Hozelock 7816 User manual

2823
7816
7819
?
Hozelock Ltd.
Midpoint Park,
Birmingham B76 1AB. England
Tel: [phone]
[email protected]
www.hozelock.com
33801-001
2
1Depth A & B must be less than 9m Max
Depth C must be less than 9m Max
garden PUMP kit
B
A
C
33801-001 GardenPump Inst 6/11/07 12:52 Page 1

A B
C
F
Ensure seals are fitted to the front between the
pump and the adaptor
Ensure hand tight
Ensure filter is
fitted the correct
way around
Ensure seal is
fitted to the
front between
the adaptor and
the filter
Ensure hand
tight
Ensure that the
pump is filled to
the brim with
clean water
There is no
requirement to
fill the hose or
filter with water
D
E
Ensure seal is fitted to the front between the filter
and the hose
Ensure all fittings are hand tight
6mm
x2
33801-001 GardenPump Inst 6/11/07 12:52 Page 2

G H I
J
L MK
The hose should be open i.e. the other end not blocked or
closed with either a spray gun or water stop connector
The pump will prime, this can be noisy and can take up to
5 minutes. It is complete when the pressure from the hose is
steady and the noise is reduced
33801-001 GardenPump Inst 6/11/07 12:52 Page 3

High pressure water can be
dangerous, always turn the power
to the pump off before
disconnecting the hose from the
pump
If the pump is running, and the
water is prevented from flowing
(eg. spraygun is in off mode) then
the water inside the pump can
become very hot. Never run the
pump for more than 10 minutes
without water flowing
Warning : Read this manual
carefully before installing this
pump.
This sign warns the user that
failure to follow an instruction may
damage the pump or the system
This sign warns the user of
important electrical safety
information.
Carefully store this manual.
If problems arise contact
Hozelock customer services.
Every Hozelock Garden Pump
is carefully tested and packed during
assembly.
On receipt, check that the pump has not
been damaged during transport. If the
pump is damaged, do not use, and
contact Hozelock customer services.
Check that the voltage and frequency
of pump shown on the rating label
corresponds to those available on the
mains.
ELECTRICAL INSTALLATION:
A 10MA OR 30MA RESIDUAL
CURRENT DEVICE (RCD)
MUST BE FITTED TO THE
MAINS SUPPLY.
PROTECT THE PLUG AND THE
POWER CABLE FROM HEAT,
OIL AND SHARP EDGES.
THE POWER CABLE SHOULD
ONLY BE REPLACED BY
QUALIFIED PERSONNEL.
MAKE SURE THAT
ELECTRIC CONNECTIONS ARE
PROTECTED FROM WATER
& SPLASHES
THE INSTALLATION OF THE PUMP
SHOULD BE ON A STABLE FLAT
DRY SURFACE
THE PUMP MUST NOT BE
SUBMERGED
THE POWER CABLE SHOULD
HAVE A MINIMUM OF 3 CORE
0.75MM2SECTION EQUIVALENT
TO THAT OF H05 RN-F. TO MAKE
SURE THE PLUG IS PROTECTED
FROM ANY SPLASHES, USE THE
CABLE SUPPLIED TO CONNECT
AS FAR AWAY FROM THE PUMP
AS POSSIBLE
BEFORE USING THE PUMP,
ALWAYS INSPECT IT VISUALLY
(ESPECIALLY THE POWER CABLE
AND THE PLUG). DO NOT USE
THE PUMP IF IT IS DAMAGED.
NEVER USE THE POWER CABLE
TO LIFT THE PUMP.
Electrical SafetyGeneral Safety
33801-001 GardenPump Inst 6/11/07 12:52 Page 4

This pump can be used to:
Drive sprayguns, sprinklers and micro
irrigation systems
This pump is not suitable to be
used with swimming pools, where
people can become immersed in
the water.
This pump is not suitable for table
fountains / aquariums / Fountains /
Filters for fish ponds / Waterfalls.
The pump cannot be used for sea
water & inflammable, corrosive,
explosive or dangerous liquids.
Do not run dry.
The pump must be used with the
filter supplied, this protects the
pump from debris that may be
present in the water. Failure to use
the filter will invalidate the pump
warranty
If the pump is not going to be
useg for more than one month or
there is a risk of freezing, the
pump, filter and hose should be
drained.
Pump performance depends upon
the length and diameter of the
outlet hose (watering hose), and
the height that the water is
pumped.
Before installation, and whenever
you are handling the pump,
always disconnect from the
electrical supply.
To prevent injury, never put your
fingers into the mouth of the pump.
• Use the handle provided to carry or
lift the pump
• When used with a Water Butt for the
first time, ensure the water butt is
emptied and cleaned of all sediment,
leaves and accumulated debris.
Pump assembly :
Attach the metal baseplate to the
pump with the bolts and washers
supplied
Screw one of the yellow accessory
adaptors to the inlet of the pump
Screw the filter onto the adaptor.
The arrow on the filter should
point towards the pump.
Remove filter adaptor from hose
and attach the suction hose to the
filter
Ensure that the inlet to the suction
hose is at least 150mm (6") under
the surface of the water. If required
weight the end of the hose using a
brick.
It is critical that all the seals are
present and that all the joints
are airtight.
There should be no elbows or
kinks in the suction hose as this
will affect performance
The installation should be
consistant with the limitations as
shown in diagrams A & B on the
cover of this booklet
E
D
C
B
A
InstallationLimitations
33801-001 GardenPump Inst 6/11/07 12:52 Page 5

Fill the pump chamber to the brim
with tap water using a watering can
The Hozelock garden pumps are
self priming, therefore they can
be primed without filling the
suction pipe or filter.
Attach the outlet connector to the
outlet of the pump
Connect the garden hose to the
outlet, ensuring that the other end
of the garden hose is open and that
it will be free to drain when the
pump is turned on
Ensure that the suction hose is
under the surface of a suitable
water reservoir (water butt etc.)
Plug the pump into a suitable power
supply
When the power is turned on, the
pump will start the priming process.
This operation can take several
minutes. During the priming process
the pump is pumping a mixture of
air and water, this drastically reduces
the performance of the pump and is
very noisy.
When the pump is primed and ready
to use, the noise reduces and the
flow and pressure are maximised.
If any of the seals or fittings are
missing, overtightened or loose
the pump will not prime
If the pump does not prime
after 5 minutes - stop and
repeat steps 6 to 10
TO CONNECT TO AN IRRIGATION
SYSTEM:
■For use with hoses and hose reels
add a 2166 hose connector
(available separately)
• The Hozelock Garden Pump has a
built in thermal protection switch.
The pump stops if an overload
condition occurs. The motor restarts
automatically after it has cooled
down.
• Insert the plug into a 220-240v A/C
socket
Make sure that the pump is
disconnected from the electric
power supply before performing
any maintenance.
If pump performance drops it may
be because the two filters in the kit
have become clogged, and require
cleaning
Regularly check the coarse filter on
the end of the suction hose, and
clean if required. After checking or
cleaning the pump with new
repriming. See steps F-J.
Regularly check fine filter fitted
prior to the pump, and clean if
required.
Use the large plastic spanner
supplied to loosen large yellow
locking nut
Remove cup and filter, clean under a
tap. ! Do not scrub
Reassemble, and make sure the nut
is tightened securely - use spanner
provided
• Disconnect hose and loosen bottom
red nut and allow to drain
• Store the pump in a dry place and
protect from frost.
M
L
K
J
I
H
G
F
Installation Overload protection
To start the pump
Maintenance
Pump storage
33801-001 GardenPump Inst 6/11/07 12:52 Page 6

Troubleshooting
Problem Possible Cause Remedy
The pump does
not pump water
and the motor is
not running
No electricity Check that the electricity supply
is turned on and that the pump is
correctly plugged in
Plug inserted incorrectly
Circuit breaker is
tripped
Reset electricity supply.
If the circuit breaker trips once
more contact a specialised
electrician
Damaged motor Contact hozelock customer
services for assistance
Pump has overheated Pump contains thermal
protection - check if pump case is
hot, and if so, allow to cool
The pump
supplies a
limited amount
of water or the
pump does not
pump water,
and the motor is
running, even
after several
minutes the
pump is still
noisy
Pump full of air Unplug from the electricity
supply
Pump is not primed Repeat priming process - follow
steps 6 -10
Obstructed inlet Check inlet is under surface of
water, inlet filter is clean, and
inlet hose is not kinked or
damaged
Obstructed pipe/outlet Remove obstructions in inlet hose
or kinks
Worn impeller Contact Hozelock customer
services for assistance
33801-001 GardenPump Inst 6/11/07 12:52 Page 7

Troubleshooting
Problem Possible Cause Remedy
The pump
works only
intermittently
The temperature of the
fluid is too high
Only use with fluids below 35ºC
Fluid too dirty Empty and clean the water butt,
refill with fresh rain/tap water
Faulty motor Contact Hozelock customer
services for assistance
Water is leaking
from the outlet
of the pump
Inlet assembly not tight
enough
Tighten
Hozelock connector not
correctly attached
Re-attach Hozelock connector
33801-001 GardenPump Inst 6/11/07 12:52 Page 8

33801-001 GardenPump Inst 6/11/07 12:52 Page 9

33801-001 GardenPump Inst 6/11/07 12:52 Page 10

Dear (neighbour)
…………………………............................(name)
I am watering my garden using a water
butt, combined with the new Hozelock
Garden Pump. This means that I can
legitimately & legally water my garden
using a hosepipe & sprinkler even if there is
a Hose pipe ban or drought order in this
area.
This new pump works with all of Hozelock’s
spraygun’s, Vortex sprinklers and Micro
Irrigation systems – even their brand new
AquaPod system, find out more at
www.hozelock.com or call 0121 313 1122.
(Monday - Friday, 9am - 5pm).
Best Wishes,
………………………...........................…(Name)
……………………….............…………(Address)
Dear (neighbour)
…………………………............................(name)
I am watering my garden using a water
butt, combined with the new Hozelock
Garden Pump. This means that I can
legitimately & legally water my garden
using a hosepipe & sprinkler even if there is
a Hose pipe ban or drought order in this
area.
This new pump works with all of Hozelock’s
spraygun’s, Vortex sprinklers and Micro
Irrigation systems – even their brand new
AquaPod system, find out more at
www.hozelock.com or call 0121 313 1122.
(Monday - Friday, 9am - 5pm).
Best Wishes,
………………………...........................…(Name)
……………………….............…………(Address)
Dear (neighbour)
…………………………............................(name)
I am watering my garden using a water
butt, combined with the new Hozelock
Garden Pump. This means that I can
legitimately & legally water my garden
using a hosepipe & sprinkler even if there is
a Hose pipe ban or drought order in this
area.
This new pump works with all of Hozelock’s
spraygun’s, Vortex sprinklers and Micro
Irrigation systems – even their brand new
AquaPod system, find out more at
www.hozelock.com or call 0121 313 1122.
(Monday - Friday, 9am - 5pm).
Best Wishes,
………………………...........................…(Name)
……………………….............…………(Address)
Dear (neighbour)
…………………………............................(name)
I am watering my garden using a water
butt, combined with the new Hozelock
Garden Pump. This means that I can
legitimately & legally water my garden
using a hosepipe & sprinkler even if there is
a Hose pipe ban or drought order in this
area.
This new pump works with all of Hozelock’s
spraygun’s, Vortex sprinklers and Micro
Irrigation systems – even their brand new
AquaPod system, find out more at
www.hozelock.com or call 0121 313 1122.
(Monday - Friday, 9am - 5pm).
Best Wishes,
………………………...........................…(Name)
……………………….............…………(Address)
✂
33801-001 GardenPump Inst 6/11/07 12:52 Page 11

...helping to keep your garden well watered ...helping to keep your garden well watered
...helping to keep your garden well watered ...helping to keep your garden well watered
✂
✂
33801-001 GardenPump Inst 6/11/07 12:52 Page 12
