Howard McCray R-OS30E-3 User manual

Open Merchandisers - Ovations-Multi Purpose
44"H-Refrigerator - Endless Design
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
Self-Contained SC-OS30E-3 SC-OS30E-4 SC-OS30E-6
Remote R-OS30E-3 R-OS30E-4 R-OS30E-6
Length with ends 39" 51" 75"
Length without ends 36" 48" 72"
Height with ends 44" 44" 44"
Height without ends 43-7/8" 43-7/8" 43-7/8"
Depth with ends 30" 30" 30"
Depth without ends 29-1/2" 29-1/2" 29-1/2"
Endless Design Yes Yes Yes
(Dimensions are +/-1/4”)
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

Open Merchandisers - Ovations-Multi Purpose
44"H-Refrigerator - Endless Design
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Foamed in place CFC free foam
Heavy gauge steel super structure
Endless design allows for continuous line up
Wide view Plexiglas on front and ends
Designer white or black end panels
Designer white or black front bumper
Designer white or black rear
Designer white or black end trim
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
Designer white or black end panels
Removable designer white or black floor racks
Designer white or black perforated rear wall (for
even air distribution)
3 tier step rack
R134a expansion valve system
Automatic condensate
Low velocity fans located below deck area (to
insure even flow of air)
Pressure control maintains constant temperatures
Auto defrost controlled by time clock (self con-
tained units only)
Air screen technology
Self contained system
Copeland hermetic unit
Remotes available
Designer white or black ends and front
Designer white or black bumper
Designer white or black end trim
Removable front grille for cleaning and servicing
7" of Plexiglass on end panel
115V/60Hz/1Ph
Cord and plug provided
UL/CUL listed
Remote available
Rear grille
Digital thermometer
Sandwich/ fruit racks
Stainless steel, laminate or paint
Night cover
Peg bars
Casters
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.
(ALL WHITE OR ALL BLACK, NO EXTRA CHARGE—IF COLORS ARE MIXED AN ADDITIONAL CHARGE WILL APPLY)

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
Open Merchandisers - Ovations-Multi Purpose
44"H-Refrigerator - Endless Design
Technical Data
SHIPPING INFORMATION
Model # Self contained SC-OS30E-3 SC-OS30E-4 SC-OS30E-6
Remote R-OS30E-3 R-OS30E-4 R-OS30E-6
39"
36"
44"
43-7/8"
30"
29-1/2"
51"
48"
44"
43-7/8"
30"
29-1/2"
75"
72"
44"
43-7/8"
30"
29-1/2"
Length with ends
Length without ends
Height with ends
Height without ends
Depth with ends
Depth without ends
(Dimensions are +/- 1/4")
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
White or Black
Exterior color
Interior color
Inside end panels
Floors
36°F to 40°F
R134a
1/2
29
12
6 @ 20 minutes
3100
115V
12.0A
0.7A
Yes(15A)
36°F to 40°F
R134a
1/2
29
12
6 @ 20 minutes
4130
115V
13.1A
1.4A
Yes(20A)
36°F to 40°F
R134a
3/4
29
12
6 @ 20 minutes
6200
115V
16.0A
1.4A
Yes(20A)
Operating temperature
Refrigerant-(expansion valve)
Compressor size- HP
Pressure control settings at
75°F, 55% RH
Defrost per day (24 hours)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Amperage
Cord and plug
Self contained
Self contained
CUT IN
CUT OUT
Air Defrost
Remote
Self contained
Remote
49"
44"
61"
330#
205#
76ft3
49"
44"
61"
360#
235#
76ft3
49"
44"
87"
495#
345#
109ft3
Height
Depth
Length
Gross weight
Cubic feet
Self contained
Remote
(ALL WHITE OR ALL BLACK, NO EXTRA CHARGE—IF COLORS ARE MIXED AN ADDITIONAL CHARGE WILL APPLY)
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Cases are equipped with drains; check your local building codes for connection requirements.
• Specification subject to change without notice
