HP Compaq dx2000 ST Manual

System Unit
1 Chassis assembly not spared
2Power supply, PFC 308617-001
3 Computer access panel 337238-001
4 Front bezel assembly with diskette drive bezel 337022-001
Easy Access Keyboards (not illustrated)
PS/2
USB 355630-xxx 355631-xxx
International -B31 PRC -AA1
Japanese -291 Taiwanese -AB1
Korean (Hanguel) -KD1 Thai -281
Mass Storage Devices (not illustrated)
40 GB\7200 RPM Hard drive 286692-001
80 GB\7200 RPM Hard drive 250185-001
160 GB\7200 RPM Hard drive 325306-001
Diskette drive with mounting screws 333505-001
48X CD-ROM drive with mounting screws 326773-001
52X CD-ROM drive 333969-001
48X/32X/48X CDRW 346788-001
48X/32X/48X +16X DVD/CD-RW 359493-001
8X DVD+R/RW 358688-001
16/40X DVD ROM Drive 325313-001
Zip 250 Drive with mounting bracket 333504-001
Zip 250 drive without mounting bracket 326772-001
Standard and Optional Boards
1System board with alcohol pad and thermal grease 360427-001
Memory Modules
2 128 MB/400 MHz FSB, PC3200 335697-001
* 256 MB/400 MHz FSB, PC3200 335698-001
* 512 MB/400 MHz FSB, PC3200 335699-001
* 1.0 GB/400 MHz FSB, PC3200 335700-001
* 128 MB/333 MHz FSB, PC2700 314795-001
* 256 MB/333 MHz FSB, PC2700 314793-001
* 512 MB/333 MHz FSB, PC2700 314796-001
* 1.0 GB/333 MHz FSB, PC2700 314794-001
Intel Processor with alcohol pad and thermal grease
3 Celeron 3.06 GHz/533 MHz FSB/256 K cache 364836-001
* Pentium 2.8 GHz/533FSB/1 GB cache 359573-001
* Pentium 2.8 GHz/800 FSB/1 MB cache with Hyper-
threading 348617-001
* Pentium 3.0 GHz/800 FSB/1 MB cache with Hyper-
threading 359574-001
* Pentium 3.2 GHz/800 FSB/1 MB cache with Hyper-
threading 364837-001
* Pentium 3.4 GHz/800 FSB/1 MB cache with Hyper-
threading 351769-001
Other Cards
* Lucent 56k modem with low profile bkt 277918-001
* nVidia Quadro4 280 NVS, 64 MB graphics card 370822-001
*Not shown
© 2004 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
Development Company, L.P.
All other product names mentioned herein may be
trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
warranty.
July 2004
Document Number
370864-001
HP Compaq Business Desktop
dx2000 ST Series Personal
Computer
illustrated parts map
Slim Tower
Cables
1 Diskette drive cable (168999-005) 337244-001
2UATA data cable, 13.5” (108950-045) 337247-001
*UATA data cable, 8.6” (108950-044) 337246-001
3Audio cable (CD to system board) (387527-001) 149806-001
4Power switch/LED cable with switch holder 337243-001
5Front I/O device with cable 337242-001
*Flying serial port with cable 341899-001
*Not shown
Miscellaneous Parts
1 Front bezel assembly with diskette drive bezel 3337022-001
* 5.25” Bay bezel blank 335937-001
2 Diskette drive bay bezel blank 337019-001
4 3.5” drive bay bezel (for Zip drive) 337021-001
5 Rubber foot (4 ea) 337545-001
6 Speaker with housing 326776-001
7 Heatsink with thermal grease and alcohol pad 360327-001
8 Chassis fan 342685-001
* Mouse, 2-Button, PS/2 with scroll wheel 323614-001
* Mouse, 2-Button, USB, with scroll wheel 323615-001
* Mouse, Optical 322323-001
* Misc screw kit, includes: 337237-001
* M3 x 5mm, hitop (263585-001) 4 ea
* #6-32 x .250, hitop (262508-001) 8 ea
* #6-32 x .250, pan head (101517-037) 3 ea
* #6-32 x .312, hitop (262508-002) 4 ea
* #6-19 x .312, pan head (101346-068) 2 ea
* #6-19 x .315, T15 head (331310-001) 2 ea
* Drive Key, 128 MB 349988-001
* Real-time-clock battery 153099-001
*Not shown

Heat Sink Removal
System Board Connectors and Jumpers (position of some untitled components may vary in location)
CR1 LED - 5 V_Aux P16 Power supply fan control
E49 Password jumper P20 Primary IDE
J20 PCI slot 1 P21 Secondary IDE
J21 PCI slot 2 P23 Front audio
J22 PCI slot 3 P24 Front USB
P1 Main power (20 pin) P54 Serial Port “B”
P3 CPU regulator power (4 pin) P70 CPU fan
P5 Front panel SW50 CMOS button
P6 Internal chassis speaker XBT1 Battery
P7 CD audio in XMM1 Memory socket
P8 Chassis fan XMM2 Memory socket
P10 Diskette drive XMM3 Memory socket
P11 Aux audio in XMM4 Memory socket
P14 Boot block
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Unused
2Interrupt Controller Cascade 10 Unused, available for PCI
3Serial Port (COM B) 11 Unused, available for PCI
4Serial Port (COM A) 12 Mouse
5Unused, available for PCI 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) Controller
7Parallel Port (LPT 1) 15 Secondary ATA (IDE) Controller
Computer Diagnostic LEDs (on front of computer)
LED Color LED Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power Green Off (S4) Suspend to Disk (if applicable)
Power Clear Off (S5) Computer off
Power Red 1 blink followed by 2-second
pause - Repeat Power Supply failure
Power Red* 2 blinks 1 second apart CPU thermal shutdown
Power Red* 3 blinks 1 second apart CPU not installed
Power Red* 4 blinks 1 second apart Power supply overload ( crow bar)
Power Red* 5 blinks 1 second apart No memory
Power Red* 6 blinks 1 second apart No graphics
Power Red* 7 blinks 1 second apart System board failure (detected prior to video)
Power Red* 8 blinks 1 second apart Invalid ROM
Hard Drive Green Blinking Hard drive activity
*Blinking codes are repeated after a 2 second pause. Blinking codes are accompanied by beeps for 5 iterations, after
which the beeps are discontinued but LED activity continues until the issue has been resolved.
Keyboard Diagnostic LEDs, PS/2 Keyboards Only
LED Color LED Activity State/Message
Num, Caps,
Scroll Lock Green On (Rising Tone) ROM reflashed successfully
Num Lock Green On ROMPaq diskette not present, is bad, or drive
not ready.*
Caps Lock Green On Enter password.
Num, Caps,
Scroll Lock Green Blink On in sequence, one at a time - N, C, SL Keyboard locked in network mode
* Insert valid ROMPaq diskette in drive A. Turn power switch off, then on to reflash ROM. If ROM flash is successful, all
three keyboard LEDs will light up, and you will hear a rising tone series of beeps. Remove diskette and turn power off,
then on to restart the computer. For more information about flashing the ROM, refer to the Troubleshooting guide.
Clearing CMOS
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using switch SW50.
To clear and reset the configuration, perform the following procedure:
1. Prepare the computer for disassembly.
ÄCAUTION: The power cord must be disconnected from the power source before pushing the Clear CMOS
Button (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
2. Remove the access panel.
3. Press the CMOS button located on the system board and keep it depressed for 5 seconds.
4. Replace the access panel.
5. Turn the computer on and run F10 Computer Setup (Setup-utility) to reconfigure the system.
Disabling or Clearing the Power-On and Setup Passwords
1. Turn off the computer and any external devices, and disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the header and jumper labeled E49.
4. Remove the jumper from pins 1 and 2. Place the jumper over pin 2 only, in order to avoid losing it.
5. Replace the access panel.
6. Plug in the computer and turn on power. Allow the operating system to start.
NOTE: Placing the jumper on pin 2 clears the current passwords and disables the password features.
7. To re-enable the password features, repeat steps 1-3, then replace the jumper on pins 1 and 2.
8. Repeat steps 5-6, then establish new passwords.
Refer to the Computer Setup (F10 Setup) instructions to establish new passwords.
Computer Setup (F10) Utility Features (not all features may be available)
File System Information About
Set Time and Date
Save to Diskette
Restore From Diskette
Set Defaults and Exit
Ignore Changes and Exit
Save Changes and Exit
Storage Device Configuration
Options IDE DPS Self-Test Controller Order Boot Order
Security Setup Password
Power-On Password
Password Options
Embedded Security
System IDs
Master Boot Record Security
Save Master Boot Record
Restore Master Boot Record
Device Security
Network Service Boot
Advanced Power-On Options BIOS Wakeup
Onboard Devices
PCI Devices
Bus Options
Device Options
PCI VGA Configuration
Note: See Computer Setup (F10) Utility Guide on the Documentation Library CD.
