Howard McCray R-CDS35-4L User manual

35 Series – Low Profile 44"H
Double Duty – Deli
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
Self Contained SC-CDS35-4L SC-CDS35-6L SC-CDS35-8L
Remote R-CDS35-4L R-CDS35-6L R-CDS35-8L
Length 50" 71" 95"
Height 44" 44" 44"
Depth 35-1/2" 35-1/2" 35-1/2"
Depth with bottom door 38-1/2" 38-1/2" 38-1/2"
(Dimensions are +/-1/4")
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

35 Series – Low Profile 44"H
Double Duty – Deli
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Foamed in place CFC free foam
Triple pane insulated front glass-26"H
Heavy gauge steel super structure
Bottom storage
Drain is included for cleaning
Satin finish extrusion on doors and door tracks
Designer white exterior front and ends
Stainless steel mirror trim
Stainless steel heavy gauge top – 17" W
Designer white exterior rear
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
Designer white ends
Stainless steel heavy gauge mezzanine shelf
White aluminum floor (bottom storage area)
Air insulated baffle (prevents moisture from
dripping into display area)
Epoxy coated main deck shelves
Copevap system (eliminates need for condensate pan)
R134a expansion valve system
Gravity coil located at inside top of unit and
bottom storage area
Self contained system
Automatic defrost controlled by time clock-(self
contained units only)
Pressure control maintains constant temperatures
Remotes available
Double pane rear removable doors
Newly designed rear compression door jamb
Removable front grille allows for cleaning
Removable rear grille for easy servicing
2 Rows of T12 lighting at top of unit
115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
115V-12AMP general purpose receptacle (wired
separately)
Scale stand
Paper cutter
Stainless steel, laminate, or paint
Mirrored doors
Extra row of mezzanine shelf
Front bumpers 1" or 3"
Door locks
Digital thermometer
Pass thru front doors
Sandwich racks
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
35 Series – Low Profile 44"H
Double Duty – Deli
Technical Data
SHIPPING INFORMATION
Model # Self contained SC-CDS35-4L SC-CDS35-6L SC-CDS35-8L
Remote R-CDS35-4L R-CDS35-6L R-CDS35-8L
50"
44"
35-1/2"
38-1/2"
71"
44"
35-1/2"
38-1/2"
95"
44"
35-1/2"
38-1/2"
Length
Height
Depth
Depth with Bottom door
(Dimensions are +/- 1/4")
White
White
White
2
19-3/16"X19-3/16"
1
2
26" X 45"
2
Yes
2
22-1/4"X31-5/8"
23
Standard
White
White
White
2
29-5/8"X19-3/16"
2
3
26" X 66"
2
Yes
3
22-1/4"X31-5/8"
34
Standard
White
White
White
4
19-3/16"X19-3/16"
3
4
26" X 90"
2
Yes
4
22-1/4"X31-5/8"
45
Standard
Exterior color
Interior color
Floors
# of top doors
Door size
# of bottom doors
Front glass
# of coils
Bottom storage
Main deck shelf #
Main deck size
Cubic capacity (ft3)
Mezzanine shelf
Self contained
Remote
36°F to 40°F
R134a
1/4
30
12
1 per day
1400
115V
6.0A
0.8A
No
36°F to 40°F
R134a
1/3
30
12
1 per day
2100
115V
8.7A
1.3A
No
36°F to 40°F
R134a
1/3
30
12
1 per day
2800
115V
9.1A
1.6A
No
Operating temperature
Refrigerant (expansion valve)
Compressor size HP
Pressure control settings @
75°F, 55%RH
Defrost per day (24 hours)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Amperage, lights only
Cord and plug
Self contained
Self contained
CUT IN
CUT OUT
Air Defrost
Remote
Self contained
Remote
58"
44"
61"
480#
434#
89ft3
58"
44"
87"
625#
571#
128ft3
58"
44"
109"
880#
826#
164ft3
Height
Depth
Length
Gross weight
Cubic feet
Self contained
Remote
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Cases are equipped with drains; check your local building codes for connection requirements.
• Specification subject to change without notice
