HP Kayak XU Series 03 User manual

HP Kayak XU 03xx PC Workstation —
Installing Accessories
In Your HP PC Workstation
Explains in detail how to install accessories, such as extra memory,
accessory boards, and additional disk drives.
03xx-i~1.fm Page 1 Tuesday, February 16, 1999 10:15 AM

HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Supported HP Accessories
2English
Supported HP Accessories
Contact your dealer for an up-to-date list of supported devices.
NOTE 256 MB registered ECC SDRAM DIMMs cannot be used with unbuffered
32 MB, 64 MB or 128 MB DIMMs
Up to six accessory boards
can be installed:
- One AGP slot (graphics)
- Three 32-bit PCI slots (one used by SCSI/LAN board, one with RAIDport)
- One combination PCI or ISA slot
- One 16-bit ISA slot
Front Access Drives, for example:
- 3.5-inch 1.44 MB flexible disk drive
(one third height)
- 5.25-inch 1.2 MB flexible disk drive
(half height)
- 5.25-inch tape drive (half height)
Internal Mass
Storage Devices
5 Pairs of Rails for Front
Access Devices:
- 3.5-inch disk drive rails
- 5.25-inch disk drive rails
Main Memory Upgrades
(DIMM slots for ECC SDRAM):
- 32 MB (unbuffered)
- 64 MB (un-buffered)
- 128 MB (un-buffered)
- 256 MB (Registered - see note below)
03xx-i~1.fm Page 2 Tuesday, February 16, 1999 10:15 AM

English 3
HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Removing and Replacing the Cover
Removing and Replacing the Cover
WARNING For your safety, never remove the PC Workstation’s cover without first
removing the power cord from the power outlet, and any connection to
a telecommunications network. Always replace the cover on the
PC Workstation before switching it on again.
Removing the Cover
1Switch off the display and computer.
2Disconnect all power cables and any telecommunications cables.
3If necessary, unlock the cover using the key on the back panel.
4Lift the two latches on the front sides of the computer upwards.
5Grasp the cover on the sides at the back of the computer and slide
it forwards and off the computer.
Step 4
Step 5
03xx-i~1.fm Page 3 Tuesday, February 16, 1999 10:15 AM

HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Removing and Replacing the Cover
4English
Replacing the Cover
1Ensure that you have installed all your accessories and that all
internal cables are properly connected and safely routed.
2Ensure that the two latches on the front sides of the cover are lifted
up, and that the lock is unlocked.
3Slide the cover onto the computer, making sure that the two guides
at the bottom of the case slide into the two rails at the base of the
computer. Firmly slide the cover backwards into position.
4Lower the latches on the front sides of the cover.
5If required, lock the cover using the key provided.
6Reconnect all the power cables.
Press here on
both sides of the
PC’s cover.
Step 3
Step 4
Step 5
03xx-i~1.fm Page 4 Tuesday, February 16, 1999 10:15 AM

English 5
HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Removing and Replacing the Cover
Intrusion Monitor Your PC Workstation is equipped with an intrusion monitor, which is
located on the front of the PC Workstation, behind the Hardware
Control Panel. It is designed to detect whether your PC Workstation
has been opened since the last time it was used:
•If your PC Workstation has been opened, it is assumed that the
system configuration has changed and a full start-up check is carried
out.
•If your PC Workstation has not been opened, it is assumed that the
system configuration has not changed and a reduced start-up check
is carried out.
03xx-i~1.fm Page 5 Tuesday, February 16, 1999 10:15 AM

HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Moving the Power Supply
6English
Moving the Power Supply
1Disconnect the computer’s power cord and any telecommunications
cable.
2Remove the computer’s cover (refer to page 3).
3Press the retaining buttons on each side of the HP UltraFlow airflow
guide and lift it partly out of the PC Workstation’s case.
4Remove the fan connection to the system board and lift the airflow
guide completely out of PC Workstation’s case.
5Unscrew the four self-retaining screws at the back of the power
supply.
HP UltraFlow
Airflow Guide
Retaining button
Fan connection to
system board
Unscrew the
self-retaining screws
03xx-i~1.fm Page 6 Tuesday, February 16, 1999 10:15 AM

English 7
HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Moving the Power Supply
WARNING To avoid electrical shock, do not open the power supply.
6Slide the power supply out of the computer until it stops—the
power supply unit remains connected to the computer.
Replacing the Power
Supply after Installing
Accessories
1Check that all internal cables are safely routed.
2Slide the power supply back into the computer.
3Tighten the four self-retaining screws.
4Replace the HP UltraFlow airflow guide.
5Reconnect the fan to the system board.
Slide the power
supply unit clear of
the computer
Power Supply
03xx-i~1.fm Page 7 Tuesday, February 16, 1999 10:15 AM

HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Installing Memory
8English
Installing Memory
Main Memory Modules
If you need more main memory to run your application software, you
can install up to 1GB of memory in four DIMM slots.
Main memory upgrades are available in single 32 MB, 64 MB and
128 MB Unbuffered ECC SDRAM or 256 MB Registered ECC SDRAM
memory modules. You should note that Registered ECC SDRAM
cannot be used with Unbuffered memory modules. Do not attempt to
combine these two types of memory.
CAUTION Static electricity can damage electronic components. Turn off all
equipment. Do not let your clothes touch the accessory.
To equalize the static electricity, rest the accessory bag on top of the
power supply while you are removing the accessory from the bag.
Handle the accessory as little as possible and with care.
To install a main memory module:
1Disconnect the computer’s power cord and any LAN or
telecommunications cable.
2Remove the computer’s cover (refer to page 3).
3Press the retaining buttons on each side of the HP UltraFlow airflow
guide and lift it partly out of the PC Workstation’s case.
4Remove the fan connection to the system board and lift the airflow
guide completely out of PC Workstation’s case.
NOTE Refer to the illustration on page 6 for steps 3 and 4.
5Remove the Ultra wide 16-bit SCSI cable from the system board.
6Remove the power supply and the transparent airflow guide
covering the processor sockets (if needed).
7Remove the floppy disk drive data cable from the system board.
03xx-i~1.fm Page 8 Tuesday, February 16, 1999 10:15 AM

English 9
HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Installing Memory
8The location of the memory module slots is shown here.
9Slide the memory module into the slot at 90° to the system board
(with the cutouts furthest away from the processor).
10 Firmly press the memory module completely into the connector
until the retaining clips click into position. Repeat this procedure for
each additional memory module you want to install.
11 Install any other accessories if necessary, then replace all units and
reconnect all cables and power cords. Replace the cover (refer to
page 4).
12 Check the HP Summary Screen to verify the new configuration.
Slide the memory module into the
slot at 90oto the system board
Push the module until the
retaining clips click into position
Memory module
cutouts
03xx-i~1.fm Page 9 Tuesday, February 16, 1999 10:15 AM

HP Kayak XU 03xx PC Workstation — Installing Accessories In Your HP PC Workstation
Installing Memory
10 English
Installing More Memory on the Video Adapter
Your PC Workstation is equipped with a video adapter that supports
2D and 3D graphics. If you need to have more video memory to display
more colors, higher resolutions, or for increased speed, you can install
more video memory on the video adapter.
To find out about available video memory upgrades, refer to the HP
World Wide Web Site at
http://www.hp.com/go/kayaksupport/
CAUTION Static electricity can damage electronic components. Turn off all
equipment. Do not let your clothes touch the accessory.
To equalize the static electricity, rest the accessory bag on top of the
power supply while you are removing the accessory from the bag.
Handle the accessory as little as possible and with care.
To install a video memory module:
1Switch off the display and computer, and disconnect the power
supply cables and any telecommunications cables. Remove the
computer’s cover (refer to page 3) and carefully place the
PC Workstation on its side.
2Carefully remove the board from the accessory slot, holding the
board at each end by its top edge. Do not bend the board. With its
components facing up, place the board on a clean, flat, solid,
static-free surface. Handle the board by its edges.
3Attach the memory module to the connectors on the video adapter.
4Replace the video adapter in the computer. Carefully slide the board
back into its accessory slot. Firmly press the board into the socket.
Make sure that the board slides into the socket completely and does
not touch components on other boards. Secure the video adapter.
5Install any other accessories before replacing the cover (refer to
page 4). Reconnect all cables and power cords.
