Hozelock Titan 3000 User manual

Titan
2000, 3000
INSTALLATION AND OPERATING INSTRUCTIONS.
READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING INSTALLATION.
1451
1452
FIG.1
FIG.2
B
H
G
F
E
A
D
C

The pump is electrically operated
and is designed to pump solid
particles up to 4mm in diameter
with minimal pre-strainer
maintenance. These types of
pumps are particularly suitable for
pumping water to external filters
or for use in high flow waterfalls
or water course applications
where low maintenance is
important. The pump does not
use oil or grease for lubrication
and can be used safely in ponds
containing fish or plants. The
motor consists of a sealed stator
and water-cooled rotor. All
electrical components are isolated
from the water.
WARNING: SAFETY AND
ELECTRICAL CONNECTIONS.
1. The pump is supplied with 10m
of 3 core electric cable which is
permanently connected and
sealed to the motor.
The supply cable cannot be
replaced. If the cable is
damaged, the pump should be
discarded.
This product is designed to be
permanently wired to the
mains supply in a dry
weatherproof enclosure
through a Double-Pole
Switched Fused Spur -
(Disconnector) to BS 3676 - with
a minimum contact gap of 3mm
in each pole. Fitted with a 3 or
5 Amp fuse.
The installation must conform to
the National and Local wiring
regulations which could include
the use of plastic or metal
conduit to protect the cable.
2. A 10mA or 30mA Residual
Current Device (RCD) Must be
fitted to the mains supply.
3. WARNING: This appliance must
be earthed and it is essential
that the connections are made
using the following code;
Brown - Live
Blue - Neutral
Green/Yellow - Earth
The BR WN lead should be
connected to the LIVE terminal
which may be marked with an
‘L’ or coloured brown or red.
The BLUE lead should be
connected to the NEUTRAL
terminal which may be marked
with an ‘N’ or coloured blue or
black.
The GREEN/YELL W lead
should be connected to the
EARTH terminal which may be
marked with an ‘E’ ( ) or
coloured green or green/yellow.
4. If an extension cable is
required, this should be
connected to the end of the
pump cable using a
weatherproof cable connector.
The joint must be positioned in
a suitable dry housing. The
extension cable should be of 3
core 0.75mm2Polychloroprene
rubber insulated cable (ref: H 5
RN-F) and permanently wired to
the mains supply with a 3 or 5
Amp fuse.
5. The pump cable (and extension
cable) should be positioned and
adequately protected against
damage especially where
contact with gardening
equipment, (lawn mowers,
forks etc..) children and
domestic animals may occur.
6. Consult a qualified electrician
or local authority if in any
doubt about wiring to the
mains supply.
IMPORTANT
1. WARNING: Always unplug or
disconnect all appliances in the
pond from the electricity supply
before putting your hands in
the water whilst equipment is
being installed, repaired,
maintained or handled.
2. Do not use the supply cable to
lift the pump, as this may cause
damage. We recommend fitting
a lifting cord to the handle on
the top of the strainer cage
when the pump is installed in
deep water.
3. Do not operate or leave the
pump in freezing conditions.
4. Do not allow the pump to run
dry.
5. Do not operate this pump
without the strainer cage
attached. Using the pump
without a filter may invalidate
your warranty.
P MP ASSEMBLY.
1. Un-pack the ball joint assembly
(A in Fig 1) from the accessory
pack.
2. Rotate the three lid latching
knobs to the open position and
lift the Strainer Cage Top from
the Strainer Base (B in Fig 1).
3. Firmly pull the pump out of its
location (C in Fig 1).
4. Checking that the ball joint’s
inlet and outlet bosses are in
line, offer the female threaded
nut to the male threaded pump
chamber outlet (D in Fig 1) and
firmly screw them together.
5. Place the pump back into the
location, reposition the lid and
rotate the lid latching knobs
back to the locked position.
P MP INSTALLATION.
ATTENTION: This product is not
suitable for water
temperatures above 35ºC
Position
1. For the best results, the pump
should be positioned in the
deepest part of the pond. This
will ensure the best circulation
of water in the pond and when
being used as a Filtration pump,
its solids handling capability
will be maximised.
Waterfall or Pond Filter Only.
ATTENTION
A TOMATIC C T-O T. To help
ensure your pump’s long life
and to prevent damage, it is
fitted with automatic thermal
overload protection. This
switches off the pump if it
overheats. If this occurs, switch
off the power at the mains
supply to the pump. Check for
the cause. Usually it will be
debris blocking the inlets of
the pump or obstructing the
impeller. Remove the
obstruction and wait 15
minutes for the pump to cool
down and automatically reset.
Then switch on the pump
again.
NOTE: YO M ST SWITCH OFF
THE MAINS S PPLY BEFORE THE
P MP WILL RESET.
From 1st January 2005 installing
this product in the garden is
classed as 'notifiable' in the
revised Building Regulations for
England and Wales. The
Regulations now require you to
tell your local authority building
control department that you
intend to install this product
before installation. Your local
authority will let you know how
you can get your installation
approved.

1. Using small bore hoses leads to
excessive restriction of the
water flow. The larger the
diameter of hose that you use
the better the performance of
the pump will be, especially
over long hose runs. The Hose
tail supplied with this unit will
accommodate 19mm (3/4"),
25mm (1"), 32mm (1.25") and
40mm (1.6") hose. We would
always recommend that on
pumps of this size, that the
40mm diameter hose should be
used. nce you have selected
the hose diameter you wish to
use, cut the steps off the Hose
tail which are smaller than the
hose diameter to eliminate
restriction (Fig 2). Attach a
suitable length hose to the
Threaded Hose tail and secure
with a suitable hose clip and
position the outlet end of the
hose in the desired position.
2. Screw the Threaded Hose tail
directly onto the outlet boss of
the ball joint (E in Fig 1). The
ball joint can be rotated to
allow the hose to be directed
away from the pump. Position
the pump as previously
described.
Wildlife Protection System.
If you have fish or other wildlife in
your pond, there are periods in
the year during which they may
breed. At this time the fish ‘fry’
are small and can be sucked into
the pump. To minimise this
possibility, the Titan range of
pumps has a unique Wildlife
Protection System which allows
you to reduce the inlet strainer
hole size down to 2mm at this
critical time in a fishes life cycle,
by moving the lever on the side of
the Strainer Cage (F in Fig1).
During the period when the
aperture size is reduced, you may
need to unblock the Strainer Cage
more frequently. nce the fish or
other wildlife have grown to a
sufficient size you can then return
the aperture size to its maximum
10mm size.
MAINTENANCE.
The Hozelock Cyprio range of
Titan pumps have been designed
to allow fast and easy
maintenance. As with all pumps of
its kind, occasionally it will
become necessary to clean the
Strainer Cage.
Always unplug or disconnect ALL
appliances in the pond from the
electricity supply before putting
your hands in the water or
starting maintenance.
Strainer.
1. Unscrew the Threaded Hose tail
from the pump outlet (E in Fig
1).
2. Rotate the three lid latching
knobs to the open position and
lift the Strainer Cage Top from
the Strainer Base (B in Fig 1).
3. Firmly pull the pump out of its
location using the handle and
wash/rinse the Strainer Cage
with clean water.
4. Reassemble the pump.
Rotor Assembly. (See Fig. 1)
1. Remove the Strainer Cage as
described above.
2. Release the Pump Chamber (G)
by rotating it until the two
retaining tongues are clear of
the lugs on the Motor Body.
3. Gently pull the Pump Chamber
squarely away from the Motor
Body (C).
4. Pull the Rotor Assembly (H) out
of the Motor Body.
5. Wash out all of the
components in clean water. Do
not use detergents or other
chemical cleaners.
6. Replace the Rotor Assembly into
the Motor Body and refit the
Pump Chamber and Strainer
Cage.
ALL YEAR P MP CARE.
A quick daily check should be
carried out to ensure that the
pump is performing satisfactorily.
nce a month- Remove and clean
the Strainer Cage in accordance
with the general maintenance
notes. Depending on pond water
conditions, cleaning may be
required more frequently.
nce a year- Completely
disassemble the pump including
the Rotor Assembly as described in
the general maintenance
instructions and wash all
components in clean, fresh water.
Replace worn or broken parts.
SPARE PARTS.
Contact the Consumer Services
Helpline on 0121 313 1122
HOZELOCK CYPRIO 3 YEAR
G ARANTEE.
If this pump, excluding the Rotor
Assembly, becomes unserviceable
within 3 years of the date of
purchase it will be repaired or
replaced at our option free of
charge, unless in our opinion it
has been damaged or misused.
Liability is not accepted for
damage due to accident, improper
installation or use. Liability is
limited to replacement of a faulty
pump. This guarantee is not
transferable. It does not affect
your statutory rights.
To obtain the benefits of the
guarantee, firstly contact
Hozelock Cyprio Consumer
Services who may request that the
pump is sent along with proof of
purchase directly to the address
below.
Hozelock Cyprio Ltd.
Midpoint Park, Birmingham
B76 1AB. England
Telephone: [phone]
www.hozelock.com
FAULT FINDING.
Important - Please keep this section for reference.
L W FL W FR M PUMP 1. Ensure the Strainer Cage is clean.
2. A small diameter outlet pipe will restrict outlet flow.
N FL W FR M PUMP 1. Check the power supply is on.
2. Check the fuse and wiring.
3. Check the Rotor Assembly is not jammed , damaged or
showing signs of excessive wear.
4. Ensure the Strainer Cage is clean.
5. The Thermal Protection has tripped. (see first paragraph).
Part No.
2000 3000
Spares
1. Pump Chamber Z13415 Z13915
Assembly and Seal.
2. Rotor Assembly. 1460 1461
3. Strainer Cage Z13426 Z13426
Assembly.
4. Threaded utlet 1470 1470
Adapter.
5. Ball joint Z13515 Z13515

Hozelock Cyprio
Midpoint Park
Birmingham
B76 1AB
England
Tel: [phone]
www.hozelock.com
The Aquatics Division of Hozelock Group
33619-004
PLEASE
NOTE:
Do not
dispose of in
household
waste
PERF RMANCE
2000 3000
V LTS (V) 230 230
WATTS (W) 37 45
MAX FL W (QMax) LPH 2000 3000
MAX HEAD (HMax) M 1.6 2.3
