON/OFF LL ON/OFF Not available
8Not used Not used Not available

Document 800-00788 Rev C 19
07/08
Attaching the Dome Cover
When you are satisfied with your field of view and image settings, follow
Figure 8 to attach the dome cover:
1. Use a soft, lint-free cloth to wipe the dome cover clean and remove
fingerprints.
2. Attach the inner liner (#3) to the base until the liner clicks into place.
3. Align the dome cover (#5) with the three dome tabs (#4) on the unit.
4. Turn the dome gently clockwise until it locks in place.
5. If desired, secure the dome to the base with the security screw.
Figure 8 Dome Installation
1
3
4
2
Legend
1Camera housing
2Security screw
3Inner liner
4Dome tabs (x3)
5Dome cover
5

20
Routine Maintenance
• The dome cover is an optical part. Use a soft, dry cloth to remove any
fingerprints or dust.
• Clean the camera housing with a soft, dry cloth. For more stubborn
stains, use a cloth dampened with a small quantity of neutral
detergent, then wipe dry.
Caution Do not use volatile solvents such as alcohol, benzene or
thinners to avoid damaging the surface finish.
