HP 2133 Mini-Note User instructions

HP recommends
Windows Vista
®
Business
1. Integrated stereo microphones 7. Volume mute function key
2. Optional VGA camera 8. Touchpad on/off button
3. WLAN antennas (with WLAN option) 9. Right touchpad button
4. Stereo speakers 10. Touchpad with scroll zone
QuickSpecs
HP 2133 Mini-Note PC
Overview
DA - 13009 North America — Version 13 — June 30, 2009 Page 1

5. Volume up function key 11. Left touchpad button
6. Volume down function key
1. VGA/external monitor 7. USB 2.0
2. Powered USB 2.0 8. RJ-45/ethernet
3. Stereo microphone in 9. Battery LED
4. Stereo headphone/line out 10. Power connector
5. ExpressCard/54 slot 11. Kensington lock slot
6. Secure Digital slot
1. Power button with LED 4. Vents
2. Internal storage activity / HP 3D DriveGuard LED 5. Battery release latches
3. Wireless on/off button with LED 6. Battery bay
QuickSpecs
HP 2133 Mini-Note PC
Overview
DA - 13009 North America — Version 13 — June 30, 2009 Page 2

At A Glance
Full-function PC with utmost mobility and durable all-aluminum case
Ultra-portable light-weight design starting at 2.8 lb (1.27 kg) and 1.05 in (27 mm) thin at front
8.9-inch diagonal WXGA or WSVGA scratch-resistant display
92% full-size QWERTY keyboard and touchpad
Optional 802.11 a/b/g/n draft 2.0 wireless LAN and Bluetooth, HP Wireless Assistant
Up to 160 GB 7200 rpm hard drive with HP 3D DriveGuard (supported on Windows models only)
Optional integrated VGA Webcam
ExpressCard/54 slot
Secure Digital slot for HCSD and MultiMedia Card media cards
Upgradeable up to 2GB of 667 MHz DDR2 SDRAM
QuickSpecs
HP 2133 Mini-Note PC
Overview
DA - 13009 North America — Version 13 — June 30, 2009 Page 3

Processors VIA C7™-M ULV processor (1.0GHz,* 128 KB L2 cache, 400 MHz FSB)
VIA C7-M ULV processor (1.2 GHz, 128 KB L2 cache, 800 MHz FSB)
VIA C7-M ULV processor (1.6 GHz, 128 KB L2 cache, 800 MHz FSB)
* SuSE Linux models only
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows Vista Home Basic 32 *
Genuine Windows Vista Business 32 *
Genuine Windows Vista Business downgrade to Genuine Windows XP
Professional installed *
†
SuSE Linux Enterprise Desktop 10
FreeDOS
Supported Genuine Windows XP Professional
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit http://www.windowsvista.com/upgradeadvisor .
†
Windows Vista Business disk also included for future upgrade if desired. To qualify for this downgrade an
end user must be a business (including governmental or educational institutions) and is expected to order
annually at least 25 customer systems with the same custom image.
Chipset VIA 896
Graphics VIA Chrome 9
Up to 256 MB of shared system memory for Windows with 2 GB of system memory
Up to 128 MB of shared system memory for Windows with 1 GB of system memory
Up to 64 MB of shared system memory for Linux
Display Internal 8.9-inch WXGA display with 1280 x 768 resolution
8.9-inch WSVGA display with 1024 x 600 resolution
Scratch-resistant treatment on acrylic panel cover
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and
lower resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 4

Memory Standard 1024 MB or 2048 MB 667 MHz * DDR2 SDRAM SODIMM; one SODIMM slot
Maximum Supports up to 2048 MB maximum
* An 800 MHz DDR2 SDRAM SODIMM memory module may be substituted (running at the maximum system
supported speed of 667 MHz)
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility.
Communications Integrated Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Wireless Devices Support for secure, integrated wireless LAN options featuring support for the latest industry standards.
Wireless LAN is factory configurable only. Integrated Bluetooth is also available (factory configurable
only) and can be combined with any of the supported wireless LAN options.
All 802.11 integrated
wireless LAN options
Wi-Fi CERTIFIED *
Cisco Compatible Extensions support (Version 4.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Broadcom 4322AGN
802.11a/b/g/draft-n Wi-
Fi Adapter
Integrated support for 802.11a, b, g, and n draft 2.0*
Up to 300 mbps data rate
Broadcom 4311AG
802.11a/b/g
Wi-Fi Adapter
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Broadcom 4312G
802.11b/g
Wi-Fi Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
with Bluetooth Wireless
Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to communicate
with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this capability is not
enabled.
Keyboard Spill-resistant keyboard is 92% of full size, 101/102-key compatible with isolated inverted-T cursor
control keys, both left and right control and alt keys, 12 function keys, and hotkey combinations for audio
volume, power conservation, brightness, and other features. US and international key layouts are
available.
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 5

Pointing Device Touchpad with scroll zone and two soft-touch buttons
Expansion Card Slots ExpressCard/54 slot Supports ExpressCard/54 and ExpressCard/34
Secure Digital slot Supports HCSD (Secure Digital), MultiMedia Card
Storage Internal Storage Device 120/160 GB 5400 rpm SATA Hard Drive
120/160 GB 7200 rpm SATA Hard Drive
NOTE: Hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to 10
GB is reserved for the system recovery software.
HP 3D DriveGuard * The hard drive is mounted to the notebook frame, reducing the transmission
of shock away from the hard drive. Uses three-axis digital motion detection
with intelligent sensitivity to help protect the hard drive during normal use
from shock and vibration. The digital accelerometer temporarily halts all data
transfer and parks the hard drive when abrupt motion is detected.
External Optical Drives Via optional HP External MultiBay II (9.5-mm):
MultiBay II DVD-ROM Drive
MultiBay II DVD/CD-RW Combo Drive
MultiBay II DVD+/-RW SuperMulti DL Drive
* Windows models only
Interfaces ExpressCard/54 slot Supports ExpressCard/54 and ExpressCard/34
External Monitor One – VGA
Stereo Microphone In One
Stereo Headphone/Line
out
One
Power Connector One
RJ-45/Ethernet One
USB 2.0 Two (one powered)
LED Status Indicators Five
Audio ADI1984HD High Definition CODEC
24-bit DAC
Integrated stereo speakers
Stereo headphone/line out
Stereo microphone in
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 6

Software Preinstalled Software
with Windows Vista or
Windows XP
MS Office Ready 2007
Norton Internet Security
MS Live Messenger
Adobe Flash Player
Roxio Creator Basic
Intervideo WinDVD
PDF Complete SE
HP Webcam
HP Recovery Manager (Vista only)
Preinstalled Software
with SuSE Linux
Enterprise Desktop 10
OpenOffice Suite
Evolution Email
Evince Document Viewer
OpenOffice Draw
F-Spot Photo Brower
Gnome CD/DVD Creator
Helix Banshee Music Player
Real Player 10 Media Player
Firefox Web Browser
Gaim Instant Messenger
Gnome FTP File Transfer
Liferea Feed Reader
Mutt Mail Client
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
Security Standard Features Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased separately)
Power Supply External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge Technology *
*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast
Charge Technology does not apply to 12-cell Ultra-Capacity batteries.
Battery Primary Battery 3-cell (28 WHr) high capacity Li-Ion
6-cell (55 WHr) high capacity Li-Ion
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 7

Battery Life 3-cell Primary Battery Up to 2 hours 15 minutes
6-cell Primary Battery Up to 4 hours 30 minutes
NOTE: The listed battery life measurements were taken on models running Microsoft Windows XP
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation Standby
ACPI compliance
Service and Support HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x 24
hardware technical phone support (depending on model). On-site service and warranty upgrades are also
available. (depending on model).
For configurations with SuSE Linux Enterprise Desktop 10, HP Services may vary depending on the country
of purchase, and toll-free 5 x 8 (Monday through Friday; 9:00am to 5:00pm CST) hardware technical phone
support is available.
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
Select Model (s)
2133
SKU Part#
KX869AT#ABA
Smart Buy
Processor VIA C7®-M ULV Processor (1.2 GHz, 128 KB L2 cache)
Operating System SuSE Linux Enterprise Desktop 10
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 120-GB 5400 rpm
Display 8.9-inch diagonal WXGA
Integrated VGA camera
Graphics Via Chrome 9
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom Gigabit Network Connection (10/100/1000 NIC)
Integrated Wireless Broadcom 802.11a/b/g
Pointing Device Touchpad with scroll zone
Battery 3-cell (28 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 8

2133
SKU Part#
KX868AT#ABA
Smart Buy
Processor VIA C7®-M ULV Processor (1.2 GHz, 128 KB L2 cache)
Operating System Genuine Windows Vista Home Basic 32
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 120-GB 5400 rpm
Display 8.9-inch diagonal WXGA
Integrated VGA camera
Graphics Via Chrome 9
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom Gigabit Network Connection (10/100/1000 NIC)
Integrated Wireless Broadcom 802.11a/b/g
Pointing Device Touchpad with scroll zone
Battery 3-cell (28 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
2133
SKU Part#
KX871AA#ABA
Regional
Processor VIA C7®-M ULV Processor (1.2 GHz, 128 KB L2 cache)
Operating System Genuine Windows Vista Home Basic 32
System Memory 1024 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 160-GB 5400 rpm
Display 8.9-inch diagonal WXGA
Integrated VGA camera
Graphics Via Chrome 9
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom Gigabit Network Connection (10/100/1000 NIC)
Integrated Wireless Broadcom 802.11a/b/g, Bluetooth 2.0
Pointing Device Touchpad with scroll zone
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 9

2133
SKU Part#
KX870AT#ABA
Smart Buy
Processor VIA C7®-M ULV Processor (1.6 GHz, 128 KB L2 cache)
Operating System Genuine Windows Vista Business 32
System Memory 2048 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 120-GB 7200 rpm
Display 8.9-inch diagonal WXGA
Integrated VGA camera
Graphics Via Chrome 9
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom Gigabit Network Connection (10/100/1000 NIC)
Integrated Wireless Broadcom 802.11a/b/g, Bluetooth 2.0
Pointing Device Touchpad with scroll zone
Battery 6-cell (55 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
2133
SKU Part#
KR922UT#ABA
Smart Buy
Processor VIA C7®-M ULV Processor (1.0 GHz, 128 KB L2 cache)
Operating System SuSE Linux Enterprise Desktop 10
System Memory 512 MB 667-MHz DDR2 (1 DIMM)
Hard Drive 4GB Flash
Display 8.9-inch diagonal WXGA
Integrated VGA camera
Graphics Via Chrome 9
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom Gigabit Network Connection (10/100/1000 NIC)
Integrated Wireless Broadcom 802.11a/b
Pointing Device Touchpad with scroll zone
Battery 3-cell (28 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
QuickSpecs
HP 2133 Mini-Note PC
Standard Features
DA - 13009 North America — Version 13 — June 30, 2009 Page 10

Memory HP 2 GB (DDR2 667 MHz) SODIMM EM995AA
HP 1 GB (DDR2 800 MHz) SODIMM* KT292AA
HP 2 GB (DDR2 800 MHz) SODIMM* KT293AA
* Runs at maximum system supported speed of 667 MHz
Storage Solutions HP Versatile Storage Cart AL587AA
MultiBay II Storage
(9.5-mm)
HP External MultiBay II PA509A#xxx
HP MultiBay II DVD-ROM Drive PA849A
HP MultiBay II DVD/CD-RW Combo Drive PA850A
HP MultiBay II DVD+/-RW SuperMulti DL Drive PA851A
HP 80-GB 5400rpm MultiBay II Hard Drive PH357A
Power HP 1-bay Battery Charging Station RW635AA#xxx
HP 5-bay Battery Charging Station RW636AA#ABA
HP 2133 Battery Adapter Kit (June 2008) KV828AA
65W Smart AC Adapter ED494AA#ABA
HP 2133 6-cell Primary Battery (June 2008) KU528AA
Carrying Cases HP 2133 Carrying Case TBD
HP Ultra-portable Carrying Case TBD
HP Basic Carrying Case AJ078AA
HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Executive Leather Case RR316AA
HP Deluxe Nylon Backpack RR317AA
HP Deluxe Roller Case GD405AA
Security HP/Kensington MicroSaver Security Lock PC766A
Input/Output Devices HP USB Keyboard & Mouse Bundle RC465AA#xxx
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Optical Travel Mouse RH304AA
QuickSpecs
HP 2133 Mini-Note PC
Options
DA - 13009 North America — Version 13 — June 30, 2009 Page 11

Supports up to 2048 MB* of 667 MHz DDR2 SDRAM
One DIMM slot
DIMM sizes supported: 1024 MB and 2048 MB
Standard Memory 1024 MB (1024 MB x 1)
2048 MB (2048 MB x 1)
Optional Memory Upgrades Support for up to 2048 MB * of memory is available (with the installation of optional DDR2 SDRAM
memory kit). Memory slot is user accessible. Please refer to the Hardware and Software Guide for
installation procedures.
Up to Slot 1
2048 MB 2048 MB
NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded
memory modules to ensure compatibility.
Memory Upgrades HP 1 GB (DDR2 667 MHz) SODIMM EM994AA
HP 2 GB (DDR2 667 MHz) SODIMM EM995AA
HP 1 GB (DDR2 800 MHz) SODIMM * KT292AA
HP 2 GB (DDR2 800 MHz) SODIMM * KT293AA
* Runs at maximum system supported speed of 667 MHz
QuickSpecs
HP 2133 Mini-Note PC
Memory
DA - 13009 North America — Version 13 — June 30, 2009 Page 12

Internal Storage Device
Hard Drives (SMART SATA) Quantity Supported Drive Bay
120 GB 5400 rpm One Dedicated hard drive bay
160 GB 5400 rpm One Dedicated hard drive bay
120 GB 7200 rpm One Dedicated hard drive bay
160 GB 7200 rpm One Dedicated hard drive bay
Optical Drive Support
External Optical Drives Quantity Supported Optional Expansion Unit
MultiBay II DVD-ROM Drive
MultiBay II DVD/CD-RW Combo Drive
MultiBay II DVD+/-RW SuperMulti DL Drive
One HP External MultiBay II
QuickSpecs
HP 2133 Mini-Note PC
Storage
DA - 13009 North America — Version 13 — June 30, 2009 Page 13

System Unit Dimensions (HxWxD) 1.05 (at front) x 10.04 x 6.5 in
27 (at front) x 255 x 165 mm
Weight Starting at 2.8 lb (1.27 kg)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight includes
3-cell battery, 1 GB memory, 4 GB flash module, 802.11 wireless communications module. Weight varies
by configuration and components.
Stand-Alone Power
Requirements
Normal Operating Voltage 19 V
Average Operating Power 25 W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C)
Non-operating –4° to 140° F (–20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating –50 to 10,000 ft (–15.24 to 3,048 m)
Non-operating –50 to 40,000 ft (–15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR
®
Yes *
EPEAT Gold **
ICES Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
MIC Yes
BSMI Yes
CE Marking Compliance Yes
BNCI or BELUS Yes
CIT Yes
GOST Yes
Saudi Arabian Compliance
(ICCP)
Yes
SABS Yes
UKRSERTCOMPUTER Yes
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 14

* Configurations of the HP 2133 that are ENERGY STAR qualified are identified as HP 2133 ENERGY STAR
on HP websites and on www.energystar.gov .
** EPEAT registration varies by country. See www.epeat.net for registration status by country.
EPEAT status listed above applies to U.S.
HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 15

6-Cell (55 WHr) Lithium-
on battery
Dimensions (HxWxL) 1.69 x 1.57 x 8.19 in (4.3 x 4 x 20.8 cm)
Weight 0.77 lb (0.35 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 55Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
3-Cell (28.8 WHr) Lithium-
on battery
Dimensions (HxWxL) 1.69 x 0.79 x 8.19 in (4.3 x 2 x 20.8 cm)
Weight 0.39 lb (0.176 kg)
Cells/Type 3-cell Lithium-Ion
Energy Watt-hour Capacity 28.8 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 16

8.9-inch diagonal WXGA
Display
Active Area (W x H) 7.63 x 4.58 in (19.39 x 11.63 cm)
Diagonal Size 8.9 in (22.6 cm)
Surface Treatment Anti-glare
Contrast Ratio 400:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch .15 mm
Format 1280 x 768
Configuration RGB stripe
Backlight CCFL
PPI 168
Viewing Angle ±60° Horizontal, ±30° Vertical (typical)
8.9-inch diagonal WSVGA
Display
Active Area (W x H) 7.68 x 4.46 in (19.51 x 11.34 cm)
Diagonal Size 8.9 in (22.6 cm)
Surface Treatment Anti-glare
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 180 nit (typical)
Pixel Resolution Pitch .19 mm
Format 1024 x 600
Configuration RGB stripe
Backlight LED
PPI 133
Viewing Angle ±45° Right/Left, ±15° Up, ±35° Down (typical)
Internal Storage
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 17

160 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lb (113 g)
Capacity 160 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1 ms
Average 10 ms
Maximum 18 ms
Rotational Speed 7200 rpm
Logical Blocks 312,581,808
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
120 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lb (113 g)
Capacity 120 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1 ms
Average 10 ms
Maximum 18 ms
Rotational Speed 7200 rpm
Logical Blocks 234,441,648
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 18

160 GB 5400 rpm SATA
Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 160 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 312,581,808
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
120 GB 5400 rpm SATA
Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 120 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7 / SATA 1.0a
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 234,441,648
Operating Temperature 41° to 140° F (5° to 60° C) [case temp]
Features ATA Security
Removable Storage Drives - MultiBay II
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 19

DVD-ROM Drive Dimensions 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight 0.34 lb (155 g)
Access Times Random <120 ms CD
<200 ms DVD
Max Data Transfer Rate 24X-CD-ROM 3,600 KB/s
8X-DVD 10,800 KB/s
Transfer Mode Multiword DMA Mode 2
Interface EIDE
Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD,
CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA,
Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10,
DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
Supported Media (write) None
Max Media Capacity (read) 8.5 GB
Transport Tray Loading
DVD/CD-RW Combo Drive Dimensions 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight 0.45 lb (205 g)
Access Times Random <120 ms CD
<155 ms DVD
Max Data Transfer Rate 24X CD-ROM 3,600 KB/s
8X DVD 10,800 KB/s
24X CD-R 3,600 KB/s
24X CD-RW 3,600 KB/s
Transfer Mode Multiword DMA Mode 2
Interface EIDE
Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD,
CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA,
Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10,
DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
Supported Media (write) CD-R, CD-RW
Max Media Capacity (read) 8.5 GB
Max Media Capacity
(write)
700 MB
Transport Tray loading
QuickSpecs
HP 2133 Mini-Note PC
Technical Specifications
DA - 13009 North America — Version 13 — June 30, 2009 Page 20
