Hoselink L450 User manual

Solar LED Strip Light | Warm White |
4m | Adhesive | ASPECT
For more information visit
hoselink.com.au
or call
1300 900 617
MODEL: L450
MODEL: L450 User ManualUser ManualUser Manual
Solar LED Strip Light | Warm White |
4m | Adhesive | ASPECT
B.1 Unspool the strip light from the roll.
If using this method, there is no need to remove the
backing tape. We recommend unspooling the full
length and laying it out along where it will be installed.
B.2 Using the provided screws, secure clips in place along
the length of the light. We recommend installing clips at
the following measurements – 0m, 1.3m, 2.6m, 4m.
B.3 Connect solar panel to strip light.
Removing the Lights
Please note that once the lights are installed, they
cannot be moved. The glue strip is intended for single
use and removing the lights will damage it.
STEP 1 Carefully peel the light strip away from the surface.
It is normal for the glue strip to come away in sections or
leave residue behind on the mounting surface. Do not rip
lights away from the surface as the glue is quite strong and
this may cause damage to the underlying surface.
STEP 2 Once the entire strip light is removed, work
back along the surface and remove any remaining
sections of glue. These should peel off.
NOTE: if the light does not turn on, this could be
due to the battery not being charged. Leave out in
direct sunlight for 6–8 hours and try again. Do not use
this light underwater or in low-lying puddles.
Cultivating ConnectionsCultivating Connections
youtube.com/hoselink

Kit Contents
1 x Solar LED strip light
1 x Solar Panel
1 x Solar Panel Hardware
4 x Mounting Clips with 8 x Screws
Lighting Modes
The Solar LED Strip Light has 4 lighting modes:
1 Constant light 3 Quick flash
2 Slow flash 4 Pulsating light
Activate the Light
Use the ‘ON/OFF’ button located on the back of the solar
panel to turn the lights on. Press the ‘MODE’ button to select
the desired light setting. The solar panel has a built-in
intelligent light sensor, which detects darkness, automatically
illuminating the light at dusk and turning it off at dawn.
Product Installation
STEP 1 Find a suitable location
While the strip light may run along the underside of a
deck or staircase, the solar panel will need access to
direct sunlight to charge. For optimum results, charge
for 6-8 hours per day. Ensure the 2m cable will reach
between the solar panel and strip lights.
STEP 2 Install Solar Panel
Solar Panel Installation - Option A
Ground spike.
Slot the ground spike into the tube on the back of the
solar panel, then push the spike into the ground.
Solar Panel Installation - Option B
Wall or fence mount.
B.1 Mark the holes.
Mark out holes with a marker pen.
B.2 Drill the holes & hammer.
Using a 6mm drill piece for masonry installation, drill
the two holes. Gently hammer the plugs into place and
then secure the screw tightly. For timber, drill 3mm pilot
holes to guide screws into place (plastic plugs are not
required).
STEP 3 Install Light strip
Strip Light Installation - Option A
Using the adhesive tape on back of light strip.
A.1 Unspool the strip light from the roll.
We recommend unspooling the full length and laying it
out along where it will be installed.
A.2 Remove the protective tape.
Working in sections, carefully remove the
backing off the glue strip (refer to image).
Be sure the tape goes directly onto
the desired surface, as the glue is very
strong, and it can be hard to remove
the lights if stuck in the wrong place.
A.3 Install Lights.
Make sure the strip is flat and even, and press and
hold for 4-5 seconds to ensure the glue sets. Run your
thumb along the section of lights to remove bumps and
unevenness. Repeat steps 2 and 3 until the light is installed.
A.4 Connect solar panel to strip light.
Strip Light Installation - Option B
Use the supplied Mounting Clips ( Non-Masonry).
