horiba HR-200RT User manual

Residual Chlorine Monitor
HR-200RT
Instruction Manual
CODE:GZ0000361153

July, 2014 © 2014 HORIBA Advanced Techno, Co., Ltd.
Preface
This manual describes the operation of the Residual Chlorine Monitor, HR-200RT.
Be sure to read this manual before using the product to ensure proper and safe operation of
the product. Also safely store the manual so it is readily available whenever necessary.
Product specifications and appearance, as well as the contents of this manual are subject to
change without notice.
Warranty and responsibility
HORIBA Advanced Techno, Co., Ltd. warrants that the Product shall be free from defects in
material and workmanship and agrees to repair or replace free of charge, at option of HORIBA
Advanced Techno, Co., Ltd., any malfunctioned or damaged Product attributable to
responsibility of HORIBA Advanced Techno, Co., Ltd. for a period of one (1) year from the
delivery unless otherwise agreed with a written agreement. In any one of the following cases,
none of the warranties set forth herein shall be extended;
zAny malfunction or damage attributable to improper operation
zAny malfunction attributable to repair or modification by any person not authorized by
HORIBA Advanced Techno, Co., Ltd.
zAny malfunction or damage attributable to the use in an environment not specified in this
manual
zAny malfunction or damage attributable to violation of the instructions in this manual or
operations in the manner not specified in this manual
zAny malfunction or damage attributable to any cause or causes beyond the reasonable
control of HORIBA Advanced Techno, Co., Ltd. such as natural disasters
zAny deterioration in appearance attributable to corrosion, rust, and so on
zReplacement of consumables
HORIBA Advanced Techno, Co., Ltd. SHALL NOT BE LIABLE FOR ANY DAMAGES
RESULTING FROM ANY MALFUNCTIONS OF THE PRODUCT, ANY ERASURE OF DATA,
OR ANY OTHER USES OF THE PRODUCT.
Trademarks
Company names and brand names are either registered trademarks or trademarks of the
respective companies. (R), (TM) symbols may be omitted in this manual.

For Your Safety
Hazard classification and warning symbols
Warning messages are described in the following manner. Read the messages and follow the
instructions carefully.
QHazard classification
QWarning symbols
This indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the most
extreme situations.
This indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
This indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against
unsafe practices.
Without safety alert indication of hazardous situation which, if not avoided,
could result in property damage.
Description of what should be done, or what should be followed
Description of what should never be done, or what is prohibited

Safety precautions
This section provides precautions to enable you to use the product safely and correctly and to
prevent injury and damage. The terms of DANGER, WARNING, and CAUTION indicate the
degree of imminency and hazardous situation. Read the precautions carefully as it contains
important safety messages.
WARNING
If there is a possibility of a lightning strike, install an arrester on the output side and receiving
instrument side of the converter.
Electric shock hazard
Be sure to turn OFF the power before wiring power source.
Be sure to ground the grounding terminal. (The ground resistance shouldbe 100 Ωor less.)
To connect any load exceeding the contact capacity or any induction load (e.g., motor, pump), be sure
to use a power relay.
Beware of strong acid
When handling nitric acid, be sure to wear protective goggles and gloves.
If it gets into your eyes, it could cause irritation to the mucous membrane and the loss of eye sight. In
order to avoid this, immediately rinse your eyes with a large quantity of running water for at least 15
minutes and quickly seek medical help. When rinsing your eyes, open your eyelids well with your
fingers so that water can reach the eyeballs and the entire eyelids. If the nitric acid touches your skin
or clothing, it could cause burns. In order to avoid this, immediately take off your clothes and rinse off
the nitric acid with a large quantity of running water.
CAUTION
Take extra care when installing the sample inlet piping. If the piping is disengaged when the pressure
increases with the operation of the flow rate adjustment valve, serious accidents may occur.

Product Handling Information
Operational precautions
Use of the equipment in a manner not specified by the manufacturer may impair the protection
provided by the equipment. And it may also reduce equipment performance.
zDo not press any operation key with the tip of your nail or anything pointed.
zDo not use solutions such as organic solvents.
zWhen cleaning the measuring cell, be extremely careful not to scratch the brownish-red
area of the anode and reference electrode surfaces.
zDirect sunlight will reduce the silver chloride covering the reference and anode electrode.
Install the sensor in a room to avoid direct sunlight.
zBe sure not to scratch or contaminate the gold electrode section on the cathode surface.
If the surface of the gold electrode is scratched, it affects the reading.
zWhen reattaching the bead cell, confirm that there are no beads inside the measuring cell
and around the O-ring, and then push it into the measuring cell.
zGradually open the supply source valve. If you open it abruptly, the flow rate or pressure
exceeds the specified level. In such a case, the beads may pop up from the bead cell.
Open the sampling valve slowly. Fully open valve passes excessive flow rate that kicks
out the ceramic beads from the bead cell. The adequate flow rate is 0.1 L/min to 0.5 L/
min.
zDo not touch the rotating electrode.
Disposal of the product
When disposing of the product, follow the related laws and/or regulations of your country for
disposal of the product.
This product includes the lead battery of uninterruptible power supply system and the
tungsten lamp of the microscope light.

Manual Information
Description in this manual
Note
This interprets the necessary points for correct operation and notifies the important points for
handling the unit.
Reference
This indicates the part of where to refer the information.
Tip
This indicates reference information.
Term Definition
This document uses the following terms as defined:
Term Definition
Hold down Maintain pressing a key until the indicator turns ON or the display changes.
Press Lightly press only one time.
Flash Quickly flash several times, indicating that the setting has been finished.

Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Breakdown of complete set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Structure of residual chlorine meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Detector unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Example of tap water cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Names and functions of each part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Detector unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Description of operation section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Description of operation keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Description of display indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Description of operation modes and menu items . . . . . . . . . . . . . . . . . . . 9
Modes and menus from the meas mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installing on a measuring cell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Sample inlet piping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Sample outlet piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Option unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wire connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Opening the cover for the converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Contact output R1 to R3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Control output for zero calibration (AC voltage output) . . . . . . . . . . . . . . . . . . . 18
Transmission output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting the contact input terminal and flow switch input terminal . . . . . . . . 19
RS-485. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Detector and connector cable connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Preparation for operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Initial setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Meas mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setup menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cal menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
User check menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Periodic inspection list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Converter maintenance procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Detector unit maintenance procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Checking the sample flow rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Checking the residual chlorine concentration (analyzed value) (cross-check) . 47
Removing the detector contamination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Cleaning/replacing the bead filter A, bead filter and ceramic beads. . . . . . . . . 50
Cleaning the measuring cell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Replacement of the string wound filter (option) . . . . . . . . . . . . . . . . . . . . . . . . 51
Pausing the measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Restarting the measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Residual chlorine concentration calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Temperature calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Problems with measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Measurements exceeding the measurement range . . . . . . . . . . . . . . . . 59
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Description of error code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Troubleshooting for error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Detector unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Cathode electrode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Filter housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Flow switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Flow meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Zero filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Automatic calibration unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Manual calibration unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
What is residual chlorine? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Measurement principle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Sample liquid conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Replacement parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Disposing of the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Detector unit (RA-30) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Detector and measuring cell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Quick reference (appendix) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Overview
1
Overview
This is a residual chlorine meter with no chemical treatment to the sample. The main
components are the transmitter HR-200RT, the detector unit, measuring cell and some
peripheral units. It is suitable to monitor the residual chlorine concentration for those samples;
city water, swimming pool water, public bath and DI water plant using hypochlorite for
sterilization. The measuring range is 0 mg/L to 3 mg/L for residual chlorine and 0°C to 45°C.
The measuring principle is 3-pole polarograph method with the gold cathode electrode, silver
anode electrode and silver/silver chloride reference electrode. The temperature is measured
to compensate sensitivity influenced by sample temperature. If the sample pH is not steady,
the function to compensate the influence by pH is provided with the information from the pH
meter aside via RS-485 digital communication.
The replaceable cathode electrode attached to the rotating shaft is always polished in the
ceramic beads to be protected from metal plating on the surface.
The zero point is calibrated by the water through activated carbon filter. The manual operation
needs to change the line to pass the water through the activated carbon filter manually and
confirm the reading is near to zero before zero calibration. The sampling pipe works with the
optional solenoid valve will change the line periodically and automatically for zero calibration.
The sensitivity is calibrated by the way to match measured value to the analyzed value by
adjusting the coefficient.
The two line analog outputs transmit the trend of residual chlorine and temperature. The
output range of the current 1 is selectable by the external contact. The four contacts output the
upper or lower alarm for residual chlorine and temperature, control signal for residual chlorine,
holding signal, calibrating signal and error signal.
Those peripheral units are provided; the filter unit to remove dust, the flow switch to detect
flow, the flow meter unit to measure sample flow rate, the activated carbon filter unit to remove
residual chlorine, the auto zero calibration unit to control line for zero calibration.
QFeatures
zDrip-proof structure equivalent to IP65 for the converter
zConcurrent temperature display can be selected
zFront-face keys for all settings
zEnhanced maintenance function (self-check function)
zProgrammable transmission output range
zMemory backup function
zEasy to view display (150%zoom as compared with our conventional type)
zImproved key operability with embossed sheet
zEnhanced status display with icons
zDetectors achieve stable and highly accurate measurements
zNo-reagent measurement method eliminates time-consuming work such as reagent
replenishment
zEasy electrode replacement
z100 V to 240 V AC power supply

Overview
2
Unpacking
Upon delivery of this product, unpack it immediately and check the contents for completeness.
In addition, check this product for any damage at the same time.
JBreakdown of complete set
zConverter.....................1
(With a bracket and a cover)
zU bolt.......................................... 2
(U bolt: 2, M8 nut: 4, Spring washer: 4,
Flat washer: 4)
zInstruction manual (this book)..... 1
zDetector unit..............1
The detector unit is separately packed.
zCeramic beads...... 2
zFilter...................... 2
zFilter A .................. 2
zAbrasive paper.......1
zO-ring (S36)...........1

Overview
3
Structure of residual chlorine meter
JConverter
JDetector unit
QRA-30
*: (size) is approximate.
[Unit: mm]
Display
Conduit Front cover
(190)*
(180)*
(140)*
(340)*
IN
OUT
(140)*
*: (size) is approximate.
[Unit: mm]
Detector
Measuring
cell

Overview
4
JExample of tap water cradle
Converter
Detector
Sample outlet
Rc3/4
Sample inlet
Rc3/4
Filter
housing
Sampling cock
Flow switch
Measuring cell
Ball valve
(1500)*
50
(66)*
(100)*
Ball valve 3
400 (500)*
20
500 mm or more
maintenance space
340
(350)*500 mm or more
maintenance space
500 mm or more
maintenance space
700 mm or more
maintenance space
50
φ14 foundation
bolts (4 pcs.)
Installation dimension diagram (front view)
(790)*
*: (size) is approximate.
[Unit: mm]

Overview
5
Names and functions of each part
JConverter
QFront panel
Display section
The measured value and other
information are displayed here.
When the cover is opened, six operation
keys appear.
Up to six electric wires of 9 mm to
11.5 mm in diameter can be used.
Purge air is sent through this inlet to prevent
internal corrosion. Normally no connection is
required.
Conduit
Hood
This hood is used for outdoor
installation.
Front cover
Purge air inlet
When the four screws are removed, the
front case can be opened.
Front case screw
With front cover opened
Six operation keys are provided.
Operation key section
Screw cap
When the two screw caps are removed,
the front case screws appear.
Front case

Overview
6
QDisplay section
QOperation key section
QTerminal block
Status display
Indicator
Status display
Main display
Sub display
Sensor terminal
Power terminal
Transmission output terminal
RS-485 terminal
Fuse box
Power switch
Contact output terminal
Contact input terminal 1
Communication terminal
Contact input terminal 2

Overview
7
JDetector unit
(1) Connector cable
This is used for connecting with the converter (HR-200RT).
(2) Reference electrode
(3) Anode electrode
Note
If an impact is applied, the electrodes could be damaged. Be extremely careful when cleaning the
measuring cell or replacing the cathode electrode.
(4) Sample outlet
This is the outlet of the sample water. A 16 A vinyl chloride piping is used for the outlet.
(5) Measuring cell
Use this cell while the sample water level is stabilized.
(6) Sampling cock
(7) Sample inlet
This is an inlet of the sample water. For the inlet, connect a φ8 mm ×φ6 mm tube.
Or, use an R1/8 joint.
(8) Ceramic beads
These are for polishing/cleaning the cathode electrode surface.
Reference
Refer to “ Cleaning/replacing the bead filter A, bead filter and ceramic beads ” (page 50).
(9) Bead cell
This cell contains the ceramic beads for polishing/cleaning the cathode electrode surface.
When replacing the ceramic beads, remove the cell from the measuring cell.
(10) Cathode electrode
Note
When replacing the cathode electrode, be sure to confirm that the O-ring (S8) is inserted.
Reference
Refer to “ Replacing the cathode electrode ” (page 49).
(11)Nut
This is a nut for fixing the detector to the measuring cell.
OUT
IN
Detector
Measuring
cell

Overview
8
Description of operation section
JDescription of operation keys
Operation keys are used to switch displays, enter settings, and perform calibration.
You can change the value or item while the display is blinking.
Select a currently blinking value or item with S/T, and press ENT. The display will flash once,
and the setting will be finished.
Note
Do not press any operation key with the tip of your nail or anything pointed.
JDescription of display indicators
QStatus display
Key Notations
in the text Description/operation
ESC
Used to go back to the previous menu from any other menus.
While specifying various settings in the hold mode, pressing this key once will return to
the previous item.
Any change that was previously made to any setting is canceled.
Hold down Holding down this key in the hold mode will select the meas mode.
HOLD Hold down Holding down this key in the meas mode will select the hold mode.
Holding down this key in the hold mode will select the meas mode.
CAL Hold down Hold down this key until the CAL indicator turns ON. Calibration will be
started.
S
T
Used to change the displayed item or set value.
Pressing S/Twill increase/decrease the value by an increase/decrease of 1. Holding
down the key will continuously increase/decrease the value.
Sand Tare used to scroll up and down, respectively. If you scroll too far up or down
with either key, press the other key to return.
ENT
Used to confirm each setting or calibrated value.
Note
No change is made if you have returned to the previous menu by pressing ESC.
HOLD indicator
zTurns ON while the hold mode is active (transmission output is in a hold mode).
zStarts blinking when contact input is received or when the hold mode becomes
active due to an error.
CAL indicator Turns ON when the cal mode becomes active.
EXT1 indicator Turns ON when contact input 1 is received.
EXT2 indicator Turns ON when contact input 2 is received.
FAIL indicator Turns ON when the FAIL signal contact is output.
System error
indicator Turns ON when system error E-90, E-91, or E-92 occurs.
Sensor error
indicator Turns ON when any of sensor errors E-11 to E-72 occurs.

Overview
9
Description of operation modes and menu items
JModes and menus from the meas mode
Note
Press MEAS to return to the last menu.
Press
T
Contact output check
Refer to page 28.
Calibration value check
Refer to page 29.
Moving average count check
Allows you to set/change some of the values while
checking the display during measurement.
Allows you to check the calibration values during
measurement.
Refer to page 29.
Meas mode
Performs measurement and control.
to
Press S/T
You can change to the hold mode screen by holding down HOLD, and to the cal mode screen by holding
down CAL, in any of the above top screens of the meas mode, contact output check, calibration check, and
moving average count check.
Hold down CAL
Span cal mode
Hold mode
Setup menu
Cal menu
User check menu
Refer to page 43.
Refer to page 41.
Refer to page 30.
(Span calibration)
Performs calibration.
Measurement output hold
Allows you to specify various settings after stopping measurement and output.
Allows you to set up all the parameters related to measurement
before operation, such as input/output terminal allocation of the
detector information.
Allows you to select the calibration mode.
There are three types of calibration mode: zero solution
calibration, span calibration, and temperature calibration.
Allows you to check the output state or measured values. It
also allows you to return the set values to the factory settings.
Refer to page 55.
Press S/T
Hold
down
HOLD
Press S/T
Press S/T
Press
S/T
Press
S/T
Press
S/T
Press ESC
Press
ESC
Press
S

Installation
10
Installation
Installation environment
Followings are the conditions of the installation of the converter and the detector unit.
QConverter
zWell-ventilated location.
zAmbient temperature in the range of −20°C to 55°C.
zSpilled water does not adversely affect the location.
zNot exposed to direct sunlight.
zHeat is less likely to be generated.
zNot exposed to direct radiant heat.
zAmbient relative humidity in the range of 5%to 90%.
zThe converter is not splashed with water or chemicals.
zMechanical vibration is rare.
zThere is sufficient space for maintenance and wiring.
zDust and corrosive gases are not present.
zThe influence of electromagnetic fields is rare.
zThe altitude is 2,000 m at maximum.
zThe range of power supply voltage fluctuation is within ±10%of the rated value (100 V to
240 V AC).
QDetector unit
zInspection and maintenance for the detector unit can be performed.
zAmbient temperature in the range of 0°C to 45°C.
zSpilled water does not adversely affect the location.
zExcessive bubbles should not be included in the sample.
zThe sample should not attack the sensor unit.
zSamples do not freeze.
zNot exposed to direct sunlight.
zAmbient relative humidity in the range of 5%to 90%.
