horiba HU-200TB SS-120 User manual

Turbidity meter
HU-200TB SS-120
Instruction Manual
CODE:GZ0000230902

October, 2010 © 2010 HORIBA Advanced Techno, CO., Ltd.
Preface
This manual describes the operation of the Turbidity meter , HU-200TB SS-120.
Be sure to read this manual before using the product to ensure proper and safe operation of
the instrument. Also safely store the manual so it is readily available whenever necessary.
Product specifications and appearance, as well as the contents of this manual are subject to
change without notice.
Warranty and Responsibility
HORIBA Advanced Techno, CO., Ltd. warrants that the Product shall be free from defects in
material and workmanship and agrees to repair or replace free of charge, at option of HORIBA
Advanced Techno, CO., Ltd., any malfunctioned or damaged Product attributable to
responsibility of HORIBA Advanced Techno, CO., Ltd. for a period of one (1) year from the
delivery unless otherwise agreed with a written agreement. In any one of the following cases,
none of the warranties set forth herein shall be extended;
zAny malfunction or damage attributable to improper operation
zAny malfunction attributable to repair or modification by any person not authorized by
HORIBA Advanced Techno, CO., Ltd.
zAny malfunction or damage attributable to the use in an environment not specified in this
manual
zAny malfunction or damage attributable to violation of the instructions in this manual or
operations in the manner not specified in this manual
zAny malfunction or damage attributable to any cause or causes beyond the reasonable
control of HORIBA Advanced Techno, CO., Ltd. such as natural disasters
zAny deterioration in appearance attributable to corrosion, rust, and so on
zReplacement of consumables
HORIBA ADVANCED TECHNO, CO., LTD. SHALL NOT BE LIABLE FOR ANY DAMAGES
RESULTING FROM ANY MALFUNCTIONS OF THE PRODUCT, ANY ERASURE OF DATA,
OR ANY OTHER USES OF THE PRODUCT.
Trademarks
Generally, company names and brand names are either registered trademarks or trademarks
of the respective companies.

Regulations
Conformable Directive
This equipment conforms to the following directives and standards:
JInstallation Environment
This product is designed for the following environment.
zInstallation Categories II
zPollution degree 2
FCC Rules
Any changes or modifications not expressly approved by the party responsible for compliance
shall void the user's authority to operate the equipment.
JWARNING
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Directives: the EMC Directive 2004/108/EC
the Low Voltage Directive 2006/95/EC
Standards: [the EMC Directive]
EN61326-1: 2006 Class A, industry
[the Low Voltage Directive] EN61010-1: 2001
Note
If the sensor cable, transmission cable, or relay cable is extended to 30 m or more, the
surge test in the EMC Directive for CE Marking is not applicable.

For Your Safety
Hazard Classification and Warning Symbols
Warning messages are described in the following manner. Read the messages and follow the
instructions carefully.
QHazard classification
QWarning symbols
This indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the most
extreme situations.
This indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
This indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against
unsafe practices.
Without safety alert indication of hazardous situation which, if not avoided,
could result in property damage.
Description of what should be done, or what should be followed
Description of what should never be done, or what is prohibited

Safety Precautions
This section provides precautions to enable you to use the product safely and correctly and to
prevent injury and damage. The terms of DANGER, WARNING, and CAUTION indicate the
degree of imminency and hazardous situation. Read the precautions carefully as it contains
important safety messages.
WARNING
To connect any load exceeding the contact capacity or any induction load (e.g., a motor or a pump),
be sure to use a power relay exceeding the load rating.
If there is a possibility of a lightning strike, install an arrester on the output side of the converter and on
the side of receiving instruments.
Be sure to ground the grounding terminal (class D grounding).
Electric shock hazard
Be sure to check that no power is supplied before starting work.
An unexpected motion may result in damage to the unit or injury. Be sure to turn OFF the power at the
time of replacement.
Do not turn ON the automatic cleaner while a turbidity detector is filled with water and a valve is
closed. The automatic cleaner may become faulty.
CAUTION
The operation of this equipment at any voltage outside the rated range may damage the equipment.
It is recommended that any fluctuations in power supply voltage fall within a range of ±10%.
When the power source of the instrument is OFF, the C-NC contact is short-circuited. Therefore, be
careful about the connection of load.
If there is any corrosive gas in the installation environment, send clean instrumentation air through the
air purge inlet on the HU-200TB SS-120.
Operation outside the rated range can cause a fault. Therefore, check the power supply voltage.
Wear protective equipment and safety glasses when using chemicals.
Replace desiccants at regular intervals. In particular, cooled water cannot be correctly measured due
to condensation.

Product Handling Information
Operational Precautions
Use of the equipment in a manner not specified by the manufacturer may impair the protection
provided by the equipment. And it may also reduce equipment performance.
Therefore, exercise the following precautions:
zDo not press any operation key with the tip of your nail or any pointed thing.
zDo not use organic solvent or the like.
Disposal of the Product
When disposing of the product, follow the related laws and/or regulations of your country for
disposal of the product.
Manual Information
Description in This Manual
Note
This interprets the necessary points for correct operation and notifies the important points for
handling the unit.
Reference
This indicates the part of where to refer the information.
Tip
This indicates reference information.
Term Definition
This document uses the following terms as defined:
Term Definition
Hold down Maintain pressing a key until the indicator turns ON or the display changes.
Flash Quickly flash several times, indicating that the setting has been established.

Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview of equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description of each part (Converter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Description of operation keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Status display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Description of operation modes and menu items . . . . . . . . . . . . . . . . . . . 7
Description of each part (Detector). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Procedures for connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting the power source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting the contact output terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting the transmission output terminals. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting the contact input terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting the communication terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting the detector cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting the automatic cleaner cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Detector installation method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sampling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Preparation for operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Starting operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Meas. mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Calibration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
User Check menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Contact output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Output conditions of various outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Cleaning operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Information for accurate measurements . . . . . . . . . . . . . . . . . . . 49
Zero calibration Cal mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Selecting turbidity standard substances . . . . . . . . . . . . . . . . . . . . . . . . . 50
Checking the zero calibration data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Span calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Replacing the desiccant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Replacing the wiper rubber of the cleaner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Replacing the motor of the cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Troubles with measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Measurements exceeding the measurable range. . . . . . . . . . . . . . . . . . 58
Error code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Reference data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Cleaner (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Measuring principle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Preparation method Formazin 4000 FTU . . . . . . . . . . . . . . . . . . . . . . . . 65
Preparation method of Kaolin standard solution. . . . . . . . . . . . . . . . . . . 66
A span calibration bottle (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Turbidity sampling system (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Disposal method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Display of turbidity meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Overview
1
Overview
Overview of equipment
Thank you very much for purchasing the HU-200TB SS-120 industrial-use turbidity meter.
This turbidity meter consists of a HU-200TB converter and a SS-120 distribution type turbidity
detector. This turbidity meter can measure a wide range of turbidities from low concentration
to high concentration with high accuracy through the 90-degree light absorption-scattering
method. Standard substances of turbidity are selectable from among Formazin, Kaolin, and
Polystyrene Latex (PSL).
The SS-120 detector for the HU-200TB SS-120 industrial-use turbidity meter can measure a
turbidity with high stability because the fluctuations in light intensity and the changes in
sensitivity of the detector are eliminated by using two LED light sources (660 nm) and two
photo detectors.
With its enhanced self-diagnosis capabilities, the status of this equipment is diagnosed at all
times.
The automatic cleaner (optional) for the SS-120 detector automatically cleans the dirt on the
inner surface of the cell which interfere with measurement. The operations such as the data
transfer of turbidity measurements and cleaning directives are carried out through
communications among the converter, the turbidity detector and the automatic cleaner. The
exclusive-use cable contains 5 wires for the 12 V DC power source, two-line communications,
and grounding.
If an automatic cleaner is installed, the length of the cable leading to the converter is 5 m. If an
automatic cleaner is not used, the cable can be extended up to 50 m.
Optional products offered by HORIBA Advanced Techno: the span calibration unit that can be
used in place of a standard solution at the time of span calibration; the piping unit that is used
to combine standard type pipes; and the filter unit that is used to prepare zero water.
QFeatures of the Converter
zRugged aluminum die cast
zWide wiring space, and a terminal block for which the drop-off of screws is prevented.
zOutdoor installation type (equivalent to IP65; splash-proof construction)
zEasy-to-view display (150% zoom as compared with the conventional type)
zFront-face keys for all key operations
zEnhanced self-diagnosis capabilities
zProgrammable transmission output range
zCalibration history memory
zMeasurement by calling up detector-specific data without machine difference.
zKey seat with good operability
QFeatures of the Cleaner
z2 light sources and 2 detectors, which can eliminate the variations in a light source or a
detector.
zLong-life LED light sources
z90-degree light absorption-scattering method that can reduce stray light.
zBlinking light sources that can eliminate ambient light.
zLow-drift electronic circuits
zCPU and memory for storage of calibration data

Overview
2
QFeatures of the Cleaner
zElectric reciprocating operation drive
zSilicon rubber wiper with high cleaning effect
zOperability by internal pressure
zCPU-based Intelligent motions
Content
QItems included
A turbidity detector is separately packed.
Components included with a detector
zThe detector and brackets
zCleaning component (optional)
zA span calibration bottle (optional)
zKaolin standard solution, 10000 mg/L (optional)
zFormazin standard solution, 4000 FTU (optional)
Components included for installation and sampling
zAn overflow tank (optional)
zA piping kit (optional)
zA zero filter (optional)
zA 50 A Pole stand (optional)
Name Illustration Quantity Remarks
Converter 1 set With bracket
With cover
Ｕbolt 2 sets
U-bolt: 2
M8 nut: 4
Spring washer: 4
Flat washer: 4
Instruction
manual 1 copy This document
Instruction
manual

Overview
3
Description of each part (Converter)
QFront view
QWith the front cover opened
Display
The measured value
and other information
is displayed here.
When the cover is
opened, there are 6
operation keys.
Up to 6 pieces of
wiring with diameter
from 9 mm to 11.5
mm can be used.
Purge air is sent through this inlet
to prevent internal corrosion,
normally no connection.
Conduit
Cover
Hood for outdoor
installation
Front cover
Purge air inlet
Screw cap
When the two screw
caps are removed, the
front case screws can
be seen.
The front case can be
opened by removing 4
screws.
Front case screw
There are 6 operation
keys.
Operation key
section
Front case

Overview
4
QDisplay
QOperation key section
QTerminal block
Status display
Indicator
Status display
Measured value display
Auxiliary display
- FTU (Formazin)
- Kaolin (Kaolin)
- PSL (Polystyrene Latex)
- mg/L (the unit of a Kaolin SS
concentration)
- TURB (the unit of a “degree” of
turbidity)
Detector connection
terminal
Power connection
terminal
Transmission output
terminal
Contact input terminal
RS-485 terminal
Fuse box
Power switch
Contact output
terminal

Overview
5
JDescription of operation keys
The operation keys are used to toggle between displayed information, to enter any setting
values, or to perform calibration work.
When the indication is blinking, the figures and parameters can be changed.
Use the ▲/▼(UP/DOWN) key to select a blinking value or item, and then press the ENT key.
The setting will flash and then be established.
Note
Do not press any operation key with the tip of your fingernail or any pointed object.
Key
Representation in
text
(meaning)
Description/Operation
ESC key
(escape)
Used to go back to the previous menu from any other menu.
When various settings are made in the Hold mode, pressing this key once
will return you to the previous item.
The change that has been previously made to any setting is canceled.
Hold
down Holding down this key in the Hold mode will enter the Meas. mode.
HOLD key
(hold)
Hold
down
Holding down this key in the Meas. mode will enter the Hold mode.
Holding down this key in the Hold mode will enter the Meas. mode.
CAL key
(calibration)
Hold
down
Holding down this key until the CAL indicator lights up will select
the Calibration mode.
▲key
▼key
(select)
Used to change the displayed item or value.
Pressing this key changes the value in increments or decrements of 1.
Holding down the key continuously increases or decreases the value.
The ▲and ▼keys are used to scroll up and down, respectively. If the
screen is scrolled up or down excessively with either key, press the other
key.
ENT key
(input)
Used to establish each setting or calibrated value.
Note
No change is reflected if you return to the previous menu by pressing
the ESC key.

Overview
6
JStatus display
QStatus display
Display
Representation
in text
(meaning)
Description/Operation
HOLD
zIlluminated in the Hold mode (when the transmission output is held).
zStarts blinking when contact input is received or when the hold mode
becomes active due to an error
CAL Illuminated when the Cal mode becomes active.
EXT1 Lights up while contact signals (such as cleaning directives) are being input
externally.
CLN Lights up while the automatic cleaner is working.
FAIL Lights up when the FAIL contact signal is output. The output relay coil
current is turned OFF when the FAIL contact signal is output.
System
Priority levels of
errors
Turns ON when system error E-90, E-91, or E-92 occurs
Sensor
Priority levels of
errors
Lights up when any of sensor errors E-41 and E-80 through E-85 occurs.
Sensor
CHECK Lights up during the connection check of sensors.

Overview
7
Description of operation modes and menu items
This equimment offers three types of operation modes and four types of menus.
QOperation mode
Meas. mode
In this mode, samples are measured, and transmission signals and relays are controlled.
Cal mode
This mode allows you to perform zero calibration and span calibration.
The Calibration menu can be also used to perform a calibration.
Hold mode
In this mode, measurements are stopped to use the Setting menu, the Calibration menu or
the User Check menu to carry out processing.
QMenu
The following menus are available at the lower levels of the hierarchy of the Hold mode and
the Meas. mode.
For selecting each mode or item, see the corresponding paragraph.
Meas. mode
Cal/Control Value Setting menu
This menu allows you to check the calibrated value or to set/change some controlled values
while checking the output.
Hold mode
Setting menu (SEt)
Prior to operation, this menu allows you to set all the measurement-related parameters, such
as the detector information input and the allocation output.
Cal menu (CAL)
This menu is used to perform zero calibration or span calibration of the turbidity detector.
User Check menu (USr)
This menu allows you to check the output status, the measured value, and other data. The set
values can be reset to the factory settings.

Overview
8
QEach mode and menu from Meas. mode
Meas. mode
Hold down the
CAL key.
See page 49.
Cal mode
Hold down the
HOLD key
Hold mode
▼key
Setup menu
▼key
Cal menu
▼key
User Check menu
▲/ ▼Key
Cal/Control Value Setting menu
See page 42.
See page 40.
See page 32.
See page 28.
(turbidity calibration)
(turbidity calibration)
The measurement output is held.

Overview
9
Hold down
Check
Hold down
Check the
Adjust a moving
Setting
Menu
Calibration
Menu
User
Check
Menu
Meas. mode Hold mode
or
Check the
cleaning
operation.
calibration data.
average.
contact output.

Overview
10
Description of each part (Detector)
QDetector (SS-120)
An automatic cleaner is optional.The options of automatic operation, manual operation, and
non-cleaner can be selected.
Automatic
cleaner cover
Cleaner locking
screw
Sample
outlet
Desiccant
holder
Sample inlet
Exclusive use cable
for the automatic
cleaner
Diagram showing the cleaner detached
Left cover Window cover
O-ring
Right cover
U bolt
2 sets

Overview
11
QAutomatic cleaner (optional)
QSpan calibration bottle unit (optional)
Pressure
releasing hole
Shaft
Wiper holder
Wiper support
Wiper
Pin
Knurled screw
Automatic cleaner
cover
Calibration jig
Calibration
bottle

Installation
12
Installation
Installation environment
To ensure the stable use of the HU-200TB SS-120 condition, install the HU-200TB SS-120 in
a location that meets the following requirements.
QInstrument mainframe
zThe location should be well ventilated to prevent build-up of moisture.
zThe ambient temperature should be between −20°C and 55°C.
zThe HU-200TB SS-120 should not be exposed to direct sunlight.
zThe HU-200TB SS-120 should not be exposed to direct high radiation heat.
zThe relative humidity should be 90% or lower.
zThe HU-200TB SS-120 should not be exposed to splashed water or chemical agent.
zThe mechanical vibration in the location should be minimal.
zThe location should have adequate space to allow maintenance and wire connecting
work.
zThe location should be free from dust and corrosive gas.
zThe location should be minimally affected by an electromagnetic fields.
zThe altitude should be no more than 2000 m.
zThe range of fluctuations in supply voltage should be within 100 V to 240 V AC ±10%.
QDetector
zThe location should have adequate space to allow for checking and maintenance of the
detector.
zSpilled water should not adversely affect the location.
zUtilities should be made available for zero water.
zMeasured liquids should be those that will not damage the portion of the detector that
comes into contact with the liquid.
zSample must not freeze.
zFor an automatic cleaner, a 5 m cable can be connected between the automatic cleaner
and the converter.
Note
If measurements are made without depressurizing a pressurized sample, water may leak from the
pressure releasing hole. This is not an abnormality.
