HP StorageWorks Modular Smart Array 500 System Installation guide

1. Display 5. Power Switch
2. Display Buttons 6. Status Indicators
3. Display Indicators 7. Redundant Controller Slot Blank
4. Modular Smart Array Controller 8. Drive Bay(s)
1. Power Supply/Blower Indicators 4. SCSI Port B
2. Power Supply/Blower Assemblies 5. SCSI I/O Indicators
3. SCSI Port A 6. SCSI I/O with Integrated Environmental Monitoring Unit (EMU)
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Overview
DA - 11050 Canada — Version 13 — July 19, 2004 Page 1

What's New
What's NewWhat's New
What's New
New name, formerly named Smart Array Cluster Storage
MSA500 Starter Kit with 2 host adapters included
MSA500 High Availability Kit includes everything needed to make MSA500 system fully redundant at a new low price
Microsoft® Windows® Server 2003 Support
UnitedLinux 1.0 Support
Novell NetWare 6.5 Support
Storage sharing with up to 4 direct attached servers
At A Glance
At A GlanceAt A Glance
At A Glance
Two node high availability clustering
Shared storage for up to 4 ProLiant servers
Redundant capable Smart Array Controllers with LCD screen to show system status messaging.
Total storage capacity of 2TB, by using 14 HP Universal U320 Hard Disks of 146.8 GB each
Multipath connectivity option with load balancing
Redundant Power Supplies and Fans standard
Fully convertible to HP StorageWorks Modular Smart Array 1000
RAID 0, 1, 1+0, 5 and ADG standard
Supports up to 512 MB of Battery Backed Cache (2x256 MB).
Pre-Failure Warranty that covers disk drives
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Overview
DA - 11050 Canada — Version 13 — July 19, 2004 Page 2

Modular Smart Array Family
Modular Smart Array FamilyModular Smart Array Family
Modular Smart Array Family
The HP StorageWorks Modular Smart Array family delivers easy, affordable storage technology to meet today's demanding and growing IT needs. These
storage solutions offer the best price/performance features for direct attach environments, small clusters, workgroup sharing and entry-level SAN
environments. Each solution is designed to be easy to deploy, secure, reduce management costs, while driving rapid return on investment.
Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
The HP StorageWorks Modular Smart Array 500 (MSA 500), formerly named Modular Smart Array 500, is an Ultra3 SCSI (supporting Ultra320 hard drives)
storage system, supporting up to 2TB of data capacity, designed specifically for 2-node clustering and multiple node (up to 4 servers) shared storage.
Designed to reduce the complexity and expense of clustering and storage sharing, the Modular Smart Array 500 is built upon Smart Array and ProLiant
technologies to provide advanced data protection features yet is simple to deploy, configure and manage. Ideal for entry level clustering and shared storage,
the Modular Smart Array 500 is familiar SCSI technology, making it a simple and powerful storage platform. As the customer's clustering and storage
requirements grow, the Modular Smart Array 500 may be converted to a SAN array by replacing the controller(s) and I/O module and installing a MSA 1000
FC I/O module, or MSA 1000 FC switch, providing the customer with extended hardware investment protection into the future.
The Modular Smart Array 500 combines the array controller shelf and the drive shelf, which holds up to fourteen 1 HP Universal Disk drives in a single 4U
rack mount cabinet, that's over 2 terabytes of storage.
Key Features
Key FeaturesKey Features
Key Features
High performance Modular Smart Array controller(s) with LCD for system status messages.
Standard 128-MB Battery Backed Cache, upgradeable to 512 MB maximum.
Optional redundant Modular Smart Array controller.
4U rack mount chassis combining both the controller and disk shelf.
Ultra3 SCSI back panel and drive interconnect.
SSP (Selective Storage Presentation) for storage sharing with multiple servers.
2TB capacities with support of 14 Ultra320, Ultra3 and Ultra2 Universal 1 Drives.
Redundant power supplies and fans are standard.
RAID levels 0, 1, 1 0, 5, RAID ADG.
Optional 4-Port Shared Storage Module with Smart Array Multipath software with load balancing.
Optional ProLiant Essentials Recovery Server Option
Convertible to MSA 1000 for capacity expansion and increased host connections
Remote configuration and monitoring via ACU & Insight Manager 7.
Qualified and certified for Windows, Linux and NetWare 2-node clustering
Support for select ProLiant servers (see Server Compatibility on page 14 or http://www.hp.com/go/msa for latest compatibility).
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Standard Features
DA - 11050 Canada — Version 13 — July 19, 2004 Page 3

Modular Smart Array 500 Highlights
Modular Smart Array 500 HighlightsModular Smart Array 500 Highlights
Modular Smart Array 500 Highlights
High Levels of
High Levels ofHigh Levels of
High Levels of
Performance, Data
Performance, DataPerformance, Data
Performance, Data
Protection and
Protection andProtection and
Protection and
Functionality
FunctionalityFunctionality
Functionality
High Availability
High AvailabilityHigh Availability
High Availability – supports a broad range of clustering options for Microsoft Windows Server, Linux Server and
Novell NetWare environments.
High Performance
High PerformanceHigh Performance
High Performance – Data transmission rate of 14,000 IOPS – 2 Node cluster configuration using Smart Array 5i
Plus embedded controller in the ProLiant servers.
Storage Capacity
Storage CapacityStorage Capacity
Storage Capacity – The Modular Smart Array 500 cabinet supports up to fourteen 1" Universal hard drives, for a
maximum of 2TB of shared storage capacity using HP 146.8 Ultra320 SCSI Universal 1" hard drives.
Data Protection
Data ProtectionData Protection
Data Protection – Modular Smart Array 500 is designed for a high level of data protection. It includes redundant
controllers (optional), redundant fans and power supplies (standard); multiple I/O path capability with Smart Array
Multipath software option, support for Hot Pluggable AIT and DAT tape drives in the storage enclosure,
transportable battery-backed cache and RAID ADG (standard).
Storage Manageability
Storage ManageabilityStorage Manageability
Storage Manageability – The Smart Array Controllers feature familiar configuration and management tools
such as Smart Array Configuration Utility and Insight Manager. Online Management Features: Online Capacity
Expansion (single path only), Online RAID Level Migration, Online Stripe Size Migration, Online Spares (Global),
User Selectable Read/Write cache, User Selectable Expand and Rebuild Priority.
Choice of Computing Platform
Choice of Computing PlatformChoice of Computing Platform
Choice of Computing Platform – The Modular Smart Array 500 is designed and qualified for ProLiant servers.
Advanced Data Guarding (RAID ADG) Fault Tolerance
Advanced Data Guarding (RAID ADG) Fault ToleranceAdvanced Data Guarding (RAID ADG) Fault Tolerance
Advanced Data Guarding (RAID ADG) Fault Tolerance – This is the highest level of RAID fault
tolerance. It allocates two sets of parity data across drives and allows simultaneous write operations. This level of
fault tolerance can withstand two simultaneous drive failures without downtime or data loss.
DtS (DAS to SAN)
DtS (DAS to SAN)DtS (DAS to SAN)
DtS (DAS to SAN)
Technology
TechnologyTechnology
Technology
The Smart Array architecture provides a quick and easy way to migrate from the Modular Smart Array 500 to the Modular
Storage Array 1000 (MSA 1000).
In order to convert the Modular Smart Array 500 to a SAN, simply remove the Modular Smart Array Controller(s) and replace
them with StorageWorks MSA 1000 Controller(s) and add FC I/O board or FC Switch (please refer to MSA 1000
Quickspecs for additional SAN requirements information). This is referred to as DtS technology (DAS-to-SAN technology).
In addition to convertibility to the SAN, the Modular Smart Array 500 allows the seamless migration of stored data in
ProLiant servers protected by Smart Array PCI controllers to a Modular Smart Array 500 system. Data that is currently stored
on 1" Universal disk drives using HP Smart Array controllers, as well as data on an RA4100 can easily be migrated to the
Modular Smart Array 500. Simply remove the drives from the older systems and insert them into the Modular Smart Array
500. Existing data and configuration will remain intact. In addition, the RAID set and data will be preserved allowing
migration to be completed in minutes, not hours.
Low Total Cost of
Low Total Cost ofLow Total Cost of
Low Total Cost of
Ownership
OwnershipOwnership
Ownership
The modular, scalable design of the Modular Smart Array 500 provides an extremely flexible platform. You can buy what
you need today and purchase additional capacity and performance as your data storage needs grow, instead of making a
large up-front investment. Additional drives, controllers, and cache can be easily added as your needs dictate.
Storage Consolidation
Storage ConsolidationStorage Consolidation
Storage Consolidation – Improve storage utilization and lower storage management cost through moving
internal storage to the Modular Smart Array 500.
Universal Hard Drive
Universal Hard DriveUniversal Hard Drive
Universal Hard Drive – Since the Modular Smart Array 500 supports Universal 1" SCSI drives, your investment in
disk drives is protected and cost is minimized as you add new drives. Sharing of a common universal drive form
factor between your server and storage can significantly reduce needs for hardware and spare inventory, and offer
overall reduction in storage management and business costs.
Pre-Failure Warranty
Pre-Failure WarrantyPre-Failure Warranty
Pre-Failure Warranty – Drives installed in a Modular Smart Array 500 and monitored under Insight Manager
are supported by a Pre-Failure (replacement) Warranty. Pre-Failure Warranty allows for the replacement of
designated drives in Modular Smart Array 500 before they actually fail when using Insight Manager on ProLiant
servers. NOTE:
NOTE:NOTE:
NOTE: Some operating systems may not support all of these features.
Integrated Configuration and Management Tools
Integrated Configuration and Management ToolsIntegrated Configuration and Management Tools
Integrated Configuration and Management Tools – The Modular Smart Array 500 utilizes the standard,
integrated set of Smart Array management and utility software. These tools consistently lower the cost of ownership
by reducing training and technical expertise necessary to install and maintain HP server storage.
Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500 The 4U array houses up to fourteen 1" Universal hot pluggable Ultra320, Ultra3 and/or Ultra2 drives. Each Modular Smart
Array 500 includes the following standard components: Modular Smart Array 500 Controller, 2-port Ultra3 SCSI I/O
Module, dual hot pluggable fans/power supplies, two power cables, two VHDCI SCSI cables and a crossover Ethernet
cable.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Product Highlights
DA - 11050 Canada — Version 13 — July 19, 2004 Page 4

Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
Controller
ControllerController
Controller
The Modular Smart Array 500 Controller is an integrated RAID controller with an integrated LCD/LED status display and
128-MB read/write battery-backed cache (expandable to 512MB per controller). One Modular Smart Array 500 Controller is
included with the Modular Smart Array 500; the redundant Modular Smart Array 500 Controller is an option..
4-Port Shared Storage
4-Port Shared Storage4-Port Shared Storage
4-Port Shared Storage
Module with Smart Array
Module with Smart ArrayModule with Smart Array
Module with Smart Array
Multipath
MultipathMultipath
Multipath
The 4-Port Shared Storage Module is an option which may be used in one of two configurations:
Enhance cluster fault tolerance by adding multiple paths from the host servers to the shared storage. This provides
an additional level of fault tolerance by adding redundancy to both the HBA in the host server as well as the SCSI
cables connecting the host servers to the shared storage.
Attach up to four independent servers to the Modular Smart Array 500. The storage capacity to each server is
assigned with SSP (Shared Storage Presentation), a feature of the Array Configuration Utility. Using SSP and sharing
storage among multiple host servers maximizes hard drive capacity utilization, and allows for additional hard drive
capacity to be deployed (up to 14) with the volume extension and capacity expansion capabilities.
Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
Controller Management
Controller ManagementController Management
Controller Management
Features
FeaturesFeatures
Features
Online RAID Level Migration: allows for online post-configuration change to RAID level without destroying data or
volume information.
Online Capacity Expansion: allows for adding storage to an operational Modular Smart Array 500-reducing
expensive server downtime (single path configuration only).
Online Volume Extension: allows for the capacity growth of existing logical volumes (single path configuration
only).
Logical Drive Capacity Extension: allows the user to increase the size of existing logical drives online under
Windows NT® and offline for other operating systems.
Online Stripe Size Migration: Allows changing stripe sizing of a logical drive.
User Selectable Read/Write Cache size, allocate cache sizes.
User Selectable Expand and Rebuild Priority.
Controller Firmware
Controller FirmwareController Firmware
Controller Firmware
Cloning
CloningCloning
Cloning
Enhanced Controller Firmware Auto-Cloning allows customer choice of controller firmware version when adding redundant
controller with different firmware version.
Multi Host Storage
Multi Host StorageMulti Host Storage
Multi Host Storage
Sharing
SharingSharing
Sharing
Selective Storage Presentation (SSP) support standard on both the base 2-port model of Modular Smart Array 500 as well as
the optional 4-port Shared Storage Module. SSP allows the administrator to create volumes and assign access rights to a
particular host server. This allows sharing the Modular Smart Array 500 with up to 4 host servers maximizing storage
capacity utilization. SSP also allows online capacity expansion as well as online volume extension in DAS configurations.
RAID
RAIDRAID
RAID Several fault tolerant configurations keep data available and servers running while drives are being replaced, including:
Advanced Data Guarding (RAID ADG): Allocates the equivalence of 2 parity drives across multiple drives and
allows simultaneous write operations.
Distributed Data Guarding (RAID 5): Allocates parity data across multiple drives and allows simultaneous write
operations.
Drive Mirroring (RAID 1 and 1+0 Striped Mirroring): Allocates half of the drive array to data and the other half to
mirrored data, providing two copies of every file.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Modular Smart Array 500 Components
DA - 11050 Canada — Version 13 — July 19, 2004 Page 5

Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
Controller
ControllerController
Controller
Controller Cache Upgrade
Controller Cache UpgradeController Cache Upgrade
Controller Cache Upgrade Cache on the Modular Smart Array 500 Controller may be upgraded to a
maximum of 512 MB.
NOTE:
NOTE:NOTE:
NOTE: The Modular Smart Array 500 Controller allows the following cache
configurations: 1 x 128 MB; 2 x 128 MB; 1 x 256 MB; 2 x 256 MB
NOTE:
NOTE:NOTE:
NOTE: When redundant controllers are installed, the cache configurations in both
controllers must be identical.
Fault Recovery
Fault RecoveryFault Recovery
Fault Recovery Minimizes downtime, reconstructs data, and facilitates a quick recovery from drive
failure.
On-Line Spares: If a failure occurs, recovery begins with an on-line spare and data
is reconstructed automatically. One on-line spare can be assigned per array and
used across multiple arrays. It is also possible to assign different on-line spares
across different arrays.
Array Accelerator: Onboard, battery-backed cache memory protects data in the
event of a power failure. In the unlikely event of a controller failure, the battery-
backed cache will save critical user data for up to three days.
SCSI I/O Module
SCSI I/O ModuleSCSI I/O Module
SCSI I/O Module The I/O module on the Modular Smart Array includes an integrated Environmental Monitoring Unit which performs several
functions including monitoring the enclosure functions, providing I/O connectors and signaling enclosure status. Modular
Smart Array 500 ships standard with a 2-Port I/O Module.
The 4-Port Shared Storage Module with Smart Array Multipath is available as an option.
The 4-Port Shared Storage Module may be deployed as follows:
As the shared storage component with up to four servers in a DAS (Direct Attached Storage) configuration.
Multiple I/O paths to a two node cluster or two direct attached servers.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Modular Smart Array 500 Components
DA - 11050 Canada — Version 13 — July 19, 2004 Page 6

The Modular Smart Array 500 utilizes a single, consistent set of utility software for storage and RAID management, setup, configuration and troubleshooting.
This consistency reduces the cost of ownership by reducing the training and technical expertise necessary to install and maintain your HP server storage
solution.
Configuration Utilities
Configuration UtilitiesConfiguration Utilities
Configuration Utilities Array Configuration Utility (ACU) [On-line for Microsoft and Linux, Remote Web-Based & Off-line]
Option ROM Configuration for Arrays (ORCA)
Management/Health
Management/HealthManagement/Health
Management/Health
Utilities
UtilitiesUtilities
Utilities
Insight Manager 7
Array Configuration
Array ConfigurationArray Configuration
Array Configuration
Utility
UtilityUtility
Utility (ACU)
Provides a graphical view of HP drive array configurations.
Easy to use Wizards for configuration.
Web Based ACU supports On-Line, Remote Web Based and Off-line configuration.
Supports on-line configuration for Microsoft and Linux.
Configures Selective Storage Presentation (SSP).
Insight Manager 7
Insight Manager 7Insight Manager 7
Insight Manager 7 Powerful storage, server and server option management tool.
Monitor storage from a remote central location.
Browser based Insight Manager 7 provides full access from anywhere on the Intranet, eliminating the need for a
dedicated Insight Manager console.
Supported Operating
Supported OperatingSupported Operating
Supported Operating
Systems
SystemsSystems
Systems
Microsoft Windows Server 2003 Web Edition
Microsoft Windows Server 2003 Standard Edition
Microsoft Windows Server 2003 Enterprise Edition
Microsoft Windows 2000 Server
Microsoft Windows 2000 Advanced Server
Microsoft Windows NT EE 4.0
Novell NetWare 5.1
Novell NetWare 6.0
Novell NetWare 6.5
Red Hat Linux 7.2, 7.3, 8.0
Red Hat Enterprise Linux 2.1
Red Hat Linux Advanced Server 2.1
UnitedLinux 1.0 (including SuSE Linux Enterprise Server 8)
SuSE Linux Enterprise Server 7 (SLES 7)
SCO OpenServer 5.0.5 and SCO OpenServer 5.0.6a
UnitedLinux = Conectiva Linux Enterprise Edition, SCO Linux 4.0, SuSE Linux Enterprise 8 and Turbolinux 8 all powered by
UnitedLinux 1.0
Not all configurations are supported on all operating systems; please refer to compatibility matrix
http://www.hp.com/products/sharedstorage for latest compatibility information.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Software Components
DA - 11050 Canada — Version 13 — July 19, 2004 Page 7

Supported Clustering
Supported ClusteringSupported Clustering
Supported Clustering
Solutions
SolutionsSolutions
Solutions
Microsoft Cluster Service for Microsoft Windows Server 2003 Enterprise Edition
Microsoft Cluster Service for Microsoft Windows 2000 Advanced Server
Microsoft Cluster Service for Microsoft Windows NT EE 4.0
Novell Cluster Services on Novell NetWare 5.1
Novell Cluster Services on Novell NetWare 6.0
Novell Cluster Services on Novell NetWare 6.5
HP Serviceguard for Linux on Red Hat Linux 7.3, Red Hat Enterprise Linux 2.1, UnitedLinux 1.0 (including SuSE
Linux Enterprise Server 8)
SteelEye's LifeKeeper for Linux on Red Hat Linux 7.2, 7.3, 8.0, Red Hat Enterprise Linux 2.1, Red Hat Linux Advanced
Server 2.1, UnitedLinux 1.0 (including SuSE Linux Enterprise Server 8), and SuSE Linux Enterprise Server 7 (SLES 7)
UnitedLinux = Conectiva Linux Enterprise Edition, SCO Linux 4.0, SuSE Linux Enterprise 8 and Turbolinux 8 all powered by
UnitedLinux 1.0
Please refer to the HP High Availability Web site http://www.compaq.com/solutions/enterprise/highavailability for latest
information.
Smart Array Multipath
Smart Array MultipathSmart Array Multipath
Smart Array Multipath
Software
SoftwareSoftware
Software (Optional)
Enhance cluster fault tolerance by adding dual paths from the host servers to the shared storage. This provides an
additional level of fault tolerance by adding redundancy and performance to both the HBA in the host server as well as the
SCSI cables connecting the host servers to the shared storage. Smart Array Multipath software delivers dual path
functionality and supports failover capabilities for redundant host bus adapters (HBAs) in a server with redundant cabling
to a Modular Smart Array 500. This fault-tolerance tool enhances availability of clustering and direct attached storage
(DAS) solutions with up to two servers managing up to 2 TB of stored data.
When an HBA failure occurs, the software moves the logical drives from the path of the failed HBA to the path of the
redundant HBA located in the same server.
Increase availability by protecting against connectivity (HBA) and cable failures and accidental pull-outs.
Ships with 4-Port Shared Storage Module
Increase performance with Static LUN Balancing (Microsoft OS) enables the administrator to optimize I/O by
assigning specific volumes to specific paths in the storage system. If one path fails the system moves volumes to the
path for redundant HBA for I/O management.
Increase performance with Static Load (read-only) Balancing (Linux OS) enables the HBAs to optimize I/O with dual
paths to the same volumes in the storage system. If one HBA fails the system moves volumes to the path for the
redundant HBA for I/O management.
Supported Operating Systems: Windows Server 2003 Standard Edition, Windows Server 2003 Enterprise Edition;
Windows 2000 Server; Windows 2000 Advanced Server; Red Hat Enterprise Linux 2.1, Red Hat Linux Advanced
Server 2.1, UnitedLinux 1.0 (including SuSE Linux Enterprise Server 8), SLES 7.
Warranty
WarrantyWarranty
Warranty Three-year labour, parts, on-site (3/3/3) Limited Warranty for Modular Smart Array 500.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Software Components
DA - 11050 Canada — Version 13 — July 19, 2004 Page 8

Software Product Services
Software Product ServicesSoftware Product Services
Software Product Services Stand-alone telephone support
Rights to new license version
Media and documentation updates
Hardware Product Services
Hardware Product ServicesHardware Product Services
Hardware Product Services Installation services
On-site maintenance (includes warranty support)
Response time upgrades during the warranty period
Post-warranty coverage
RAID setup and performance consulting via statement of work
For additional hardware installation and maintenance information, please refer to the URLs listed below:
English:
English:English:
English: http://www.compaq.ca/English/service/cusserv/carepaq/carepaq.htm
French:
French:French:
French: http://www.compaq.ca/Francais/service/ccs/carepaqf/carepaqf.htm
Warranty Upgrade
Warranty UpgradeWarranty Upgrade
Warranty Upgrade
Options
OptionsOptions
Options
Response – Upgrade on-site response from next business day to same day 4-hours
Coverage – Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours
Duration – Three-year, on-site Limited Warranty for Modular Smart Array 500, expandable to five years
HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific duration and hours of
coverage.
HP Care Pack is not available for less than the product's warranty duration.
HP Care Pack is available for sale anytime during the warranty period for most products, but the commencement
date will be the same as the Warranty Start Date (delivery date to end user customer). Proof of purchase may be
required.
HP Care Pack services are prepaid.
For additional HP Care Pack (hardware & software) information, as well as orderable part numbers, please refer to the URL
listed below:
English:
English:English:
English: http://www.compaq.ca/English/productinfo/storage/storageworks.htm
French:
French:French:
French: http://www.compaq.ca/Francais/Produits/stockage/Storageworksf.htm
HP Care Pack Description
HP Care Pack DescriptionHP Care Pack Description
HP Care Pack Description 9x5, 4-Hour Response, On-Site Coverage, 3 years FP-FC4HR-36
24x7, 4-Hour Response, On-Site Coverage, 3 years FP-FC724-36
Hardware Installation (on site) FP-FCINS-IN
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
HP Care Pack Service and Support
DA - 11050 Canada — Version 13 — July 19, 2004 Page 9

Step 1: Order Required Items
Step 1: Order Required ItemsStep 1: Order Required Items
Step 1: Order Required Items
Models
ModelsModels
Models HP Modular Smart Array 500 Starter Kit (includes MSA 500 and 2 SA-532 Adapters) 351504-B21
HP Modular Smart Array 500 201724-B21
Package Contents
Package ContentsPackage Contents
Package Contents 4U Modular Smart Array 500
Modular Smart Array 500 Controller with 128 MB cache
2-port SCSI I/O Module
Redundant Hot Pluggable Power Supply/blower assemblies
Modular Smart Array 500 Rack Mounting Kit
Modular Smart Array 500 Support Software or Smart Start
Power cables (2)
VHDCI SCSI cables 6' each (2)
Crossover Ethernet cable for clustering
User Manual
Smart Array 532 Adapters (2) – Included in "MSA500 Starter Kit Only"
Step 2: Choose Modular Smart Array 500 System Options
Step 2: Choose Modular Smart Array 500 System OptionsStep 2: Choose Modular Smart Array 500 System Options
Step 2: Choose Modular Smart Array 500 System Options
Options
OptionsOptions
Options Modular Smart Array 500 High Availability Kit (includes MSA500 controller, 4-port IO Module, Smart
Array Multipath Software and 2 SA-532 Adapters)
351281-B21
Modular Smart Array 500 Controller 218252-B21
4-Port Shared Storage Module with Smart Array Multipath Software 292944-B21
128MB Battery Backed Cache Module 153506-B21
256MB Battery Backed Cache Module 254786-B21
M-Series Rack Rail Kit Option 313877-B21
NOTE:
NOTE:NOTE:
NOTE: The Modular Smart Array 500 Controller allows the following cache configurations:
1 x 128 MB; 2 x 128 MB; 1 x 256 MB; 2 x 256 MB.
NOTE:
NOTE:NOTE:
NOTE: When redundant controllers are installed, the cache configurations in both controllers must be identical.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Configuration Information
DA - 11050 Canada — Version 13 — July 19, 2004 Page 10

Step 3: Choose ProLiant Server(s)
Step 3: Choose ProLiant Server(s)Step 3: Choose ProLiant Server(s)
Step 3: Choose ProLiant Server(s)
Server Compatibility
Server CompatibilityServer Compatibility
Server Compatibility ML330 G2 (Direct Attached and RSO configurations only)
ML330 G3 (Direct Attached and RSO configurations only)
ML350 G2 (Direct Attached and RSO configurations only)
ML350 G3 (Clustering, Direct Attached and RSO configurations)
ML370 G2 (Clustering, Direct Attached and RSO configurations)
ML370 G3 (Clustering, Direct Attached and RSO configurations)
DL360 G2 (Clustering, Direct Attached and RSO configurations)
DL360 G3 (Clustering, Direct Attached and RSO configurations)
DL380 G2 (Clustering, Direct Attached and RSO configurations)
DL380 G3 (Clustering, Direct Attached and RSO configurations)
DL560 (Clustering, Direct Attached and RSO configurations)
DL580 (Clustering, Direct Attached and RSO configurations)
DL580 G2 (Clustering, Direct Attached and RSO configurations)
DL740 (Clustering and Direct Attached configurations)
DL760 (Clustering and Direct Attached configurations)
DL760 G2 (Clustering and Direct Attached configurations)
Step 4: Choose Host Connectivity (Skip If Purchased MSA500 Starter Kit)
Step 4: Choose Host Connectivity (Skip If Purchased MSA500 Starter Kit)Step 4: Choose Host Connectivity (Skip If Purchased MSA500 Starter Kit)
Step 4: Choose Host Connectivity (Skip If Purchased MSA500 Starter Kit)
Required for ML330 G2,
Required for ML330 G2,Required for ML330 G2,
Required for ML330 G2,
ML350 G2, ML350 G3,
ML350 G2, ML350 G3,ML350 G2, ML350 G3,
ML350 G2, ML350 G3,
ML370 G3, DL360 G2,
ML370 G3, DL360 G2,ML370 G3, DL360 G2,
ML370 G3, DL360 G2,
DL360 G3, DL580, DL580
DL360 G3, DL580, DL580DL360 G3, DL580, DL580
DL360 G3, DL580, DL580
G2, DL760
G2, DL760G2, DL760
G2, DL760
Smart Array 532 Controller Option Kit 225338-B21
Required for ML370 G2
Required for ML370 G2Required for ML370 G2
Required for ML370 G2 Smart Array 532 Controller 225338-B21
Smart Array 5i Controller Option Kit 226593-B21
NOTE:
NOTE:NOTE:
NOTE: Either one Smart Array 532 Controller or one Smart Array 5i or Smart 5i Plus Controller
Option Kit is required.
Optional for DL380 G2
Optional for DL380 G2Optional for DL380 G2
Optional for DL380 G2 Smart Array 532 Controller Option Kit 225338-B21
NOTE:
NOTE:NOTE:
NOTE: The Smart Array 5i controller is included with the ProLiant DL380 G2. No additional
No additionalNo additional
No additional
adapter required unless implementing Smart Array Multipath technology
adapter required unless implementing Smart Array Multipath technologyadapter required unless implementing Smart Array Multipath technology
adapter required unless implementing Smart Array Multipath technology
Optional for DL380 G3
Optional for DL380 G3Optional for DL380 G3
Optional for DL380 G3 Smart Array 532 Controller Option Kit 225338-B21
NOTE:
NOTE:NOTE:
NOTE: The Smart Array 5i Plus controller is included with the ProLiant DL380 G3. No additional
adapter required unless implementing Smart Array Multipath technology
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Configuration Information
DA - 11050 Canada — Version 13 — July 19, 2004 Page 11

Step 5: Choose Configuration Options
Step 5: Choose Configuration OptionsStep 5: Choose Configuration Options
Step 5: Choose Configuration Options
High Availability Software
High Availability SoftwareHigh Availability Software
High Availability Software ProLiant Essentials Recovery Server Option (RSO) 280189-B21
HP Serviceguard for Linux ProLiant Cluster 305199-B21
HP Serviceguard for Linux License 307754-B21
ProLiant Cluster HA/L100 – LifeKeeper for Linux 303523-B21
NOTE:
NOTE:NOTE:
NOTE: Above options not required for Microsoft clustering, Novell clustering or non-clustered shared
storage configurations
Step 6: Choose Hard Drives
Step 6: Choose Hard DrivesStep 6: Choose Hard Drives
Step 6: Choose Hard Drives
Pluggable, Universal
Pluggable, UniversalPluggable, Universal
Pluggable, Universal
Hard Drives
Hard DrivesHard Drives
Hard Drives
36.4GB 10,000 rpm, U320 Universal Hard Drive, 1" 286713-B22
72.8GB 10,000 rpm, U320 Universal Hard Drive, 1" 286714-B22
146.8GB 10,000 rpm, U320 Universal Hard Drive, 1" 286716-B22
18.2GB 15,000 rpm, U320 Universal Hard Drive, 1" 286775-B22
36.4GB 15,000 rpm, U320 Universal Hard Drive, 1" 286776-B22
72.8GB 15,000 rpm, U320 Universal Hard Drive, 1" 286778-B22
NOTE:
NOTE:NOTE:
NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives
require an optional U320 Smart Array Controller or U320 SCSI HBA to support U320 transfer rates.
NOTE:
NOTE:NOTE:
NOTE: For complete compatibility information, refer to the HP SCSI Hard Drive Compatibility table
located at http://www.compaq.com/products//hdd/hotplug.html
Step 7: Choose Rack Option
Step 7: Choose Rack OptionStep 7: Choose Rack Option
Step 7: Choose Rack Option
HP Rack 10000 Series
HP Rack 10000 SeriesHP Rack 10000 Series
HP Rack 10000 Series
(Graphite Metallic)
HP Rack 10842 (42U, 800mm wide) - Pallet 257415-B21
HP Rack 10842 (42U, 800mm wide) - Shock Pallet 257415-B22
HP Rack 10647 (47U) - Pallet 245160-B21
HP Rack 10647 (47U) - Crated 245160-B23
HP Rack 10642 (42U) - Pallet 245161-B21
HP Rack 10642 (42U) - Shock Pallet 245161-B22
HP Rack 10642 (42U) - Crated 245161-B23
HP Rack 10636 (36U) - Pallet 245162-B21
HP Rack 10636 (36U) - Shock Pallet 245162-B22
HP Rack 10636 (36U) - Crated 245162-B23
HP Rack 10622 (22U) - Pallet 245163-B21
HP Rack 10622 (22U) - Shock Pallet 245163-B22
HP Rack 10622 (22U) - Crated 245163-B23
NOTE:
NOTE:NOTE:
NOTE: -B21 (pallet) used to ship empty racks shipped on a truck
-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and
Channels)
-B23 (crated) used for air shipments of empty racks.
NOTE:
NOTE:NOTE:
NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment installed.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Configuration Information
DA - 11050 Canada — Version 13 — July 19, 2004 Page 12

Step 8: Expansion Options
Step 8: Expansion OptionsStep 8: Expansion Options
Step 8: Expansion Options
SAN Conversion Options
SAN Conversion OptionsSAN Conversion Options
SAN Conversion Options Modular Smart Array 1000 Controller 218231-B22
MSA Fibre Channel I/O Module 218960-B21
MSA SAN Switch 2/8 (Integrated) 288247-B21
FCA2101 Host Adapter (Microsoft) 245299-B21
FCA2210 Host Adapter (NetWare) 281540-B21
FAC2214 Host Adapter (Microsoft/Linux) 281541-B21
2Gb/s SFP SW Transceiver Kit 221470-B21
Modular Smart Array 30 Single Bus (rack-mountable) 302969-B21
NOTE:
NOTE:NOTE:
NOTE: The MSA 1000 controller and the MSA 1000 Fibre Channel I/O module (or the MSA SAN
Switch 2/8) are required for conversion. To obtain conversion procedure document go to
http://www.hp.com/go/msa500 and download "Converting Modular Smart Array 500 to a Modular
Smart Array 1000 for Additional Scalability document.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Configuration Information
DA - 11050 Canada — Version 13 — July 19, 2004 Page 13

Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
LED Indicators on Front
LED Indicators on FrontLED Indicators on Front
LED Indicators on Front
(3)
Power
Fault detected in one or more sub-systems
Fault in Enclosure Management
LED Indicators for Drive
LED Indicators for DriveLED Indicators for Drive
LED Indicators for Drive
Modules
ModulesModules
Modules (3)
Drive Access (centre)
Online (left)
Drive Failure (right)
LED Indicators on Rear
LED Indicators on RearLED Indicators on Rear
LED Indicators on Rear
Panel
PanelPanel
Panel (4)
Power Supply/Blower Assembly Fault (1)
EMU (3): Power; A bus; B bus
Interface
InterfaceInterface
Interface Ultra3 SCSI to Hard Drives
Ultra3 SCSI to Host Servers
Maximum Number of
Maximum Number ofMaximum Number of
Maximum Number of
Drives
DrivesDrives
Drives
14, 1-in Ultra320, Ultra3 or Ultra2 Universal Hard Drives (Modular Smart Array 500 cabinet)
Temperature Range
Temperature RangeTemperature Range
Temperature Range Operating
OperatingOperating
Operating 50° to 95° F (10° to 35° C)
Shipping
ShippingShipping
Shipping -2° to 122° F (-0° to 50° C)
NOTE:
NOTE:NOTE:
NOTE: Rated 1°C per 1000 feet of elevation to 10000 ft.
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity Operating
OperatingOperating
Operating 10% to 90%
Non-operating
Non-operatingNon-operating
Non-operating Up to 95%
Input Power Requirements
Input Power RequirementsInput Power Requirements
Input Power Requirements Rated Input Voltage
Rated Input VoltageRated Input Voltage
Rated Input Voltage 100 to 240 VAC
Rated Input Frequency
Rated Input FrequencyRated Input Frequency
Rated Input Frequency 50 to 60 Hz
Rated Input Current
Rated Input CurrentRated Input Current
Rated Input Current 2.3 A at12 VAC typical, 6A Maximum
Input Power
Input PowerInput Power
Input Power (max) 549 W*
Heat Dissipation
Heat DissipationHeat Dissipation
Heat Dissipation
(maximum)
1876 Btu/hr*
*Input Power and Heat Dissipation specifications are maximum values and apply to worst-case conditions at full rated
power supply load. The power/heat dissipation for your installation will vary depending on the equipment configuration.
2-Port SCSI I/O Module
2-Port SCSI I/O Module2-Port SCSI I/O Module
2-Port SCSI I/O Module Ports
PortsPorts
Ports 2 VHDCI Ultra3 SCSI ports
Dimensions
DimensionsDimensions
Dimensions 4.5 x 1.375 x 9.5 in (11.4 x 3.5 x 24.1 cm)
Weight
WeightWeight
Weight 1.3 lb (0.6 Kg)
Modular Smart Array 500
Modular Smart Array 500Modular Smart Array 500
Modular Smart Array 500
Cabinet
CabinetCabinet
Cabinet
4U Rack Form Factor
Dimensions
DimensionsDimensions
Dimensions (H x W x D) 6.9 x 19 x 20.5 in (17.5 x 48.3 x 52.1 cm)
Weight
WeightWeight
Weight (Net) 50 lb (22.5 kg)
Shipping Packaging
Shipping PackagingShipping Packaging
Shipping Packaging Dimensions
DimensionsDimensions
Dimensions (L x W x D) 33.7 x 14.8 x 33.8 in (85.6 x 37.5 x 85.9 cm)
Weight
WeightWeight
Weight (Gross) 70 to 105 lb (31.5 kg)
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Technical Specifications
DA - 11050 Canada — Version 13 — July 19, 2004 Page 14

Modular Smart Array 500 Controller
Modular Smart Array 500 ControllerModular Smart Array 500 Controller
Modular Smart Array 500 Controller
User Interface
User InterfaceUser Interface
User Interface Controller Display with Status Indicators (2) and Push Buttons (4)
Status Indicators on front of Controller (16)
Electrical Interface
Electrical InterfaceElectrical Interface
Electrical Interface LVD (Low Voltage Differential)
Protocol Support
Protocol SupportProtocol Support
Protocol Support Wide Ultra3 SCSI (160 MB/s per channel)
SCSI Ports
SCSI PortsSCSI Ports
SCSI Ports 2 external VHDCI connectors standard. Optional 4-Port Shared Storage Module with 4 VHDCI connectors.
Drives Supported
Drives SupportedDrives Supported
Drives Supported Up to 14 drives
Maximum Capacity
Maximum CapacityMaximum Capacity
Maximum Capacity 2.0 TB (14 drives x 146.8GB)
Logical Drives
Logical DrivesLogical Drives
Logical Drives Up to 32 logical drives
RAID Support
RAID SupportRAID Support
RAID Support RAID ADG (Advanced Data Guarding)
RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 1 (Mirroring)
RAID 0 (Striping)
Cache Memory
Cache MemoryCache Memory
Cache Memory Standard 128 MB Read/Write Cache
Up to 512 MB Read/Write
ECC protection, battery-backed, and removable
NOTE:
NOTE:NOTE:
NOTE: The Modular Smart Array Controller allows the following cache configurations:
1 x 128 MB; 2 x 128 MB; 1 x 256 MB; 2 x 256 MB.
NOTE:
NOTE:NOTE:
NOTE: When redundant controllers are installed, the cache configurations in both controllers must be identical.
Cache Batteries
Cache BatteriesCache Batteries
Cache Batteries Up to three days of redundant battery life, removable for easy replacement
Upgradeable Firmware
Upgradeable FirmwareUpgradeable Firmware
Upgradeable Firmware 2 MB flashable ROM
Disk Drive and Enclosure
Disk Drive and EnclosureDisk Drive and Enclosure
Disk Drive and Enclosure
Protocol Support
Protocol SupportProtocol Support
Protocol Support
Ulltra320, Ultra3 and Ultra2 SCSI 1-inch Universal drives
Packaging
PackagingPackaging
Packaging Dimensions
DimensionsDimensions
Dimensions (L x W x D) 14.5 x 11.5 x 3.1 in (36.8 x 29.2 x 8 cm)
Weight
WeightWeight
Weight (Gross) 6 lb (2.72 kg)
4-port Shared Storage I/O Module (option)
4-port Shared Storage I/O Module (option)4-port Shared Storage I/O Module (option)
4-port Shared Storage I/O Module (option)
Connector Type
Connector TypeConnector Type
Connector Type VHDCI Ultra3 SCSI
Ports
PortsPorts
Ports 4 Ultra3 SCSI
Bandwidth
BandwidthBandwidth
Bandwidth 160 MB/s per port
Protocols/HBA Supported
Protocols/HBA SupportedProtocols/HBA Supported
Protocols/HBA Supported Ultra320, Ultra3 and Ultra2 SCSI/Smart Array 532, Smart Array 5i adapters
Packaging
PackagingPackaging
Packaging Dimensions
DimensionsDimensions
Dimensions (L x W x D) 14.5 x 11.5 x 3.1 in (36.8 x 29.2 x 8 cm)
Weight
WeightWeight
Weight (Gross) 6 lb (2.72 kg)
MSA500 High Availability Kit (option)
MSA500 High Availability Kit (option)MSA500 High Availability Kit (option)
MSA500 High Availability Kit (option)
Contents
ContentsContents
Contents MSA500 Controller, 4-port Shared Storage I/O Module, 2 6ft. SCSI Cables, 2 SA-532 Adapters, and Smart Array Multipath
Software 2.0
Packaging
PackagingPackaging
Packaging Dimensions
DimensionsDimensions
Dimensions (L x W x D) 22.6 x 18.6 x 12.4 in (57.5 x 47.3 x 31.4 cm)
Weight
WeightWeight
Weight (Gross) 14.2 lb (6.5 kg)
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Technical Specifications
DA - 11050 Canada — Version 13 — July 19, 2004 Page 15

© Copyright 2002-2004 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
QuickSpecs
HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500HP StorageWorks Modular Smart Array 500
HP StorageWorks Modular Smart Array 500
Technical Specifications
DA - 11050 Canada — Version 13 — July 19, 2004 Page 16
