Horizon Hobby LOSI LOS03041 User manual

NO PREP DRAG ROLLER
1/10 2WD
Before operating this vehicle, please read all
printed materials thoroughly. Horizon Hobby is not
responsible for inadvertent errors in this manual.
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D’UTILISATION
MANUALE DI ISTRUZIONI
Scan the QR code and select the
Manuals & Support tab from the product
page for the most up-to-date information
Battery,Battery,
Charger,Charger,
ElectronicsElectronics
Not IncludedNot Included

EN
2LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in dam-
age to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and
responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with
incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and mainte-
nance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon
Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM
or Spektrum.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or
towerhobbies.com and click on the support or resources tab for this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
As the user of this product, you are solely responsible for operating in a manner that does not
endanger yourself and others or result in damage to the product or property of others.
This model is controlled by a radio signal subject to interference from many sources outside
your control. This interference can cause momentary loss of control, so it is advisable to
always keep a safe distance in all directions around your model as this margin will help avoid
collisions or injury.
• Never operate your model with low transmitter batteries.
• Always operate your model in open spaces away from full-size vehicles, traffic and people.
• Never operate the model in the street or in populated areas for any reason.
• Carefully follow the directions and warnings for this and any optional support equipment
(chargers, rechargeable battery packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Never lick or place any portion of the model in your mouth as it could cause serious injury
or even death.
• Exercise caution when using tools and sharp instruments.
• Take care during maintenance as some parts may have sharp edges.
• Immediately after using your model, do NOT touch equipment such as the motor, electronic
speed control and battery, because they generate high temperatures.You may burn yourself
seriously touching them.
• Do not put fingers or any objects inside rotating and moving parts, as this may cause
damage or serious injury.
• Always turn on your transmitter before you turn on the receiver in the car. Always turn off the
receiver before turning your transmitter off.
• Keep the wheels of the model off the ground when checking the operation of the radio
equipment.
SAFETY PRECAUTIONS AND WARNINGS
BOX CONTENTS
INCLUDED REQUIRED
COMPONENTS RECOMMENDED COMPONENTS PART NUMBER
Losi®Brushless 22S
No Prep Drag Roller
2+ Channel Radio Control System Spektrum DX5C DSMR 5CH TX Only, SR315 Receiver SPM5115
SPMSR315
High Torque Steering Servo Spektrum 6KG Waterproof Servo SPMS606
ESC Spektrum Firma 100 Amp Smart ESC SPMXSE1100
Motor Spektrum 3652 4-Pole Brushless Motor 6500Kv SPMXSM2800
Pinion 16T See parts list
2S Hardcase LiPo Battery 50C or Higher Spektrum 2S
Smart Hardcase LiPo with IC5 SPMX50002S100H5
Charger Spektrum SMART S1200 DC Charger, 1x200W SPMXC1000
REQUIRED TOOLS
1.5mm Hex Driver
2.0mm Hex Driver
2.5mm Hex Driver
5.5mm Nut Driver
7.0mm Nut Driver
TABLE OF CONTENTS
BOX CONTENTS........................................................................................................2
QUICK START............................................................................................................3
INSTALL THE MOTOR ................................................................................................3
SETTING THE GEAR MESH ............................................................................................3
INSTALL THE SERVO .................................................................................................3
INSTALL THE ESC......................................................................................................4
INSTALL THE RECEIVER ............................................................................................4
INSTALL THE BATTERY..............................................................................................5
WHEELIE BAR ADJUSTMENT ....................................................................................5
ROUGH TUNING...........................................................................................................5
FINE TUNING................................................................................................................5
CAMBER ADJUSTMENT ............................................................................................5
TOE ADJUSTMENT ........................................................................................................5
REAR DIFFERENTIAL REMOVAL................................................................................6
DRIVING PRECAUTIONS...........................................................................................7
POWERING ON THE VEHICLE....................................................................................7
BEFORE RUNNING YOUR VEHICLE............................................................................7
RUN TIME.................................................................................................................7
TO IMPROVE RUN TIMES...................................................................................................7
PERFORMING A CONTROL DIRECTION TEST.............................................................7
TROUBLESHOOTING GUIDE......................................................................................7
2-YEAR LIMITED WARRANTY ...................................................................................8
WARRANTY AND SERVICE CONTACT INFORMATION................................................8
COMPLIANCE INFORMATION FOR THE EUROPEAN UNION......................................8
EXPLODED VIEW ..............................................................................................29–33
REPLACEMENT PARTS ......................................................................................34–35
RECOMMENDED PARTS..........................................................................................35
OPTIONAL PARTS .............................................................................................36–37

3
EN
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
QUICK START
Please read the entire manual to gain a full understanding of the 22S Roller, fine-tuning the setup and performing maintenance.
1. Read the safety precautions found in this manual.
2. Install the motor, receiver, ESC, and steering servo.*
3. Connect the steering drag link to the servo saver.
4. Route the servo and ESC wires, and connect them to the receiver.
5. Charge a battery* for the vehicle. Refer to your charger* manual for impor-
tant charging warnings and instructions.
6. Install the fully charged battery in the vehicle.
7. Bind the receiver to the transmitter. Verify the controls are centered.
8. Mount the servo saver to the servo with steering centered.
9. Adjust the servo direction and travel as needed in the transmitter.
10. Calibrate the ESC.
11. Install the cover on the receiver.
12. Verify the steering and throttle control directions. Reverse the servo in the
transmitter if the steering is reversed. Reverse the motor with the wire
connections or ESC settings if the throttle is backward.
13. Install the wheels.
14. Drive your vehicle.
15. Disconnect the battery when done driving.
*Electronics not included
INSTALL THE MOTOR INSTALL THE SERVO
1. Install the pinion gear on the motor. Place the pinion
on the end of the motor shaft so the set screw is
located over the flat on the shaft.
2. Position it so the teeth line up with the spur gear
and secure the pinion by tightening the set screw.
3. Install the motor. Two slots will line up with the mo-
tor mounting holes. The motor can slide forward or
back to obtain proper gear mesh.
CAUTION: It is important to set the gear mesh properly. Failure to do so will result
in stripped gears.
4. Install the gear cover.
1. Using a 2mm hex driver, remove the four (4) screws on the top of the front-end brace.
2. Remove the four (4) screws that secure the servo mounting bracket to the chassis.
SETTING THE GEAR MESH
Proper gear mesh (how gear teeth meet) is important to the performance
of the vehicle. When the gear mesh is too loose,
the spur gear could be damaged by the pinion
gear of the motor. If the mesh is too tight,
speed could be limited and the motor and ESC
will overheat.
1. Loosen the motor screws and slide the
motor back.
2. Put a small piece of paper between the pinion
and spur gears.
3. Push the gears together while tightening the motor screws.
4. Remove the paper. Check the mesh at 3–5 different locations around the spur gear for a
small amount of movement.
Pinion sold separately

EN
4LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
1. Install the ESC. Connect the motor wires to the ESC. Refer to the ESC manual for more
information.
2. Run the throttle lead to the receiver box.
3. To power auxiliary options such as lights, run the leads into the receiver box.
3. Remove the four (4) screws that hold the right-side mud guard.
4. Remove the servo brackets from the chassis, and mount the servo with the output shaft
toward the right side of the chassis.
5. Remove the servo horn from the steering link.
6. Center the steering servo by plugging the servo into the receiver, or using a servo checker.
Install the servo horn so the ball is 90°.
NOTE: Before installing the servo horn, verify the transmission servo trim is centered.
7. Slide the servo into position on the chassis, and loosely secure the assembly to the chassis
using the two (2) rear screws.
8. Route the servo wire down the right mud guard using the supplied hooks to guide
the wire to the receiver box. Then secure the mud guard using the four (4)screws from
underneath.
9. Replace all the screws that were removed during the disassembly.
10.Secure the steering link to the servo horn ball to complete the servo installation.
INSTALL THE RECEIVER
1. Remove the two receiver box lid screws, and install the receiver with double-sided or hook
and loop tape.
2. Insert the servo and ESC connectors into the appropriate ports on the receiver.
3. Connect the steering drag link to the servo saver (not yet connected to the servo).
4. Verify the steering servo is centered and traveling in the correct direction.
5. With the steering linkage centered, connect the servo saver to the servo, and install the
included servo screw.
6. Check the steering direction and travel, and fine tune the center point using the transmitter
settings. See the transmitter manual for additional information.
TLR
LOK
INSTALL THE ESC

5
EN
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
INSTALL THE BATTERY
The Losi 22S drag car wheelie bar is designed to provide optimal adjustment.There are two
adjustment options, allowing for height fine tuning, as well as easy adjustment.
ROUGH TUNING
1. Move the lower turnbuckle attachment point forward or backward to set the wheelie bar to
the required height.
2. Move the attachment point back to raise the wheelie bar and to provide more support to
the wheelie bar rear.
FINE TUNING
Adjust the turnbuckle to fine tune the wheelie bar height, precisely controlling the height of
the wheelie bar wheels from the ground.
TIP: Wheelie bar wheels ½ inch from the ground provides appropriate clearance and ad-
equate rear wheel traction during full acceleration.
CAMBER ADJUSTMENT
Camber is the angle of the wheel top from straight up and down.
Leaning in is Negative Camber; leaning out is Positive Camber.
As the vehicle turns, the chassis rolls.As the vehicle rolls, the tires lean toward the turn, caus-
ing less tire surface to come in contact with the ground (at 0° camber). To compensate for
this, a few degrees of negative camber are added at the factory.
Front Camber Effects: Adding approximately -1 to -2 negative camber provides optimal
contact to the ground, allowing for adequate front end traction. Adding additional camber
decreases steering traction. If the steering feels loose, remove a degree of camber.
Rear Camber Effects: Camber affects two things on rear suspension. In a straight line,
maximum acceleration is achieved using 0° of camber. Adding camber reduces forward trac-
tion, but increases steering stability. If the vehicle is loose, add rear camber to keep the vehicle
going straight.
1. To adjust the front and rear camber, select one of several hole positions on both hubs as
well as the camber blocks. The rear camber block is integrated into the shock tower.
2. Adjust the turnbuckle for fine tuning.
TOE ADJUSTMENT
FRONT
Adding Toe-In will increase on-power steering and provide a more directing steering feel.
Adding Toe-Out will decrease on-power steering and may provide the feel of more rear traction.
REAR
More Toe-In: Increased forward traction. Increase toe-in on lower traction surfaces.
Less Toe-In: Decreased forward traction. Decrease toe-in on higher traction surfaces.To adjust
the rear toe:
The stock rear toe on the 22S Roller is 3 Degrees. Adjust the rear toe using the Rear Pivot
Block Set (LOS234048) which includes 1.5, 3, and 4.5-degree pivot blocks.
1. Ensure the ESC is powered OFF.
2. Remove one side of the elastomer strap from the battery posts.
3. Slide a fully charged battery in through the vehicle front until the battery drops into place.
4. Resecure the elastomer straps to the battery posts.
5. Connect the battery to the ESC noting the correct polarity.
6. Power ON the transmitter, then the vehicle.
WHEELIE BAR ADJUSTMENT
TOE-IN
TOE-OUT

EN
6LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
REAR DIFFERENTIAL REMOVAL
1. To remove the rear differential, start by removing the two (2) rear tires using a 7mm nut
driver.
2. Remove the two (2) rear camber links.
3. Using a 2.0mm allen driver, remove the six (6) screws holding the transmission and rear
motor guard to the aluminum chassis.
4. Using a 2.0mm allen driver, remove the wheelie bar upper attachment.
5. Remove the rear body mount.
6. Remove the four (4) screws securing the transmission to the chassis, then remove the
motor guard and wheelie bar.
7. Remove the gear cover, spur gear, and slipper plates on the left side of the chassis.
8. Disconnect the three brushless motor wires from the ESC.
9. Remove the rear pivot block and rear arms.
10. Remove the transmission pass through screw, and slide the transmission out of the chassis
(lift up and back).
11. Use a 2.5mm driver to remove the motor from the transmission.
12. Remove the three (3) screws on the left side of the transmission, and remove the side
cover.
13. Slide the differential out of the transmission.

7
EN
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
BEFORE RUNNING YOUR VEHICLE
1. Check for free suspension movement. All suspension arms and steering components should
move freely. Any binds will cause the vehicle to handle poorly.
Tip: To increase the ride height and ground clearance of your vehicle, install the included
shock spacers.
2. Charge a battery pack. Always charge the battery pack as per the battery and/or
charger manufacturers’ instructions.
3. Set the transmitter steering trim. Follow the instructions to set the steering trim/subtrim
so that the vehicle drives straight with no input to the steering.
4. Perform a Control Direction Test.
RUN TIME
The largest factor in run time is the capacity of the battery pack. A larger mAh rating increases
the amount of run time experienced.
The condition of a battery pack is also an important factor in both run time and speed. The
battery connectors may become hot during driving. Batteries will lose performance and
capacity over time.
Driving the vehicle from a stop to full speed repeatedly will damage the batteries and
electronics over time. Sudden acceleration will also lead to shorter run times.
TO IMPROVE RUN TIMES
• Keep your vehicle clean and well maintained.
• Allow more airflow to the ESC and motor.
• Change the gearing to a lower ratio. A lower ratio decreases the operating temperature
of the electronics. Use a smaller pinion gear or larger spur gear to lower the gear ratio.
• Use a battery pack with a higher mAh rating.
• Use the optimum charger to charge battery packs.
PERFORMING A CONTROL DIRECTION TEST
Perform a control test with the vehicle wheels off the ground. If the wheels rotate after the
vehicle is powered ON, adjust the TH Trim knob until they stop.To make the wheels move
forward, pull the trigger. To reverse them, wait for the wheels to stop, then push the trigger.
When moving forward, the wheels should maintain a straight line without any steering wheel
input. If not, adjust the ST Trim knob, so the wheels maintain a straight line without having to
turn the steering wheel.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE SOLUTION
Vehicle does not operate
Battery not charged or plugged in Charge battery/plug in
ESC switch not “ON” Turn on ESC switch
Transmitter not “ON” or low battery Turn on/replace batteries
Motor runs but wheels
do not rotate
Pinion not meshing with spur gear Adjust pinion/spur mesh
Pinion spinning on motor shaft Tighten pinion gear setscrew on motor shaft flat spot
Transmission gears stripped Replace transmission gears
Drive pin broken Check and replace drive pin
Steering does not work Servo plug not in receiver properly Make sure the steering servo plug is connected to the receiver steering channel, noting proper polarity
Servo gears or motor damaged Replace or repair servo
Will not turn one direction Servo gears damaged Replace or repair servo
Motor does not run
Motor wire solder joint is damaged Resolder the motor wire with the proper equipment
Motor wire broken Repair or replace as needed
ESC damaged Contact Horizon Hobby Product Support
Battery voltage is low Check battery voltage and charge if necessary
ESC gets hot Motor over-geared Use smaller pinion or larger spur gear
Driveline bound up Check wheels and transmission for binding
Poor run time and/or sluggish
acceleration
Battery pack not fully charged Recharge battery
Charger not allowing full charge Try another charger
Driveline bound up Check wheels, transmission for binding
Poor range and/or glitching
Transmitter batteries low Check and replace
Vehicle battery low Recharge battery
Loose plugs or wires Check all wire connections and plugs
DRIVING PRECAUTIONS
• Maintain sight of the vehicle at all times.
• Routinely inspect the vehicle for loose wheel hardware.
• Routinely inspect the steering assembly for any loose hardware. Driving the vehicle
off-road can cause fasteners to loosen over time.
• Do not drive the vehicle in tall grass. Doing so can damage the vehicle or electronics.
• Stop driving the vehicle when you notice a lack of power. Driving the vehicle when
the battery is discharged can cause the receiver to power off. If the receiver loses power,
you will lose control of the vehicle. Damage due to an over-discharged Li-Po battery is
not covered under warranty.
CAUTION: Do not discharge a Li-Po battery below 3V per cell. Batteries discharged
to a voltage lower than the lowest approved voltage may become damaged,
resulting in loss of performance and potential fire when batteries are charged.
• Do not apply forward or reverse throttle if the vehicle is stuck.
Applying throttle in this instance can damage the motor or ESC.
• After driving the vehicle, allow the electronics to cool before driving the vehicle again.
IMPORTANT: Keep wires away from all moving parts.
POWERING ON THE VEHICLE
1. Center the ST TRIM and TH TRIM dials on the transmitter.
2. Power on the transmitter.
3. Install a fully charged battery pack per the Installing the Battery section.
4. Power on the ESC.
IMPORTANT: The vehicle MUST remain on a flat, level surface and motionless
for at least 5 seconds.

EN
8LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD • INSTRUCTION MANUAL
2-YEAR LIMITED WARRANTY
What this Warranty Covers
Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased
(the “Product”) will be free from defects in materials and workmanship 2-years from the date of
purchase.
What is Not Covered
This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due
to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use,
installation, operation or maintenance, (iii) modification of or to any part of the Product, (iv)
attempted service by anyone other than a Horizon Hobby authorized service center, (v) Product
not purchased from an authorized Horizon dealer, or (vi) Product not compliant with applicable
technical regulations or (vii) use that violates any applicable laws, rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO OTHER WARRANTY
OR REPRESENTATION, AND HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.THE PURCHASER
ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY
MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
Purchaser’s Remedy
Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon
will, at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be
defective. Horizon reserves the right to inspect any and all Product(s) involved in a warranty
claim. Service or replacement decisions are at the sole discretion of Horizon. Proof of purchase
is required for all warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY,
REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT,WARRANTY,TORT,
NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability
of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon
has no control over use, setup, final assembly, modification or misuse, no liability shall be
assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly,
the user accepts all resulting liability. If you as the purchaser or user are not prepared to
accept the liability associated with the use of the Product, purchaser is advised to return the
Product immediately in new and unused condition to the place of purchase.
Law
These terms are governed by Illinois law (without regard to conflict of law principals). This
warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. Horizon reserves the right to change or modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services
Your local hobby store and/or place of purchase cannot provide warranty support or service.
Once assembly, setup or use of the Product has been started, you must contact your local
distributor or Horizon directly. This will enable Horizon to better answer your questions and
service you in the event that you may need any assistance. For questions or assistance, please
visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or call the toll
free telephone number referenced in the Warranty and Service Contact Information section to
speak with a Product Support representative.
Inspection or Services
If this Product needs to be inspected or serviced and is compliant in the country you live
and use the Product in, please use the Horizon Online Service Request submission process
found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA)
number. Pack the Product securely using a shipping carton. Please note that original boxes
may be included, but are not designed to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and insurance for lost or damaged parcels,
as Horizon is not responsible for merchandise until it arrives and is accepted at our facility.
An Online Service Request is available at http://www.horizonhobby.com/content/service-
center_render-service-center. If you do not have internet access, please contact Horizon
Product Support to obtain a RMA number along with instructions for submitting your product
for service. When calling Horizon, you will be asked to provide your complete name, street
address, email address and phone number where you can be reached during business hours.
When sending product into Horizon, please include your RMA number, a list of the included
items, and a brief summary of the problem. A copy of your original sales receipt must be
included for warranty consideration. Be sure your name, address, and RMA number are clearly
written on the outside of the shipping carton.
NOTICE: Do not ship Li-Po batteries to Horizon. If you have any issue with a
Li-Po battery, please contact the appropriate Horizon Product Support office.
Warranty Requirements
For Warranty consideration, you must include your original sales receipt verifying
the proof-of-purchase date. Provided warranty conditions have been met, your Product
will be serviced or replaced free of charge. Service or replacement decisions are at the sole
discretion of Horizon.
Non-Warranty Service
Should your service not be covered by warranty, service will be completed and
payment will be required without notification or estimate of the expense unless
the expense exceeds 50% of the retail purchase cost. By submitting the item for
service you are agreeing to payment of the service without notification. Service estimates are
available upon request.You must include this request with your item submitted for service.
Non-warranty service estimates will be billed a minimum of ½ hour of labor. In addition you
will be billed for return freight. Horizon accepts money orders and cashier’s checks, as well as
Visa, MasterCard, American Express, and Discover cards. By submitting any item to Horizon for
service, you are agreeing to Horizon’s Terms and Conditions found on our website http://www.
horizonhobby.com/content/service-center_render-service-center.
ATTENTION: Horizon service is limited to Product compliant in the country of
use and ownership. If received, a non-compliant Product will not be serviced.
Further, the sender will be responsible for arranging return shipment of the
un-serviced Product, through a carrier of the sender’s choice and at the
sender’s expense. Horizon will hold non-compliant Product for a period of
60 days from notification, after which it will be discarded.
10/15
Country of Purchase Horizon Hobby Contact Information Address
United States of America
Horizon Service Center
(Repairs and Repair Requests) servicecenter.horizonhobby.com/RequestForm/
2904 Research Rd
Champaign, Illinois 61822 USA*
Horizon Product Support
(Product Technical Assistance)
[e-mail]
877-504-0233
Sales [e-mail]
800-338-4639
European Union Horizon Technischer Service [e-mail]
[phone]
Hanskampring 9
D 22885 Barsbüttel, Germany
Sales: Horizon Hobby GmbH
WARRANTY AND SERVICE CONTACT INFORMATION
*For the most up-to-date customer service contact information, please visit: www.horizonhobby.com/content/service-center-render-service-center
COMPLIANCE INFORMATION FOR THE EUROPEAN UNION
EU Manufacturer of Record:
Horizon Hobby, LLC
2904 Research Road
Champaign, IL 61822 USA
EU Importer of Record:
Horizon Hobby, GmbH
Hanskampring 9
22885 Barsbüttel Germany
WEEE NOTICE:
This appliance is labeled in accordance with European Directive 2012/19/EU
concerning waste of electrical and electronic equipment (WEEE).This label
indicates that this product should not be disposed of with household waste. It
should be deposited at an appropriate facility to enable recovery and recycling.

30 LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
EXPLODED VIEW // EXPLOSIONSZEICHNUNG // VUE ÉCLATÉE DES PIÈCES // VISTA ESPLOSA DELLE PARTI
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
Front Shock
40 WT
OIL

31
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
EXPLODED VIEW // EXPLOSIONSZEICHNUNG // VUE ÉCLATÉE DES PIÈCES // VISTA ESPLOSA DELLE PARTI
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
Rear Shock
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
70 WT
OIL

32 LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
EXPLODED VIEW // EXPLOSIONSZEICHNUNG // VUE ÉCLATÉE DES PIÈCES // VISTA ESPLOSA DELLE PARTI
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
500,000 WT
DIFF OIL
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903

33
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
EXPLODED VIEW // EXPLOSIONSZEICHNUNG // VUE ÉCLATÉE DES PIÈCES // VISTA ESPLOSA DELLE PARTI
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903
TLR336000
LOS232043
LOS43052
LOS43048
LOS231049
TLR5904
TLR5904
LOS235028
TLR6313
TLR5092
LOS235024
TLR8202
LOS231047
LOS234026
LOS232048
LOSA6943
LOS232045
TLR5904
LOS234048
LOS234029
LOS234032
LOS232036
TLR6313
TLR5900
LOS232047
LOS232047
LOS235003
LOS235003
TLR6352
TLR6352 LOSA6937
LOSA6937
LOS232041
LOS232037
TLR5910
TLR5903
LOS232038
LOS232038
LOS232038
LOS234028
TLR6313
TLR5092
LOS234032
TLR336000
LOS232044
LOS234025
LOS232044
LOS234026
LOS234034
LOS234034
LOS234034
LOS234034
TLR5903
LOS235024
LOS234029
TLR5909
LOS231045
LOS231045
LOS231046
LOS231046
LOS234027
LOS231050 LOS231050
TLR336000
LOS231050
LOS231050
LOS231043
LOS231043
LOS231043
TLR5903
TLR5903
TLR5904
TLR6352
LOS232048
LOSA6937
LOSA6937
LOS234033
LOS234032
TLR5903
TLR5962
TLR5962
LOS235028
LOS232037
LOS232039
LOS232043
LOSA6957
LOS232042
LOSA6937 LOS232042
LOS234033
LOS233021
LOS233018
LOS233021
LOS233024
LOS233023
LOS233023
LOS235029
LOS233022
LOS233022
LOS233022
LOS233021
LOS233020
LOS233019
LOS233018
LOS233021
LOS233024
LOS233021
LOS233020
LOS233021
LOS233018
LOS233023
LOS233022
LOS233022
LOS233018
LOS233023
LOS235029
LOS233022
LOS233021
LOS233019
LOS233021
LOSA6937
LOS232048
LOSA6957
LOS232040
LOS232040
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232046
LOS232049
LOS232049
LOS231043
TLR8202
LOSA6943
LOS231083
LOS231083
TLR5903
TLR5903
LOS43051
LOS43047
LOS231076
LOS231076
LOS231077
LOS231077
LOS232071
LOS234044
LOS235178
TLR5902
LOS232071
TLR5904
LOS234045
LOS234034
LOS234034
LOS234044
TLR5904
TLR5962
LOS234033 TLR5904
LOS231076
TLR235004
LOS231081
LOS234032
LOS234033 LOS234032
LOS234033
LOS234043
LOS234043
TLR5911
LOS234032
TLR5911
LOS234047
LOS231077
LOS230090
LOS230090
LOS231074
LOS231083
LOS231083
LOS231082
LOS231075
LOS231075
TLR5902
LOS231077
LOS231080
LOS237004
LOS237004
LOS231079
LOS231079
LOS235004
LOS235004
TLR5903
TLR5961
TLR5962
TLR5961
LOS232040
LOS234047
LOS234045
LOS234046
TLR5903

34 LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
Part # English Deutsch Français Italiano
LOS43047 Front Wheel, Satin (2) Hinterrad, Satin (2) Roue arrière, satinée (2) Ruota posteriore, satinata (2)
LOS43048 Rear Wheel, Satin (2) Vorderrad, Satin (2) Roue avant, satinée (2) Ruota anteriore, satinata (2)
LOS43051 Front Tire, M/T (2) Vorderreifen, M/T (2) Pneu avant, M/T (2) Ruota anteriore, M/T (2)
LOS43052 Rear Tire, M/T (2) Hinterreifen, M/T (2) Pneu arrière, M/T (2) Ruota posteriore, M/T (2)
LOS230090 Body Support Sets, Short & Long Body Gehäuse Sets, kurz und lang Ensembles de Support carrosserie,
courts et longs Set di supporti per carrozzeria, corti e lunghi
LOS231043 Composite Steering Set Komposit-Lenkungssatz Ensemble de direction composite Set sterzo, composito
LOS231045 Bulkhead Camber Block & Servo Mount Spritzwandsturz schwarz und Servohalte-
rung Cale de carrossage à cloison et support du servo Paratia, blocco camber, supporto servo
LOS231046 Steering Hardware Set Hardwaresatz Lenkung Ensemble de matériel de direction Set accessori sterzo
LOS231047 Body Mount Set Gehäusehalterungssatz Ensemble de montage de carrosserie Set supporti carrozzeria
LOS231049 Rear Bumper Set Heckstoßstangensatz Ensemble de pare-chocs arrière Set paraurti posteriore
LOS231050 Steering Bearing Set Lenklagersatz Ensemble de roulement de direction Set cuscinetti sterzo
LOS231074 Chassis,Aluminum Karosserie,Aluminium Châssis, aluminium Telaio, alluminio
LOS231075 Battery Mount Set,Aluminum Chassis Akkuhalterungssatz,Aluminiumkarosserie Ensemble support de batterie, châssis en
aluminium Set supporto batteria, telaio alluminio
LOS231076 Body Mount Set Gehäusehalterungssatz Ensemble de montage de carrosserie Set supporti carrozzeria
LOS231077 Wheelie Bar Set, Complete Wheelie-Stangensatz, vollständig Ensemble de barre de cabré, complet Set Wheelie Bar, completo
LOS231078 Wheelie Bar Mount Wheelie-Halterungssatz Montage de barre de cabré Supporto Wheelie Bar
LOS231079 Wheelie Bar Wheel Set (2) Wheelie-Stangen-/Reifensatz (2) Ensemble de roues avec barre de cabré (2) Set ruote Wheelie Bar (2)
LOS231080 Wheelie Bar Truss Wheelie-Stangenträger Barre de cabré inclinée Travatura Wheelie Bar
LOS231081 Front Bumper Set Stoßstangensatz, Front Jeu de pare-chocs avant Set ammortizzatore anteriore
LOS231082 Rear Bulkhead,Aluminum Chassis Hintere Spritzwand,Aluminiumchassis Cloison arrière, châssis en aluminium Paratia posteriore, telaio alluminio
LOS231083 Side Guard Set Aluminum Chassis Seitenschutz-Set Aluminiumchassis Ensemble de protections latérales,
châssis en aluminium Set paracolpi laterali, telaio alluminio
LOS232036 Gear Cover and Motor Guard Getriebeabdeckung und Motorschutz Cache de l’engrenage et protection moteur Coperchio pignone e protezione motore
LOS232037 Transmission Case Getriebeabdeckung Boîtier de transmission Scatola del cambio
LOS232038 Spur Gear and Slipper Pad 48P 84T Stirnrad und Gleitkissen 48P 84T Engrenage cylindrique et sabot de piston 48P
84T Corona e pattino scorrevole 48P 84T
LOS232039 Complete Gear Differential Komplettes Getriebe Differential Engrenage différentiel complet Differenziale pignone completo
LOS232040 Gear Set, Gear Differential Getriebesatz, Getriebe Differential Ensemble d’engrenages, engrenage différentiel Set pignone, differenziale pignone
LOS232041 Motor Plate Motorplatte Plaque moteur Piastra motore
LOS232042 Idler Gear and Shaft Zwischenrad und Welle Axe de pignon intermédiaire Ingranaggio e albero folle
LOS232043 Layshaft and Gear Zwischenwelle und Getriebe Arbre intermédiaire et engrenage Albero secondario e ingranaggio
LOS232044 Front Axle Vorderachse Essieu avant Assale anteriore
LOS232046 Gear Differential Rebuild Set Nachbausatz Getriebe Differential Ensemble de reconstruction de l’engrenage
différentiel Set differenziale pignone rigenerato
LOS232047 Slipper Hardware Set Hardwaresatz Gleiter Ensemble de matériel du sabot Set bulloneria scorrevole
LOS232048 Wheel Hex Set Radsechskantsatz (4) Hexagones de roues (4) Set esagoni ruote (4)
LOS232071 CVA Driveshaft, Complete CVA-Antriebswelle, komplett Arbres de transmission CVA, complet Albero di trasmissione CVA completo
LOS233016 Front Shock Set, Complete Kompletter Vorderer Stoßdämpfersatz Lot d’amortisseurs avant, complet Set ammortizzatore anteriore completo
LOS233018 Shock Body Set Stoßdämpfergehäusesatz Carrosserie amortisseurs Set corpo ammortizzatore
LOS233019 Shock Shaft Set Kolbenstangensatz Lot de bras d’amortisseurs Set albero ammortizzatore
LOS233020 Spring Set Federsatz Ressort Set molle
LOS233021 Spring Cups and Clip Set Satz mit Federtellern und Clips Lot de coupelles de ressort et d’attaches Set molle, coppe e clip
LOS233022 Shock Seal Set Stoßdämpferdichtungssatz Lot de joints d’amortisseurs Set guarnizioni ammortizzatore
LOS233023 Shock Caps (2) Stoßdämpferkappen (2) Capuchons d’amortisseurs (2) Tappi ammortizzatore (2)
LOS233024 Shock Ends Stoßdämpferenden Extrémités d’amortisseurs Terminali ammortizzatore
LOS234025 Front Caster Block Set Vorderradblocksatz Lot de blocs de roulettes avant Set blocco ruota anteriore
LOS234026 Hub and Spindle Set Satz aus Nabe und Spindel Lot de moyeux et de fusées Set mozzo e fuselli
LOS234027 Camber and Steering Link Set Spurstange- und Lenklenkersatz Ensemble de bras de carrossage et de direction Set camber e braccetti sterzo
LOS234028 Shock Tower Set Stossdämpfersatz Support d’amortisseurs Set Torre Ammortizzatore
LOS234029 Pivot Set Drehgelenksatz Lot pivot Set perni
LOS234032 Hinge Pin Set Scharnierbolzensatz Lot de charnière Set piastrine per perni
LOS234033 Hinge Pin Lock Screws Scharnierbolzen-Sicherungsstifte Vis de blocage de charnière Viti di supporto piastrine per perni
LOS234034 Ball Stud, 4.8mm x 6mm (4) Kugelzapfen, 4,8mm x 6mm (4) Piton à rotule, 4,8mm x 6mm (4) Viti a sfera, 4,8 mm x 6 mm (4)
LOS234043 Front Arm Set Vorderarmsatz Ensemble bras avant Set bracci anteriori
LOS234044 Rear Arm Set Hinterarmsatz Ensemble bras arrière Set bracci posteriori
LOS234045 Camber Link Set, Front & Rear Spurstange, Front und Heck Ensemble de bras de carrossage, avant et
arrière Set braccetti camber, ant e post
LOS234046 Steering Link Set Lenkgliedset: 22S Drag 22S - Drag Ensemble de timonerie de direction Set braccetti sterzo
LOS234047 Rear Shock Tower: 22S Drag Hintere Stoßdämpferbrücke Tour d’amortisseur arrière Torre ammortizzatore posteriore: 22S Drag
LOS234048 Rear Pivot Block Set Hinterer Drehblocksatz Ensemble de blocs de pivot arrière Set blocco perno posteriore
LOS235003 Cap Head Screws M3 x 6mm (10) Inbusschrauben M3 x 6mm (10) Vis à tête bombée, M3 x 6mm (10) Viti a testa cilindrica, M3 x 6 mm (10)
LOS235018 Set Screws, M3 X 3mm (10) Stellschrauben, M3 x 3mm (10) Vis de fixation, M3 x 3mm (10) Viti di fermo, M3 x 3 mm (10)
REPLACEMENT PARTS // TEILELISTE // LISTE DES PIÈCES DE RECHANGE // ELENCO DEI RICAMBI

35
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
Part # English Deutsch Français Italiano
SPMXPS2 Smart Powerstage Bundle 2S Smart Leistungsteilpaket 2 Lot à étage de puissance Smart 2S Smart Bundle Powerstage 2S
SPMS606 S606 Standard Waterproof Surface
Servo S606 wasserdichter Standard- Oberflächenservo Servo de surface étanche standard S606 S606, servo di sup impermeabile std
SPMXSE1100 Firma 100A Brushless Smart ESC, 3S Firma 100A bürstenloser Smart-
Geschwindigkeitsregler, 3S Variateur ESC Smart sans balais 100A Firma, 3S Smart ESC Firma 100A Brushless, 3S
SPMXSM2800 Spektrum 3652 4-Pole Brushless Motor
6500Kv Spektrum 3652 4-poliger Bürstenloser-Motor 6.500 kV Moteur Spektrum 3652 4 pôles sans balais 6 500 kV Motore Spektrum 3652 4 poli Brushless 6500 Kv
SPMXC1000 Smart S1200 DC Charger, 1x200W Smart S1200 Wechselstrom-Ladegerät,
1 x 200 W Chargeur Smart S1200, 1x200 W Caricabatterie Smart S1200 CC 1x200 W
SPMX50002S100H5 7.4V 5000mAh 2S 100C LiPo,
Smart Hardcase: EC5 7,4 V 5.000 mAh 2S 100C Smart- Hartschalen-LiPo-Akku mit IC5-Stecker Batterie Li-po 7,4 V 5 000 mAh 2S 100C Smart avec connecteur IC5 Batteria 7,4 V 5000 mAh 2S 100C Smart Hardcase LiPo con connettore IC5
RECOMMENDED PARTS // EMPFOHLENE TEILE // PIÈCES RECOMMANDÉES //
PEZZI RACCOMANDATI
Part # English Deutsch Français Italiano
LOS235024 Button Head Screws M3 x 25mm (10) Halbrundschrauben, M3 x 25mm (10) Vis à tête bombée M3 x 25mm (10) Viti a testa tonda, M3 x 25 mm (10)
LOS235028 Flat Head Screws M3 x 45mm (6) Flachkopfschrauben, M3 x 45mm (6) Vis à tête fraisée, M3 x 45mm (6) Viti a testa piatta, M3 x 45 mm (6)
LOS235029 Cap Head Screws M2 x 4mm (10) Inbusschrauben M2 x 4mm (10) Vis à tête bombée, M2 x 4mm (10) Viti a testa cilindrica, M2 x 4 mm (10)
LOS235178 Flat Head Screws, M3 x 14mm (10) Flachkopfschrauben, M3 x 14mm (10) Vis à tête fraisée, M3 x 14mm (10) Viti a testa piatta, M3 x 14 mm (10)
LOS237004 3 x 7 x 3mm Ball Bearing (4) 3 x 7 x 3 mm, Kugellager (4) Roulement à billes 3 x 7 x 3mm (4) Cuscinetti a sfera 3x7x3 mm (4)
LOSA6937 5 x 10mm Shielded Ball Bearing (2) 5 x 10mm abgedichtetes Kugellager (2) Roulement à billes blindé 5 x 10mm (2) Cuscinetti a sfera schermati 5 x 10 mm (2)
LOSA6943 10 X 15mm Sealed Ball Bearings (2) 10 x 15 mm abgedichtete Kugellager (2) Roulements à Billes Scellés 10 X 15mm (2) Cuscinetti a sfere sigillati 10 x 15 mm (2)
LOSA6955 5 x 13mm HD Clutch Bearings (2) 5 x 13mm HD Kupplungslager (2) Roulements à embrayage ultra-résistant
5 x 13mm (2) Cuscinetti frizione HD 5 x 13mm (2)
LOSA6957 10 x 15 x 4mm BB (2) w/ Nylon Retainer 10 x 15 x 4mm BB (2) mit Nylon-Halter Roulements à billes 10 x 15 x 4mm (0)
avec bague de retenue en nylon Cuscinetto a sfera 10 x 15 x 4mm (2) con fermo in nylon
TLR235004 Flat Head Screws, M3 x 25mm (10) Flachkopfschrauben, M3 x 25mm (10) Vis à tête fraisée, M3 x 25mm (10) Viti a testa piatta, M3 x 25 mm (10)
TLR235007 Flat Head Screws M2.5 x 10mm (10) Flachkopfschrauben, M2.5 x 10mm (10) Vis à tête fraisée, M2.5 x 10mm (10) Viti a testa piatta, M2.5 x 10 mm (10)
TLR5092 Upper Shock Bushing (4) Oberes Dämpferlager (4) Bague d’amortisseurs supérieurs (4) Boccole ammortizzatore superiore (4)
TLR5900 Button Head Screws, M3 x 5mm (10) Halbrundschrauben, M3 x 5mm (10) Vis à tête bombée M3 x 5mm (10) Viti a testa tonda, M3 x 5 mm (10)
TLR5901 Button Head Screws, M3 x 6mm (10) Halbrundschrauben, M3 x 6mm (10) Vis à tête bombée M3 x 6mm (10) Viti a testa tonda, M3 x 6 mm (10)
TLR5902 Button Head Screws, M3 x 8mm (10) Halbrundschrauben, M3 x 8mm (10) Vis à tête bombée M3 x 8mm (10) Viti a testa tonda, M3 x 8 mm (10)
TLR5903 Button Head Screws, M3 x 10mm (10) Halbrundschrauben, M3 x 10mm (10) Vis à tête bombée M3 x 10mm (10) Viti a testa tonda, M3 x 10 mm (10)
TLR5904 Button Head Screws, M3 x 12mm (10) Halbrundschrauben, M3 x 12mm (10) Vis à tête bombée M3 x 12mm (10) Viti a testa tonda, M3 x 12 mm (10)
TLR5906 Button Head Screws, M3 x 35mm (10) Halbrundschrauben, M3 x 35mm (10) Vis à tête bombée M3 x 35mm (10) Viti a testa tonda, M3 x 35 mm (10)
TLR5909 Button Head Screws, M3 x 16mm (10) Halbrundschrauben, M3 x 16mm (10) Vis à tête bombée M3 x 16mm (10) Viti a testa tonda, M3 x 16 mm (10)
TLR5910 Button Head Screws M3 x 14mm (10) Halbrundschrauben, M3 x 14mm (10) Vis à tête bombée M3 x 14mm (10) Viti a testa tonda, M3 x 14 mm (10)
TLR5911 Button Head Screws, M3 x 20mm (10) Halbrundschrauben, M3 x 20mm (10) Vis à tête bombée M3 x 20mm (10) Viti a testa tonda, M3 x 20 mm (10)
TLR5912 Button Head Screws, M3 x 54mm (2) Halbrundschrauben, M3 x 54mm (2) Vis à tête bombée M3 x 54mm (2) Viti a testa tonda, M3 x 54 mm (2)
TLR5914 Button Head Screws, M2 x 12mm (10) Halbrundschrauben, M2 x 12mm (10) Vis à tête bombée M2 x 12mm (10) Viti a testa tonda, M2 x 12 mm (10)
TLR5961 Flat Head Screws, M3 x 8mm (10) Flachkopfschrauben, M3 x 8mm (10) Vis à tête fraisée, M3 x 8mm (10) Viti a testa piatta, M3 x 8 mm (10)
TLR5962 Flat Head Screws, M3 x 10mm (10) Flachkopfschrauben, M3 x 10mm (10) Vis à tête fraisée, M3 x 10mm (10) Viti a testa piatta, M3 x 10 mm (10)
TLR5963 Flat Head Screws, M3 x 12mm (10) Flachkopfschrauben, M3 x 12mm (10) Vis à tête fraisée, M3 x 12mm (10) Viti a testa piatta, M3 x 12 mm (10)
TLR6105 E-Clips, 3mm Shaft (12) E-Clips 3mm (12) E-Clips 3mm (12) E-clip 3 mm (12)
TLR6288 Set Screws, M3 x 2.5mm (10) Stellschraube, M3 x 2,5mm (10) Vis de fixation, M3 x 2,5mm (10) Set viti, M3 x 2,5 mm (10)
TLR6313 Locknut, M3 x .5 x 5.5mm (10) Einstellmutter, M3 x .5 x 5.5 mm (10) Écrou auto-freiné, M3 x .5 x 5.5mm (10) Dado Nylock, M3 x .5 x 5.5 mm (10)
TLR6352 Washers, M3 (10) Unterlegscheiben, M3 (10) Rondelles, M3 (10) Rondelle, M3 (10)
TLR8202 Body Clips, Black (12) Karosserieklammern, Schwarz (12) Clips de carrosserie noirs (12) Clip carrozzeria, nero (12)
VTR235178 Flat Head Screws, M3 x 14mm (10) Flachkopfschrauben, M3 x 14mm (10) Vis à tête fraisée, M3 x 14mm (10) Viti a testa piatta, M3 x 14 mm (10)
REPLACEMENT PARTS // TEILELISTE // LISTE DES PIÈCES DE RECHANGE // ELENCO DEI RICAMBI

36 LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
Part # English Deutsch Français Italiano
DTXC2390 Pit Tech Deluxe Tool Stand Blue Pit Tech Deluxe-Werkzeugständer, blau Porte-outils Pit Tech Deluxe bleu Stand attrezzi Pit Tech Deluxe
DYN2950 8-in-1 Hex Wrench Kit 8-in-1 Sechskantschlüsselsatz Kit de clés hexagonales 8-en-1 Kit chiave esagonale 8 in 1
DYN4403 GPS Speed Meter GPS-Tachometer Indicateur de vitesse GPS Tachimetro GPS
LOS43049 Front Wheel Black Chrome (2) Vorderrad, schwarz Chrom (2) Roue avant, noire chromée (2) Ruote anteriori, nera cromate (2)
LOS43050 Rear Wheel, Black Chrome (2) Hinterrad, schwarz Chrom (2) Roue arrière, noire chromée (2) Ruote posteriori, nera cromate (2)
LOS230086 69 Camaro Body, Clear 69 Camaro-Karosserie, transparent Carrosserie Camaro 69, transparente 69 Camaro, carrozzeria, trasparente
LOS230088 69 Chevy Camaro Drag Car Body
Set, Summit 69 Chevy Camaro Drag-Car-Karosserie-Set, Summit Ensemble de carrosserie pour voiture Chevy Camaro 69 de dragster 69 Chevy Camaro Drag Car, Set carrozzeria, Summit
LOS230092 69 Chevy Camaro Drag Body 69 Chevy Camaro Drag-Karosserie Carrosserie Chevy Camaro 69 de dragster 69 Chevy Camaro Drag, carrozzeria,
TLR232009 HDS Spur Gear 76T 48P Kevlar® HDS Stirnrad 76T 48P Kevlar Engrenage HDS 76T 48P Kevlar Corona HDS 76T 48P Kevlar
TLR232010 HDS Spur Gear 78T 48P Kevlar® HDS Stirnrad 78T 48P Kevlar Engrenage HDS 78T 48P Kevlar Corona HDS 78T 48P Kevlar
LOS233004 FR/RR Shock Seal/Limiter Set: BR FR/RR Stoßdämpfer/Stoßbegrenzer-Set: BR Ensemble de joints d’amortisseur/limiteur
avant/arrière : BR Set limitatori/tenute amm ant/pst: BR
LOS233020 Spring Set Federnsatz Ensemble ressort Set molle
LOS234048 Rear Pivot Block Set Zapfenlager-Set, hinten Ensemble de blocs pivots arrière Set blocco pivot posteriore
LOS331013 Clamping Servo Horn Aluminum, 23T Klemm-Servohorn,Aluminium, 23T Renvoi de commande du servo de serrage,
aluminium, 23T Squadretta servo blocc, allum, 23T
LOS331014 Clamping Servo Horn Aluminum, 25T Klemm-Servohorn,Aluminium, 25T Renvoi de commande du servo de serrage,
aluminium, 25T Squadretta servo blocc, allum, 25T
LOS332005 Clamping Front Wheel Hex Aluminum Aluminium Klemmvorderrad Sechskant Serrage de roue avant hexagonale en
aluminium Esagono serraggio ruote allum ant
LOS332006 Clamping Rear Wheel Hex Aluminum Aluminium Klemmhinterrad Sechskant Serrage de roue arrière hexagonale en
aluminium Esagono serraggio ruote allum pst
LOS333000 Front Shocks,Aluminum Assembly Vordere Stoßdämpfer,Aluminiumgehäuse Assemblage d’amortisseurs avant, aluminium Ammortizzatori ant, gruppo allum
LOS334014 Rear Hub Set,Aluminum Nabensatz, hinten, Aluminiumgehäuse Ensemble de moyeu arrière, aluminium Set mozzo posteriore, alluminio
LOS334015 Front Pivot,Aluminum Vorderes Drehgelenk,Aluminium Pivot avant, aluminium Pivot anteriore, alluminio
LOS334016 Front Spindle Set,Aluminum Front-Spindelsatz,Aluminium Ensemble d’axe avant, aluminium Set fusello anteriore, alluminio
LOS334017 Caster Block Set,Aluminum Radblock-Set, Aluminium Ensemble de blocs de rondelle, aluminium Set caster block, alluminio
LOS334018 Front Camber Block,Aluminum Vorderer Radsturzblock,Aluminium Cale de carrossage avant, aluminium Blocco camber anteriore, alluminio
LOS334019 Rear Pivot Set,Aluminum Zapfenlager-Set, vorn,Aluminium Ensemble de pivot arrière, aluminium Set pivot posteriore, alluminio
LOS334021 Rear Sway Bar Set Heck Schwingen-Satz Ensemble barre stabilisatrice arrière Set barra antirollio posteriore
LOSA99174 Car Stand Fahrzeugständer Socle Supporto automodello
PRO277503 Pomona Drag Spec 2.2", Black:
Slash Front Pomona Drag Spec 2.2", schwarz: Slash Front Pomona de dragster Spec 2,2", noir : Oblique avant Pomona Drag Spec 2.2", nero: Slash ant
PRO277603 Pomona Drag Spec 2.2 3.0", Black:
Slash 2WD Rear, 4x4 F/R
Pomona Drag Spec 2.2 3.0", schwarz:
Slash 2WD Rear, 4x4 F/R
Pomona de dragster Spec 2,2 3,0", noir :
2 roues motrices obliques arrière, 4x4 avant/
arrière
Pomona Drag Spec 2.2 3.0", nero:
Slash 2WD post, 4x4 F/R
PRO352300 Clear Body, Super J Pro-Mod: 1/10
Slash 2WD, Drag Car Transparente Karosserie, Super J Pro-Mod: 1/10 Slash 2WD, Drag Car Carrosserie transparente, Super J Pro-Mod :Voi- ture de dragster, 2 roues motrices Slash 1/10 Carrozzeria trasparente, Super J Pro-Mod: 1/10 Slash 2WD, Drag Car
PRO353100 Clear Body, 1969 Chevrolet Nova:
1/10 Slash 2WD, Drag Car Transparente Karosserie, 1969 Chevrolet Nova: 1/10 Slash 2WD, Drag Car
Carrosserie transparente, Chevrolet Nova 1969
:Voiture de dragster, 2 roues motrices Slash
1/10
Carrozzeria trasparente, 1969 Chevrolet Nova:
1/10 Slash 2WD, Drag Car
PRO354900 1978 Chevrolet Malibu Body: Slash
2WD Drag & DR10 1978 Chevrolet Malibu-Karosserie: Slash 2WD Drag und DR10 Carrosserie Chevrolet Malibu 1978 : Slash 2 roues motrices de dragster et DR10 Carrozzeria, 1978 Chevrolet Malibu: Slash 2WD Drag & DR10
PRO355000 Clear Body, 1972 Plymouth Bar-
racuda Slash 2WD Drag Transparente Karosserie, 1972 Plymouth Barracuda Slash 2WD Drag Carrosserie transparente, Slash 2 roues motri- ces de dragster Plymouth Barracuda 1972 Carrozzeria trasparente, 1972 Plymouth Barracuda Slash 2WD Drag
PRO636800 No Prep Drag Racing Hood Scoops &
Blowers (8) Ohne Vorbereitung, Drag Racing Hood- Schaufeln und -Gebläse (8) Souffleries de capot pour course de dragster sans préparation (8) No Prep Drag, prese dinamiche e di aspirazione da gara (8)
PRO1015717 Hoosier Drag Slick SC MC Drag
Racing Tires, SC Rear (2) Hoosier-Schleppseil SC MC Drag-Rennreifen, SC hinten (2) Pneus slick SC MC pour course de dragster Hoosier, SC arrière (2) Ruote da gara Hoosier Drag Slick SC MC Drag, SC posteriori (2)
PRO1015817 Hoosier Drag 2.2" 2WD MC Drag
Racing Front Tires (2) Hoosier-Schleppseil 2.2" 2WD MC Drag- Rennreifen, vorn (2) Pneus avant pour course de dragster MC 2 roues motrices 2.2" Hoosier (2) Ruote da gara Hoosier Drag 2.2" 2WD MC Drag, anteriori (2)
PRO10157203 Hoosier Drag Slick SC S3 Drag
Racing Tires, SC Rear (2) Hoosier-Schleppseil SC S3 Drag-Rennreifen, SC hinten (2) Pneus slick SC S3 pour course de dragster Hoosier, SC arrière (2) Ruote da gara Hoosier Drag Slick SC S3 Drag, SC posteriori (2)
PRO10158203 Hoosier Drag 2.2" 2WD S3 Drag
Racing Front Tires (2) Hoosier-Schleppseil 2.2" 2WD S3 Drag- Rennreifen, vorn (2) Pneus avant pour course de dragster S3 2 roues motrices 2.2" Hoosier (2) Ruote da gara Hoosier Drag 2.2" 2WD S3 Drag, anteriori (2)
PRO10170203 Reaction HP S3 (Soft) Drag Belted
Rear Short Course Tires (2) Reaction HP S3 (weich) Drag Belted Short Course-Hinterreifen (2) Pneus Short Course arrière ceinturés de drag- ster Reaction HP S3 (souples) (2) Ruote cinturate Reaction HP S3 (morbide), SC posteriori (2)
SPM2340 DX3 Smart 3-Channel Transmitter
with SR315 Receiver DX3 Smart 3-Kanal-Sender mit SR315- Empfänger Émetteur DX3 Smart 3 canaux avec récepteur SR315 Trasmittente DX3 Smart 3 canali con ricevitore SR315
SPMR5115 DX5C Smart 5-Channel DSMR
Transmitter Only DX5C Smart 5-Kanal-DSMR, nur Sender Émetteur DSMR Smart 5 canaux DX5C unique- ment DX5C Smart 5 canali DSMR solo trasmittente
SPMR52000 DX5 Rugged DSMR Transmitter Only,
Orange Nur DX5 Rugged DSMR-Sender, Orange Émetteur DX5 robuste DSMR uniquement, orange DX5 Rugged DSMR solo trasmittente, arancione
SPMSR6100AT SR6100AT DSMR 6-Channel AVC
Telemetry Surface Receiver SR6100AT DSMR AVC-Telemetrie- Oberflächenempfänger mit 6 Kanälen Récepteur de surface de télémétrie AVC 6 canaux SR6100AT DSMR Ricevitore di superficie SR6100AT DSMR 6 canali AVC con telemetria
SPMX50002S100H5 7.4V 5000mAh 2S 100C Smart
Hardcase LiPo Battery: IC5 7,4 V 5.000 mAh 2S 100C Smart Li-Po- Akku, Hartschale: IC5 Batterie Li-Po Smart 7,4 V 5 000 mAh 2S 100C, boîtier rigide : IC5 Batteria 7,4 V 5000 mAh 2S 100C Smart Hardcase LiPo: IC5
SPMX50002S100HT 7.4V 5000mAh 2S 100C Smart Race Shorty Hardcase LiPo Battery:
Tubes, 5mm
7,4 V 5.000 mAh 2S 100C Smart Race Li-Po-
Akku, Shorty-Hartschale: Rohre, 5 mm Batterie Li-Po Smart Race Shorty 7,4 V 5 000 mAh 2S 100C, boîtier rigide : Tubes, 5 mm Batteria 7,4 V 5000 mAh 2S 100C Smart Hardcase LiPo, da gara, corta:Tubi, 5 mm
SPMX50002S50H5 7.4V 5000mAh 2S 50C Smart
Hardcase LiPo Battery: IC5 7,4 V 5.000 mAh 2S 50C Smart LiPo-Akku, Hartschale: IC5 Batterie Li-Po Smart 7,4V 5 000 mAh 2S 50C, boîtier rigide : IC5 Batteria 7,4 V 5000 mAh 2S 50C Smart Hardcase LiPo: IC5
SPMXBC100 XBC100 Smart LiPo Battery Checker
& Servo Driver XBC100 Smart-LiPo-Akkuprüfer und Servotreiber Contrôleur pour batterie Li-Po Smart XBC100 et servomoteur Tester per batterie LiPo Smart e servomotore XBC100
SPMXC1010 Smart S2100 AC Charger, 2x100W Smart S2100 Wechselstrom-Ladegerät,
2 x 100 W Chargeur c.a. Smart S2100, 2 x 100 W Caricabatterie Smart S2100 CA, 2x100 W
OPTIONAL PARTS // OPTIONALE TEILE // PIÈCES OPTIONNELLES // PARTI OPZIONALI

37
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
Part # English Deutsch Français Italiano
SPMXC1070 S150 AC/DC Smart Charger, 1x50W S150 Smart-Wechsel-/Gleichstrom-
Ladegerät, 1 x 50 W Chargeur Smart S150 CA/CC, 1x50 W Caricabatterie S150 CA/CC Smart, 1x50 W
SPMXCA200 Smart ESC Programming Update
Box:Avian and Firma Smart Geschwindigkeitsregler Programmier- box:Avian und Firma Boîte de programmation de mise à jour pour variateur ESC Smart :Avian et Firma Box programmazione e aggiornamento ESC Smart:Avian e Firma
SPMXSE1120 Firma 120A Brushless Smart ESC, 4S Firma 120A bürstenloser Smart-
Geschwindigkeitsregler, 4S Variateur ESC sans balais Smart Firma 120A, 4S Smart ESC Firma 120A Brushless 4S
TLR332016 48P Aluminum Pinion Gear, 16T 48P Aluminium Zahnradgetriebe, 16T Engrenage à pignons en aluminium 48P, 16T Pignone alluminio 48P, 16T
TLR332017 48P Aluminum Pinion Gear, 17T 48P Aluminium Zahnradgetriebe, 17T Engrenage à pignons en aluminium 48P, 17T Pignone alluminio 48P, 17T
TLR332018 48P Aluminum Pinion Gear, 18T 48P Aluminium Zahnradgetriebe, 18T Engrenage à pignons en aluminium 48P, 18T Pignone alluminio 48P, 18T
TLR332019 48P Aluminum Pinion Gear, 19T 48P Aluminium Zahnradgetriebe, 19T Engrenage à pignons en aluminium 48P, 19T Pignone alluminio 48P, 19T
TLR332020 48P Aluminum Pinion Gear, 20T 48P Aluminium Zahnradgetriebe, 20T Engrenage à pignons en aluminium 48P, 20T Pignone alluminio 48P, 20T
TLR332021 48P Aluminum Pinion Gear, 21T 48P Aluminium Zahnradgetriebe, 21T Engrenage à pignons en aluminium 48P, 21T Pignone alluminio 48P, 21T
TLR332022 48P Aluminum Pinion Gear, 22T 48P Aluminium Zahnradgetriebe, 22T Engrenage à pignons en aluminium 48P, 22T Pignone alluminio 48P, 22T
TLR332023 48P Aluminum Pinion Gear, 23T 48P Aluminium Zahnradgetriebe, 23T Engrenage à pignons en aluminium 48P, 23T Pignone alluminio 48P, 23T
TLR332024 48P Aluminum Pinion Gear, 24T 48P Aluminium Zahnradgetriebe, 24T Engrenage à pignons en aluminium 48P, 24T Pignone alluminio 48P, 24T
TLR332025 48P Aluminum Pinion Gear, 25T 48P Aluminium Zahnradgetriebe, 25T Engrenage à pignons en aluminium 48P, 25T Pignone alluminio 48P, 25T
TLR336000 4mm Aluminum Serrated Lock Nuts,
Black (6) 4mm Aluminium Rändelmutter, schwarz (6) Contre-écrous en aluminium à embase striée 4mm, noir (6) Controdado dentato in alluminio 4 mm, nero (6)
TLR336001 4mm Aluminum Serrated Lock Nuts,
Blue (6) 4mm Aluminium Rändelmutter, blau (6) Contre-écrous en aluminium à embase striée 4mm, bleu (6) Controdado dentato in alluminio 4 mm, blu (6)
TLR74004 Silicone Shock Oil, 25 wt, 2 oz Stoßdämpfer-Silikonöl, 25wt, 59ml (2oz) Huile de silicone pour amortisseurs, 25wt, 2oz Olio di silicone ammortizzatore, 25 wt, 2 oz
TLR74005 Silicone Shock Oil, 27.5 wt, 2 oz Stoßdämpfer-Silikonöl, 27,5wt, 59ml (2oz) Huile de silicone pour amortisseurs, 27,5wt,
2oz Olio di silicone ammortizzatore, 27,5 wt, 2 oz
TLR74006 Silicone Shock Oil, 30 wt, 2 oz Stoßdämpfer-Silikonöl, 30wt, 59ml (2oz) Huile de silicone pour amortisseurs, 30wt, 2oz Olio di silicone ammortizzatore, 30 wt, 2 oz
TLR74008 Silicone Shock Oil, 35 wt, 2 oz Stoßdämpfer-Silikonöl, 35wt, 59ml (2oz) Huile de silicone pour amortisseurs, 35wt, 2oz Olio di silicone ammortizzatore, 35 wt, 2 oz
TLR74009 Silicone Shock Oil, 37.5 wt, 2 oz Stoßdämpfer-Silikonöl, 37,5wt, 59ml (2oz) Huile de silicone pour amortisseurs, 37,5wt, 2oz Olio di silicone ammortizzatore, 37,5 wt, 2 oz
TLR74020 Shock Oil, 6Pk, 20, 25, 30, 35, 40,
45, 2oz Schock öl, 20, 25, 30, 35, 40, 45; 6er Pack: 2 Unzen Huile d'amortisseur, 20, 25, 30, 35, 40, 45; Paquet de 6: 2 onces Olio shock, 20, 25, 30, 35, 40, 45; Confezione da 6: 2 once
TLR74021 Shock Oil, 6Pk, 50, 60, 70, 80, 90,
100, 2oz Schock öl, 50, 60, 70, 80, 90, 100; 6er Pack: 2 Unzen Huile d'amortisseur, 50, 60, 70, 80, 90, 100; Paquet de 6: 2 onces Olio shock, 50, 60, 70, 80, 90, 100; Confezione da 6: 2 once
TLR75001 Silicone Diff Fluid, 40,000 CS Differenzial-Silikonflüssigkeit, 40.000 CS Liquide silicone pour différentiel, 40 000 CS Fluido siliconico differenziale, 40.000 CS
TLR75002 Silicone Diff Fluid, 60,000 CS Differenzial-Silikonflüssigkeit, 60.000 CS Liquide silicone pour différentiel, 60 000 CS Fluido siliconico differenziale, 60.000 CS
TLR75003 Silicone Diff Fluid, 80,000 CS Differenzial-Silikonflüssigkeit, 80.000 CS Liquide silicone pour différentiel, 80 000 CS Fluido siliconico differenziale, 80.000 CS
TLR75004 Silicone Diff Fluid, 100,000 CS Differenzial-Silikonflüssigkeit, 100.000 CS Liquide silicone pour différentiel, 100 000 CS Fluido siliconico differenziale, 100.000 CS
TLR75009 Silicone Diff Fluid, 500,000 CS Differenzial-Silikonflüssigkeit, 500.000 CS Liquide silicone pour différentiel, 500 000 CS Fluido siliconico differenziale, 500.000 CS
TLR76004 TLR Lok, Threadlock, Blue Reifenklebemittel, Standard Colle à pneus, standard Colla pneumatici, standard
TLR76007 Tire Glue, Standard TLR Lok, Schraubensicherung, blau Verrou TLR, frein-filet, bleu TLR Lok, frenafiletti, blu
TLR331041 Rear Brass Weight Set, 16g & 25g:
22 5.0 Heck Gewicht, Satz, Messing, 16 g & 25 g: 22 5.0 Ensemble de poids arrière en laiton, 16 et 25 g : 22 5.0 Set peso ottone posteriore, 16 e 25 g: 22 5.0
OPTIONAL PARTS // OPTIONALE TEILE // PIÈCES OPTIONNELLES // PARTI OPZIONALI

38 LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
ShocksShocks
Front Rear
Shock Caps
Oil
Piston Thin Thin
Limiter, Int mm mm
Shaft Dia 3.0mm 3.5mm 3.0mm 3.5mm
Limiter, Ext mm mm
Stroke mm mm
Eyelet Std +2mm Std +2mm
Spring
Spring Cup
Low
Mid
High
Low
Mid
High
DifferentialsDifferentials
Rear
Fluid
Int Gears Stl Comp
Weight g
Ring/Pin Stl Comp
Slipper Pads
TiresTires
Front Rear
Brand
Tread
Compound
Insert
Sauce
Wheel
Notes
Ride Height mm
Camber ˚
Toe ˚
Notes: ___________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
Ride Height mm
Camber ˚
Sway Bar mm
Notes: _____________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
Track ConditionsTrack Conditions
Unprepped Asphalt Unprepped Concrete Smooth Rough Tire Type:
Belted
Drag Radial
Modified
Notes: __________________
_______________________
_______________________
Swept Prepped Launch Flashlight Christmas Tree
Name: Date: Event: Track:
Front Suspension
Rear SuspensionChassis
AerodynamicsAerodynamics
Body
Fr Scoop
Rr Wing
Wheelie Bar
Wheelie Bar Height ˚
Notes
25g
16g
Total Weight: ____________g Fr/Rr _______% /_______%
Standard
Stiffezel
25g 16g
_____mm
Spacer
Standard
Stiffezel
_____mm
Spacer
X67mm
X68mm
________
21
21
Soft
Stiffezel
1.5°
3.0°
4.5°
2
1
2
1
21
3
21
3
1
2

39
LOSI®22S PRO NO PREP DRAG ROLLER: 1/10 SCALE 2WD
ShocksShocks
Front Rear
Shock Caps
Oil
Piston Thin Thin
Limiter, Int mm mm
Shaft Dia 3.0mm 3.5mm 3.0mm 3.5mm
Limiter, Ext mm mm
Stroke mm mm
Eyelet Std +2mm Std +2mm
Spring
Spring Cup
Low
Mid
High
Low
Mid
High
DifferentialsDifferentials
Rear
Fluid
Int Gears Stl Comp
Weight g
Ring/Pin Stl Comp
Slipper Pads
TiresTires
Front Rear
Brand
Tread
Compound
Insert
Sauce
Wheel
Notes
Ride Height mm
Camber ˚
Sway Bar mm
Notes: ___________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
________________________________________
Track ConditionsTrack Conditions
Unprepped Asphalt Unprepped Concrete Smooth Rough Tire Type:
Belted
Drag Radial
Modified
Notes: __________________
_______________________
_______________________
Swept Prepped Launch Flashlight Christmas Tree
Name: Date: Event: Track:
Front Suspension
Rear SuspensionChassis
AerodynamicsAerodynamics
Body
Fr Scoop
Rr Wing
Wheelie Bar
Wheelie Bar Height
Notes
25g
16g
Total Weight: ____________g Fr/Rr _______% /_______%
Standard
Stiffezel
Soft
Stiffezel
_____mm
Spacer
Standard
Stiffezel
_____mm
Spacer
X67mm
X68mm
________
21
21
20
1
Not Used
500,000wt None
Stock
Stock
20mm
Losi Losi
MT Drag Radial
MT Drag
Radial Grooved
Losi Drag Losi Drag
Foam Foam
None None
Plastic Plastic
40wt 70wt
2x1.6mm 2x1.6mm
12 15
 
None None

 
25g 16g
1.5°
3.0°
4.5°
2
1
21
3
Ride Height mm
Camber ˚
Toe ˚
Notes: ____________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
12
0
-2
2
1



21
3
1
2

©2021 Horizon Hobby, LLC.
Losi, 22S, DSMR, Firma, IC5, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trade-
mark is used with permission of Bachmann Industries, Inc.
Created 03/21 130639 LOS03041
WWW.LOSI.COM
