Howard McCray R-CMS40E-4C User manual

40E Series - Endless Design
Curved Glass - Red Meat
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
Self-Contained SC-CMS40E-4C SC-CMS40E-6C SC-CMS40E-8C
Remote R-CMS40E-4C R-CMS40E-6C R-CMS40E-8C
Length with (2) ends 51" 75" 99"
Length without ends 48" 72" 96"
Height with ends 53" 53" 53"
Height without ends 52-1/2" 52-1/2" 52-1/2"
Depth with ends 40" 40" 40"
Depth without ends 38-7/8" 38-7/8" 38-7/8"
Endless Design YES YES YES
(Dimensions are +/-1/4")
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

40E Series - Endless Design
Curved Glass - Red Meat
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Foamed in place CFC free foam
Heavy gauge steel super structure
Single duty display
Endless design allows for continuous line up
Drain is included for cleaning
Extra wide double bend curved glass (enhances
product display)
Grey finish extrusion on doors and door tracks
Designer white exterior front and ends
Trim
Stainless steel heavy gauge top– 13-3/4" W
Rear of unit is stainless steel brush finish at top
Bottom rear is designer white aluminum
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
Designer white interior ends
White interior
White aluminum floor (main deck area)
Epoxy coated main deck shelves
Air insulated baffle (prevents moisture from
dripping into display area)
Copevap system eliminates need for condensate pan
R134a expansion valve system
Gravity coil located at inside top of unit
Humidity coil located at main deck
Self contained system
Temperature and defrost electronically controlled
Remotes available
Scale Stand
Paper cutter
Stainless steel, laminate or paint
Mirrored doors
Stainless steel mezzanine shelf
Red meat bulbs
Drop work shelf
Front bumpers 3”
Door locks
Digital thermometer
Meat platters
Lights for mezzanine shelf
EXTERIOR LIGHTING
Double pane rear removable doors
Rear doors use the McGlide door system** (for
easy access)
Removable front grille allows for cleaning
Removable rear grille for easy servicing
1-1/2" removable end panels
Front bumper 2"- gray
1 Row of T8 lighting at top of unit
**McGlide door system is built with a extra
tight door jam which helps seal the door tight
when closed and prevents cold air from leaving
the unit saving energy costs.
ELECTRICAL REQUIREMENTS
115V/60Hz/1Ph
Hard wired
UL/CUL listed
115V-12AMP general purpose receptacle (wired
separately)
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
40E Series - Endless Design
Curved Glass - Red Meat
Technical Data
SHIPPING INFORMATION
Model # Self contained SC-CMS40E-4C SC-CMS40E-6C SC-CMS40E-8C
Remote R-CMS40E-4C R-CMS40E-6C R-CMS40E-8C
51"
48"
53"
52-1/2"
40"
38-7/8"
YES
75"
72"
53"
52-1/2"
40"
38-7/8"
YES
99"
96"
53"
52-1/2"
40"
38-7/8"
YES
Length with (2) ends
Length without ends
Height with ends
Height without ends
Depth with ends
Depth without ends
Endless design
(Dimensions are +/- 1/4")
White
Stainless
White
White
2
2
No
Curved
2
23-1/2"X32-5/8"
24.5
Optional
White
Stainless
White
White
2
2
No
Curved
3
23-1/2"X32-5/8"
36.8
Optional
White
Stainless
White
White
4
2
No
Curved
4
23-1/2"X32-5/8"
49
Optional
Exterior color
Interior color
Inside end panels
Floors
# of top doors
Door size
# of coils
Bottom storage
Front Glass
# of main deck shelves
Shelf size
Cubic capacity (ft3)
Mezzanine- shelf
34°F to 36°F
R134a
1/4
36
34
1 per day
1400
115V
6.0A
0.8A
No
34°F to 36°F
R134a
1/3
36
34
1 per day
2100
115V
8.7A
1.3A
No
34°F to 36°F
R134a
1/2
36
34
1 per day
2800
115V
11.2A
1.6A
No
Operating temperature
Refrigerant (expansion valve)
Compressor size- HP
Electronic control settings
@ 75°F, 55%RH
Defrost per day (24 hours)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Amperage - lights only
Cord and plug
Self contained
Self contained
CUT IN
CUT OUT
Air Defrost
Remote
Self Contained
Remote
58"
44"
61"
530#
497#
89ft3
58"
44"
87"
741#
693#
128ft3
58"
44"
109"
897#
832#
164ft3
Height
Depth
Length
Gross weight
Cubic feet
Self contained
Remote
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Cases are equipped with washout drains; check your local building codes for connection requirements.
• Specification subject to change without notice
