HP J3420B HP-HSC ATM/155 User manual

HP J3420B HP-HSC ATM/155 Adapter for
Industrial Workstations Installation
Guide
HP 9000 Networking
Manufacturing Part Number: J3420-90001
E0499
U.S.A.
© Copyright 1999, Hewlett-Packard Company.

2
Legal Notices
The information in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
manual, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard
shall not be held liable for errors contained herein or direct, indirect,
special, incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
Warranty. A copy of the specific warranty terms applicable to your
Hewlett-Packard product and replacement parts can be obtained from
your local Sales and Service Office.
Restricted Rights Legend. Use, duplication or disclosure by the U.S.
Government is subject to restrictions as set forth in subparagraph (c) (1)
(ii) of the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013 for DOD agencies, and subparagraphs (c) (1) and
(c) (2) of the Commercial Computer Software Restricted Rights clause at
FAR 52.227-19 for other agencies.
HEWLETT-PACKARD COMPANY
3000 Hanover Street
Palo Alto, California 94304
U.S.A.
Use of this manual and flexible disk(s) or tape cartridge(s) supplied for
this pack is restricted to this product only. Additional copies of the
programs may be made for security and back-up purposes only. Resale of
the programs in their present form or with alterations, is expressly
prohibited.
Copyright Notices. ©copyright 1983-99 Hewlett-Packard Company, all
rights reserved.
Reproduction, adaptation, or translation of this document without prior
written permission is prohibited, except as allowed under the copyright
laws.
©copyright 1979, 1980, 1983, 1985-93 Regents of the University of
California
This software is based in part on the Fourth Berkeley Software
Distribution under license from the Regents of the University of

3
California.
©copyright 1980, 1984, 1986 Novell, Inc.
©copyright 1986-1992 Sun Microsystems, Inc.
©copyright 1985-86, 1988 Massachusetts Institute of Technology.
©copyright 1989-93 The Open Software Foundation, Inc.
©copyright 1986 Digital Equipment Corporation.
©copyright 1990 Motorola, Inc.
©copyright 1990, 1991, 1992 Cornell University
©copyright 1989-1991 The University of Maryland
©copyright 1988 Carnegie Mellon University
Trademark Notices UNIX is a registered trademark of The Open
Group.
X Window System is a trademark of the Massachusetts Institute of
Technology.
MS-DOS and Microsoft are U.S. registered trademarks of Microsoft
Corporation.
OSF/Motif is a trademark of the Open Software Foundation, Inc. in the
U.S. and other countries.

4

Contents
5
1. Before Installing the HP-HSC ATM/155 Adapter
Computer Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Tools and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Switch Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2. Installing the HP-HSC ATM/155 Adapter
Installation Steps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Verifying Hardware Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

6
Contents

7
Safety and Regulatory Information
Safety Information
All inputs/outputs of the J3420B HP-HSC ATM/155 adapter are Safety
Extra Low Voltage (SELV) circuits.
CAUTION The hardware contains electronic components that can be damaged by
static electricity. To avoid damage, follow these guidelines:
• Store the hardware in its conductive plastic bag.
• If possible, work in a static-free area.
• Handle circuit boards by the edges only.
Do not touch electronic components or electrical traces. We strongly
recommend that you use a grounding wrist strap that is connected to
the metallic chassis of the host computer. If you do not have a wrist
strap, touch the chassis before handling adapters and frequently
thereafter to equalize any static charge.
Laser Information
Class 1 Laser product. Hazardous radiation inside the fiber optic module.
Do not open. Refer to qualified personnel only.
Wavelength: 1330 nm.

8
Power Consumption
The J3420B adapter is powered from the HP-HSC connector and has the
following maximum power consumption requirements:
Regulatory Information
For the United States
Federal Communications Commission (FCC) Radio Frequency
Interference Statement.
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that might cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
Hewlett-Packard’s system verification tests were conducted with
HP-supported peripheral devices and cables. Use of this adapter in
non-HP systems may void the user’s authority to operate the equipment.
J3420B
Voltage Wattage
+5 V 15 W
+12 V 0 W
-12 V 0W

9
For Canada
Canadian regulations ICES-003
Warning: Complies with Canadian Electromagnetic compatibility (EMC)
Class A requirements.
Pour le Canada
Comforme à la class A des normes Canadiennes de compatibilité
électromagnetique (CEM).
Pour la France
Déclarations d’installation et de mise en exploitation d’un matériel de
traitement de l’information (ATI), classe A
En fonction des niveaux de perturbations radioélectriques émis, définis
dans la norme européenne EN 55022 concernant la Compatibilité
électromagnétique.
Cher client, Conformément à la Réglementation Française en vigueur,
l’installation, ou le transfert d’installation, et l’exploitation de cet
appareil de classe A, doivent faire l’objet d’une déclaration (en deux
exemplaires) simultanément auprès des services suivants:
• Comité de Coordination des Télécommunications 20 Avenue de Ségur
- 75700 PARIS
• La Préfecture du département du lieu d’exploitation
Le formulaire à utiliser est disponible auprès des Préfectures. La
déclaration doit être faite dans les 30 jours suivant la mise en
exploitation. Le non-respect de cette obligation peut être sanctionné par
les peines prévues au code des Postes et Télécommunications et celles
indiquées dans la loi du 31 mai 1993.
Arrêté du 27 Mars 1993, publié au J.O du 28 Mars - ATI.

10

11
1 Before Installing the HP-HSC
ATM/155 Adapter
This chapter contains the following sections that discuss what you must
do before you install the J3420B HP-HSC ATM/155 adapter in the Model

12 Chapter1
Before Installing the HP-HSC ATM/155 Adapter
74x Single Board Computer:
• “Computer Requirements” on page 13.
• “Package Contents” on page 14.
• “Tools and Accessories” on page 15.
• “Switch Specifications” on page 16.
• “Cables” on page 17.

Chapter 1 13
Before Installing the HP-HSC ATM/155 Adapter
Computer Requirements
Computer Requirements
Ensure that the following computer requirements are met:
• You must fit a 2-slot expansion plate to the Model 74x Single Board
Computer before installing the HP-HSC ATM/155 adapter. This is
because the Model 74x requires three adjacent slots in the System
Enclosure when the ATM adapter is installed. Chapter 2 , “Installing
the HP-HSC ATM/155 Adapter,” on page 19 includes the steps for
fitting the plate.
• Up to two HP-HSC ATM/155 adapters can be installed in the 74x
Single Board Computer.
• The operating system must be HP-UX 10.20 or 11.0.
• Approximately 2.5 Mbytes of free space are required in the /(root)
file system.

14 Chapter1
Before Installing the HP-HSC ATM/155 Adapter
Package Contents
Package Contents
CAUTION Keep the HP-HSC ATM/155 adapter in its protective antistatic bag until
installation. Electronic components can be damaged by even small
amounts of static discharge. So, we strongly recommend that you use
antistatic procedures when handling this or any other computer
component. Handle the adapter by the edges and avoid touching all
components and metal parts.
When you unpack the adapter hardware and software, keep all original
packing materials for storing, transporting, or returning the product if
necessary.
Ensure that the HP-HSC ATM/155 adapter hardware package contains
the following items:
• One HP-HSC ATM/155 adapter (J3420B).
• Two plastic screws and washers.
• One Model 743iboot ROM (revision K or later).
• One IC removal tool.
• One grounding wrist strap.
• One 2-slot expansion plate.
Ensure that the ATM software package contains the following items:
• One CD-ROM containing the ATM link software product (J2806CA).
Note that the J2806CA ATM software is not locked. So, you do not
need a codeword to unlock and install the software.
• The HP ATM Release Note you received with the software.
• One ATM Configuration and Troubleshooting Guide (hardcopy or on
the Instant Information CD).
If any of the items are missing or damaged, contact your HP
representative.

Chapter 1 15
Before Installing the HP-HSC ATM/155 Adapter
Tools and Accessories
Tools and Accessories
You need the following tools to install the HP-HSC ATM/155 adapter:
• The IC removal tool supplied with the product (Model 743ionly).
• The grounding wrist strap supplied with the product.
• A flat-bladed screwdriver.
• A No. 1 Pozidriv screwdriver.
• A Phillips head screwdriver.
• Your 74x Owner’s Guide.

16 Chapter1
Before Installing the HP-HSC ATM/155 Adapter
Switch Specifications
Switch Specifications
Check the following on the ATM switch:
• The switch has SC or ST connectors for use with Multi-Mode Fiber
(MMF) connections.
• The switch must be UNI 3.0, 3.1, or 4.0 compliant.

Chapter 1 17
Before Installing the HP-HSC ATM/155 Adapter
Cables
Cables
The HP-HSC ATM/155 adapter uses MMF connections with SC
connectors. For connecting to switches with ST connectors, SC-to-ST
duplex adapters are necessary. Ensure that you have the following
cables:
• SC-to-SC cable.
• SC-to-ST cable (duplex adapter).
• SC loopback connector (for troubleshooting).

18 Chapter1
Before Installing the HP-HSC ATM/155 Adapter
Cables

19
2 Installing the HP-HSC ATM/155
Adapter
This chapter describes the steps you must follow to install the J3420B
HP-HSC ATM/155 adapter in the Model 74x Single Board Computer

20 Chapter2
Installing the HP-HSC ATM/155 Adapter
system.
WARNING Electric shock hazard. Shut down and turn off the system, and
disconnect the power cable and all telecommunications network
cables before opening the system or accessing the slots.
CAUTION You must turn off the power to the system before you install the adapter.
Otherwise, the equipment—the system and/or the adapter—might be
damaged.
