INSTALLATION INSTRUCTIONS
SWAY BAR KITS # 2205 & 2206
Thank you for your purchase. Please call us at [phone] if you have any questions
about your Hotchkis Performance product.
HOTCHKIS PERFORMANCE RECOMMENDS THE USE OF OUR
LOWER TRAILING ARMS WHEN MOUNTING THE REAR SWAY
BAR ON YOU’RE B BODY CAR.
THE TRAILING ARM PART NUMBER IS:
•1305 FOR PART # 2205 OR 2206 78-96 B BODY
ATTENTION WAGON OWNERS (WITH STOCK TRAILING ARMS):
THE REAR SWAY BAR CAN BE INSTALLED USING THESE PARTS FROM GM.
CHANNEL BRACKET – PART # 10191120 – QTY. 2
BOLTS – PART # 9433477 – QTY. 8
BOLTS (SWAY BAR TO ARMS) – PART # 11516714 – QTY. 4
FRONT SWAY BAR REMOVAL AND INSTALLATION
1) Raise vehicle and place on jack stands (make sure the surface is flat; ramps are ok).
2) Notice how the stock sway bar looks ie: bracket placement, bends etc.
3) Remove end links from sway bar.
4) Using a floor jack, support the sway bar. Remove the brackets holding the sway bar
to the frame. Lower the sway bar and remove it.
5) Apply a thin layer of supplied grease to the inside of the bushing and install the
bushings and brackets on the new sway bar (split in polyurethane bushing to front).
6) Attach the new sway bar with the PASSENGER SIDE BRACKET FIRST, then
complete the driver’s side.
7) Torque both bracket bolts to 24 ft./lbs.
8) Tighten end link bolts to 13 ft./lbs.

REAR SWAY BAR REMOVAL AND INSTALLATION
1) Raise vehicle and place on jack stands. (make sure the surface is flat; ramps are ok)
2) FOR THE 2205 ONLY - Using a floor jack, support the sway bar. Remove the bolts
holding the sway bar to the trailing arms. Lower the sway bar and remove.
3) If using the stock lower trailing arms, inspect sway bar mount locations for cracking
or damage. We recommend our fabricated trailing arms for improved traction and
performance. SEE ABOVE FOR APPLICATION.
4) Install new rear sway bar bolts to 45 ft./lbs.
5) Check for exhaust clearance on aftermarket exhaust systems and lower car off of jack
stands or ramps.
