Honeywell 013080 User manual

Operating Instructions
MB TouchScreen ControlPanel
Item no. 013080, 013081
P00471-03-0G0-00 Subject to change
without notice
G121014
2021-06-25
ETSCP.04.0V01.xx

2
Operating Instructions MB TouchScreen ControlPanel
Contens
1. Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Important information on operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 Visual angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Integrated reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. Operating code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1 Code input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.2 Overvoew of levels of authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.3 Variations of the code input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Keypad basic state . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6.1 Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6.2 Operating menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.3 LED indicators ans Buzzer function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7. Area view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7.1 More functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.1.1 Detector groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.1.2 User & Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.1.3 Doorguards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.1.4 Alter times. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.1.5 Event memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.1.6 Clear part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.1.7 Installer information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.1.8 Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.1.9 Activation of access level 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8. Security screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8.1 Filter for view of alarm partitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9. Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
10. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
10.1 Remote parameterisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
11. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
12. Description of function arming/disarming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12.1 Intrusion detection control unit arming/disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12.2 Absence security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12.3 Presence security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
13. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
14. Certifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3
1. Safety notes
Read this manual carefully and completely before installing and starting up the device. It contains
important instructions on installation and operation.
The device is designed to state-of-the-art technological standards. It should only be used:
- correctly and
- in a technically perfect and correctly installed condition
- in accordance with the technical data.
The manufacturer is not liable for damage resulting from incorrect use.
Installation, programming, maintenance and repair work should only be carried out by authorised skilled
personnel.
Soldering, connection and installation work within the overall system should only be realised in a
deenergised condition. Soldering work should only be realised with a soldering iron with temperature
control which is galvanically isolated from the mains power supply.
German electrical standards and regulations of local electricity suppliers should be observed.
The MB TouchScreen ControlPanel operating module should not be used in rooms where
there is a risk of explosion or where vapours may decompose metal or plastic materials.
This symbol on our product shows a crossed-out "wheelie-bin" as required by law regarding the
Waste of Electrical and Electronic Equipment (WEEE) disposal. This indicates your
responsibility to contribute in saving the environment by proper disposal of this Waste i.e. Do
not dispose of this product with your other wastes. To know the right disposal mechanism
please check the applicable law.
2. General
By deciding to install an intrusion detection control unit, you have taken a step towards greater security. In
the control unit unites are the most up-to-date electronics, innovative technology and years of experience
of one of the largest manufacturers of intrusion detection systems in one highly-developed product.
The large number of operating options and alarm types and the extensive programming options
guarantee ideal adaptation to your individual security requirements.
If the control unit is also fitted with an integrated telephone dialling device, a silent alarm can be
transmitted via the public telephone network to the digitized receiving control unit of a commissioned
security firm. The security firm can then take the necessary steps (e.g. police operation). There is also the
possibility of triggering a local alarm, if the relevant person cannot be reached.
If your control unit is installed for remote parameterization, the installer can access the intrusion detection
control unit via remote programming (e.g. to change a telephone number).
These instructions explain how to work with the control unit at user level. You will learn all you need to
know about operating the device, from the functions of the display and operating elements to simple
troubleshooting.
Programming which affects the system is reserved for the installer. Please contact the installation
company if you have any problems, desires to upgrade the system, etc.
Very few operating procedures are required in normal, everyday operation. This means that knowledge of
operating and general handling can be quickly forgotten under certain circumstances. These instructions
should therefore, be stored in the immediate vicinity of the device so that they are at hand when required.
Important information!
Depending on the type of panel and the panel programming not all functions described in
this manual are possible.
Operating Instructions MB TouchScreen ControlPanel

3. Important information on operation
3.1 Operation
The operating and display panel "MB TouchScreen ControlPanel" is used as a status display for operating
your intrusion detection central control unit. Operation of the system is dialog managed via a touch
screen. i.e. by touching the display with a finger the desired operating functions can be selected and
operated. The operating and display panel provides clear and comprehensive information on the system
status
Electrostatic discharges can cause malfunctions of the touch screen. Therefore, make sure that
the touch screen does not come into contact with other electrical devices, e.g. mobile phones.
Moisture or drops of water can cause the touch screen to malfunction. Therefore, make sure that
the touch screen does not come into contact with heavy moisture or water.
4
3.2 Visual angle
Note the viewing angle of the display for optimal visibility and
legibility.
4. Integrated reader
An IK2/proX1, IK3/proX2 and mifare and mifare DESFire
card reader for user authorization is integrated into the
TochScreen ControlPanel.
When used in systems according to SES, the use of
mifare Classic and proX data carriers is not
permitted.
Hold the data carrier - approximately in the middle of the
reading range.
Whether a data carrier is required for the authorization, will be
determined on the panel programming.
The following combinations are possible::
- PIN only
- Data carrier only
- PIN and/or data carrier
3.3 Cleaning and care
Before cleaning please disable touchcsreen (see Chapter
7.1.8). For cleaning use a damp, soft cloth. DO NOT use
any other liquid, sprays or ammonia-based cleansers.
Do not use aggressive or plastic decomposing liquids, e.g. petrol, terpentine, thinner, etc. Aggressive
cleaning agents can damage or discolour the surfaces.
Do not use abrasives, e.g. scouring agents, scour pad. Clean with a soft, moist cloth. Only use clear
water.
Do not operate the touch screen with sharp or rough
objects!
Do not apply too much pressure with your fingers.
The reader can be used at the panels MB-Secure (from V10.xx).
Lesefeld
Operating Instructions MB TouchScreen ControlPanel
100°

5
5. Operating code
5.1 Code input
- Enter code
- Clear input by touching "CLR"
Acknowledge by touching "OK".
5.2 Overview of levels of authorization
MB Classic (except 561-MB256 plus):
The following overview provides information on which operating functions may require the entry of a code
according to the programming
MB-Secure and 561-MB256 plus:
In this control panels the individual operating functions are allocated to the operating code (MB-Secure with 4
to 8 digits, 561-MB256 plus with 1 to 8 digits).
Ask your installer for further information on the operating code (number of digits and released functions).
Code 4-digit Code 5-digit Code 6-digit
- View detector groups - Clear detector groups - External disabling/enabling
- Start Makro - Internal disable detector groups - Clear tamper detector groups
- Internal arming - Activate walk test - Change date and time
- TouchScreen settings - View event memory
- Slideshow - Internal disarming
When using a hold-up code, the
above specified variation possibility is
halved.
Same code for different users can not
be used.
5.3 Variations of the code inputs
Code digits Variations Security Grade
Code 4 digits 10.000 possibilities Grade 2
Code 5 digits 100.000 possibilities Grade 3
Code 6 digits 1.000.000 possibilities Grade 4
Code 7 digits 10.000.000 possibilities Grade 4
Code 8 digits 100.000.000 possibilities Grade 4
The TouchScreen ControlPanel can be programmed as follows depending on the application:
for Zone(s): Display without Operation without
PIN PIN
Data carrier Data carrier
PIN or Data carrier PIN or Data carrier
PIN and Data carrier PIN and Data carrier
A possible tens digit is not carried over.
Depending on the panel type the operating
functions are distributed over 3 different
authorization levels or the operating functions are
allocated to the operating code (see 5.2).
Hold-up code: PIN + (1 – 9)
Operating Instructions MB TouchScreen ControlPanel

6
6. Keypad basic state
6.1 Home screen
Selecting an alarm partition
If you tap on a selected alarm partition (alarm zone), this area is
displayed in the security screen window view.
More functions
This selection area contains the other functions for operating the panel. Depending on the
programming, these buttons are always visible or only after tapping the button More functions. è
Tap
To select menu icons or press
buttons on the display or to
confirm a selection from a list, tap
each with one finger.
Swipe
Swipe your finger up and
down on the screen or a
list to display more fields
and information.
In the basic state the screen is dark.
In case of alarm, the display is activated to achieve a better signalling effect.
In normal operating mode, after a touch, depending on the settings of the TouchScreen ControlPanel:
- the home screen with the area view,
- or the home screen with the security screen overview will be displayed.
Pressing the " [→ ", key at the top right of the display exits the operating mode and the display is darkened
again.
If there is no more input, the display changes to the home screen or to the dark-controlled mode after a
programmed time.
Touch the screen surface to switch the display illumination back on and return to the operating mode.
Operating Instructions MB TouchScreen ControlPanel

7
6.3 LED indicators and Buzzer function
LED red lights up: Intrusion alarm
LED red flashes: Tamper- or hold-up alarm
LED green lights up: Unit ready for operation
LED green flashes: Unit not ready for operation
LED yellow lights up: Gereral fault of central control panel
LED yellow flashes: Mains fault of central control panel
Buzzer active at: - when switch-on delay is active
(programmable) - reading an ID data carrier
- in case of internal alarm (time limited)
- in case of tamper alarm or fault until manually stopped
- when clearing (system reset), walk test on
- when touching the screen as acknowledgement signal
- with door interlock function when arming and disarming
- with reminder signal after alarm and external disarming
- in case of faults
- Additional functions programmable by installer
(output programming)
6.2 Operating menus
Set up (Details see Chapter 11)
Display brightness, display settings, set language, configure home screen,
System settings, date/time, etc..
Exit operation.
Security screen
Selection of an area, display and overview of alarms and faults.
Area view
Information and operations concerning the alarm partition. Arming and disarming,
viewing event logs, etc..
Automation
Starting executable macros.
Show / Hide information to the buttons.
Maintenance (Details see chapter 10)
Enable remote parameterisation, show maintenance date, show system
information.
Operating Instructions MB TouchScreen ControlPanel

8
7. Area view
The Area View button opens
the preferred area defined for
this panel within the panel
programming. If no preferred
area is programmed, the first
assigned area of the panel
appears.
The area view is used to operate the selected alarm partition of the panel. This view allows a quick
overview of the status of the panel's zone. Messages are highlighted in colour and displayed in plain text.
The selected area can be switched intuitively. To do this, use the symbol buttons internal arming / è è
external arming / and again disarming. A single tap with the finger is all you have to do to perform the è
desired operation.
If messages, faults or alarms are pending, the alarm partition/zone cannot be armed. This can be
recognised by a dark symbol button. The pending messages can be queried and are shown on the è
display.
Button brightness dark Internal arming not possible.è
Display indication Observe upcoming messages for internal arming.è
Button bright, tap the button Internal arming possible .è
Button dark external arming not possible.è
Display indication Observe upcoming messages for external arming.è
Button bright, tap the button External arming possible .è
Tap the button Disarming operation for the alarm partition.è
Tap the button More Messages. è
Display of upcoming Messages of the alarm partition/zone.
Tap the button More functions to open the operating menu for further functions.è
Operating Instructions MB TouchScreen ControlPanel

9
7.1 More functions
7.1.1 Detector groups
All detector groups in this alarm partition are displayed. Triggered detector groups are marked with
a red dot.
Operating functions:
Detector group
- disable internal
- disable external
- set bypass
The blue button
indicates a
change in the normal
state of the detector
group.
7.1.2 User & Pin (Function only available with panel MB-Secure)
The user & Pin menue allows you to block individual users. To block a user, tap on the button è
ENABLED. The button changes to DISABELED.
The blue button
indicates a blocked
User.
The button è Change PIN
is used to change the own
PIN code.
The on-screen keyboard
is displayed.
To confirm the new code,
the new PIN code must
be entered a second time
again.
Depending on the user's authorisation, PIN codes of other users can be changed, not only the
user's own PIN code.
Depending on the programming,
this operating menu can already
be displayed in the area view.
Button More functions show è
the operating menu for additional
operating functions.
Operating Instructions MB TouchScreen ControlPanel

7.1.3 Doorguards (Funktion nur bei Zentrale MB-Secure verfügbar)
This menu is used to control and operate the connected Doorguards.
Operating functions:
- Permanent Closed (Locked)
- Normal operation
- Short Release
- Permanent Release
In the event of an alarm, the
triggered door is displayed
in red.
7.1.4 Alter times
Selection via touch menu. The following times can be changed:
Switch on delay time
Pre-alarm time
Time for exit route
Pre-warnig exit route
Time for entry route
Pre-warning entry route
7.1.5 Event memory
The event memory list shows all events in chronological order. The alarm counter indicates the number of
external alarms (main alarms) since the system was commissioned.
Filter the events:
Filters can be set.
Events that do not correspond
to the filter are hidden.
è Show all events
è Show only alarms
EVENT MEMORY
ALARM MEMORY
sek.
sek.
sek.
sek.
sek.
sek.
min.
min.
min.
min.
min.
min.
10
Operating Instructions MB TouchScreen ControlPanel

7.1.6 Clear part
Clear all triggered detector groups and faults in this alarm partition.
For this function, an additional code entry may be required as an operating release.
7.1.7 Installer information
Display of a freely programmable text during central programming (e.g. name and address of the
installer, telephone number, etc.).
7.1.8 Test
The operating menue is used to switch on the walk test for the alarm partition, the cleaning mode
for the screen and to display the ID data code of an ID data carrier held in the reading field of the
TouchScreen ControlPanel.
Walktest
The walk test is switched off by arming/disarming the alarm partition, too.
Clean display
RFID-Code
Hold the ID data carrier in the reading field of the TouchScreen ControlPanel. Display Codeè
7.1.9 Activation of access level 3
After receiving the normal operating authorisation, the operating authorisation for access level 3
can be entered after pressing this button. This can be done by entering a code or by presenting an
authorised data carrier to the integrated reader. This button is not usually displayed, only if it has
been programmed accordingly in the panel.
Press the button to
switch on the walk test
Press the button to
switch off the walk test
Button change Button change
Walktest switched off Walktest switched off
Walk test in progress
Start clean display
Press the button to
start display cleaning
Press the button Continue è
start display cleaning
Display changes
Display is disabled for
30 seconds.
Information text
Display changes
11
Operating Instructions MB TouchScreen ControlPanel

12
8. Security screen
T h e s e c u r i t y s c r e e n
overview button opens the
view of all alarm partitions.
The security screen overview provides a quick overview of the status of the individual alarm
partitions/zones of the panel. Messages are highlighted in colour and displayed in plain text.
The TouchScreen ControlPanel can be switched to another operating area/alarm partition.
A single touch
is sufficient to select the desired alarm partition/zone
If another operating code / operating authorisation is required for the alarm partition/zone selected there,
this is indicated by ***. If an alarm partition marked with *** is selected. the display automatically changes
to the "Code input" or the following message appears: "No authorisation for this area".
8.1 Filter for view of alarm partitions
The filter can be combinated (e. g. show only disarmed partitons with alarm).
To get a quick overview of disarmed partitions/zones as well as partitions with alarms, filters can be set.
Areas that do not correspond to the filter are hidden. Tapping once sets the filter, tapping again resets the
filter (toggle function).
NUR BEREICHE MIT ALARM ANZEIGENShow only disarmed Areas
Show only Areas with Alarm
è Only disarmed partitions/zones are displayed.
è Only partitions/zones with alarms are displayed.
Operating Instructions MB TouchScreen ControlPanel

9. Automatic
10. Maintenance
Select the button Automatic. A macro or automatic function can combine several individual
functions and thus also contain extensive function or control sequences.The operating menu
shows executable macros / automatic functions. The selected macro or automatic function is
started with the "Start" key (only start possible with the MB-Secure panel).The "Lock" key locks
the selected macro, i.e. the automatic function no longer runs.
Select the Maintenance button.
The operating menu is used to display the next maintenance date of the panel and to display
information about the TouchScreen ControlPanel and the panel.
The operating menu is also used to enable remote parameterisation, i.e. remote access to the
panel by the installer.
10.1 Remote parameterisation
The type of remote parameterisation release depends on the programming of the panel. If a permanent
release is programmed on the panel, the button Remote papametrisation Disabeled is replaced by the è
label Permanent release.è
Press Button for
Release
Manual release:
Press Button for
disable the parametrisation
Button change
Remote parametrisation
Disabled
Remote parametrisation
Disabled
Remote parametrisation
Enabled
Button change
13
Operating Instructions MB TouchScreen ControlPanel

14
11. Setup
Select the button Setup.
This operating menu contains programming options for the TouchScree ControlPanel.
Some of the programming is reserved for the installer to ensure safe operation of the unit.
Date / Time
Setting the time and date using the touch menu.
Activate or deactivate DST (daylight saving time) changeover, save setting.
Language
Selection via drop-down menu, selection between German, Czech, English, Spanish French, Italian, è
Dutch, Polish, Romanian, Russian, Turkish.
Brightness Level
Selection via slider bar.
Startscreen/Homepage
Selection via drop-down menu, selection between Area view and Security screen.è è
To Startscreen after
Time until the display returns to the Home screen / Start screen.
Info: Operating time from panel
Only display, the operating time is defined via the programming of the control panel. If the operating time
of the control panel is programmed to "infinite", an additional selection button appears Operating time è
from this device. In this case the operating time for this TouchScreen Control Panel can be set individually
via the drop-down menu.
BUS-2 Address
Display of the BUS-2 address. This programming is reserved for the installer.
Font-Size
Selection via drop-down menu, selection between Normal and Big.è è
Button More functions
Selection via drop-down menu, selection between completely invisible and always active. è è
If you select completely invisible, you first must press the operating button More functions in the è è
area view to operate any other function.
Operating Instructions MB TouchScreen ControlPanel

15
12. Description of function arming/disarming
12.1 Intrusion detection control unit arming/disarming
Arming/disarming - these terms mean practically the same thing as switching the system on and off.
To switch on: means to arm the system.
This can either be the "internally armed" status for presence security or the
"externally armed" status for absence security.
To switch off: means to disarm the system.
Arming and disarming is performed using appropriate operating elements.
Depending on the version and components of your system, these elements can be operating units, a
block lock, a security operating panel, a door code or a proximity operating device (IDENT-KEY System).
Detector groups which were internally disabled are automatically reactivated by external arming.
However, after disarming disabling is active again.
Arming is acknowledged by an audible signal which lasts approx. 3 seconds.
Every impending alarm criterion now releases a main alarm. Depending on the system configuration, the
alarm is transmitted visually (flashing lamp) and/or audibly (loudspeaker). This alarm can also be reported
to a security service via a transmission device, if installed.
Absence security status can only be lifted by disarming using an operating element such as the IK3 reader.
After disarming, an actuated alarm is displayed on the corresponding displays of the operating units and
on any parallel display boards installed.
The intrusion control panels additionally offers the function external arming of a zone via the
TouchScreen operating unit. For this purpose the function must be released by the installer.
12.2 Absence security
Absence security refers to external arming using a
suitable operating element e.g. an IK3 reader. This means
that you assume that the zone to be secured has been
vacated and cannot be entered even accidentally through
an unlocked door, for example.
The control unit can only be externally armed if:
- there is no fault in the mains or the accumulator
- no detector group or lock group may be triggered
- no uncleared alarm should be pending
- no fault of the telephone dialing device (transmission
device).
Operating Instructions MB TouchScreen ControlPanel

16
12.3 Presence security
Presence security does not require that the secured zone be vacated. Partial zone arming is possible with
this form of security, i.e you can disable detector groups. It is then possible to move about within these
detector groups without releasing an alarm by actuating a motion detector or a window contact, for
example. Internal arming is carried out using operating units.
An impending alarm criterion releases an internal alarm. The displays
of operating units and parallel boards are not blanked - this means that
the system status is immediately recognizable.
Presence security can be cancelled by disarming using operating
units or, if installed ID card readers.
This disarming simultaneously switches off the internal acoustic
signal transmitters.
Operating Instructions MB TouchScreen ControlPanel

17
13. Technical data
Rated operating voltage U_b 12V DC
Operating voltage range 9V DC bis 15V DC
Max. permissible ripple 1Vpp (peak-to-peak)
Current consumption stand by mode
at 12V DC 190mA
at 10V DC 220mA
Current consumption at 12V DC
by max. screen brightness: - average 230mA - max. 390mA
Current consumption at 10V DC
by max. screen brightness: - average 270mA - max. 480mA
Integrated reader IK2/proX1, IK3/proX2 and mifare DESFire EV1, EV2
Reading distance 0 ~ 3cm for proX and mifare data carrier (*1)
Frequency range, transmission power:
proX1, proX2 125 kHz <10dBµA/m in 10m distance
mifare 13,56 MHz, <0dBµA/m in 10m distance
Screen diagonal (visible) 9" (22,8cm)
Screen format 16 : 9
Environmental class as per VdS II
Environmental class as per EN 50131-3 Class II
Protection class as per EN 60529 IP30
Operating temperature range -5 °C to +45 °C
Storage temperature range -25 °C to +60 °C
Relative humidity 93% non-condensing
Weight 850 g
Dimensions (W x H x D) 218 x 162 x 30 mm
Colour white (similar to RAL 9016), black (similar to RAL 9017)
*1) Specified reading distance on non-metallic mounting surface.
On metallic surfaces, the reading distance may be be reduced slightly.
The specified reading distance can only be garanteed by using data carriers provided by our
company.
When using the encryption method mifare DESFire EV1/EV2, the reading distance may be lower
for EV1 data carriers.
Operating Instructions MB TouchScreen ControlPanel
Hereby, the Novar GmbH declares that the radio equipment MB TouchScreen PanelControl,
Item no. 013080 and 013081 is in compliance with Directive 2014/53/EU.
T he f u ll t e xt o f t h e E U d e c l ar a t io n c a n b e d o w nl o a d e d f r o m o u r h o m e p a g e
https://www.security.honeywell.de/ Service / Download.
14. Certifications
VdS approval no. G121014
VdS2252 Class C / Environmental class II
EN Conformity EN 50131-3: Grade 3
EN 50131-1: Environmental class II
SES Conformity SES-EMA-RL-T2:2021-04
Type B When used in systems according to VdS, EN or SES in the
monitored area, for internal use only.

18
Notes
Operating Instructions MB TouchScreen ControlPanel

19
Operating Instructions MB TouchScreen ControlPanel

20
Honeywell Commercial Security
Novar GmbH
Johannes-Mauthe-Straße 14
D-72458 Albstadt
www.honeywell.com/security/de
P00471-03-0G0-00
2021-06-25
© 2021 Novar GmbH
Operating Instructions MB TouchScreen ControlPanel
P00 4 71- 03 - 0G000
