Horizon Hobby axial 1940'S DODGE POWER WAGON User manual

INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D’UTILISATION
MANUALE DI ISTRUZIONI
AXI00007T1/T2
Before operating this vehicle, please read all printed
materials thoroughly. Horizon Hobby is not responsible
for inadvertent errors in this manual.
Scan the QR code and select the Manuals and Support quick links
from the product page for the most up-to-date manual information.
Scannen Sie den QR-Code und wählen Sie auf der Produktseite die Quicklinks
Handbücher und Unterstützung, um die aktuellsten Informationen zu Handbücher.
Scannez le code QR et sélectionnez les liens rapides Manuals and Support sur la
page du produit pour obtenir les informations les plus récentes sur le manuel.
Scannerizzare il codice QR e selezionare i Link veloci Manuali e Supporto dalla
pagina del prodotto per le informazioni manuali più aggiornate.
1940’S DODGE
POWER WAGON

EN
2
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the
product or other property. This product is not intended for use by children without direct adult supervision. Do not use with
incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This
manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and
warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or
resources tab for this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral
damage, and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or
no possibility of injury.
As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and
others or result in damage to the product or property of others.
This model is controlled by a radio signal subject to interference from many sources outside your control. This interference
can cause momentary loss of control, so it is advisable to always keep a safe distance in all directions around your model
as this margin will help avoid collisions or injury.
• Never operate your model with low transmitter batteries.
• Always operate your model in open spaces away from full-size vehicles, traffic and people.
• Never operate the model in the street or in populated areas for any reason.
• Carefully follow the directions and warnings for this and any optional support equipment
(chargers, rechargeable battery packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Never lick or place any portion of the model in your mouth as it could cause serious injury or even death.
• Exercise caution when using tools and sharp instruments.
• Take care during maintenance as some parts may have sharp edges.
• Immediately after using your model, do NOT touch equipment such as the motor, electronic speed control and battery,
because they generate high temperatures. You may burn yourself seriously touching them.
• Do not put fingers or any objects inside rotating and moving parts, as this may cause damage or serious injury.
• Always turn on your transmitter before you turn on the receiver in the car. Always turn off the receiver before turning
your transmitter off.
• Keep the wheels of the model off the ground when checking the operation of the radio equipment.
SAFETY PRECAUTIONS AND WARNINGS

EN
3
TABLE OF CONTENTS
Safety Precautions and Warnings ....................................2
Table of Contents..............................................................3
Box Contents.....................................................................3
USB Charging Warnings ...................................................4
charge the Vehicle Battery................................................4
Transmitter Functions........................................................5
servo Travel.......................................................................6
Install the Transmitter Batteries.......................................6
Remove the Vehicle Body .................................................6
Install the Vehicle Battery.................................................7
Power on the Transmitter..................................................7
Power on the Vehicle ........................................................8
Test the Controls...............................................................8
After Driving......................................................................9
Binding the Transmitter and Receiver...............................9
Receiver and ESC wiring Diagram....................................9
Troubleshooting...............................................................10
Parts List..........................................................................10
Limited Warranty ............................................................11
Warranty and Service Contact Information....................12
FCC Information...............................................................12
IC Information..................................................................13
Compliance Information for the European Union ...........13
Exploded Views...............................................................48
BOX CONTENTS
SPECIFICATIONS
Length 9.65” (245mm)
Width 4.2” (107mm)
Height 3.9” (100mm)
Operating Weight 11.5 oz (325.5g)
INCLUDED COMPONENTS
Vehicle SCX24 1940s Dodge Power Wagon 1/24th Scale
RTR (AXI00007)
Transmitter SLT2 2.4 GHz 3 channel (SPMRSLT200)
Charger USB LiPo Charger (SPMXC0030)
Vehicle Battery 7.4V, 350mAh, 2S LiPo (SPMX3502S30)
Motor SCX24 030-Motor with Pinion (DYNS1217)
ESC/Receiver 2-in-1 ESC/Rx with Forward and Reverse
(SPMXSE2425RX)
Servo AS-1 Micro Servo (AXI31619)
Transmitter Batteries (4) AA Alkaline

EN
4
USB CHARGING WARNINGS
CHARGE THE VEHICLE BATTERY
WARNING: Failure to exercise caution while using this product and comply with the following warnings could
result in product malfunction, electrical issues, excessive heat, FIRE, and ultimately injury and property damage.
• NEVER LEAVE CHARGING BATTERIES UNATTENDED.
• NEVER CHARGE BATTERIES OVERNIGHT.
• Never attempt to charge dead, damaged or wet battery packs.
• Never attempt to charge a battery pack containing different types of batteries.
• Never allow children under 14 years of age to charge battery packs.
• Never charge batteries in extremely hot or cold places or place in direct sunlight.
• Never charge a battery if the cable has been pinched or shorted.
• Never connect the charger if the power cable has been pinched or shorted.
• Never attempt to dismantle the charger or use a damaged charger.
• Always use only rechargeable batteries designed for use with this type of charger.
• Always inspect the battery before charging.
• Always keep the battery away from any material that could be affected by heat.
• Always monitor the charging area and have a fire extinguisher available at all times.
• Always end the charging process if the battery becomes hot to the touch or starts to change form (swell) during the
charge process.
• Always connect the positive leads (+) and negative leads (–) correctly.
• Always disconnect the battery after charging, and let the charger cool between charges.
• Always charge in a well-ventilated area.
• Always terminate all processes and contact Horizon Hobby if the product malfunctions.
• Charge only rechargeable batteries. Charging non-rechargeable batteries may cause the batteries to burst, resulting
in injury to persons and/or damage to property.
• The USB outlet shall be installed near the equipment and shall be easily accessible.
CAUTION: Always ensure the battery you are charging meets the specifications of this charger. Not doing so
can result in excessive heat and other related product malfunctions, which can lead to user injury or property
damage. Please contact Horizon Hobby or an authorized retailer with compatibility questions.
CAUTION: If at any time during the charge process the battery pack becomes hot or begins to puff, disconnect the
battery immediately and discontinue the charge process as batteries can cause fire, collateral damage and injuries.
Use only the included USB charger to charge the battery.
1. Connect the charger to a suitable USB power port. The charger will work with most 5V
mobile power sources or smartphone chargers with at least 1 amp of power output.
NOTICE: Charging the battery with a USB power port with less than 1 amp of power
output can produce heat.
2. Connect the charge lead to the battery, noting correct polarity. Charging a fully
discharged battery takes approximately 45–60 minutes. Charge times may vary
depending on the power source.
3. Remove the battery from the charger when the charging cycle is complete.
4. Remove the charger from the power supply.
CAUTION: Once charging is complete, immediately remove
the battery. Never leave a battery connected to the charger.
CHARGER LED INDICATIONS
RED, solid = Charging error: ensure battery is healthy and
properly connected to the charger
ORANGE, solid = Charging in progress
GREEN, solid = Charging complete
ORANGE/GREEN, flashing =Charger is
ready to charge

EN
5
TRANSMITTER FUNCTIONS
A. Steering Trim
Adjusts the front steering center point. Normally, the steering
trim is adjusted until the vehicle tracks straight.
B. LED
• Solid red lights: Indicates the power is ON and adequate
battery power.
• Flashing red lights: Indicates the battery voltage is critically
low. Replace batteries.
C. Steering Wheel
D. Throttle/Brake
E. Steering Rate
On-The-Fly knob for travel adjustment on the steering.
F. Throttle Limit
Limits throttle output to 50/75/100%
Select 50% or 75% for less experienced drivers or when you
are driving the vehicle in a small area.
G. Steering (ST) Servo Reversing
Move the switch to reverse the steering channel.
H. Power Button
A.
B.
C.
D.
E.
F.
G.
H.
Specifications
Power Supply: 4 AA Batteries
Operating Frequency: 2.4GHz
Transmit Power: <100mw
Control Protocol: SLT

EN
6
INSTALL THE TRANSMITTER BATTERIES
SERVO TRAVEL
CAUTION: NEVER remove the transmitter
batteries while the vehicle is powered ON.
Loss of vehicle control, damage, or injury may occur.
CAUTION: If using rechargeable batteries,
charge only rechargeable batteries. Charging
non-rechargeable batteries may cause the batteries to
burst, resulting in injury or property damage.
CAUTION: Risk of explosion if battery is
replaced by an incorrect type. Dispose of used
batteries according to state and local laws.
1. Press the battery compartment latch and
rotate the batter cover to open.
2. Install 4 AA alkaline batteries (or Ni-Cd or
Ni-MH), verifying correct polarity.
3. Close the battery cover until it latches.
1. Begin with the transmitter binding process to the
receiver complete. Power ON the receiver.
2. Hold full right and full brake while powering the
transmitter ON to put the transmitter into program-
ming mode.
The LED on the transmitter will flash 4 times to
indicate it is in programming mode.
3. Turn and hold the wheel full left to set the travel
limit for that direction, Press the A button to in-
crease travel, press the B button to reduce travel.
The LED will flash once with every change. Return
the wheel to center to set the travel value.
IMPORTANT: If the value has reached the maximum or
minimum that can be accepted, the LED will not flash with
further input.
4. Turn the wheel to the right and repeat the process to
set the steering travel to the right.
5. For electric vehicles, power the Transmitter OFF to
save the settings. Calibrate your ESC to the default
throttle travel.
6. For fuel powered vehicles, set the throttle travel
without the engine running; After setting steering
travel, you can set throttle travel with the same
process. Pull and hold full throttle, adjust travel
with the A and B buttons, return to center to set the
value.
7. Push full brake, adjust travel with the A and B but-
tons, return to center.
8. Power the transmitter OFF to save the values.
The servo travel on the Steering and Throttle channels can be
adjusted through a special programming mode in the transmitter.
REMOVE THE VEHICLE BODY

EN
7
INSTALL THE VEHICLE BATTERY
POWER ON THE TRANSMITTER

EN
8
POWER ON THE VEHICLE
With the vehicle wheels off the ground, test the throttle
and steering controls. Ensure the wheels spin in the proper
direction and the front wheels turn in the proper direction
with steering input.
After checking for proper direction of controls, start driving
slowly. If the vehicle does not go straight without steering
input, adjust the steering trim dial on the transmitter until
the vehicle holds a straight line with no steering input.
Have FUN driving your vehicle!
TEST THE CONTROLS

EN
9
AFTER DRIVING
When you are finished driving your vehicle:
1. Power off the vehicle. 2. Power off the transmitter. 3. Remove the vehicle battery
and charge if necessary.
BINDING THE TRANSMITTER AND RECEIVER
RECEIVER AND ESC WIRING DIAGRAM
Binding is the process of programming the receiver to recognize a specific transmitter signal, thus preventing interference
from other transmitters. The transmitter and receiver included with your vehicle are bound at the factory. If you need to
rebind, follow the instructions below.
NOTICE: Do not attempt to bind the transmitter and reciever if any other compatible transmitters are in bind mode
within approximately 400 feet (120 meters). Doing so may result in unexpected binding to the wrong transmitter and
loss of control of your vehicle.
Prior to starting the binding procedure, ensure the servos and motor are connected to the proper ports on the receiver
and the transmitter has fresh batteries installed.
1. Insert the bind plug into the receiver.
2. Power on the receiver. The receiver LED will flash rapidly.
3. Power on the transmitter while pressing the BIND button. The transmitter LED will flash.
4. When the LED glows solid, binding is complete.
The receiver LED will glow solid when both the transmitter and receiver are powered on. If the receiver LED flashes
rapidly or is not illuminated, the transmitter and receiver are not bound. Power off both the transmitter and receiver and
repeat the binding procedure.
Antenna
LED
Motor Port Battery Port Power Switch
Mode (Jumper)
Bind Port
Front Steering
Throttle
(For optional external ESC,
not used with stock motor)
Forward/Reverse, no
Brake. Recommended
for crawlers.
Forward/Brake/Reverse Not
recommended for crawlers.

EN
10
PARTS LIST
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Vehicle does not move
Batteries are not installed properly in the
transmitter Ensure the transmitter batteries are properly installed
Weak or no battery in the vehicle Install a freshly charged vehicle battery
Damaged motor Replace the motor
Frayed or broken wiring Replace any damaged wiring
ESC is shut down by heat protection circuit Allow the ESC to cool down completely
Loss of vehicle control
Improper antenna placement Ensure the transmitter antenna is not blocked
and the receiver antenna is located properly
Weak or no batteries in the transmitter
or vehicle Install a freshly charged vehicle battery and new transmitter batteries
Neutral or trim position is incorrect Adjust the steering trim
Receiver and/or battery not connected properly Check all receiver and battery connections
Steering and/or throttle
function is reversed
Servo travel is reversed at the transmitter Set the transmitter servo reversing switch to
the correct position
Motor wires are not connected properly Check all motor wires for correct polarity and
secure connection
AXI10001 LED Light Set: SCX24 Dodge Power Wagon
AXI200008 Overland Acc Pack: SCX24 Glad
AXI200013 Body,White: SCX24 Dodge Power Wagon
AXI200014 Cage Set: SCX24 Dodge Power Wago
AXI200015 Bumper Set: SCX24 Dodge Power Wagon
AXI200016 Inner Fenders, Frnt: SCX24 DPW
AXI201003 Chassis, XL WB 153.7mm: SCX24
AXI202000 Driveshaft Set Short & XL: SCX24
AXI203002 OilShkSt6mm(.213LBS/INRed): SCX24
AXI203003 SpngSt(146Ppl,213Rd,272Gn): SCX24
AXI204001 Susp Links, XL WB 153.7mm: SCX24
AXI31608 Transmission, Assembled: SCX24, AX24
AXI31609 Steering Axle, Assembled: SCX24, AX24
AXI31610 Straight Axle, Assembled: SCX24, AX24
AXI31619 AS-1 Micro Servo
AXIC1147 AX31147 Nylon Lock Nut 2mm(10)
DYNS1217 SCX24 Motor with Pinion
SPMX3502S30 350 mAh 2S 7.4V LiPo with PH2.0 2p
SPMXC0030 2S USB-C PH2.54 JST-XH Charger
SPMXS2425RX 2n1 10a SLT ESC/RX 1/24 Scale
Optional Parts:
Check the SCX24 product page at axialadventure.com for
the latest releases
AXI302001 Diff Cover, Brass: SCX24, AX24
AXI302002 Hex Hub, Brass (2): SCX24, AX24
AXI302003 Knuckles, Brass: SCX24, AX24
AXI302004 Knckl Wghts, Brass(4): SCX24, AX24
AXI302005 Servo Mount, Brass: SCX24, AX24
AXI302006 Rear Upper Lnk Mnt, Brass: SCX2
AXI31567 1.0 Nitto Trail Grappler M/T V1 4p
AXI31615 1.0 KMC Machete Wheels (4): SCX24,
AX24
AXI40000 1.0 Method MR307 whls(4): SCX24, AX24
AXI40001 1.0 BFG KrawlerT/A Tire(4): SCX24, AX24
AXI40004 1.0 Nitto Trl Grapp V2 Tire(4): SCX24,
AX24
DYNH2027 SS Screw Set: Axial SCX24
SPMXC1050 Smart S1500 DC Charger, 1x500W
SPMXC2050 Smart S155 G2 AC 1x55W Charger
SPMXCA309 Adapter: IC3 Battery/JST PH2.0 Dev.
AXI302005 Servo Mount, Brass: SCX24, AX24
AXI302004 Knuckle Weights, Brass (4): SCX24, AX24
AXI302003 Knuckles, Brass (L/R): SCX24, AX24
AXI302001 Differential Cover, Brass: SCX24, AX24
DYNH2027 SS Screw Set: Axial SCX24
DYNT0503 Startup Tool Set: Axial 1/24
PRO1021410 1/24 Interco Super Swamper F/R 1.0”
Tires MTD 7mm Black Holcomb (4)
PRO1020910 1/24 Trencher Fr/Rr 1.0” Tires Mounted
7mm Black Impulse (4)
PRO616900 1.0" Dual Stg Rck Crwlng Insrts
PRO1019410 1/24 Hyrax Front/Rear 1.0” Tires Mounted
7mm Black Impulse (4)
PRO1021510 1/24 Mickey Thompson Baja Pro X F/R
1.0” MTD 7mm Black Holcomb (4)
