Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP EliteOne 1000 G2 34-in Curved All-in-One Business PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
Motherboard, RAM
2
Batteries
All types including standard alkaline and lithium coin
or button style batteries RTC battery
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps LCD
1
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
EPS, Power Cord
2
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
radioactive substances
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdiver
TORX T8
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Removed Base Top Cover
2. Removed Base Front Cover
3. Removed Power Switch Board, Sensor Board
4. Remove 4 screws then disassembly the LID (LCD chassis)
5. Removed Fan Module
6. Removed Heat Sink
7. Removed Stand Arm Base, MB Protect Cover
8. Removed Side I/O Top Shielding
9. Remove SSHD
10. Removed Speaker module
11. Removed Wireless Card, Ram, CPU
12. Removed RTC battery
13. Removed Motherboard, Bottom Base Cover
14. Removed Stand Rear Cover, Stand Front Cover
15. Removed Stand Arm
16. Removed Rear Cover
17. Removed Hinge Stand, OSD board
18. Removed Scalar Shielding, Scalar Board, Scalar Bracket Bottom
19. Removed Camera Box, Camera Transfer Board
20. Removed Camera Module, Camera Bracket , DMIC Board, RGB Camera Box Cable
21. Removed Camera Holder, LCD Frame
22. Removed LCD Chin, LCD Chin Bracket, LCD Panel
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
1. Removed Base Top Cover

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
2. Removed Base Front Cover
3. Removed Power Switch Board, Sensor Board
4. Remove 4 screws then disassembly the LID (LCD chassis)
5. Removed Fan Module

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
6. Removed Heat Sink
7. Removed Stand Arm Base, MB Protect Cover
8. Removed Side I/O Top Shielding
9. Remove SSHD

EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
10. Removed Speaker module
11. Removed Wireless Card, Ram, CPU
12. Removed RTC battery

EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
13. Removed Motherboard, Bottom Base Cover
14. Removed Stand Rear Cover, Stand Front Cover
15. Removed Stand Arm

EL-MF877-00 Page 7
Template Revision B
PSG instructions for this template are available at EL-MF877-01
16. Removed Rear Cover
17. Removed Hinge Stand, OSD board
18. Removed Scalar Shielding, Scalar Board, Scalar Bracket Bottom

EL-MF877-00 Page 8
Template Revision B
PSG instructions for this template are available at EL-MF877-01
19. Removed Camera Box, Camera Transfer Board
20. Removed Camera Module, Camera Bracket , DMIC Board, RGB Camera Box Cable
21. Removed Camera Holder

EL-MF877-00 Page 9
Template Revision B
PSG instructions for this template are available at EL-MF877-01
22. Removed LCD Chin, LCD Chin Bracket, LCD Frame, LCD Panel
