Howen AI Thermodetector
User Manual
Model :Hero-TD01-G

2
CONTENTS
1. PRODUCT OVERVIEW.............................................................................................................................3
1.1 PRODUCT INTRODUCTION............................................................................................................................. 3
1.2 PRODUCT FUNCTIONS.................................................................................................................................. 3
2. WIRING INSTRUCTIONS..........................................................................................................................3
2.1 WIRING INSTRUCTIONS................................................................................................................................. 4
2.2 CONNECT THE DEVICE TO PC....................................................................................................................... 5
2.3 CONNECT THE LOCK OF DOOR (PUSH_OUT)............................................................................................... 6
2.4 WIRING INSTRUCTIONS（LOCK_NONC_12V ）..................................................................................... 6
3. CLIENT OPERATIONS..............................................................................................................................7
3.1 DEVICE MANAGEMENT ................................................................................................................................. 8
3.1.1 Adding Device..................................................................................................................................... 8
3.1.2 Device Settings................................................................................................................................... 9
3.2 STAFF MANAGEMENT.................................................................................................................................. 15
3.2.1 Adding Staff....................................................................................................................................... 15
3.2.2 Batch-adding From file..................................................................................................................... 16
3.2.3 Edit Users.......................................................................................................................................... 16
3.2.4 Delete................................................................................................................................................. 17
3.2.5 Staff Sync .......................................................................................................................................... 18
3.2.6 Clearing Device users...................................................................................................................... 20
3.2.7 Blacklist and White-list..................................................................................................................... 21
3.2.8 Device Access Control Parameters............................................................................................... 22
3.2.9 User Access Information ................................................................................................................. 23
3.3 VOICE OF NOTIFICATION ............................................................................................................................. 23
4. DATA QUERY...........................................................................................................................................24
4.1 UPDATING ATTENDANCE RECORDS............................................................................................................ 24
4.2 EXPORT ATTENDANCE RECORD................................................................................................................. 24
5. FAQ ...........................................................................................................................................................25

3
1. Product Overview
1.1 Product Introduction
HowenAI Thermodetector Hero-TD01-G adopts the new AI chip-set, large thermal sensor array,
and latest algorithm, providing the cutting-edge face recognition and body temperature detection,
with ability to detect wearing the mask. Hero-TD01-G can identify human forehead automatically
from 0.3meter ~1.2meter to get ±0.2℃high accuracy body temperature within 0.05second.
1.2 Product Functions
⚫Proximity wake-up activation: the device is automatically activated when a person
approaches.
⚫7-inch touch screen: displays the software interface, operation guidance and face frame.
Performs real-time face detection (supports local video preview).
⚫2 million pixel binocular wide angle camera.
⚫Anti-fake function for pictures and videos.
⚫Facial recognition distance of up to 1 meter, for a height range of 1.4m to 1.9m.
⚫Use of deep learning algorithms to support a capacity of 10,000 faces. Fast recognition
with a higher recognition rate.
⚫Storage of up to 30,000 events.
⚫Multiple authentication methods.
⚫Facial comparison time ≤ 0.05s/person. Recognition rate ≥99.9%.
⚫Support for importing of card and facial data to devices through TCP/IP transmission or
USB interfaces.
⚫Uploading of data through the internet.
⚫Uploading of comparison results and interconnected snapshots to the platform for
storage.
⚫Personnel information can be sent down from the platform or uploaded from local
devices.
⚫Stand-alone operation in offline mode.
⚫Local login for managing, searching and configuring device parameters.
2. Wiring instructions
Face recognition terminal can be docked through the tail line access control locking, in the
retention of existing access control system function of the colleague, the access control intelligent
operation upgrade. It is possible to simulate the opening of the door with the PUSHOUT signal and
directly drive the electromagnetic anode or cathode locks with the LOCKNONC signal.
For direct drive of Anodic or cathodic locks, a 12V/2A switched power supply is recommended for
panel machine input.
Note the following when wiring.

4
⚫If 1.0mm national standard wire is used, 12V switching power supply is used, and the wiring
distance from the site construction (switching power to equipment distance) does not exceed
20m.
⚫If 1.5mm national standard cable is used, 12V switching power supply is used, and the wiring
distance from the site construction (switching power to equipment distance) does not exceed
30m.
⚫If 2.0mm national standard wire is used, 12V switching power supply is used, and the wiring
distance (switching power to the equipment distance) is not more than 40m.
2.1 Wiring instructions
The wiring instructions are shown in the table below.
Wire Description
Function
Wire
sequence
Name
Description
A DC IN
POWER
1
12V in
12V power supply, 2A
2
GND
Ground
B Type-A USB
USB Host
1
5V
Only used for factory testing.Do
Not connect it.
2
DN
3
DP
4
GND
C RJ45
Ethernet
1
Ethernet
Standard 100 megabit network
port, connect to PC for
configuration.
D OUT-4pin
lock control
signal
1
PUSH_OUT
Switching Level Output
2
LOCK_NONC_1
12V switching drive output

5
2V
3
GND
Ground
4
12V out
12V power output
E 2 pin
Reserved
1
N/A
2
Precautions：
1). Line group 4, pin 4 (12V out), current limit output 1A, load beyond power, will cause panel
machine hardware damage.
2). Wire group 4, pin 2 (LOCK_NONC_12V), current limit output 800mA, beyond the power of the
latch access, will cause panel machine hardware damage.
3). Wire group 4, pin 2 (LOCK_NONC_12V) and pin 3 (GND), please do not short-circuit,
otherwise it will cause hardware damage to the panel machine.
4). Wire group 4, pin 1 (PUSHOUT) and pin 4 (12V out), please do not short-circuit, otherwise it
will cause hardware damage to the terminal.
2.2 Connect the device to PC
1.Connect the network cable via RJ45 to your PC directly or via router.
2.The default IP address of device is 192.168.1.100, so need make sure your PC in the same IP
address segment (192.168.1.***). Or you can add the 192.168.1.** IP segment in Advanced.

6
3. Turn off firewall of your PC.
2.3 Connect the Lock of door (Push_out)
A. Conventional access control system, generally with a button to open the door function, it is
recommended that the terminal PUSHOUT terminal directly and connected to the open the door
button wiring, in line with the permission to open the door action through PUSHOUT directly
simulate the button grounding operation, does not affect the original door button function.
2.4 Wiring instructions（LOCK_NONC_12V ）
The hardware wiring is as follows, the switching quantity signal can be directly output 12V, no
external power supply is required to power the lock.
Note: The original door controls cannot be unlocked when the power is removed.

7
Anode Lock
Software Configuration: In the ARFaceManager tool, go to the Personnel Permissions page (3.2.8
Device Access Control) and set the door magnet type to "Normally Closed".
Cathode Lock
Software Configuration: In the ARFaceManager tool, go to the Personnel Permissions page (3.2.8
Device Access Control) and set the door magnet type to "Normally Open".
3. Client operations
You can set up and operate your device through client ARFaceManager.exe. This chapter
introduces the functions and operating procedures of access control.
The main interface contains System menu, 4-channel preview interface, identified staff
info( temperature, mask, name) and Un-identified person info (temperature, wear mask or not).

8
Video Preview: You can get the live streaming info;
Device Manage: Search, edit and set the device.
Staff Manage:Add/edit/delete the staff personal info, and authorize the door-Lock function.
Data Query: Export the attendance of registered staff.
3.1 Device Management
3.1.1 Adding Device

9
1) On the left side of the control panel, click Device Management -> Search Device
2) Click Device Management -> Add Device
Select the camera you want to add, fill in the device name (required) and position (required), and
click “Add select”. You can also delete it via “Delete”.
3.1.2 Device Settings
Device settings includes device parameters, upload settings, algorithm configurations, display
configurations, and video settings.

10
3.1.2.1 Device parameters
⚫Internet settings
Static IP settings:
1. Uncheck “Enable DHCP”. Check “Directly”.
2. Configure unified IP address, you can change the IP address. Click “ Reboot after
setting” .The default one is 192.168.1.100.
3. Click “Set up”. The parameters will be synchronized to the device.
⚫NTP settings:
1. Configure the NTP server IP address, port number, update cycle and time zone.

11
2. Check “Enable”.
3. Click “Set Up”. The parameters will be synchronized to the device.
⚫Timezone
⚫Manual time setting
You can synchronize with your PC’s time.
3.1.2.2 Upload settings (Need develop or integrate)
⚫Private cloud settings
1. Check “Open private cloud”.
2. Fill in the server IP, port, appKey, appSecret, appNote.
3. Click “Set Up”. The parameters will be synchronized to the device.
⚫Upload settings
Server type: supports snapshot mode and recognition mode.
Supports simultaneous Http and mqtt uploading.

12
3.1.2.3 Algorithm settings
⚫Target image settings

13
⚫Background image settings
⚫Other settings
⚫Threshold settings
3.1.2.4 Display settings
⚫Image settings
⚫Video settings : You can mirror the preview image.
⚫OSD settings
Edit it, and check these OSD info, then it will display in the preview image. Click Set to save.
⚫Temperature Threshold setting

14
⚫Language setting ( Multiple notification language can be customized)
3.1.2.5 Video setting

15
Video settings support H.265 and H.264.
And you can customize the background picture via Upload BG Image（Size：600*1024 PNG）
3.2 Staff Management
3.2.1 Adding Staff
1. On the left side of control panel lick Staff Manage -> Staff Info

16
2. Click “Add ”. The staff information display zone becomes available for editing.
3. Name, workId , ID, photo are required fields. The other fields are optional.
4. Click “Add ”. The data will be stored in the client software and local database.
Notification：Must make sure the picture is originally without any filter-effect /editing.
3.2.2 Batch-adding From file
1. Click Staff Manage -> Staff Info on the left side of control panel.
2. Click “Import from file” and select a pre-edited Excel document of user information. You
can refer to the model document person.xlsx in configuration tools.
3. Click “Open” and complete the import.
Notice: You can refer to our Excel file’s format, and set the pictures’ path, then import them.
3.2.3 Edit Users
Attention: If you edit or change the Name and Work ID, the system will deem it’s another staff. So
if any wrong message of Name and work ID, you can delete this user, then add again.
For other info, you can change it directly.

17
1. On the left side of control panel, click Staff Manage -> Staff Sync , then select the list .
2. Click “Modify”. The personnel information display zone becomes available for editing.
3. Click “Modify” after editing. The data will be stored in the local database of the client.
Attention: After you edit the user, need synchronize with device end, please follow with 3.2.5
Staff Sync.
3.2.4 Delete
⚫Single removal
1. Select the user to be removed.
2. Click “Delete”.

18
⚫Batch Delete
1. Select multiple users by pressing Ctrl key or select all by pressing Ctrl+A of keyboard.
2. Click “Delete”to delete all users.
3.2.5 Staff Sync
On the left side of control panel, click Staff Manage -> Staff Sync.
1. Select the device node to be synchronized and click “Read staff info” to synchronize
personnel data between the device and the client.

19
2. Click “Show All Differences”, and click “Compare”.
Yellow indicates that information is on the local client but not on the device.
Grey indicates that information is on the device but not on the local client.
3. Click “Sync to dev”, and click Sync to device to import users from the local client to the
device.

20
4. If there are some info only saving in device, Click “Sync to local”, and click “Sync to local”
to import data from the device to the local database.
3.2.6 Clearing Device users
On the left side of control panel, click Staff Management -> Staff Sync.
Click “Clear Faces” and click “Read staff Information” to check whether all information is cleared.
