honor Earbuds 2 Lite Technical specifications

HONOR Earbuds 2 Lite Product
Description
1.2
2021-4-12
Honor Device Co., Ltd.

Copyright © Honor Device Co., Ltd. 2021. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Honor Device Co., Ltd.
Trademarks and Permissions
and other Honor trademarks are trademarks of Honor Device Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services, and features are stipulated by the contract made between Honor and the
customer. All or part of the products, services, and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise agreed by the contract, all statements, information, and
recommendations in this document are provided "AS IS" without warranties, guarantees, or representations of
any kind, either express or implied.
The information in this document is subject to change without notice. This document is for reference only, and
all statements, information, and recommendations in this document do not constitute a warranty of any kind,
express, or implied.

1 Overview
1.1 Introduction
HONOR Earbuds 2 Lite are true wireless stereo (TWS) earbuds consisting of left and
right earbuds and a charging case, and feature an in-ear design for increased
comfort when being worn. The earbuds can be connected with other devices such as
phones, tablets, and PCs over Bluetooth to make voice calls and play music.
Featuring a 10 mm-diameter dynamic driver unit, two microphones for environmental
noise cancellation during calls, feedforward active noise cancellation (ANC), and
Awareness mode, the earbuds achieve crystal clear audio delivery. With a low power
solution and 55 mAh battery, the earbuds have a long battery life and a fast charging
speed via the charging case.
Glacier White

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page4
2 Technical Specifications
2.1 Hardware Specifications
The following table describes the hardware specifications.
Item
Description
External model
Earbuds model: T0005
Charging case model: T0005C
Hardware platform for
earbuds
BES2500Z
Bluetooth version
Bluetooth 5.2, backward compatible
Bluetooth protocol
A2DP 1.3, Hands-free protocol (HFP) 1.7, AVRCP 1.6,
RFCOMM 1.2, SPP 1.2, AVCTP 1.4, and AVDTP 1.3
Bluetooth name
HONOR Earbuds 2 Lite
Hardware platform for
charging case
Third-party MCU
Charging the case
Charged via a USB Type-C port and a cable
Charging the earbuds
Charged via the charging case
Charging time
Full charge for the earbuds: around 1 hour
Full charge for the charging case (without the earbuds
inside): around 1.5 hours
Data comes from Honor lab tests.
Battery capacity and
type
Earbuds capacity: 55 mAh (minimum value)
Charging case capacity: 410 mAh (minimum value)
Battery type: Lithium-ion battery

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page5
Item
Description
Music playback/Voice
call duration
Music playback duration: 10 hours (with noise
canceling disabled)/7.5 hours (with noise canceling
enabled)
Voice call duration: 6.5 hours (with noise canceling
disabled)/5.5hours (with noise canceling enabled).
Honor conducted tests with a prototype of the Earbuds 2 Lite and the
accompanying software using the HONOR V30 phone.
Music playback test: The earbuds were connected to the phone over
Bluetooth for music playback in the AAC format with the volume set to 50%.
The battery was completely discharged until the music stopped playing from
one of the earbuds.
Voice call test: The earbuds were connected to the phone over Bluetooth with
the volume set to 50%. A voice call was then conducted until the voice could
not be heard from one of the earbuds.
The battery life will vary depending on the device settings, usage, and other
factors.
Standby time
1. Standby time with the earbuds fully charged,
connected with a device, and outside the charging
case: 2 days.
2. Standby time with the earbuds and charging case
fully charged and the earbuds placed inside the
charging case: about 1 year.
Button
A button is on the charging case.
1. Power on the case: When using the charging case
for the first time, press and hold the button for 2
seconds.
2. Enter Pairing mode: Open the charging case and
leave the earbuds inside, then press and hold the
button for more than 2 seconds.
3. Restore the earbuds to their factory settings: Open
the charging case and leave the earbuds inside,
then press and hold the button for more than 10
seconds. This will clear all pairing data.
4. Reset the charging case: Press and hold the button
for more than 16 seconds.

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page6
Item
Description
Indicator
The indicator outside the case provides information
about the charging case by turning red, orange, green,
or white.
1. Battery level of the earbuds
2. Pairing status
3. Factory reset status
4. Charging status of the charging case
5. Battery level of the charging case
Input power of the
charging case
5 V/1 A
Number of full charge
times
When the charging case is fully charged, it can provide
at least 1 full charge for both earbuds or at least 2
charges for a single earbud.
Effective bandwidth
frequency for music
playback
20 Hz to 20,000 Hz
A2DP decoding format
AAC and SBC
Speaker
Each earbud has a 10 mm-diameter dynamic driver
unit
Microphone
Each earbud has two MEMS microphones that
support uplink environmental noise cancellation for
calls and feedforward active noise cancellation.
Color (earbuds and
charging case)
Glacier White, Midnight Black
Weight
Single earbud: about 5.5 g
Charging case: about 41 g
Dimensions (H x W x D)
Earbud: 37.5 mm x 23.9 mm x 21 mm
(including ear tips in size M that are installed on the
earbuds by default)
Charging case: 45.5mm*61.2mm*25.35mm
Temperature
Operating temperature: 0°C to 35°C
Charging temperature: 0°C to 45°C
Storage temperature: –20°C to +45°C
Certification
The product has obtained SRRC, CE, and Bluetooth
certifications.
Environmental protection
requirements
The product complies with RoHS, REACH, and WEEE
environmental protection requirements.

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page7
2.2 Features
2.2.1 Immersive stereo sound and switching between primary/secondary
earbuds
After connecting to a Bluetooth device, the earbuds will play stereo
sound through both channels when making voice calls or playing
music. They intelligently designate one earbud as primary and the
other as secondary based on their condition and battery level.
2.2.2 Feedforward noise cancellation for crystal clear audio
A feedforward microphone is used to pick up background noise, and a
reverse sound wave is generated in real time to eliminate the noise,
bringing comfortable noise canceling.
Maximum noise canceling depth in the core frequency band: 22 dB
2.2.3 Be aware of clear and natural ambient sound
You can switch to Awareness mode by touching and holding either
earbud, which enables you to be aware of the surrounding sound
without taking off your earbuds.
2.2.4 Dual-microphone environmental noise cancellation during calls
Each earbud has two Micro-Electro-Mechanical System (MEMS)
silicon microphones that use beamforming directional sound pickup,
wind-resistant structure, and AI noise canceling technology, effectively
reducing environmental noise to achieve high-quality calls even when
you are walking or running.
2.2.5 Fast charging and long battery life
With a large-capacity battery in a compact body, the HONOR Earbuds
2 Lite feature a long battery life with a low-power solution.
With noise canceling disabled and the volume set to 50%, a full charge
of the earbuds allows for 10 hours of music playback (in AAC format),
or 6.5 hours of voice calls.
A full charge of the earbuds and charging case allows for 32 hours of
music playback, or 20 hours of voice calls.
The earbuds support fast charging, and a 10-minute charge allows for
4 hours of music playback.
(Conditions: The charging case has sufficient battery, the earbuds are
fast-charged at room temperature, and the earbuds are used to play
music in AAC format with a 50% volume level.)
2.2.6 Proximity pairing prompt upon opening the case
On phones running Magic UI 3.0 or later, a proximity pairing prompt
will be displayed each time you open the charging case for a rapid

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page8
pairing or connection. The battery level of the earbuds and charging
case will be displayed on the prompts.
Note：Depend on overseas server construction.
2.2.7 In-ear design and surging bass
The HONOR Earbuds 2 Lite feature a 10 mm-diameter dynamic driver
and an in-ear design for maximum comfort and stability.
2.2.8 Easy touch controls
Both earbuds use built-in capacitive sensors to achieve the double-tap
and touch-and-hold shortcuts. You can change the shortcut settings in
the AI Life app on a phone running Magic UI 4.0 or later.
Double-tap either earbud to perform the following:
Default settings:
1. Play/Pause music.
2. Answer/End a call.
Touch and hold either earbud to perform the following:
Choose a noise control mode: Noise canceling, Awareness, or Off.
Optional settings:
Double-tap either earbud to perform the following:
1. Play/Pause music.
2. Skip to the next song.
3. Return to the previous song.
4. Wake up the voice assistant.
5. None
Touch and hold either earbud to perform the following:
Choose a noise control mode.
2.2.9 Low latency and audio-video synchronization
To reduce the latency of Bluetooth transmission and synchronize audio
and video during gaming, the HONOR Earbuds 2 Lite automatically
enter low-latency mode when you are playing games on a phone
running Magic UI 4.0 or later.
2.2.10 Convenient settings and updates in the AI Life app
The HONOR Earbuds 2 Lite work in conjunction with the AI Life app
for you to switch between different noise control modes, customize
noise canceling settings, set shortcut operations, and perform OTA
updates.
Note: Only for Android.

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page9

HONOR Earbuds 2 Lite Product Description
Issue 1.0 (Chyba!
Neznámý název
vlastnosti
dokumentu.)
Chyba! Neznámý název vlastnosti
dokumentu.
page10
2.3 Packing List
No.
Item
Quantity
1
Earbuds
1 pair (left and right earbuds)
2
Ear tip
3 pairs (Available in large, medium, and small. The
medium size is pre-installed on the earbuds.)
3
Charging case
1
4
Quick Start
Guide
1
5
Safety
Information
1
6
Warranty card
1
7
USB-C cable
1
