Hoshizaki Lancer S8E V2 Series Manual

www.lancerbeverage.com
230V / 50Hz
Installation, Operation &
Service Manual
S8E V2 Hi-Carb
Superchiller

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 2 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
This page is intentionally left blank

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 3 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
Table of contents
1.Introduction........................................................................................................................... 5
2.The Company........................................................................................................................ 5
3.Our Products ........................................................................................................................ 5
4.Product Details ..................................................................................................................... 5
4.1Product Features .......................................................................................................... 5
4.2Specifications................................................................................................................ 6
4.3Models .......................................................................................................................... 6
4.4Options.......................................................................................................................... 6
5.Superchiller Safety Information.......................................................................................... 7
5.1Safety Instructions ........................................................................................................ 7
5.2Recognise Safety Alert Symbols.................................................................................. 7
5.3Operating ...................................................................................................................... 7
5.4Service & Maintenance ................................................................................................ 8
5.5Carbon Dioxide (CO2).................................................................................................. 8
6.Installation............................................................................................................................. 9
6.1Receiving ...................................................................................................................... 9
6.2Unpacking..................................................................................................................... 9
6.3Selecting a Location ..................................................................................................... 9
6.4Mounting Superchiller................................................................................................. 10
6.5Connecting Python ..................................................................................................... 10
6.6Connecting to water supply ........................................................................................ 11
6.7Connecting to CO2supply .......................................................................................... 11
6.8Filling unit with water .................................................................................................. 11
6.9Electrical Connection.................................................................................................. 11
6.10Plumbing the drain and CO2exhaust......................................................................... 12
6.11Commissioning ........................................................................................................... 12
6.12Purge System ............................................................................................................. 12
6.13Sanitise System.......................................................................................................... 12
7.Scheduled Maintenance .................................................................................................... 13
7.1.Daily ............................................................................................................................ 13
7.2.Quarterly ..................................................................................................................... 13
7.3.Half Yearly .................................................................................................................. 13
7.4.Yearly.......................................................................................................................... 14
7.5.Sanitisation of Beverage System ............................................................................... 14
8.Postmix Circuit Diagram ................................................................................................... 15
8.1.Single Carbonator Superchiller (3 pumps)................................................................. 15
8.2.Twin Carbonator Superchiller (4 pumps) ................................................................... 16
8.3Twin Carbonator Superchiller (5 pumps) ................................................................... 17
9.Electrical Circuit Diagram ................................................................................................. 18
9.1.Refrigeration Wiring Diagram..................................................................................... 18
9.2.Postmix Wiring Diagram............................................................................................. 19
10.Airflow Diagram.................................................................................................................. 20
11.Trouble Shooting................................................................................................................ 21
11.1Refrigeration ............................................................................................................... 21

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 4 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
11.2Troubleshooting – Postmix......................................................................................... 22
12.Hydra Icebank Control Go/No Go Test............................................................................ 24
13.Hydra Carbonator Level Control Test.............................................................................. 25
14.Assembly Diagrams & Parts List ..................................................................................... 26
14.1.Postmix Spare Parts List ............................................................................................ 26
14.2.Postmix Assembly Diagram ....................................................................................... 27
14.3.Refrigeration Spare Parts List .................................................................................... 28
14.4.Refrigeration Assembly Diagram ............................................................................... 29
15.Certificate of Warranty....................................................................................................... 30
16.Manufacturer’s Checklist .................................................................................................. 31

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 5 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
1. Introduction
Thank you for purchasing this quality Lancer product. All Lancer products are constructed using the highest
quality materials and components. They are designed to the highest possible standards, therefore offering
our customers endless hours of optimum performance.
2. The Company
Hoshizaki Lancer is a wholly owned subsidiary of Lancer Corporation, a world leader in the supply of
Beverage Dispensing Equipment based in San Antonio, Texas. Lancer has manufacturing bases and
distribution networks in 97 countries. Lancer is in turn ultimately owned by Hoshizaki Electric Co Ltd of
Nagoya, Japan. Hoshizaki is a global leader in food service equipment.
Hoshizaki Lancer’s head office and manufacturing base is located in Adelaide (SA), with branch offices and
warehousing facilities in Sydney (NSW), Melbourne (VIC), Brisbane (QLD), Perth (WA) and Auckland (New
Zealand).
3. Our Products
Lancer specialises in the design, engineering, manufacture, and marketing of beverage dispensing in two
core categories:
Soft Drink Equipment
Mechanically cooled and ice cooled soft drink dispensers, frozen beverage dispensers, dispensing valves,
carbonators and an extensive line of beverage dispensing parts and accessories.
Beer Equipment
Lancer manufactures and markets beer dispensing and chilling equipment, and related accessories.
Products include founts, chillers, Chillerplates, drip trays, taps, handles, beer line cleaning equipment and an
extensive line of beverage dispensing parts and accessories.
4. Product Details
4.1 Product Features
The Lancer Superchiller is an Australian designed and manufactured remote refrigerated unit
designed to refrigerate and distribute post-mix (soft drinks) as well as maintaining the product
temperature through the python and dispenser.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 6 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
4.2 Specifications
Voltage 230 Volts
Frequency 50 Hz
Max Current Draw Refrig 15 Amps / Postmix 10 Amps
Ambient Temperature 2 - 40°C
Heat Rejection 6346 Watts
Dimensions
Width 1300 mm
Depth 685 mm
Height 815 mm
Weight 3 pump 4 pump 5 pump
Shipping 210 kg 221kg 232kg
Empty 190 kg 201kg 212kg
Operating 372 kg 383kg 394kg
Refrigerant 1000 grams R134a x 2
Ice bank Weight 75 kg
Water Bath Capacity 180 litres
Construction Stainless Steel
Compressor Danfoss x 2
Agitator Motor 12W, 230 VAC 1 Phase
Condenser Motor 20W, 230 VAC 1 Phase
Ice bank Control Electronic
Carbonation Level Control Electronic
Drink Capacity Continuous 473ml (16 oz) drinks below 4.4°C at 4 drinks per minute
with 40°C ambient, syrup inlet temperature and 32°C water inlet
temperature.
4.3 Models
S8E22LA V2 Lancer S8E Superchiller with 2 pumps, single Carbonator.
S8E23LA V2 Lancer S8E Superchiller with 3 pumps, single Carbonator.
S8E94LA V2 Lancer S8E Superchiller with 4 pumps, dual Carbonator.
S8E95LA V2 Lancer S8E Superchiller with 5 pumps, dual Carbonator.
4.4 Options
Adjustable Legs (79232218) – height with legs approx 960mm.
Casters (79602411) – height with casters approx. 921mm.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 7 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
5. Superchiller Safety Information
5.1 Safety Instructions
For your personal safety, and that of others working around you please read, understand, and follow
thoroughly all safety instructions included in this manual and on the Superchiller.
Review all applicable OSH (Occupational Safety & Health) regulations.
Review all applicable Beverage Dispensing Gas Standards
Learn how to operate the Superchiller and use the controls properly.
Do not allow untrained personnel to operate the machine.
Ensure that the Superchiller is maintained according to service manual instructions.
Do not allow any unauthorised modifications to the machine.
5.2 Recognise Safety Alert Symbols
The safety alert symbol precedes Warning and Caution notes throughout this manual. To prevent
personal injury or damage to the machine these alerts must be strictly adhered too.
Warning Alerts to a potentially hazardous situation that if not avoided CAN
result in death, serious injury.
Caution Alerts to a potentially hazardous situation that if not avoided MAY
result in injury or equipment damage.
5.3 Operating
Warning
Superchillers are intended for indoor operation only; do not operate
outside unless suitably protected by a weatherproof enclosure. This
appliance is not suitable for installation in an area where a water jet
could be used.
Caution
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 8 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
5.4 Service & Maintenance
Caution
Installation of Superchiller and service work should only be
performed by fully trained & certified Electrical, Plumbing, &
Refrigeration Technicians.
Warning Carbonator contains CO2gas and water under pressure. De-
pressurise before performing any work on the system.
Warning ALL WIRING AND PLUMBING MUST CONFORM TO LOCAL
AND NATIONAL CODES.
Warning
SUPERCHILLER MUST BE ISOLATED FROM ELECTRICAL
SUPPLY BEFORE COMMENCING ANY SERVICE OR
MAINTENANCE WORK.
5.5 Carbon Dioxide (CO2)
Warning
The Superchiller uses a CO2 (Carbon Dioxide) supply. CO2is a
heavier than air, colourless, non-combustible gas with a faintly
pungent odour.
Personnel exposed to high concentrations of CO2gas will
experience tremors, which are followed rapidly by loss of
consciousness and suffocation.
If a CO2gas leak is suspected, immediately ventilate the
contaminated area before attempting to repair the leak.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 9 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
6. Installation
Warning
To avoid personal injury or damage, do not attempt to lift a
Superchiller without help.
Use of a mechanical lift is recommended.
(NOTE: Empty S8E Superchiller weight: 212kg)
6.1 Receiving
Each unit is completely tested under operating conditions and thoroughly inspected before shipment.
At time of shipment, the carrier accepts the unit and any claim for damage(s) must be made with the
carrier. Upon receiving units from the delivering carrier, carefully inspect shipping crate for visible
indication(s) of damage. If damage exists, have carrier note damage on bill of landing and file a claim
with the carrier.
6.2 Unpacking
Caution
The use of gloves is recommended to protect hands from
potential injury from sharp edges. The Superchiller must
always be handled in a vertical position.
Carefully unpack the Lancer S8E Superchiller from the shipping carton, remove the wooden base.
If appropriate, assemble legs to unit by carefully tilting (tilt should not be more than 45°).
Inspect unit for concealed damage and if evident, notify delivering carrier and file a claim against the
carrier.
6.3 Selecting a Location
Warning
Superchillers are intended for indoor operation only; do not
operate outside unless suitably protected by a weatherproof
enclosure.
This appliance is not suitable for installation in an area where a
water jet could be used.
Caution
The Superchiller is not suitable for use in subfreezing
temperatures.
To prevent damage to the water supply line, turn off and drain
unit when air temperature is below zero.
The S8E Superchiller should be located in a well-ventilated, firm, level location close to
dispenser, water and electrical supplies, with easy access for servicing
Ensure sufficient clearance around Superchiller to allow good fresh air circulation through the
condenser – allow at least 200mm at rear and sides.
Installation should only be performed by a qualified and competent technician.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 10 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
6.4 Mounting Superchiller
Install on a flat, level surface using adjustable legs or casters (Optional).
Fix to supporting structure using 4 x ¾” BSW bolts screwed into base supports.
Caution
Superchiller operational weight is 394kg; ensure that all
supporting structures are certified for this loading by a
registered Mechanical Engineer.
Supporting structure must be securely fixed to floors or walls.
6.5 Connecting Python
Connect Python to Chiller and Dispenser.
Caution
NOTE: The S8E Superchiller is rated to operate with a maximum
of 90m of python connected at 32°C.
Exceeding manufacturer’s ratings may cause damage to the
Superchiller and void warranty.
Connect the Python to Chiller and Dispenser.
Refer to Python and Dispenser specifications for connection data.
Superchiller can be supplied with 4 or 5 pumps, dual carbonator, or 3 pumps single carbonator;
python should be connected to Chiller as follows:
5 Pump 4 Pump 3 Pump
SODA
RETURN A
WATER
RETURN
SODA
RETURN B SODA RETURN A
SODA
RETURN B SODA RETURN A
WATER
RETURN
SODA
SUPPLY A
WATER
SUPPLY
SODA
SUPPLY B SODA SUPPLY A
SODA
SUPPLY B SODA SUPPLY A
WATER
SUPPLY
Important: Ensure lines from python to Superchiller connections are insulated to prevent
condensation.
Note: For additional Soda reserve on short python lengths used in high volume accounts, it may be
necessary to extend the soda circuit by connecting the 2 spare lines in the python onto the soda
return line (i.e. double pass of soda circuit out and back from dispense point to soda return).
SODA SUPPLY
SODA RETURN
10mm 'U' BEND
PYTHON

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 11 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
6.6 Connecting to water supply
Using appropriate tubing and fittings connect a 10mm water supply line from Superchiller
carbonator pump inlet to a filtered, regulated water supply. (See Postmix circuit diagram page
13-15). Installation in accordance with AS/NZS 3500.1 and AS/NZS 3500.2.
Turn on water supply, check for leaks, adjust water regulator to 172-275kpa.
Open the bypass ball valve on the carbonator relief and bypass assembly until water flows from
CO2exhaust tube; then close the bypass ball valve. For dual carbonators, repeat this operation
for each carbonator.
Caution
Maximum water supply pressure to be 275 kpa.
Normal operating water temperature should be within 7°C to
32°C.
6.7 Connecting to CO2supply
Warning
As carbon dioxide (CO2) displaces oxygen; prevention of CO2
leaks is paramount. If a leak is suspected, immediately ventilate
the contaminated area, before attempting repairs.
Connect CO2supply line from regulator to gas inlet on carbonator. (See Postmix circuit diagram
page 13 – 15 for details)
Adjust CO2Regulator supplying Carbonator to 550 kpa.
Turn on CO2supply.
6.8 Filling unit with water
Remove Superchiller lid and fill water bath until water flows out overflow tube.
NOTE: Do not use water supplied from newly installed carbon filter as ice bank control operation will
be adversely affected.
6.9 Electrical Connection
This unit requires a separate 10 amp (Postmix) and a 15amp (Refrigeration) power supplies.
Check the name plate on the machine for electrical supply requirements. Use only the power
supply specified on the name plate.
Warning
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 12 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
Warning
To avoid possible fatal electric shock or serious injury the
Superchiller must be electrically grounded.
Electrical Connection Must Be Made In Accordance With The
Appropriate Local Codes And Regulations.
Use of an RCD is recommended.
6.10 Plumbing the drain and CO2exhaust
The 19mm overflow drain tube exiting from the base of the tank should be plumbed to a suitable
drain, installation in accordance with AS/NZS 3500.1 and AS/NZS 3500.2.
The 6mm barb labelled as CO2 EXHAUST should be plumbed to an outside safe area.
6.11 Commissioning
Unplug carbonator and recirculation pumps power supply leads from electrical box located
under lid.
Connect Superchiller power supply lead to an appropriate 3 pin socket outlet and switch on.
Compressors, condenser fans and agitator motors should all operate.
When Superchiller ice bank is fully formed (approx. 4 hours) the compressors and condenser
fans will cycle off, but agitator will run continuously (unit has cycled off).
After Superchiller has cycled off, reconnect carbonator and recirculation pumps.
6.12 Purge System
Progressively activate each dispensing valve or Bargun connected to the Superchiller systems until
an uninterrupted flow of soda, water (where applicable), and syrup pours from each dispenser.
6.13 Sanitise System
Prepare sanitising solution:
Prepare sanitising solution in accordance with the manufacturer’s written recommendations and
safety guidelines.
Sanitising BIB System
Remove all disconnects from BIB containers.
Immerse all disconnects in warm water and clean using a nylon bristle brush. Rinse with clean
water.
Prepare sanitising solution according to manufacturer’s instructions.
Attach sanitising fittings to BIB disconnects, if sanitising fittings are not available cut fittings from
empty BIB bags.
Immerse all sanitising fittings with attached BIB disconnects in bucket of sanitising solution.
Operate all dispensing valves until the sanitising solution flows from the valve. Allow sanitiser
to remain in lines for fifteen (15) minutes.
Immerse all sanitising fittings with attached BIB disconnects in bucket of clean water. Operate
all dispensing valves until all sanitiser has been flushed from the system.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 13 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
Remove sanitising fittings from BIB disconnects and re-connect disconnects to appropriate
BIB's. Operate dispensing valves until syrup flows freely.
7. Scheduled Maintenance
The following Superchiller routine maintenance should be performed at the intervals listed.
7.1. Daily
Cleaning/Sanitising
The Superchiller supplies soda water to the dispensing valves/barguns. To ensure optimum drink
quality and system performance at all times please follow cleaning and sanitising procedures for the
dispensing valves/barguns recommended by the valve/bargun manufacturer.
Checking CO2Supply
Ensure that the contents gauge on the CO2Regulator reads higher than 1400kpa on the dial. If it
does not, then the CO2cylinder is empty and must be changed using safe working practices.
Warning
To avoid personal injury and/or property damage, always
secure the CO2cylinder with a safety chain to prevent it from
falling over; and use appropriate protective equipment (as
defined in Clause 3.3.2 of AS 5034) to handle cylinders.
Should the valve become accidentally damaged or broken
off, a CO2cylinder can cause serious personnel injury.
7.2. Quarterly
The Superchiller should be connected to a filtered water supply. To ensure optimum drink quality and
system performance, supply water filters should be replaced every 3 months.
7.3. Half Yearly
Remove & Clean condenser filters on the Superchiller. When the environment is dirty and
dusty, the interval between cleaning the filters may need to be reduced. Clean condenser with
low pressure compressed air. When using compressed air always direct air from the fan side
through condenser. Remove all dust and foreign particles from refrigeration deck.
Caution When using compressed air always wear safety glasses.
Check that the water is level with the top of the overflow tube. Add water if necessary.
Open carbonator relief valve to purge CO2 and check leakage, close relief valve after checking.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 14 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
7.4. Yearly
Water bath and recirculation pump inspection.
Isolate Superchiller from power supply by switching off at socket.
Thaw the bank of ice formed in the tank. Empty the water from the tank with a suction pump or
drainage pipe.
Inspect coils and agitator in water bath for algae or slime accumulation. Clean as necessary
using a soft brush, rinse with clean water.
Check recirculation pump strainers for accumulation, replace if necessary.
Fill tank with clean water until water flows out the overflow tube.
Switch on power supply and check ball position in flow indicator section of strainer. If ball
indicates flow is less than 5 litres per minute, replace pump.
Commission and purge system as per clause 6.11 and 6.12.
7.5. Sanitisation of Beverage System
To maintain optimum quality of dispensed product each Superchiller and its associated beverage
system components must be thoroughly cleaned and sanitised annually.
Prepare sanitising solution
Prepare sanitising solution in accordance with the manufacturer’s written recommendations and
safety guidelines.
Sanitising BIB System
Remove all disconnects from BIB containers.
Immerse all disconnects in warm water and clean using a nylon bristle brush. Rinse with clean
water.
Prepare sanitising solution according to manufacturer’s instructions.
Attach sanitising fittings to BIB disconnects, if sanitising fittings are not available cut fittings from
empty BIB bags.
Immerse all sanitising fittings with attached BIB disconnects in bucket of sanitising solution.
Operate all dispensing valves until the sanitising solution flows from the valve. Allow sanitiser to
remain in lines for fifteen (15) minutes.
Immerse all sanitising fittings with attached BIB disconnects in bucket of clean water. Operate
all dispensing valves until all sanitiser has been flushed from the system.
Remove sanitising fittings from BIB disconnects and re-connect disconnects to appropriate
BIB's. Operate dispensing valves until syrup flows freely.

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 15 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
8. Postmix Circuit Diagram
8.1. Single Carbonator Superchiller (3 pumps)

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 16 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
8.2. Twin Carbonator Superchiller (4 pumps)
8.3.
SODA RELIEF
VALVE
SODA RELIEF
VALVE

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 17 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
8.3 Twin Carbonator Superchiller (5 pumps)
SODA RELIEF
VALVE
SODA RELIEF
VALVE

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 18 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
9. Electrical Circuit Diagram
9.1. Refrigeration Wiring Diagram

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 19 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
9.2. Postmix Wiring Diagram

S8E V2 Hi-Carb Superchiller 230V / 50Hz
www.lancerbeverage.com Page 20 of 31
Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000008
Images are for illustration purposes only as product may vary. No 026 – 20 November 2013
10. Airflow Diagram
