Howard McCray R-CMS35-10 User manual

35 Series – Double Duty
Red Meat
• PRODUCT SPECIFICATIONS SHEETS
• Specification subject to change without notice
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
Self-Contained SC-CMS35-4 SC-CMS35-6 SC-CMS35-8 SC-CMS35-10 SC-CMS35-12
Remote R-CMS35-4 R-CMS35-6 R-CMS35-8 R-CMS35-10 R-CMS35-12
Length 50" 71" 95" 119" 143"
Height 52" 52" 52" 52" 52"
Depth 35-1/2" 35-1/2" 35-1/2" 35-1/2" 35-1/2"
Depth w/bottom door 38-1/2" N/A N/A N/A N/A
(Dimensions are +/-1/4")

35 Series – Double Duty
Red Meat
Standard Specifications and Optional Features
OPTIONAL FEATURES
A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
UL Classified to ANSI/NSF 7
Foamed in place CFC free foam
Triple pane insulated front glass-26"H
Heavy gauge steel super structure
Bottom storage
Drain is included for cleaning
Satin finish extrusion on doors and door tracks
Designer white exterior front and ends
Stainless steel mirror trim
Stainless steel heavy gauge top – 17" W
Designer white exterior rear
CONSTRUCTION FINISHES
INTERIOR REFRIGERATION
EXTERIOR LIGHTING
ELECTRICAL REQUIREMENTS
Designer white interior ends
White aluminum floor (bottom storage area)
Air insulated baffle (prevents moisture from
dripping into display area)
Copevap system (eliminates need for condensate pan)
R134a expansion valve system
Gravity coil located at inside top of unit and
bottom storage area
Humidity coil located at main deck
Self contained system
Automatic defrost controlled by time clock-(self
contained units only)
Temperature control maintains constant temperatures
Remotes available
Double pane rear removable doors
Newly designed rear compression door jamb
Removable front grille allows for cleaning
Removable rear grille for easy servicing
2 Rows of T12 lighting at top of unit
115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
115V-12AMP general purpose receptacle (wired
separately)
Scale stand
Paper cutter
Paint, laminate or stainless steel
Mirrored doors
Stainless steel mezzanine shelf
Drop work shelf
Front bumpers 1" or 3"
Door locks
Digital thermometer
Pass thru front doors 4', 6' and 8 foot only
Meat platters
Red meat bulbs
Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.
Important Note: Product must be cooled
before being displayed within the case.

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA
[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com
35 Series – Double Duty
Red Meat
Technical Data
SHIPPING INFORMATION
Model Self contained SC-CMS35-4 SC-CMS35-6 SC-CMS35-8 SC-CMS35-10 SC-CMS35-12
Remote R-CMS35-4 R-CMS35-6 R-CMS35-8 R-CMS35-10 R-CMS35-12
50"
52"
35-1/2"
38-1/2"
71"
52"
35-1/2"
N/A
95"
52"
35-1/2"
N/A
119"
52"
35-1/2"
N/A
143"
52"
35-1/2"
N/A
Length
Height
Depth
Depth with bottom door
(Dimensions are +/- 1/4")
White
White
White
2
19-3/16"X19-3/16"
1 external
2
3
Yes
26" X 45"
2
31-5/8"X22-1/4"
30
Optional
White
White
White
2
29-5/8"X19-3/16"
2
2
3
Yes
26" X 66"
3
31-5/8"X22-1/4"
45
Optional
White
White
White
4
19-3/16"X19-3/16"
2
4
3
Yes
26" X 90"
4
31-5/8"X22-1/4"
60
Optional
White
White
White
4
23-1/2"X19-3/16"
3
4
3
Yes
26" X 114"
5
31-5/8"X22-1/4"
75
Optional
White
White
White
4
29-5/8"X19-3/16"
4
4
3
Yes
26" X 138"
6
31-5/8"X22-1/4"
90
Optional
Exterior color
Interior color
Floors
# of top doors
Door size
# of bottom doors
# of coils
Bottom storage
Front glass
# of main deck shelves
Main deck size
Cubic capacity (ft3)
Mezzanine Shelf
Self contained
Remote
34°F to 36°F
R134a
1/4
40
20
1 per day
1400
115V
6.0A
0.8A
No
34°F to 36°F
R134a
1/3
40
20
1 per day
2100
115V
8.7A
1.3A
No
34°F to 36°F
R134a
1/2
40
20
1 per day
2800
115V
11.2A
1.6A
No
34°F to 36°F
R134a
1/2
40
20
1 per day
3500
115v
13.8A
2.4A
No
34°F to 36°F
134a
3/4
40
20
1 per day
4200
115V
17.4A
2.4A
No
Operating temperature
Refrigerant (expansion valve)
Compressor size HP
Temperature control set-
tings @ 75°F, 55%RH
Defrost per day (24 hours)
BTU’s at +20°F Evap. Temp.
Voltage
Amperage
Amperage, lights only
Cord and plug
Self contained
Self contained
CUT IN
CUT OUT
Air Defrost
Remote
Self contained
Remote
58"
44"
61"
500#
460#
90ft3
58"
44"
87"
645#
595#
128ft3
58"
44"
109"
900#
845#
160ft3
58"
44"
135"
1230#
1175#
200ft3
58"
44"
157"
1344#
1295#
231ft3
Height
Depth
Length
Gross weight
Cubic feet
Self contained
Remote
• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity
• Cases are equipped with drains; check your local building codes for connection requirements.
• Specification subject to change without notice
