Hozelock 7825 User manual

7825
?
flood PUMP
Hozelock Ltd.
idpoint Park,
Birmingham B76 1AB. England
Tel: [phone]
[e-mail]
www.hozelock.com
33713-001

4
1
400mm
AUT N AUT FF
190mm
2 3
✗✓25mm
32mm

5
98
6
x3
x6
7
95mm
F R AUT PERATI N
50cm 50cm

Warning : Read this manual carefully
before installing this pump.
This sign warns the user that
failure to follow an instruction may
damage the pump or the system
This sign warns the user of
important electrical safety
information.
Carefully store this manual.
If problems arise contact
Hozelock customer services.
Every Hozelock Flood Pump
is carefully tested and packed
during assembly.
n receipt, check that the pump has not
been damaged during transport. If the
pump is damaged, do not use, and
contact Hozelock customer services.
Check that the voltage and frequency
of pump shown on the rating label
corresponds to those available on the
mains.
ELECTRICAL INSTALLATION:
A 10MA R 30MA RESIDUAL
CURRENT DEVICE (RCD)
MUST BE FITTED T THE
MAINS SUPPLY.
PR TECT THE PLUG AND THE
P WER CABLE FR M HEAT,
IL AND SHARP EDGES.
D N T PERATE THE PUMP IF
IT HAS A DAMAGED P WER
C RD R PLUG. IF THE P WER
C RD R PLUG IS DAMAGED, IT
MUST BE REPLACED BY A
SUITABLY QUALIFIED PERS N IN
RDER T AV ID A HAZARD.
MAKE SURE THAT
ELECTRIC C NNECTI NS ARE
PR TECTED FR M WATER
& SPLASHES
THE P WER CABLE SH ULD
HAVE A MINIMUM F 3 C RE
0.75MM2SECTI N EQUIVALENT
T THAT F H05 RN-F. T
MAKE SURE THE PLUG IS
PR TECTED FR M ANY
SPLASHES, USE THE 10M CABLE
SUPPLIED T C NNECT AS FAR
AWAY FR M THE PUMP AS
P SSIBLE
BEF RE USING THE PUMP,
ALWAYS INSPECT IT VISUALLY
(ESPECIALLY THE P WER CABLE
AND THE PLUG). D N T USE
THE PUMP IF IT IS DAMAGED.
NEVER USE THE P WER CABLE
T LIFT THE PUMP.
(UK and Ireland)
This product is fitted with a BS 1363
plug with a 5 amp ASTA approved fuse.
If you have to replace the fuse, only
those that are ASTA or BSI approved to
BS 1362 and with a rated current of 5
amps should be used. If there is a fuse
cover fitted, this cover must be refitted
after changing the fuse. If the fuse
cover is lost or damaged, the plug must
not be used. Spare fuse holders and
fuses are available from electrical
outlets.
If the power supply cord or plug
becomes damaged in any way, it
should be replaced by a suitably
qualified person. A replacement plug
should be wired according to the
following instructions.
IMP RTANT: This appliance must be
earthed. As the colours of the wires in
the mains lead of this product may not
correspond with the colours or
Electrical Safety
General Safety
Plug Wiring

markings identifying the terminals in
your plug, you should proceed as
follows:
The wire that is
coloured green & yellow must be
connected to the EARTH terminal in
the plug which may be marked with
the letter E or coloured green or green
& yellow or marked with the earth
symbol ( ).
The wire that is coloured blue must be
connected to the NEUTRAL terminal
which may be marked with the letter N
or coloured blue or black.
The wire that is coloured brown must
be connected to the LIVE terminal
which may be marked with the letter L
or coloured brown or red.
If in doubt, contact a qualified
electrician.
The pump can be completely or partially
submersed and used to transfer clean or
dirty fluids.
This pump should not be used with
swimming pools where people can
become immersed in water.
This pump shouldnot be used for
table fountains / aquariums /
fountains / filters for fish ponds /
waterfalls
If aquatic wildlife eg fish or frogs
could be present in the water, you
must take the required measure to
prevent them being sucked into the
pump.
The pump cannot be used for sea
water & inflammable, corrosive,
explosive or dangerous liquids.
The pump must never run dry.
The pump can handle max solids of
30mm. However this will be
reduced by the diameter of the
hose. eg 25mm hose may block if
solids greater than 25mm are
present.
When set up for automatic
operation the pump will turn on at a
water depth of 400mm, and turn off
at a water depth of 190mm (Fig 1).
The pump must not be used when
people are in the water.
The sprayer must not be used
when people are in the water.
Do not spray the outlet towards
people or animals.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of
the appliance by a person
responsible for their safety.
Before installation, and whenever
you are handling the pump,
always disconnect from the
electrical supply.
To prevent injury, never put your fingers
into the mouth of the pump.
• Use the handle provided to carry or
lift the pump (see Fig 2).
• To maximise pump performance
always use either 25mm or 32mm
hose with this pump.
• Cut the hose tail to match the
Installation
Brown - Live
Blue - Neutral
Green/Yellow - Earth
Limitations

diameter of the hose selected.
25mm (no cut required),
32mm (cut as indicated Fig 3).
• Screw the threaded fitting supplied
onto the pump (Fig. 4).
•To connect the pump to a hose, push
over the inlet and secure with a rust
proof hose clip (not supplied). Ensure
that the hose is not kinked and free to
drain to waste. Pump performance
depends upon hose length, hose
diameter and discharge height.
NEVER use 1⁄2" (12.5mm garden hose).
• The flood pump is fitted with an
automatic float switch. This turns the
pump on/off automatically as the
water level rises. For correct operation
it needs a minimum of 50cm in all
directions to prevent the float switch
jamming on the container (Fig 5).
• The Hozelock Flood Pump has
a built in thermal protection switch.
The pump stops if an overload
condition occurs. The motor restarts
automatically after it has cooled
down.
• Insert the plug into a 220-240v A/C
socket (Fig 6).
• To use the pump manually the float
switch should be supported. In manual
mode the pump will pump down to a
minimum depth of 70mm.
• To ensure correct automatic
operation, the float switch should be
clipped into the pump housing as
indicated (Fig 7).
In ordinary conditions the Flood Pump
does not require any maintenance,
however occasionally it will be necessary
to clean the inlet (see Figs 8 & 9).
Make sure that the pump is
disconnected from the electric
power supply before performing
any maintenance (Fig 6).
• Stage 1 Cleaning :
Remove the 3 screws on the base
plate and remove any visible debris
(Fig 8).
• Stage 2 Cleaning :
Remove a further 6 screws and
remove debris within the pump
chamber (Fig 9).
• Then re-assemble.
• Store the pump in a dry place and
protect from frost.
Overload protection
To start the pump
aintenance
Pump storage

Troubleshooting
Problem Possible Cause Remedy
The pump does
not pump water
and the motor is
not running
No electricity Check that the electricity supply is
turned on and that the pump is
correctly plugged in
Plug inserted incorrectly
Circuit breaker is
tripped
Reset electricity supply.
If the circuit breaker trips once
more contact a specialised
electrician
Blocked impeller Unplug from the electricity supply
and remove possible obstructions
from the impeller (Figs 8 & 9)
Damaged motor Contact hozelock customer
services for assistance
Pump has overheated Pump contains thermal
protection - check if pump case is
hot, and if so, allow to cool
Float switch is
preventing pump
turning on
The pump will only work when
the float switch is in the upright
position, ensure that is is able to
reach the vertical position
The pump
supplies a
limited amount
of water or the
pump does not
pump water,
and the motor is
running
Pump full of air Unplug from the electricity supply
and disconnect outlet hose,
submerge in water and allow air
to escape, re-connect hose and
power
Obstructed inlet Follow cleaning instructions
detailed in maintenance section
(Figs 8 &9)
Obstructed pipe/outlet Remove obstructions in inlet hose
or kinks and clean out filter
Worn impeller Contact Hozelock customer
services for assistance

Troubleshooting - contd.
Problem Possible Cause Remedy
The pump works
only
intermittently
Solid particles prevent
the free rotation of the
impeller
Clean inlet and impeller
(Figs 8 & 9)
The temperature of the
fluid is too high
Only use with fluids below
35ºC
Faulty motor Contact Hozelock customer
services for assistance
Water is leaking
from the outlet
of the pump
Inlet assembly not tight
enough
Tighten
Hozelock Ltd.
idpoint Park,
Birmingham B76 1AB. England
Tel: [phone]
[e-mail]
www.hozelock.com
33713-001
Max Pumping Height, Hmax: 5m
Maximum Suction Height : 8m
Maximum Flow Rate, Qmax : 8000 lph
Pump Specification
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information
regarding the collection systems available.
If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging
your health and well-being.
When replacing old appliances with new ones, the
retailer is legally obligated to take back your old
appliance for disposals at least free of charge.
