Honeywell
T8602C Chronotherm® IV
Deluxe Programmable
Thermostats
INSTA ATION INSTRUCTIONS
APP ICATION
The T8602 Chronotherm ® IV Deluxe Programmable Thermostat provi es electronic control of 24 Vac single-stage
heating an cooling systems or 750 mV heating system. Refer to Table 1 for a general escription of the thermostat. All
T8602 thermostats are powere by batteries.
Table 1. Description of T8602 Thermostats.
T8602 System Changeover System Selection Fan Selection Comments
C Heat-Cool Manual Heat-Off-Cool On-Auto System an fan selections are ma e on
keyboar .
® MERCURY NOTICE
If this control is replacing a control that contains
mercury in a seale tube, o not place your ol
control in the trash. Dispose of properly.
Contact your local waste management authority
for instructions regar ing recycling an the
proper isposal of the ol control.
INSTA ATION
When Installing this Product...
1. Rea these instructions carefully. Failure to follow
the instructions can amage the pro uct or cause
a hazar ous con ition.
2. Check the ratings given in the instructions an on
the pro uct to make sure the pro uct is suitable for
your application.
3. Installer must be a traine , experience service
technician.
4. After completing installation, use these instructions
to check out the pro uct operation.
ocation
Install the thermostat about 5 ft (1.5m) above the floor in
an area with goo air circulation at average temperature.
See Fig. 1.
Do not install the thermostat where it can be affecte by:
— rafts, or ea spots behin oors an in corners.
— hot or col air from ucts.
— ra iant heat from sun or appliances.
— conceale pipes an chimneys.
— unheate (uncoole ) areas such as an outsi e wall
behin the thermostat.
Wallplate Installation
The thermostat can be mounte horizontally on the wall
or on a 2 in. x 4 in. (50.8 mm x 101.6 mm) wiring box.
Position wallplate horizontally on the wall or on a
2 in. x 4 in. (50.8 mm x 101.6 mm) wiring box.
® U.S. Registere Tra emark
Copyright © 2003 Honeywell • • All Rights Reserve 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
Fig. 1. Typical location of thermostat.
1. Position an level the wallplate (for appearance
only). The thermostat functions correctly even
when not level.
2. Use a pencil to mark the mounting holes.
See Fig. 2.
3. Remove the wallplate from the wall an rill two
3/16 inch (76 mm) holes in the wall (if rywall) as
marke . For firmer material such as plaster, rill
two 7/32 inch (5.56 mm) holes. Gently tap anchors
(provi e ) into rille holes until flush with wall.
4. Position the wallplate over the holes, pulling wires
through the wiring opening.
5. Loosely insert the mounting screws into the holes.
6. Tighten mounting screws.
MOUNTING
HOLES
Fig. 2. Mounting the wallplate.
WIRING
All wiring must comply with local electrical co es an
or inances. Refer to Fig. 3 an 6 for typical hookup. A
letter co e is locate near each terminal for i entification.
A CAUTION
Electrical Hazard.
Can cause electric shock or equipment
damage.
Disconnect power before wiring.
1. Loosen the terminal screws on the wallplate an
connect the system wires. See Fig. 7.
IMPORTANT
Use 18 g uge, color-coded thermost t c ble for
proper wiring.
2. Securely tighten each terminal screw.
3. Push excess wire back into the hole.
4. Plug the hole with nonflammable insulation to
prevent rafts from affecting the thermostat.
THERMOSTAT
K
L1
(HOT)
L2
TRANSFORMER
1 POWER SUPPLY. PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED. M10409
Fig. 3. Typical hookup in heat application.
69-1670 2

T8602C CHRONOTHERM®IV DELUXE PROGRAMMABLE THERMOSTATS
THERMOSTAT THERMOSTAT
TRANSFORMER
A p o w e r s u p p l y . p r o v id e d is c o n n e c t m e a n s a n d o v e r l o a d Fig. 6 T8602 typical millivoltage heating circuit.
PROTECTION AS REQUIRED.
A CAN BE USED FOR CHANGEOVER VALVE ON SINGLE-STAGE HEAT
PUMP SYSTEMS.
A AVAILABLE ON SELECT MODELS. OT WIRES MUST HAVE A
SEPARATE CABLE FROM THE THERMOSTAT CABLE. Min34?A
Fig. 4. Typical hookup in heat and cool system
with one transformer.
FOR WRAPAROUND
INSERTION STRIP
7/16 IN. (11 MM).
FOR STRAIGHT INSERTION
STRIP 5/16 IN. (8 MM).
M4826
Fig. 7. Correct wiring technique.
THERMOSTAT
ky
?
O B
p ? ^
W
?
J ____
__ 5 4
COMPRESSOR
CONTACTOR COOL DAMPER
FAN
RELAY
^uQti
- COOlINi
AHEAT
RELAY
HEAT
DAMPER
A
COOLING
TRANSFORMER
o u td o o r
t e m p e r a t u r e
SENSOR
K
L1
(HOT)
HEATING
TRANSFORMER
RC
L2
A POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
A JUMPER RC TERMINAL TO R TERMINAL WHEN INSTALLED ON A
ONE TRANSFORMER SYSTEM.
A CAN BE USED FOR CHANGEOVER VALVE ON SINGLE-STAGE HEAT
PUMP SYSTEMS.
A AVAILABLE ON SELECT MODELS. OT WIRES MUST HAVE A
SEPARATE CABLE FROM THE THERMOSTAT CABLE.
A T8600D MODELS REQUIRE POWER TO R TERMINAL AT ALL TIMES.
M10348
Fig. 5. Typical hookup in heat and cool system
with two transformers.
Mounting Thermostat
1. Engage tabs at the top of the thermostat an
wallplate. See Fig. 8.
2. Press lower e ge of case to close an latch.
NOTE: To remove the thermostat from the wall, first pull
out at the bottom of the thermostat; remove top
last.
Fig. 8. Mounting thermostat on wallplate.
3 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
Using Thermostat Keys
The thermostat keys are use to:
• set current ay an time,
• program times an setpoints for heating an cooling,
• temporarily overri e program temperatures,
• isplay present setting,
• configure Installer Setup,
• check Self-Test,
• isplay out oor temperature (select mo els),
See Fig. 9 for location of the keys.
NOTE: Always press the keys with your fingertip or
similar blunt tool. Sharp instruments like a pen
or pencil point can amage the keyboar .
SET CURRENT
DAY AND TIME
RETURN TO
NORMAL
ENTER
INDEFINITE
OR TIMED
HOLD MODE
DECREASE TEMPERATURE
SETTING OR SCROLL
BACKWARD THROUGH
INSTALLER SETUP OPTIONS
DISPLAY INFORMATION
SUCH AS PRESENT
SETTINGS AND OUTDOOR
TEMPERATURE
SET SLEEP TIMES
AND SETPOINTS
SYSTEM SWITCH
— FAN SWITCH
INSTALLER SETUP AND SYSTEM TEST SETPOINTS M14880
Fig. 9. T8602D key locations and descriptions.
SETTINGS
System and Fan Settings
The system efault setting is Heat an the fan efault
setting is Auto. Use the System an Fan keys to change
the settings. See Fig. 10.
System settings control the thermostat operation:
Heat: The thermostat controls the heating.
Off: Both the heating an cooling are off.
Cool: The thermostat controls the cooling.
Fan settings control the system fan:
On: Fan operates continuously.
Auto: Fan operates with equipment.
Temperature Settings
Refer to Table 2 for the efault program. If the aytime
energy savings perio is not use , press the perio key
(Leave or Return) until the time is blank. See Owner’s
Gui e for complete instructions on changing the
program.
Table 2. Default Program Settings.
Period Time Heat Setpoint Cool Setpoint
Wake 6:00 AM 70°F
(21°C) 78°F (25.5°C)
Leave 8:00AM 62°F
(16.5°C) 85°F (29.5°C)
Return 5:00 PM 70°F
(21°C) 78°F (25.5°C)
Sleep 10:00 PM 62°F
(16.5°C) 82°F (28°C)
Fig. 10. Thermostat System and Fan key locations.
69-1670 4

T8602C CHRONOTHERM®IV DELUXE PROGRAMMABLE THERMOSTATS
FAN OPERATION SWITCH
The thermostat fan operation switch, labele FUEL
SWITCH in Fig. 11 is factory set in the F position. This is
the correct setting for most systems. If your system is an
electric heat system, set the switch to E. The E setting
allows the fan to turn on imme iately with the heating or
cooling in a system where the G terminal is connecte .
Fig. 11. Fan operation switch.
INSTA ER SETUP
NOTE: For most applications, the thermostat factory-
settings o not require changing. Review
factory settings in Table 3 an if no changes are
necessary, go to the Installer Self-Test section.
The Installer Setup is use to customize the thermostat
to specific systems. Some of the options inclu e
temperature isplay an out oor temperature isplay.
Installer Setup numbers are liste in Table 3. The table
inclu es all the configuration options an the factory
settings for the T8602.
A combination of key presses are require to use the
Installer Setup feature:
— To enter the installer setup, press an hol the
information i key with the increase A an
ecrease ▼ keys until the first number is isplaye .
All isplay segments appear for approximately three
secon s before the number is isplaye . See Fig. 12
an 13.
— To a vance to the next Installer Setup, press the
Time A key.
— To change a setting, use the increase A or
ecrease ▼ key.
— To scroll the Installer Setup numbers backwar , press
the Time V key.
— To exit the Installer Setup, press Run Program.
Tem porary Setting
Recovery
Hol for z
DPM
MonTueW e T hu Fri SatSu n Repl Batt Room
Wake Leave Return Sleep DST T H e a t Cool A
*
Off
Cool
Fig. 12. Display of all CD segments.
Fig. 13. Display of Installer Setup number and
setting.
System
Heat
Wait
M19014
M14618
IMPORTANT
Only configur ble numbers re shown on the
device. Ex mple: If thermost t does not h ve
system key, Inst ller Setup Number 12 will not
be displ yed. Review T ble 3 f ctory-settings
nd m rk ny desired ch nges in the Actu l
Setting column. When Inst ller Setup is com
plete, review the settings to confirm th t they
m tch the system.
5 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
Table 3. Thermostat Installer Setup Options.
Select
Installer Setup
Number (Press
Time A key to
change)
Factory Setting Other Choices (Press A or ▼ key to change) Actual
SettingDisplay Description Display Description
Not Use . 1 thru 3 — — — — —
Heating cycle
rate. 4 6 6—6 cph use for conventional heat 1,3 or 9 1—1 cph use for ra iant floor heat, gravity system
3—3 cph use for hot water
systems or high
efficiency furnaces
9—9 cph use for electric
heat systems
Not Use . 5 thru 12 — — — — —
A aptive
Intelligent
Recovery™
control.
13 0 A aptive Intelligent
Recovery™
control is activate
(system starts
early so setpoint is
reache by start of
program perio ).
1 Conventional recovery
(system starts recovery at
programme time).
Degree
temperature
isplay
14 0 Temperature is
isplaye in °F 1 Temperature is isplaye in °C
Not Use . 15 — — — — —
Clock format. 16 0 12-hour clock
format. 1 24-hour clock format.
Not Use . 17 thru 23 — — — — —
Out oor
temperature
isplay (mo els
with OT
terminals).
24 0 No out oor
temperature is
isplaye .
1 Out oor temperature is
isplaye . Nee s a
C7089B1000 Out oor
Temperature Sensor to
operate.
Not Use . 25 thru 32 — — — — —
Minimum off
time for the
compressor.
33 5 5 minute minimum
off time for the
compressor.
0 thru 4 Minimum number of minutes
(0 thru 5) the compressor is
off between calls for the
compressor.
Temperature
range stops in
heating.
34 90 Highest heating
setpoint setting. 40 to 89 Temperature range (1°F increments) of heating
setpoint settings.
Temperature
range stops in
cooling.
35 45 Lowest cooling
setpoint setting. 46 to 99 Temperature range (1°F increments) of cooling
setpoint settings.
Not Use . 36 — — — — —
69-1670 6

T8602C CHRONOTHERM®IV DELUXE PROGRAMMABLE THERMOSTATS
Table 3. Thermostat Installer Setup Options. (Continued)
Select
Installer Setup
Number (Press
Time A key to
change)
Factory Setting Other Choices (Press ▲ or ▼ key to change) Actual
SettingDisplay Description Display Description
Temperature
isplay
a justment.
37 0 No ifference in
isplaye
temperature an
actual room
temperature.
3 thru -3 1— Display a justs to 1°F
higher than actual room
temperature.
2— Display a justs to 2°F
higher than actual room
temperature.
3— Display a justs to 3°F
higher than actual room
temperature.
-1 —Display a justs to 1 °F
lower than actual room
temperature.
-2—Display a justs to 2°F
lower than actual room
temperature.
-3—Display a justs to 3°F
lower than actual room
temperature.
Furnace Air
Filter Timer. 43 2 90 ays (calen ar ays) 0, 1, 3, 4 0 - off
1 - 30 ays
3 - 180 ays
4 - 365 ays
(Time is counte by calen ar
ays in any mo e.)
Humi ifier Pa
Monitor. 44 0 Off 1,2, 3 1 - 90 ays
2 - 180 ays
3 - 365 ays
(Time is counte by calen ar
ays in heat mo e.)
Ultraviolet (UV)
Air Treatment
System Lamp
Monitor.
45 0 Off 1 1 - 365 ays
(Time is counte by calen ar
ays in any mo e.)
IMPORTANT
Review the settings to confirm th t they m tch
the system. Press Run Progr m to exit the
Inst ller Setup. The thermost t h s s ved the
Inst ller Setup ch nges nd initi ted reset in
order to oper te using the new settings. Be sure
to set the current d y nd time immedi tely.
7 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
Setting Current Day and Time
1. Press Set Current Day/Time.
NOTE: On initial powerup or after an exten e power
loss, 1:00 pm flashes on the isplay until a
key is presse .
1 I B ]
1----------------------------1 S
Daylight
Time " N ^ ‘ =■
..... '
U - I_ l
M14622
il I n i
IT • k lo- i.n n
[Set Current]
Day/Time I =? * -a- e-t-r r n i
| ¡¡¡a - > v ~v|Mon
M14619
2. Press Day until the current ay is isplaye .
4. Press Run Program.
M14623
NOTE: Sun=Sun ay, Mon=Mon ay,
Tue=Tues ay, We =We nes ay,
Thu=Thurs ay, Fri=Fri ay, Sat=Satur ay.
View or Reset Timer Settings
When the thermostat activates a timer, the thermostat
flashes Filter until the timer resets.
.1 ___________ IS 1i.nn
[ Day ruUfM
M14620
3. Press Time A or Time V until the current time is
isplaye .
NOTE: Tapping the Set Current Day/Time changes the
time in one hour increments.
œ:K — B 1
a
G
^ ^ --■ ■■
^^BsëTDavJTimel
C r ih*
M14621
1. Reset the timer by pressing the i key until the
expire timer is isplaye .
o 0
^ 1 1
Filter Days
_
It
M20243
Press the Time A key to reset the timer.
Zin r
_ IU f-i
Filter Days
! i r
M20244
3. Press the Run Program key.
NOTE: If the current time is Daylight Savings Time,
press Daylight Time until DST is isplaye . NOTE: You can view the number of ays remaining at
any time by pressing the i key three or four
times. If more than one timer is active, all active
timers show sequentially when pressing the
i key several times.
69-1670 8

T8602C CHRONOTHERM®IV DELUXE PROGRAMMABLE THERMOSTATS
INSTA ER SYSTEM TEST
Use the Installer System Test to check the thermostat
operation. Refer to Table 4 for a list of the available
system tests.
A CAUTION
Equipment Damage Hazard.
Minimum compressor off-time is bypassed
during Installer System Test.
Avoi cycling compressor quickly.
To start the system test:
Press an hol the increase A an ecrease ▼ keys at
the same time until 10 appears. All segments of the
isplay will be isplaye before the 10 appears.
See Fig. 13 an 14.
Table 4. Tests Available In Installer System Test.
Test
Number System Test Description
10-19 Heating equipment can be turne on an off.
30-39 Cooling equipment can be turne on an off.
40-49 Fan equipment can be turne on an off.
60 0 to
60 19 Keyboar keys test.
WaiflSet Program |Set Day/Time Temporary Setting System
Recovery A M Off
Hol for P M Cool
Days
MonTueWe Thu Fri SatSun Repl Batt Room
Wake Leave Return Sleep DST Heat Cool
M19014
Fig. 14. Display of all CD segments.
M14612
Fig. 15. Display of test number.
Refer to Table 5 for the irections an results of the
specific tests.
NOTE: Press Time A to a vance to the next test an
Time V to go back to the previous test. Press
Run Program to exit the system test.
Table 5. Installer System Test Options.
Keys to
Press Test Number Description
Heating Equipment System Test
Time A 10 Enter heating equipment system test.
A11 Heat comes on. When Installer Setup number 2 is 1, the system fan is also energize .
▼10 Heat an system fan turn off.
Cooling Equipment System Test
Time A 30 Change from heating to cooling equipment system test.
A31 Cool an system fan come on.
▼30 Cool an system fan turn off.
Fan Equipment System Test
Time A 40 Change from cooling to fan equipment system test.
A41 Fan comes on.
▼40 Fan turns off.
Key Operation System Test
Time A 60 2 Change from fan to key operation system test.
NOTE: Press any key an the isplaye numbers change. Press Time V to go to the previous test an Time A to go to
the next test. The Run Program key will not exit this test. Press Time A or Time V an then the
Run Program key to exit.
9 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
THERMOSTAT INFORMATION
1. Press the Time A key to access the thermostat
information. 4. Press the increase A key again to isplay the soft ware revision number.
(Example: 001 = Revision number 1).
M14613
2. Press the increase A key to isplay the pro uction
ate co e. The first two large igits are the month
an the thir igit is the last igit of the year.
(Example: 027 = February 1997).
M14614
3. Press the increase A key again to isplay the soft
ware i entification co e.
(Example: 02 = software ID co e 2).
■ < -/ nri
I I
M14616
Press the increase A key again to isplay the
EEPROM i entification co e.
(Example: 314 = EEPROM ID 314).
-¡>-1 3 n j
1 1 3 II
M14617
6. Press the Run Program key to exit the System
Test. The System Test times out after four minutes
without any key presses.
M14615
CHECKOUT
Outdoor Temperature Sensor
(Select Models)
Allow the out oor temperature sensor to absorb the
out oor air for a minimum of five minutes before taking a
rea ing.
69-1670 10

T8602C CHRONOTHERM®IV DELUXE PROGRAMMABLE THERMOSTATS
TROUB ESHOOTING GUIDE
Table 6. Troubleshooting Guide.
Symptom Possible Cause Action
Display oes not
come on. Thermostat is not being powere . • Check if batteries are present an installe correctly. — If batteries are present an installe correctly, replace
thermostat.
Temperature
isplay is incorrect. Room temperature isplay has been reconfigure . Enter Installer Setup number 37 an reconfigure the isplay.
Thermostat is configure for °F
or °C isplay. Enter Installer Setup number 14 an reconfigure the isplay.
Ba thermostat location. Relocate the thermostat.
Temperature
settings o not
change. (Example:
Cannot set the
heating higher or
the cooling lower.)
The upper or lower temperature
limits were reache . Check the temperature setpoints:
• Heating limits are 40 to 90°F (4.5 to 32°C)
• Cooling limits are 48 to 99°F (7 to 37°C)
The setpoint temperature range
stops were configure . Check Installer Setup numbers 34 an 35 an reconfigure the setpoint stops.
Heating oes not
come on. No power to the thermostat. • Check for 24 Vac between R an W terminals (check for
750 mV on PowerPile® Systems).
— If missing 24 Vac:
— check if the circuit breaker is trippe —reset the circuit
breaker.
— check if the system fuse is blown—replace the fuse.
— check if the power switch on the HVAC equipment is in
the Off position—set to the On position.
— check wiring between thermostat an HVAC
equipment—replace any broken wires an tighten any
loose connections.
— If 24 Vac is present, procee with troubleshooting.
Thermostat minimum off time is
activate . Wait up to five minutes for the system to respon .
System selection is not set to
Heat. Set system selection to Heat.
Heating setpoint is below room
temperature. Check heating setpoint. Set heating setpoint to esire temperature.
Cooling oes not
come on. No power to the thermostat. • Check for 24 Vac between R or RC an Y terminals — If missing 24 Vac:
— check if the circuit breaker is trippe —reset the circuit
breaker.
— check if the system fuse is blown—replace the fuse.
— check if the power switch on the HVAC equipment is in
the Off position—set to the On position.
— check wiring between thermostat an HVAC
equipment—replace any broken wires an tighten any
loose connections.
— If 24 Vac is present, procee with troubleshooting.
Thermostat minimum off time is
activate . • Wait up to five minutes for the system to respon .
• Enter Installer Setup number 33. Reconfigure minimum off
time (if require ).
System selection is not set to
Cool. Set system selection to Cool.
Cool setpoint is above room
temperature. Check cooling setpoint. Set cooling setpoint to esire temperature.
11 69-1670

T8602C CHRONOTHERM®IVDELUXE PROGRAMMABLE THERMOSTATS
Table 6. Troubleshooting Guide. (Continued)
Symptom Possible Cause Action
System on in icator
(flame=heat,
snowflake=cool) is
isplaye , but no
warm or cool air is
coming from the
registers.
Fan operation set for F
(conventional heat) when it
shoul be set for E (electric
heat).
Set Fan Operation switch (Fuel switch).
Conventional heating equipment
turns on the fan when the
furnace has warme up to a
setpoint.
Wait a minute after seeing the on in icator an then check the
registers.
Heating or cooling equipment is
not operating. Verify operation of heating or cooling equipment in self-test.
Out oor tempera
ture not isplaye 3 Option not activate . Enter Installer Setup number 24 an set to 1. Thermostat must
have OT terminals an a C7089B1000 installe .
Out oor
temperature
isplay is incorrecta
Out oor sensor is connecte
incorrectly. Refer to C7089B1000 Installation Instructions an check wiring between the thermostat an sensor.
Wrong sensor. Replace sensor with C7089B1000 Sensor.
Thermostat
backlight appears
im.
Backlight can fa e over the life
of the batteries. • Wait until Replace Battery in icator is illuminate an replace batteries.
• Replace batteries now.
a Select mo els.
Honeywell
Automation and Control Solutions
Honey ell International Inc Honey ell Limited-Honey ell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
M1V 4Z9
69-1670 GH. 1-03 Printe in U.S.A. on recycle
paper containing at least 10%
post-consumer paper fibers. www.honeywell.com/yourhome
